13B-1
GROUP 13B
FUEL SUPPLY
CONTENTS
GENERAL INFORMATION . . . . . . . .13B-2FUEL TANK . . . . . . . . . . . . . . . . . . . .13B-3

GENERAL INFORMATION
FUEL SUPPLY13B-2
GENERAL INFORMATIONM2134000100833.The fuel system consists of the following compo-
nents:
•Fuel injector
•Fuel rail
•Fuel pipe
•Fuel tank
•Fuel pump module
•Evaporative emission canister
SPECIFICATIONS
CONSTRUCTION DIAGRAM
This fuel system is designed with consideration for
global environment protection to ensure safety at a
collision, reduce weight, and improve reliability and
quality. This system has the following features:
•A quick-joint connector of a plastic tube is used
for the fuel high-pressure hoses in the engine
compartment to reduce the permeation of fuel
evaporative emission.
•The surface of underfloor fuel pipes is coated
with 1-mm thickness of plastic to improve resis
-
tance to corrosion and chipping.
•A returnless fuel system eliminates returned fuel
from the engine. The heat that fuel receives from
the engine is reduced, minimizing fuel tempera
-
ture in the fuel tank and controlling the amount of
evaporated gas.
ItemSpecification
Fuel tank capacity dm3 (gal)59 (15.5)
Fuel pump typeElectric
Fuel filter typeCartridge (incorporates fuel pump module)
Fuel return systemReturnless
Fuel pump pressure regulator pressure kPa (psi)324 (46)
Fuel injectorTy p eElector-magnetic
Quantity4
Evaporative emission control systemCanister
AC610224
Fuel rail
Fuel injector
Fuel pipeFuel pump moduleEvaporative
emission
canister Fuel tank
AB

FUEL TANK
FUEL SUPPLY13B-3
FUEL TANKM2134001000817.The fuel tank assembly consists of the fuel pump
module, the fuel tank, and so on, and features the
following characteristics:
•The fuel tank is mounted underneath the second
seat to improve safety at a collision.
•The fuel tank itself is made of a pre-coat zinc
alloy galvanised steel sheet that contains no
lead.
•The capacity of the fuel tank is 59 dm3 (15.5 gal)
to meet long-distance drives.
•The fuel cut-off valve, fuel tank leveling valve and
fuel tube have been installed using in-tank con
-
struction to reduce the amount of evaporated fuel
from hoses.
The fuel pump module consists of the following com-
ponents:
•Fuel pump
•Fuel level sensor
•Fuel filter
•Fuel pump pressure regulator
•Fuel tank differential pressure sensor
•Fuel tank temperature sensor
CONSTRUCTION DIAGRAM
AC610225AB
Fuel pump module
Fuel tank
AC610226
Fuel cut-off valve
Fuel check valve
Leveling valve
AC

NOTES

13A-1
GROUP 13A
MULTIPORT FUEL
SYSTEM (MFI)
CONTENTS
GENERAL DESCRIPTION. . . . . . . . .13A-2
CONTROL UNIT. . . . . . . . . . . . . . . . .13A-6
SENSOR. . . . . . . . . . . . . . . . . . . . . . .13A-8
ACTUATOR . . . . . . . . . . . . . . . . . . . .13A-23
FUEL INJECTION CONTROL . . . . . .13A-29
IGNITION TIMING AND CONTROL FOR
CURRENT CARRYING TIME . . . . . .13A-35
THROTTLE VALVE OPENING ANGLE
CONTROL AND IDLE SPEED

CONTROL . . . . . . . . . . . . . . . . . . . . .13A-38
MIVEC (Mitsubishi Innovative Valve
Timing Electronic Control System) .13A-40
MULTIPORT FUEL INJECTION (MFI)
RELAY CONTROL . . . . . . . . . . . . . . .13A-45
FUEL PUMP RELAY CONTROL . . . .13A-46
STARTER RELAY CONTROL . . . . . .13A-47
HEATED OXYGEN SENSOR HEATER
CONTROL . . . . . . . . . . . . . . . . . . . . . .13A-49
A/C COMPRESSOR RELAY
CONTROL . . . . . . . . . . . . . . . . . . . . . .13A-50
GENERATOR CONTROL . . . . . . . . . .13A-51
EVAPORATIVE EMISSION CONTROL
SYSTEM INCORRECT PURGE FLOW
MONITOR . . . . . . . . . . . . . . . . . . . . . .13A-52
EXHAUST GAS RECIRCULATION
CONTROL . . . . . . . . . . . . . . . . . . . . . .13A-53
CONTROLLER AREA NETWORK
(CAN) . . . . . . . . . . . . . . . . . . . . . . . . .13A-53
EVAPORATIVE EMISSION PURGE
CONTROL . . . . . . . . . . . . . . . . . . . . . .13A-53
HC TRAP CATALYTIC CONVERTER
DETERIORATION MONITOR . . . . . . .13A-53
ON-BOARD DIAGNOSTICS . . . . . . . .13A-53

GENERAL DESCRIPTION
MULTIPORT FUEL SYSTEM (MFI)13A-2
GENERAL DESCRIPTIONM2132000101283
Although the control systems are basically the same as those of 2.4L engine used in the GALANT, the follow-
ing improvements have been added.
Improvement / AdditionsRemark
MIVEC, continuously and variably control the intake
valve timing and exhaust valve timing, is used.System optimally control the timing of the intake
valve and exhaust valve in accordance with the
engine speed and load.
Addition of heated oxygen sensor (3rd)
Detection of the HC trap catalyst malfunction.

GENERAL DESCRIPTION
MULTIPORT FUEL SYSTEM (MFI)13A-3
System Block Diagram
AK604116
Mass airflow sensor
Intake air temperature sensor
Intake camshaft position
sensor
Exhaust camshaft position
sensor
Crankshaft position sensor Throttle position sensor (main)
Throttle position sensor (sub)
Accelerator pedal position
sensor (sub) Accelerator pedal position
sensor (main) Engine coolant temperature
sensor Manifold absolute pressure
sensor
Heated oxygen sensor (front)
Heated oxygen sensor (rear)
Power steering pressure
switch Engine oil pressure switch Generator L terminal
Ignition switch-ST
Power supply Ignition switch-IG
CAN communication
(input signal)
· A/C switch
· Vehicle speed
· Fuel level sensor
· Transmission range switch
Fuel tank differential pressure
sensor Heated oxygen sensor
(3rd)*
Knock sensor
Generator FR terminal
Fuel tank temperature sensor
Vehicle speed sensor Engine control unit Barometric pressure sensor
[1] Fuel injection control
[2] Ignition timing control
[3] Throttle valve opening angle
control and idle speed control
[4]
MIVEC (Mitsubishi Innovative
Valve timing Electronic Control
system)
[5] Power supply control
(Power supply to sensor,
actuator)
[6] Fuel pump relay control
[7] Starter relay control
[8] Heated oxygen sensor heater
control
[9] A/C compressor relay control
[10] Generator control
[11] Evaporative emission purge
control
[12] EGR control
[13] Diagnosis output
[14] RAM data transmission
CAN communication
(output signal) Intake engine oil control
valve
A/C compressor relay No. 2 injector
No. 3 injector
No. 4 injector
Heated oxygen sensor (front)
heater
Heated oxygen sensor (rear)
heater Throttle actuator control
motor
Throttle actuator control
motor relay No. 1 injector
No. 1 ignition coil
No. 2 ignition coi
No. 3 ignition coi
No. 4 ignition coi
Fuel pump relay
Generator G terminal Heated oxygen sensor (3rd)
heater*
Multiport fuel injection (MFI)
relay Exhaust engine oil control
valve
Evaporative emission ventilation
solenoid Evaporative emission purge
solenoid
EGR valve (stepper motor)*
Starter relay
AB
Sensor, switch Engine control module (ECM) Actuator
NOTE
*1: California

GENERAL DESCRIPTION
MULTIPORT FUEL SYSTEM (MFI)13A-4
Control System Diagram

AK604117
Fuel level
sensorFuel tank Air
inlet
2 Exhaust engine
oil control valve
1 Intake engine
oil control valve4 Manifold absolute pressure sensor
2 Intake air
temperature sensor
1 Mass airflow sensor
6 Intake
camshaft
position
sensor
7 Exhaust
camshaft
position
sensor
3 Throttle position
sensor (main/sub)
5 Evaporative emission
purge solenoid
3 Throttle actuator
control motor
12 Fuel tank differential
pressure sensor
13 Fuel tank
temperature
sensor10 Heated oxygen sensor (front)
11 Heated oxygen
sensor (rear)
8 Crankshaft position sensor5 Engine coolant
temperature sensor
9 Knock sensor
4 Injector
Fuel pump Fuel pressure
regulator Evaporative
emission
canister
6 Evaporative
emission
ventilation
solenoid
1 Mass airflow sensor
2 Intake air temperature sensor
3 Throttle position sensor (main/sub)
4 Manifold absolute pressure sensor
5 Engine coolant temperature sensor
6 Intake camshaft position sensor
7 Exhaust camshaft position sensor
8 Crankshaft position sensor
9 Knock sensor
10 Heated oxygen sensor (front)
11 Heated oxygen sensor (rear)
12 Fuel tank differential pressure sensor
13 Fuel tank temperature sensor
Ignition switch-IG
Ignition switch-ST
Power supply
CAN communication (input signal)1 Intake engine oil control valve
2 Exhaust engine oil control valve
3 Throttle actuator control motor
4 Injector
5 Evaporative emission purge solenoid
6 Evaporative emission ventilation
solenoid
Ignition coil, ignition power transistor
Multiport fuel injection (MFI) relay
Fuel pump relay
Starter relay
Throttle actuator control motor relay
Generator G terminal
Heated oxygen sensor heater
A/C compressor relay
Diagnostic output
CAN communication (output signal) SenseAct
Engine oil pressure switch
Power steering pressure switch
Generator FR terminal
Generator L terminal
Vehicle speed sensor Accelerator pedal position sensor (main/sub)
Decide
ECM
(with barometric
pressure sensor)
AB

GENERAL DESCRIPTION
MULTIPORT FUEL SYSTEM (MFI)13A-5

AK604118
Fuel tank
Fuel level
sensor Air
inlet
2 Exhaust engine
oil control valve
1 Intake engine
oil control valve4 Manifold absolute pressure sensor
2 Intake air
temperature sensor
1 Mass airflow sensor
6 Intake
camshaft
position
sensor
7 Exhaust
camshaft
position
sensor
3 Throttle position
sensor (main/sub)
5 Evaporative emission
purge solenoid
3 Throttle actuator
control motor
12 Fuel tank differential
pressure sensor
13 Fuel tank
temperature
sensor11 Heated oxygen sensor (rear)
10 Heated
oxygen
sensor
(front)
12 Heated oxygen sensor (3rd)
8 Crankshaft position sensor5 Engine
coolant
temperature
sensor
9 Knock sensor
4 Injector
Fuel pump Fuel pressure
regulator Evaporative
emission
canister
6 Evaporative
emission
ventilation
solenoid
7 EGR valve
(stepper motor)
1 Mass airflow sensor
2 Intake air temperature sensor
3 Throttle position sensor (main/sub)
4 Manifold absolute pressure sensor
5 Engine coolant temperature sensor
6 Intake camshaft position sensor
7 Exhaust camshaft position sensor
8 Crankshaft position sensor
9 Knock sensor
10 Heated oxygen sensor (front)
11 Heated oxygen sensor (rear)
12 Heated oxygen sensor (3rd)
13 Fuel tank differential pressure sensor
14 Fuel tank temperature sensor
Ignition switch-IG
Ignition switch-ST
Power supply
CAN communication (input signal)1 Intake engine oil control valve
2 Exhaust engine oil control valve
3 Throttle actuator control motor
4 Injector
5 Evaporative emission purge solenoid
6 Evaporative emission ventilation
solenoid
7 EGR valve (stepper motor)
Ignition coil, ignition power transistor
Multiport fuel injection (MFI) relay
Fuel pump relay
Starter relay
Throttle actuator control motor relay
Generator G terminal
Heated oxygen sensor heater
A/C compressor relay
Diagnostic output
CAN communication (output signal) SenseAct
Engine oil pressure switch
Power steering pressure switch
Generator FR terminal
Generator L terminal
Vehicle speed sensor Accelerator pedal position sensor (main/sub)
Decide
ECM
(with barometric
pressure sensor)
AB

CONTROL UNIT
MULTIPORT FUEL SYSTEM (MFI)13A-6
CONTROL UNITM2132021500153
ENGINE CONTROL MODULE (ECM)
ECM is installed in the engine room. ECM judges
(calculates) the optimum control to deal with the con
-
stant minute changes in driving conditions based on
information input from the sensors and drives the
actuator. ECM is composed of 32-bit microprocessor
and Random Access Memory (RAM), Read Only
Memory (ROM) and Input /Output interface. ECM uses flash-memory ROM that allows re-writing of
data so that change and correction of control data is
possible using special tools. It also uses Electrically
Erasable Programmable Read Only Memory
(EEPROM) so that studied compensation data is not
deleted even if battery terminals are disconnected.
ECM CONNECTOR INPUT/OUTPUT PIN ARRANGEMENT
NOTE: *: California
AK604119
ECM
Microprocessor
RAM Input
interfaceOutput
interface Input
sensorOutput
actuator
AB
ROM
AK602565AC
1 2 3 4 5 6 7 8 9 10 11 1213 14 15 16
17 18 19 20 21 91
90
89
87
86
84 85
83 82
88 92 93 94
95 96 97 98 99
109
108
107 106
105
104
103
102
112 113 114 115 116 117 118
100 101
111
110
41
40
39
38
37
36
35
34
33 32
31
30
29
28
27
26
25
24
23
2260
59
58
57
56
55
54
53
52
51
50
49 48
47
46
45
44
43
4263
61 62 6471 72 73 74 75 76 77 78 79 80 81
1Intake engine oil control valve2No.1 injector
3No.2 injector4Ignition coil No.1 (ignition power transistor)
5Ignition coil No.2 (ignition power transistor)6Starter active signal
7Exhaust camshaft position sensor8Crankshaft position sensor
9Sensor supplied voltage10Throttle position sensor (main)
11Throttle position sensor (sub)12Power supply voltage applied to throttle
position sensor
13Throttle position sensor ground14Intake camshaft position sensor
