NISSAN ALMERA TINO 2001 Service Repair Manual
Manufacturer: NISSAN, Model Year: 2001, Model line: ALMERA TINO, Model: NISSAN ALMERA TINO 2001Pages: 3051, PDF Size: 46.38 MB
Page 2771 of 3051

NLMA0046
MAINTENANCEOPER ATION MAINTENANCEINTE RVAL
Engin ean dEmissio nContro lMaintenanc e(QG18DE/SR20D Eengine)
Page 2772 of 3051

*1: Models without three way catalyst
*2: For models with three way catalyst, periodic maintenance is not required. However, if valve noise increases, check valve clearance.
*3: Models with three way catalyst
PERIODIC MAINTENANCE (EXCEPT FOR EUROPE)
Engine and Emission Control Maintenance (QG18DE/SR20DE engine) (Cont’d)
MA-5
Page 2773 of 3051

Engine Maintenance (YD22DDTi engine)=NLMA0046S02Abbreviations: I = Inspect and correct or replace as necessary, R = Replace, A = Adjust, D = Check filter and drain water.
MAINTENANCE OPERATIONMAINTENANCE INTERVAL
Perform either at number of kilome-
ters (miles) or months, whichever
comes first.km×1,000 1 10 20 30 40 50 60 70 80
Reference
page (mile×1,000) (0.6) (6) (12) (18) (24) (30) (36) (42) (48)
Months—6 12182430364248
Underhood and under vehicle
Torque of manifolds & exhaust tube
nutsI—
Intake & exhaust valve clearance See NOTE (1) EM-214
Drive beltsIIIIIEM-166
Engine oil (Use API CD, CE, CF,
CF-4 oil.)See NOTE (5) Replace every 15,000 km (9,000 miles) or 12 months LC-47
Engine oil filter (Use Eco filter or
equivalent)See NOTE (2) Replace every 15,000 km (9,000 miles) or 12 months LC-48
Engine coolant (Use Nissan genuine
engine coolant or equivalent in its
quality.)See NOTE (3) E R LC-59
Cooling systemIIIILC-53
Fuel linesI I FE-15
Air cleaner filter (Viscous paper
type)R R EM-169
Fuel filterDDDRDDDRFE-15
Injection nozzles See NOTE (4) EC-1085
NOTE:
Maintenance item with“”should be performed more frequently according to“Maintenance Under Severe Driving Condi-
tions”.
(1) If valve noise increases, check valve clearance.
(2) Oil filter element assembly (part No. 15208 AD200) and O-ring seal (part No. 15226 AD200) are replacement parts.
(3) Use Nissan genuine engine coolant or equivalent in its quality, in order to avoid possible aluminium corrosion within the
engine cooling system caused by the use of non-genuine engine coolant. After first replacement, replace every 40,000 km (24,
000 miles) or 24 months.
(4) If engine power decreases, black exhaust smoke is emitted or engine noise increases, check injection nozzles and, if
necessary, replace injection nozzle assembly.
(5) Never use CG-4 oil.
PERIODIC MAINTENANCE (EXCEPT FOR EUROPE)
Engine Maintenance (YD22DDTi engine)
MA-6
Page 2774 of 3051

Chassis and Body Maintenance=NLMA0046S03Abbreviations: I = Inspect and correct or replace as necessary, R = Replace, A = Adjust, L = Lubricate
MAINTENANCE OPERATIONMAINTENANCE INTERVAL
Reference
page Perform either at number of kilometers
(miles) or months, whichever comes
first.km×1,000 1 10 20 30 40 50 60 70 80
(mile×1,000) (0.6) (6) (12) (18) (24) (30) (36) (42) (48)
Months—6 12182430364248
Underhood and under vehicle
Brake & clutch fluid (For level &
leaks)IIIIIIIIBR-7
Brake fluidR R BR-7
Brake booster vacuum hoses, connec-
tions & check valveI I BR-16
Power steering fluid & lines (For level
& leaks)I*1 I I*1 I I*1 I I*1 I ST-7
Brake, clutch & exhaust systemsIIIIIIIIBR-7,
CL-5,
FE-13,
FE-15,
FE-23
H·CVT fluid (For level and leaks)IIIIIIII AT-10
H·CVT fluidR R AT-11
Manual transaxle gear oil (For level &
leaks)I*1 I I*1 I I*1 I I*1 IMT-10,
MT-11
Steering gear & linkage, axle & sus-
pension parts & drive shaftsI*2IIIIST-7,
SU-5,
SU-18
Outside and inside
Wheel alignment (if necessary, rotate
& balance wheels)IIIISU-15,
SU-27
Brake pads, rotors & other brake com-
ponentsIIIIIIIIBR-24,
BR-28
Lock, hinges & hoods latchL*1 L L*1 L L*1 L L*1 LBT-7,
BT-13
Seat belts, buckles, retractors,
anchors & adjusterIIIIRS-3
Foot brake, parking brake & clutch
(For free play, stroke & operation)I*1 I I*1 I I*1 I I*1 IBR-11,
BR-40,
CL-5
Ventilation air filterReplace every 12,000 km (7,500 miles) or 12 months HA-103
Supplemental air bag systems See NOTE (1) RS-16
NISSAN Mobility System See NOTE (2)IIIII—
NOTE:
(1) Inspect at the first 10 years, and then every 2 years.
Maintenance item with“”should be performed more frequently according to“Maintenance Under Severe Driving Condi-
tions”.
(2) Check expiration date of the tyre sealant bottle. Replace if necessary.
*1: Models except for Australia
*2: Models without three way catalyst
PERIODIC MAINTENANCE (EXCEPT FOR EUROPE)
Chassis and Body Maintenance
MA-7
Page 2775 of 3051

Maintenance Under Severe Driving Conditions=NLMA0046S04The maintenance intervals shown on the preceding pages are for normal operating conditions. If the vehicle
is mainly operated under severe driving conditions as shown below, more frequent maintenance must be per-
formed on the following items as shown in the table.
SEVERE DRIVING CONDITIONSNLMA0046S0401A—Driving under dusty conditions
B—Driving repeatedly short distances
C—Towing a trailer or caravan
D—Extensive idling
E—Driving in extremely adverse weather conditions or in areas where ambient temperatures are either
extremely low or extremely high
F—Driving in high humidity areas or in mountainous areas
G—Driving in areas using salt or other corrosive materials
H—Driving on rough and/or muddy roads or in the desert
I—Driving with frequent use of braking or in mountainous areas
Driving condition Maintenance itemMaintenance
operationMaintenance
intervalRefer-
ence
page
A........Aircleaner filter Viscous paper type Replace More frequentlyEM-18,
EM-88,
EM-169
ABCD.....Engine oil & oil filter (QG18DE/SR20DE
engine)ReplaceEvery 5,000 km
(3,000 miles) or 3
monthsLC-8,
LC-28,
LC-9,
LC-28
ABCD.....Engine oil (YD22DDTi engine)
ReplaceMore frequently LC-47
Engine oil filter (YD22DDTi engine)Every 7,500 km
(4,500 miles) or 6
monthsLC-48
A...E....Fuel filter (YD22DDTi engine) ReplaceEvery 20,000 km
(12,000 miles) or
12 monthsFE-15
.....F...Brake fluid ReplaceEvery 20,000 km
(12,000 miles) or
12 monthsBR-7
..C....H.H·CVT fluid ReplaceEvery 20,000 km
(12,000 miles) or
12 monthsAT-11
......GH.Steering gear & linkage, axle & suspen-
sion parts & drive shaftsCheckEvery 10,000 km
(6,000 miles) or 6
monthsST-7,
SU-5,
SU-18
A.C...GHIBrake pads, rotors & other brake com-
ponentsCheckEvery 5,000 km
(3,000 miles) or 3
monthsBR-24,
BR-28
......G..Lock, hinges & hood latch LubricateEvery 5,000 km
(3,000 miles) or 3
monthsBT-7,
BT-13
A........Ventilation air filter Replace More frequently HA-103
PERIODIC MAINTENANCE (EXCEPT FOR EUROPE)
Maintenance Under Severe Driving Conditions
MA-8
Page 2776 of 3051

NLMA0043
MAINTENANCEOPER ATION MAINTENANCEINTE RVAL Referencepages
Maintenanc eSchedul eforPetro lEngine s(Annua lMileag e< 30,00 0km/year)
Page 2777 of 3051
![NISSAN ALMERA TINO 2001 Service Repair Manual CHASSIS AND BODY MAINTENANCE=NLMA0043S0102Abbreviations: R = Replace I = Inspect: Correct or replace if necessary [ ] = At the specified mileage only
MAINTENANCE OPERATIONMAINTENANCE INTERVAL
Refer-
e NISSAN ALMERA TINO 2001 Service Repair Manual CHASSIS AND BODY MAINTENANCE=NLMA0043S0102Abbreviations: R = Replace I = Inspect: Correct or replace if necessary [ ] = At the specified mileage only
MAINTENANCE OPERATIONMAINTENANCE INTERVAL
Refer-
e](/img/5/57352/w960_57352-2776.png)
CHASSIS AND BODY MAINTENANCE=NLMA0043S0102Abbreviations: R = Replace I = Inspect: Correct or replace if necessary [ ] = At the specified mileage only
MAINTENANCE OPERATIONMAINTENANCE INTERVAL
Refer-
ence
pages Perform on a kilometer basis, but on
an annual basis when driving less
than 15,000 km (9,000 miles) in a
year.km x 1,000
(miles x 1,000)
Months15
(9)
1230
(18)
2445
(27)
3660
(36)
4875
(45)
6090
(54)
72105
(63)
84120
(72)
96
Underhood and under vehicle
Headlamp aimingIIIIIIIIEL-72
Wheel alignment (if necessary, bal-
ance & rotate wheels)IIIIIIIISU-15/
SU-27
Brake pads, rotors & other brake
componentsIIIIIIIIBR-24/
BR-28
Foot brake, parking brake & clutch
(for free play, stroke & operation)IIIIIIIIBR-11/
BR-40/
CL-5
Brake booster vacuum hoses,
connections, check valveIIIIBR-16
Brake & clutch, systems and fluid (for
level and leaks)IIIIIIIIBR-7
Brake fluidRRRRBR-7
Power steering fluid and lines (for
level and leaks)IIIIIIIIST-7
Supplemental air bag systems See NOTE (1) RS-16
Ventilation air filterRRRRHA-103
Manual transaxle gear oil (check for
leakage. Use genuine NISSAN XZ
gear oil or exact equivalent)IIIIIIIIMT-10
MT-11
CVT fluid [for level and leaks or
replace. Use genuine NISSAN CVT
fluid (NS-1) or exact equivalent]I I I [R] I I I [R] AT-10
Steering gear & linkage, axle & sus-
pension parts, drive shafts, exhaust
systemIIIIST-7/
SU-5/
SU-18/
FE-13/
FE-15/
FE-23
NISSAN Mobility System See NOTE (2)IIIIIII—
Body corrosion See NOTE (3) BT-6
NOTE:
(1) Inspect after 10 years, then every 2 years.
(2) Check expiration date of the tyre sealant bottle. Replace if necessary.
(3) Inspect once per year.
Maintenance items with“”should be performed more frequently according to“Maintenance Under Severe Driving Con-
ditions”.
PERIODIC MAINTENANCE
Maintenance Schedule for Petrol Engines (Annual Mileage < 30,000 km/year) (Cont’d)
MA-10
Page 2778 of 3051

Maintenance Schedule for Diesel Engines
(Annual Mileage < 30,000 km/year)
=NLMA0043S02YD22DDTI ENGINENLMA0043S0201Abbreviations: R = Replace I = Inspect: Correct or replace if necessary
MAINTENANCE OPERATIONMAINTENANCE INTERVAL
Reference
pages Perform on a kilometer basis, but
on an annual basis when driving
less than 20,000 km
(12,000 miles) per year.km x 1,000
(miles x 1,000)
Months20
(12)
1240
(24)
2460
(36)
3680
(48)
48100
(60)
60120
(72)
72
Engine compartment and under vehicle
Engine oil (Use recommended
oil)RRRRRRLC-47
Engine oil filter (Use Eco filter or
equivalent)See NOTE (1)RRRRRRLC-48
Drive beltsIIIIIIEM-166
Cooling systemIIIIIILC-53
Engine anti-freeze coolant (Use
genuine NISSAN Anti-freeze
Coolant (L2N) or equivalent)See NOTE (2) I I LC-59
Air cleaner filterR R EM-169
Intake & exhaust valve clearance See NOTE (3) EM-214
Fuel lines I I I FE-15
Injection nozzles See NOTE (4) EC-1085
Fuel filterR R R FE-15
NOTE:
(1) Oil filter element assembly and O-ring seal are replacement parts.
(2) First replace at 100,000 km (60,000 miles)/60 months, then every 60,000 km (36,000 miles)/36 months. After first replacement,
perform“I”(checking the mixture ratio and correcting the mixture ratio if necessary) at the middle of replacement interval.
(3) If valve noise increases, check valve clearance.
(4) If engine power decreases, black exhaust smoke is emitted or engine noise increases, check injection nozzles and if
necessary, replace injection nozzle assembly.
Maintenance items with“”should be performed more frequently according to“Maintenance Under Severe Driving Con-
ditions”.
PERIODIC MAINTENANCE
Maintenance Schedule for Diesel Engines (Annual Mileage < 30,000 km/year)
MA-11
Page 2779 of 3051

CHASSIS AND BODY MAINTENANCE=NLMA0043S0202Abbreviations: R = Replace I = Inspect: Correct or replace if necessary
MAINTENANCE OPERATIONMAINTENANCE INTERVAL
Reference pages Perform on a kilometer basis, but
on an annual basis when driving
less than 20,000 km (12,000 miles)
per year.km x 1,000
(miles x 1,000)
Months20
(12)
1240
(24)
2460
(36)
3680
(48)
48100
(60)
60120
(72)
72
Underhood and under vehicle
Headlamp aimingIIIIIIEL-72
Wheel alignment (if necessary, bal-
ance & rotate wheels)IIIIIISU-15
SU-27
Brake pads, rotors & other brake
componentsIIIIIIBR-24
BR-28
Foot brake, parking brake & clutch
(for free play, stroke & operation)IIIIIIBR-11
BR-40
CL-5
Brake booster vacuum hoses,
connections, check valveI I I BR-16
Brake & clutch, systems and fluid
(for level and leaks)IIIIIIBR-7
CL-5
Brake fluidR R R BR-7
Power steering fluid and lines (for
level and leaks)IIIIII ST-7
Supplemental air bag systems See NOTE (1) RS-16
Ventilation air filterRRRRRRHA-103
Manual transaxle gear oil (check for
leakage. Use genuine NISSAN XZ
gear oil or exact equivalent)IIIIIIMT-10
MT-11
Steering gear & linkage, axle &
suspension parts, drive shafts,
exhaust systemIIIST-7
SU-5
SU-18
FE-13
FE-15
FE-23
NISSAN Mobility System See NOTE (2)IIIII—
Body corrosion See NOTE (3) BT-6
NOTE:
(1) Inspect after 10 years, then every 2 years.
(2) Check expiration date of the tyre sealant bottle. Replace if necessary.
(3) Inspect once per year.
Maintenance items with“”should be performed more frequently according to“Maintenance Under Severe Driving Con-
ditions”.
PERIODIC MAINTENANCE
Maintenance Schedule for Diesel Engines (Annual Mileage < 30,000 km/year) (Cont’d)
MA-12
Page 2780 of 3051

Maintenance Under Severe Driving Conditions
(Annual Driving Distance < 30,000 km/year)
=NLMA0043S03The maintenance intervals shown on the preceding pages are for normal operating conditions. If the vehicle
is mainly operated under severe driving conditions as shown below, more frequent maintenance must be per-
formed on the following items as shown in the table.
A—Driving under dusty conditions
B—Driving repeatedly short distances
C—Towing a trailer or caravan
D—Extensive idling
E—Driving in extremely adverse weather conditions or in areas where ambient temperatures are either
extremely low or extremely high
F—Driving in high humidity areas or in mountainous areas
G—Driving in areas using salt or other corrosive materials
H—Driving on rough and/or muddy roads or in the desert
I—Driving with frequent use of braking or in mountainous areas
J—Frequent off road use or driving in water
K—Sustained high speed driving
L—For models without Euro-OBD system
Driving conditionMaintenance
itemMaintenance
operationMaintenance interval
ABCD........Engine oil & engine oil filter
Petrol models ReplaceEvery 7,500 km (4,500 miles) or 6
months
Diesel models ReplaceEvery 10,000 km (6,000 miles) or
6 months
A...........Air cleaner filter
Petrol models ReplaceEvery 30,000 km (18,000 miles) or
24 months
Diesel models ReplaceEvery 30,000 km (18,000 miles) or
18 months
A...E.......Fuel filter
Diesel models ReplaceEvery 20,000 km (12,000 miles) or
12 months
A...........Ventilation air filter
Petrol models ReplaceEvery 15,000 km (9,000 miles) or
12 months
Diesel models ReplaceEvery 10,000 km (6,000 miles) or
6 months
.....F......Brake fluid
Petrol models ReplaceEvery 15,000 km (9,000 miles) or
12 months
Diesel models ReplaceEvery 20,000 km (12,000 miles) or
12 months
A.C...GHI...Brake pads, rotors & other brake system components
Petrol models InspectEvery 7,500 km (4,500 miles) or 6
months
Diesel models InspectEvery 10,000 km (6,000 miles) or
6 months
PERIODIC MAINTENANCE
Maintenance Under Severe Driving Conditions (Annual Driving Distance < 30,000 km/year)
MA-13
