Page 361 of 1839

MITSUBISHI MONTERO 2000 Service Repair Manual GDI -Troubleshooting <A/T>13A-147 Code No.41 Injector systemProbable cause Range of Check DThe enginespeed is 4,000 r/min or less. DThe battery voltage is 10 V or more. DThe fuel cut operation or the

Page 362 of 1839

MITSUBISHI MONTERO 2000 Service Repair Manual GDI -Troubleshooting <A/T>13A-148 OK Use an analyzer to measure the signal waveform at engine-A/T-ECU connectors D-119 and D-120. DEngine: Idling DSelector lever position: P DVoltage between terminal

Page 363 of 1839

MITSUBISHI MONTERO 2000 Service Repair Manual GDI -Troubleshooting <A/T>13A-149 OK Check trouble symptom. OK Check trouble symptom. OK Check the following connectors: B-101, B-108, B-112, B-113, B-116, B-119 NG Repair OK Replace the engine-A/T-EC

Page 364 of 1839

MITSUBISHI MONTERO 2000 Service Repair Manual GDI -Troubleshooting <A/T>13A-150 Code No.54 Immobilizer systemProbable cause Range of Check DIgnition switch: ON Set Conditions DImproper communication between the engine-A/T-ECU and the immobilizer-

Page 365 of 1839

MITSUBISHI MONTERO 2000 Service Repair Manual GDI -Troubleshooting <A/T>13A-151 Code No.56 Abnormal fuel pressureProbable cause Range of Check DIgnition switch: ON Set Conditions DThe sensor output voltage is 4.8V or more, or 0.2 V or less for fo

Page 366 of 1839

MITSUBISHI MONTERO 2000 Service Repair Manual GDI -Troubleshooting <A/T>13A-152 NG (2) NGCheck the following connector: B - 111NG Repair OK Measure at intermediate connector B-110. DUse test harness (MB991658) to connect the connector, and measur

Page 367 of 1839

MITSUBISHI MONTERO 2000 Service Repair Manual GDI -Troubleshooting <A/T>13A-153 Code No.64 Alternator FR terminal systemProbable cause Range of Check DEngine speed: 50 r/min or more Set Conditions DInput voltage from the alternator FR terminal is

Page 368 of 1839

MITSUBISHI MONTERO 2000 Service Repair Manual GDI -Troubleshooting <A/T>13A-154 Code No.77 Accelerator pedal position sensor (2nd channel) systemProbable cause Range of Check DAcceleratorpedal positionsensor (1st channel) is normal. DCommunicatio

Page 369 of 1839

MITSUBISHI MONTERO 2000 Service Repair Manual GDI -Troubleshooting <A/T>13A-155 OK Measure at throttle valve controller connector D-11. DMeasure voltage at the throttle valve controller connector terminals. DIgnition switch: ON DThe resistance be

Page 370 of 1839

MITSUBISHI MONTERO 2000 Service Repair Manual GDI -Troubleshooting <A/T>13A-156 Code No.78 Accelerator pedal position sensor (1st channel) systemProbable cause Range of Check DAcceleratorpedal positionsensor (2nd channel) is normal. DCommunicatio
