Page 91 of 321
Be sure not to put anything on top of the
photo sensor
A
located on the top left-
hand side of the instrument panel. The
photo sensor controls the autolamp; if it is
covered, the photo sensor reacts as if it is
dark and the headlights will illuminate.
Headlight beam select
1To select the low beam, put the lever in the
neutral position as shown.
2To select the high beam, push the lever
forward while the switch is in the
po-
sition. Pull it back to select the low beam.
3Pulling the lever toward you will flash the
headlight high beam.
Battery saver systemWhen the headlight switch is in the
or
position while the ignition switch is in
the ON position, the lights will automatically
turn off 5 minutes after the ignition switch has
been turned to the OFF position.
When the headlight switch remains in theor
position after the lights auto-
matically turn off, the lights will turn on for 5
minutes when the headlight switch is turned
to the OFF position and then turn to the
or
position.CAUTION
Even though the battery saver feature
automatically turns off the headlights
after a period of time, you should turn
the headlight switch to the OFF position
when the engine is not running to avoid
discharging the vehicle battery.
SIC2052
SIC2048
2-24
Instruments and controls
04.8.3/Z50-D/V5.0
Page 92 of 321
Headlight aiming control (if so
equipped)Depending on the number of occupants in the
vehicle and the load it is carrying, the headlight
axis may be higher than desired. If the vehicle is
traveling on a hilly road, the headlights may
directly hit the rearview mirror of the vehicle
ahead or the windshield of the oncoming vehicle.
The light axis can be lowered with the operation
of the switch.
The larger the number designated on the switch,
the lower the axis.When traveling with no heavy load or on a flat
road, select position 0.
WARNING
Xenon headlights are extremely bright
compared to conventional headlights. If
the xenon headlights hit the rearview
mirror of the vehicle ahead or the wind-
shield of oncoming vehicle, the driver of
these vehicles may have difficulty driv-
ing because of the brightness. Use the
headlight aiming control switch to lower
the light axis. See “Xenon headlights”
earlier in this section for additional in-
formation.DAYTIME RUNNING LIGHT SYSTEM
(CANADA ONLY)The daytime running lights automatically illumi-
nate when the engine is started with parking
brake released. The daytime running lights op-
erate with the headlight switch in the OFF
position or in the
position.
The daytime running lights may come on after
turning the switch to the OFF position andimmediately turning it to the ON position. This is
not a malfunction.
The daytime running lights will be turned off
when the headlight switch is turned to the AUTO
(only when the headlights are lit) or
posi-
tion or when the fog light is turned on.
The daytime running lights will remain on until
the ignition switch is turned to the ACC or OFF
position.
WARNING
When the daytime running light system
is active, tail lights on your vehicle are
not on. It is necessary at dusk to turn on
your headlights. Failure to do so could
cause an accident injuring yourself and
others.
SIC1911
Instruments and controls
2-25
04.8.3/Z50-D/V5.0
Page 93 of 321
INSTRUMENT BRIGHTNESS
CONTROLThe instrument brightness control operates
when the light switch is in the
or
position and the ignition switch is in the
ON position.
To adjust the brightness of instrument panel
lights, push the control switches located on the
left side of the meter panel. Pushing the upper
switchA
will brighten the lights. The lower
switch
B
dims the lights. Repeatedly pushing
the lower switch will turn the lights off.
TURN SIGNAL SWITCH1
Turn signal
Move the lever up or down to signal the turning
direction. When the turn is completed, the turn
signals cancel automatically.2
Lane change signal
To indicate a lane change, move the lever up or
down to the point where lights begin flashing.
FOG LIGHT SWITCH (if so
equipped)To turn the fog lights on, turn the headlight
switch to the
position, then turn the switch
to the
position. To turn them off, turn the
switch to the OFF position.
The headlights must be on for the fog lights to
operate (except for the daytime running light).
SIC2053
SIC2049
SIC2054
2-26
Instruments and controls
04.8.3/Z50-D/V5.0
Page 94 of 321
Push the switch (located on the right side of the
meter panel) on to warn other drivers when you
must stop or park under emergency conditions.
All turn signal lights will flash.
Some state laws may prohibit the use of
the hazard warning flasher switch while
driving.
WARNING
If stopping for an emergency, be sure
to move the vehicle well off the road.Do not use the hazard warning flash-
ers while moving on the highway un-
less unusual circumstances force you
to drive so slowly that your vehicle
might become a hazard to other traf-
fic.
Turn signals do not work when the
hazard warning flasher lights are on.
The flasher will operate with the ignition switch in
any position.
To sound the horn, push the center pad upper
area of the steering wheel.
WARNING
Do not disassemble the horn. Doing so
could affect proper operation of the
supplemental front air bag system. Tam-
pering with the supplemental front air
bag system may result in serious per-
sonal injury.
SIC2475
SIC2627
HAZARD WARNING FLASHER
SWITCHHORN
Instruments and controls
2-27
04.8.3/Z50-D/V5.0
Page 95 of 321
The front seats are warmed by built-in heaters.
The switches located on the center console can
be operated independently (driver side seat
A
and front passenger side seat
B) of each other.
1. Start the engine.
2. Select heat range.
1For high heat, push the
(High) side
of the switch.
2For low heat, push the
(Low) side of
the switch.
3For no heat, the switch has a center OFF
position between low and high.The indicator light in the switch
C
will
illuminate when low or high is selected.
The heater is controlled by a thermostat,
automatically turning the heater on and off.
The indicator light will remain on as long as
the switch is on.
3. When the vehicle’s interior is warmed, or
before you leave the vehicle, be sure to turn
the switch to the off position (center)
3.
CAUTION
The battery could run down if the
seat heater is operated while the en-
gine is not running.
Do not use the seat heater for ex-
tended periods or when no one is
using the seat.
Do not put anything on the seat
which insulates heat, such as a blan-
ket, cushion, seat cover, etc. Other-
wise, the seat may become over-
heated.
Do not place anything hard or heavy
on the seat or pierce it with a pin orsimilar object. This may result in
damage to the heater.
Any liquid spilled on the heated seat
should be removed immediately with
a dry cloth.
When cleaning the seat, never use
gasoline, benzine, thinner, or any
similar materials.
If any abnormalities are found or the
heated seat does not operate, turn
the switch off and have the system
checked by a NISSAN dealer.
SIC2056
HEATED SEATS (if so equipped)2-28
Instruments and controls
04.8.3/Z50-D/V5.0
Page 96 of 321
The vehicle should be driven with the Vehicle
Dynamic Control (VDC) system ON for most
driving conditions.
If the vehicle is stuck in mud or snow, the VDC
system reduces the engine output to reduce
wheel spin. The engine speed will be reduced
even if the accelerator is depressed to the floor.
If maximum engine power is needed to free a
stuck vehicle, turn the VDC system off.
To turn off the Vehicle Dynamic Control (VDC)
system, push the VDC OFF switch. The
in-
dicator light will come on.
Push the VDC OFF switch again or restart the
engine to turn ON the system. See “Vehicledynamic control (VDC) system” in the “5. Start-
ing and driving” section.
SIC1881
SIC2066
VEHICLE DYNAMIC CONTROL
(VDC) OFF SWITCH (if so
equipped)POWER OUTLET
Instruments and controls
2-29
04.8.3/Z50-D/V5.0
Page 97 of 321
The power outlet is for powering electrical ac-
cessories such as cellular telephones.1Located beside the glove box (if so
equipped):
Pull down the cover to open.
2Located inside the console box:
Pull to remove the cover to open.
3Located the side of the luggage room (if so
equipped):
Pull up the cover to open.
CAUTION
The outlet and plug may be hot dur-
ing or immediately after use.
This power outlet is not designed for
use with a cigarette lighter unit.
Do not use with accessories that ex-
ceed a 12 volt, 120W (10A) power
draw. Do not use double adapters or
more than one electrical accessory.
Use only one power outlet at a time.
Use power outlet with the engine
running to avoid discharging the ve-hicle battery.
Avoid using power outlets when the
air conditioner, headlights or rear
window defroster is on.
Before inserting or disconnecting a
plug, be sure to turn off the power
switch of electrical accessory being
used or the ACC power of the vehicle.
Push the plug in as far as it will go. If
good contact is not made, the plug
may overheat or the internal tem-
perature fuse may open.
When not in use, be sure to close the
cap/cover. Do not allow water to con-
tact the outlet.
COIN BOX
WARNING
The coin box should not be used while
driving so full attention may be given to
vehicle operation.
To open, push the coin box lid
1
as illustrated.
The inner tray can be removed
2
as illustrated.
Do not place valuable items in the box.
Do not use the coin box as an ashtray.
SIC2057
STORAGE
2-30
Instruments and controls
04.8.3/Z50-D/V5.0
Page 98 of 321
CELLULAR PHONE HOLDER
WARNING
The cellular phone holder should not
be used while driving so full attention
may be given to vehicle operation.
A cellular telephone should not be
used while driving so full attention
may be given to vehicle operation.
Some jurisdictions prohibit the use
of cellular telephones while driving.If a conversation in a moving vehicle
requires you to take notes, pull off
the road to a safe location and stop
your vehicle before doing so.
To open, push the cellular phone holder lid
1
as illustrated.
The inner tray can be removed
2
as illustrated.
Do not place valuable items in the holder.
Do not use the cellular phone holder as an
ashtray.
CUP HOLDERS
WARNING
The cup holder should not be used while
driving so full attention may be given to
vehicle operation.
CAUTION
Avoid abrupt starting and braking
SIC2058
SIC2628
Instruments and controls
2-31
04.8.3/Z50-D/V5.0
Page 99 of 321
when the cup holder is being used to
prevent spilling the drink. If the liquid
is hot, it can scald you or your pas-
senger.
Use only soft cups in the cup holder.
Hard objects can injure you in an
accident.
Front:
Push the cup holder lid
A
to open.
The flap
Bwill be folded down when inserting a
bigger container.
Pull up the inner tray as illustrated
Cto remove
for cleaning.Rear:
Push
A
to open the cup holder.
GLOVE BOXTo open the glove box, pull the handle
A.
To close, push the lid in until the lock latches.
To lock
2
or unlock
1
the glove box, use the
master key, mechanical key (Intelligent Key sys-
tem) or wallet key.
WARNING
Keep glove box lid closed while driving
to help prevent injury in an accident or a
sudden stop.
SIC2315A
SIC2669
2-32
Instruments and controls
04.8.3/Z50-D/V5.0
Page 100 of 321
CONSOLE BOX
WARNING
The center console box should not beused while driving so full attention may
be given to vehicle operation.
Push the button
A
to open the console box lid.The inside of the console box lid is designed to
be used as a holder
B
such as pen, etc. There
is a power outlet
C
inside the console box.
Remove the inside tray
D
to store a large
object.
To lock the console box, turn the key to the
1
position.
To unlock the console box, turn the key to the
2
position.
Push the button
3and adjust the armrest to the
desired position.
SIC2208A
Instruments and controls
2-33
04.8.3/Z50-D/V5.0
