Page 2811 of 3051

NISSAN ALMERA TINO 2001  Service Repair Manual SMT941D
InstallationNLMT0090S021. Put transaxle under the engine compartment.
2. Set chain block on transaxle and hang.
3. Lift up transaxle case so as not to hit against the side frame
and suspension

Page 2812 of 3051

NISSAN ALMERA TINO 2001  Service Repair Manual NLMT0038
ComponentsNLMT0038S01
NMT133
1. Control lever knob
2. Boot
3. Control lever socket
4. Control lever
5. Bearing seat spring
6. Seat
7. Bush
8. O-ring9. Hand lever socket
10. Plate bolt
11. Tra

Page 2813 of 3051

NISSAN ALMERA TINO 2001  Service Repair Manual NLMT0054
Case ComponentsNLMT0054S02
SMT942D
1. Clutch housing
2. Dust seal
3. Oil pocket
4. Check plug
5. Input shaft oil seal
6. Oil channel
7. Mainshaft front bearing
8. Bearing retainer
9. Bush
10.

Page 2814 of 3051

NISSAN ALMERA TINO 2001  Service Repair Manual Gear Components=NLMT0054S03
SMT641DA
1. Reverse idler gear front thrust
washer
2. Reverse idler gear
3. Reverse idler gear bearing
4. Reverse idle gear rear thrust
washer
5. O-ring
6. Reverse idler ge

Page 2815 of 3051

NISSAN ALMERA TINO 2001  Service Repair Manual Shift Control Components=NLMT0054S04
SMT642DB
1. Clutch housing
2. 3rd & 4th bracket
3. 3rd & 4th shift fork
4. Retaining pin
5. Check ball
6. Check pin
7. Check spring
8. Check plug
9. Stopper ring
1

Page 2816 of 3051

NISSAN ALMERA TINO 2001  Service Repair Manual Final Drive Components=NLMT0054S05
YMT001
1. Differential side bearing adjusting
shim
2. Differential side bearing outer race
3. Differential side bearing
4. Final gear
5. Differential case6. Speedome

Page 2817 of 3051

NISSAN ALMERA TINO 2001  Service Repair Manual NLMT0055
SMT648D
Transaxle CaseNLMT0055S011. Remove reverse switch, PNP switch, drain plug, and filler plug
from transaxle case.
SMT644D
2. Remove snap rings from reverse idler shaft.
3. Remove side c

Page 2818 of 3051

NISSAN ALMERA TINO 2001  Service Repair Manual SMT649D
9. Remove mounting bolts.
10. Remove input shaft rear bearing adjusting shim from transaxle
case.
SMT650D
11. Remove oil gutter from case.
SMT651DB
12. Remove differential side bearing outer r

Page 2819 of 3051

NISSAN ALMERA TINO 2001  Service Repair Manual SMT654D
Clutch HousingNLMT0055S021. Remove transaxle case from clutch housing.
2. Remove magnet from housing.
3. Remove check plugs, check springs, check pins, and check
balls from housing.
SMT656DC
4

Page 2820 of 3051

NISSAN ALMERA TINO 2001  Service Repair Manual SMT659DC
14. Remove check ball from housing.
15. Remove retaining pin for 1st & 2nd shift fork and bracket.
16. Remove 1st & 2nd fork rod.
17. Remove 5th & reverse and 1st & 2nd shift forks, and 1st &
