NISSAN MURANO 2005 1.G Repair Manual

curtain side-impact/rollover air bag
system.

Tampering with the supplemental
system may result in serious per-
sonal injury. For example, do not
change the front seats by placing
material near the seatback or by in-
stalling additional trim material, such
as seat covers, around the side air
bag.

Work around and on the side air bag
and curtain side-impact/rollover air
bag system should be done by a
NISSAN dealer. Installation of elec-
trical equipment should also be done
by a NISSAN dealer. The SRS wiring
harnesses* should not be modified or
disconnected. Unauthorized electri-
cal test equipment and probing de-
vices should not be used on the side
air bag system.
* The SRS wiring harnesses are cov-
ered with yellow and orange insula-
tion either just before the harness
connectors or over the complete har-
ness for easy identification.When selling your vehicle, we request that you
inform the buyer about the side air bag and
curtain side-impact/rollover air bag system and
guide the buyer to the appropriate sections in
this Owner’s Manual.
Pre-tensioner seat belt system (For
front seats)
WARNING

The pre-tensioner seat belt cannot be
reused after activation. It must be
replaced together with the retractor
and buckle as a unit.

If the vehicle becomes involved in a
frontal collision but the pre-tensioner
is not activated, be sure to have the
pre-tensioner system checked and, if
necessary, replaced by a NISSAN
dealer.

No unauthorized changes should be
made to any components or wiring of
the pre-tensioner seat belt system.
This is to prevent accidental activa-
tion of the pre-tensioner seat belt or
damage to the pre-tensioner seatbelt operation. Tampering with the
pre-tensioner seat belt system may
result in serious personal injury.

Work around and on the pre-
tensioner seat belt system should be
done by a NISSAN dealer. Installa-
tion of electrical equipment should
also be done by a NISSAN dealer.
Unauthorized electrical test equip-
ment and probing devices should not
be used on the pre-tensioner seat
belt system.

If you need to dispose of the pre-
tensioner or scrap the vehicle, con-
tact a NISSAN dealer. Correct pre-
tensioner disposal procedures are
set forth in the appropriate NISSAN
Service Manual. Incorrect disposal
procedures could cause personal
injury.
The front seat pre-tensioner seat belt system
activates in conjunction with the supplemental
front air bag system. Working with the seat belt
retractor, it helps tighten the seat belt when the
vehicle becomes involved in certain types of
1-48
Safety — seats, seat belts and supplemental restraint system


04.8.3/Z50-D/V5.0


collisions, helping to restrain front seat occu-
pants.
Also, the front seat pre-tensioner seat belt sys-
tem activates in conjunction with the supple-
mental side-impact/rollover air bag system.
Working with the seat belt retractor, it helps
tighten the seat belt when the vehicle becomes
involved in certain types of rollover collisions or
rear rollovers.
The pre-tensioner is encased with the seat belt’s
retractor. These seat belts are used the same as
conventional seat belts.
When the pre-tensioner seat belt activates,
smoke is released and a loud noise may be
heard. The smoke is not harmful, but care should
be taken not to inhale it as it may cause irritation
and choking. Those with a history of a breathing
condition should get fresh air promptly.
If any abnormality occurs in the pre-tensioner
seat belt system, the supplemental air bag warn-
ing light
will not come on, will flash inter-
mittently or will turn on for 7 seconds and remain
on after the ignition switch has been turned to
the ON or START position. In this case, the
pre-tensioner seat belt may not function prop-
erly. They must be checked and repaired. Take
your vehicle to a NISSAN dealer.
When selling your vehicle, we request that youinform the buyer about the pre-tensioner seat
belt system and guide the buyer to the appro-
priate sections in this Owner’s Manual.
SUPPLEMENTAL AIR BAG
WARNING LABELSWarning labels about the supplemental front air
bag and supplemental side-impact air bag sys-
tems are placed in the vehicle as shown in the
illustration.1
SRS air bag
The warning labels are located on the surface of
the sun visors.2
SRS side-impact air bag
The warning label is located on the side of the
passenger’s side center pillar.
SSS0330
Safety — seats, seat belts and supplemental restraint system
1-49


04.8.3/Z50-D/V5.0


SUPPLEMENTAL AIR BAG
WARNING LIGHTThe supplemental air bag warning light, display-
ing
in the instrument panel, monitors the
circuits of the supplemental front air bag,
supplemental side air bag and curtain side-
impact and rollover air bag systems, and pre-
tensioner seat belt. The circuits monitored by the
air bag warning light are the diagnosis sensor
unit, satellite sensors, front air bag modules, side
air bag modules, curtain side-impact/rollover air
bag modules, and pre-tensioner seat belt and all
related wiring.
After turning the ignition switch to the ONposition, the supplemental air bag warning light
illuminates. The supplemental air bag warning
light will turn off after about 7 seconds if the
system is operational.
If any of the following conditions occur, the
supplemental front air bag, supplemental side air
bag and curtain side-impact/rollover air bag
systems, and pre-tensioner seat belt need ser-
vicing:

The supplemental air bag warning light re-
mains on after approximately 7 seconds.

The supplemental air bag warning light
flashes intermittently.

The supplemental air bag warning light does
not come on at all.
Under these conditions, the supplemental front
air bags, supplemental side air bags, curtain
side-impact/rollover air bags and/or pre-
tensioner seat belt may not operate properly.
They must be checked and repaired. Take your
vehicle to a NISSAN dealer.
WARNING
If the supplemental air bag warning
light is on, it could mean that thesupplemental front air bag, supplemen-
tal side air bag, curtain side-impact/
rollover air bag systems and/or pre-
tensioner seat belt systems will not op-
erate in an accident. To help avoid injury
to yourself or others, have your vehicle
checked by a NISSAN dealer as soon as
possible.
Repair and replacement procedureThe supplemental front air bags, supplemental
side air bags, curtain side-impact/rollover air
bags and pre-tensioner seat belt are designed to
activate on a one-time-only basis. As a reminder,
unless it is damaged, the supplemental air bag
warning light will remain illuminated after inflation
has occurred. Repair and replacement of these
systems should be done only by a NISSAN
dealer.
When maintenance work is required on the
vehicle, the supplemental front air bags, side air
bags, curtain side-impact/rollover air bags, re-
lated parts and pre-tensioner seat belt should be
pointed out to the person conducting the main-
tenance. The ignition switch should always be in
the LOCK position when working under the
hood or inside the vehicle.
SPA1097
1-50
Safety — seats, seat belts and supplemental restraint system


04.8.3/Z50-D/V5.0


WARNING

Once a supplemental front air bag,
supplemental side air bag or curtain
side-impact/rollover air bag has in-
flated, the air bag module will not
function again and must be replaced.
Additionally, if any of the supplemen-
tal front air bags inflate, the activated
pre-tensioner seat belts must also be
replaced. The air bag module and
pre-tensioner seat belt system
should be replaced by a NISSAN
dealer. The air bag module and pre-
tensioner seat belt system cannot be
repaired.

The supplemental front air bag, side
air bag and curtain side-
impact/rollover air bag and systems
and the pre-tensioner seat belt sys-
tem should be inspected by a
NISSAN dealer if there is any damage
to the front end or side portion of the
vehicle.

If you need to dispose of these
supplemental systems or scrap thevehicle, contact a NISSAN dealer.
Correct disposal procedures are set
forth in the appropriate NISSAN Ser-
vice Manual. Incorrect disposal pro-
cedures could cause personal injury.
Safety — seats, seat belts and supplemental restraint system
1-51


04.8.3/Z50-D/V5.0


MEMO1-52
Safety — seats, seat belts and supplemental restraint system


04.8.3/Z50-D/V5.0


MEMO
Safety — seats, seat belts and supplemental restraint system
1-53


04.8.3/Z50-D/V5.0


2 Instruments and controlsInstrument panel ..................................................................... 2-2
Meters and gauges ............................................................... 2-3
Speedometer and odometer ......................................... 2-4
Tachometer ........................................................................ 2-4
Engine coolant temperature gauge ............................. 2-5
Fuel gauge ......................................................................... 2-5
Compass display (if so equipped) .................................... 2-6
Warning/indicator lights and audible reminders ............ 2-9
Checking bulbs................................................................. 2-9
Warning lights ................................................................... 2-9
Indicator lights ................................................................ 2-14
Audible reminders.......................................................... 2-16
Security systems.................................................................. 2-17
Vehicle security system (if so equipped) ................ 2-17
NISSAN Vehicle Immobilizer System ....................... 2-18
Windshield wiper and washer switch ........................... 2-20
Rear window wiper and washer switch ....................... 2-21
Rear window and outside mirror defroster switch...... 2-21
Headlight and turn signal switch ................................... 2-22
Xenon headlights (if so equipped) .......................... 2-22
Headlight switch ........................................................... 2-22
Daytime running light system (Canada only) ........ 2-25
Instrument brightness control ..................................... 2-26
Turn signal switch ........................................................ 2-26Fog light switch (if so equipped) .............................. 2-26
Hazard warning flasher switch ......................................... 2-27
Horn ........................................................................................ 2-27
Heated seats (if so equipped) ......................................... 2-28
Vehicle dynamic control (VDC) off switch
(if so equipped).................................................................... 2-29
Power outlet.......................................................................... 2-29
Storage .................................................................................. 2-30
Coin box........................................................................... 2-30
Cellular phone holder ................................................... 2-31
Cup holders .................................................................... 2-31
Glove box ........................................................................ 2-32
Console box .................................................................... 2-33
Cargo net (if so equipped) ......................................... 2-34
Tonneau cover (if so equipped)................................. 2-34
Windows................................................................................ 2-35
Power windows.............................................................. 2-35
Sunroof (if so equipped) ................................................... 2-37
Automatic sunroof ......................................................... 2-37
Interior lights ......................................................................... 2-39
Ceiling light ..................................................................... 2-39
Map light .......................................................................... 2-40
Rear personal light ........................................................ 2-40
Luggage light .................................................................. 2-41


04.8.3/Z50-D/V5.0


Vanity mirror light (if so equipped) ................................. 2-41
HomeLink
Universal Transceiver (if so equipped) .... 2-41
Programming HomeLink
............................................ 2-42
Programming HomeLinkfor Canadian
customers ........................................................................ 2-44
Operating the HomeLinkUniversal
Transceiver ...................................................................... 2-44Programming trouble diagnosis ................................. 2-44
Clearing the programmed information...................... 2-44
Reprogramming a single HomeLink
button .......... 2-45
If your vehicle is stolen................................................. 2-45


04.8.3/Z50-D/V5.0


1. Headlight, fog light (if so equipped) and turn
signal switch
2. Trip odometer reset button
3. Instrument brightness control switch
4. Meters/gauges
5. Windshield/rear window wiper and washer
switch
6. Hazard warning flasher switch
7. Center ventilator
8. Audio control
9. Display/clock
10. Rear window defroster and Heated outside
mirror (if so equipped) switch
11. Display screen control and/or Navigation
system*
12. Passenger supplemental air bag
13. Side ventilator
14. Headlight aiming control switch (if so
equipped)
15. VDC (Vehicle dynamic control) off switch (if
so equipped) or Headlight aiming control (if
so equipped)
16. Steering switch for audio control (if so
equipped)
17. Fuse box cover
18. Tilting steering wheel lock lever
19. Driver supplemental air bag/Horn
20. Cruise control main/set switch
21. Ignition switch/steering lock
22. Heater/air conditioner control
23. Coin box
24. Outside mirror remote control
25. Cellular phone holder
26. AWD lock switch (AWD models)
27. Heated seat switch (if so equipped)
SSI0072
INSTRUMENT PANEL2-2
Instruments and controls


04.8.3/Z50-D/V5.0


28. Power outlet cover (if so equipped)
29. Glove box
*: Refer to the separate Navigation System
Owner’s Manual.
1. Tachometer
2. Turn signal indicator/Hazard indicator
3. Speedometer
4. Engine coolant temperature gauge
5. Fuel gauge6. Reset button for trip odometer
7. Warning/Indicator lights
8. Odometer (Total/Twin trip)
9. CVT shift position indicator
SIC2039
METERS AND GAUGES
Instruments and controls
2-3


04.8.3/Z50-D/V5.0
