SPEEDOMETER AND ODOMETER
SpeedometerThe speedometer indicates vehicle speed.Odometer/Twin trip odometerThe odometer
1/twin trip odometer
2
are
displayed when the ignition switch is in the ON
position.
The odometer records the total distance the
vehicle has been driven.
The twin trip odometer records the distance of
individual trips.Changing the display:
Pushing the reset button
3
located on the left
side of the meter panel changes the display as
follows:
TRIP A→TRIP B→TRIP A
Resetting the trip odometer:
Pushing the reset button for more than 1 second
resets the trip odometer to zero.
Elapsed time, driving distance and average
speed information is also available. Refer to
“How to use TRIP button” in the “4. Display
screen, heater, air conditioner and audio sys-
tems” section later in this manual.
TACHOMETERThe tachometer indicates engine speed in revo-
lutions per minute (rpm).
Do not rev engine into red zone
A.
CAUTION
When engine speed approaches the red
zone, shift to a higher gear. Operating
the engine in the red zone may cause
serious engine damage.
SIC2175
SIC2041
2-4
Instruments and controls
04.8.3/Z50-D/V5.0
Page 72 of 321
ENGINE COOLANT TEMPERATURE
GAUGEThe gauge indicates the engine coolant tem-
perature.
The engine coolant temperature is within the
normal range
A
when the gauge needle points
within the zone shown in the illustration.
The engine coolant temperature will vary with the
outside air temperature and driving conditions.
CAUTION
If the gauge indicates engine coolant
temperature near the hot (H) end of the
normal range, reduce vehicle speed to
decrease temperature. If the gauge is
over the normal range, stop the vehicle
as soon as safely possible. If the engine
is overheated, continued operation of
the vehicle may seriously damage the
engine. See “If your vehicle overheats”
in the “In case of emergency” section
for immediate action required.
FUEL GAUGEThe gauge indicates the approximate fuel level in
the tank.
The gauge may move slightly during braking,
turning, acceleration, or going up or down hill.
The gauge needle is designed to move to the E
(Empty) position when the ignition switch is
turned to the OFF position.
Refill the fuel tank before the gauge regis-
ters Empty.
SIC2042A
SIC2043
Instruments and controls
2-5
04.8.3/Z50-D/V5.0
Page 73 of 321
The low fuel warning light comes on when
the fuel tank is getting low. Refuel as soon
as it is convenient, preferably before the
gauge reaches E. There will be a small
reserve of fuel in the tank when the fuel
gauge needle reaches E.
The
indicates that the fuel filler lid is
located on the driver’s side of the vehicle.
CAUTION
If the vehicle runs out of fuel, the
malfunction indicator lamp
(MIL) may come on. Refuel as soon
as possible. After a few driving trips,
the
lamp should turn off. If the
lamp remains on after a few driving
trips, have the vehicle inspected by a
NISSAN dealer.
For additional information, see “Mal-
function indicator lamp (MIL)” later in
this section.When the COMPASS switch
A
is pushed, the
compass display
B
will indicate the direction
the vehicle is heading.
N: north
E: east
S: south
W: west
If the display reads “C”, calibrate the compass
by driving the vehicle in 3 complete circles at
less than 5 MPH (8 km/h).
You can also calibrate the compass by driving
your vehicle on your everyday route. The com-
pass will be calibrated once it has tracked 3
complete circles.
SIC1901B
COMPASS DISPLAY (if so
equipped)
2-6
Instruments and controls
04.8.3/Z50-D/V5.0
Page 74 of 321
Zone variation change procedureThe difference between magnetic north and
geographical north is known as variance. In
some areas, this difference can sometimes be
great enough to cause false compass readings.
Follow these instructions to set the variance for
your particular location if this happens:
1. Push the COMPASS switch for more than 3
seconds. The current zone number will ap-
pear in the display.
2. Find your current location and variance one
number on the zone map
A.
3. Push the COMPASS switch until the new
zone number appears in the display. After you
stop pushing the switch in, the display will
show a compass direction within a few sec-
onds.
Inaccurate compass direction:
1. With the display turned on, push the COM-
PASS switch for 3 seconds, until the zone
selection comes up (a number will be dis-
played in the mirror compass window).
2. Toggle until correct zone is found and release
switch.
3. It returns to the normal compass mode within
10 seconds of no switch activity.
SIC0611C
Instruments and controls
2-7
04.8.3/Z50-D/V5.0
Page 75 of 321
4. If the vehicle changes zone, repeat steps 1
thru 3. See map.
If the compass deviates from the correct
indication soon after repeated adjustment,
have the compass checked at an authorized
dealer.
The compass may not indicate the correct
compass point in tunnels or while driving up
or down a steep hill.
(The compass returns to the correct com-
pass point when the vehicle moves to an area
where the geomagnetism is stabilized.)
CAUTION
Do not install a ski rack, antenna,
etc., which are attached to the vehicle
by means of a magnet. They affect
the operation of the compass.
When cleaning the mirror, use a pa-
per towel or similar material damp-
ened with glass cleaner. Do not spray
glass cleaner directly on the mirror as
it may cause the liquid cleaner to
enter the mirror housing.2-8
Instruments and controls
04.8.3/Z50-D/V5.0
Page 76 of 321
All Wheel Drive (AWD) warning light
(AWD models)
Low tire pressure warning light (if so
equipped)
Cruise set indicator light
or
Anti-lock Brake System (ABS)
warning light
Low washer fluid warning light
High beam indicator light (Blue)
or
Brake warning light
P position selecting warning light (if so
equipped)
Malfunction indicator lamp (MIL)
Charge warning light
Seat belt warning light
Security indicator light
Door open warning light
Supplemental air bag warning light
Slip indicator light (if so equipped)
Engine oil pressure warning light
All Wheel Drive (AWD) LOCK indicator
light (AWD models)
Turn signal/hazard indicator lights
Intelligent Key warning light (if so
equipped)
Continuously Variable Transmission (CVT)
indicator light
Vehicle Dynamic Control (VDC) off indi-
cator light (if so equipped)
Low fuel warning light
Cruise main switch indicator light
CHECKING BULBSApply the parking brake and turn the ignition
switch to ON without starting the engine. The
following lights will come on:
,
or
,
,
,
The following lights come on briefly and then go
off:
,
or
,
,
,
,
,
,
,
If any light fails to come on, it may indicate a
burned-out bulb or an open circuit in the elec-
trical system. Have the system repaired
promptly.
WARNING LIGHTS
All wheel drive (AWD) warning
light (AWD models)
The
warning light comes on when the
ignition switch is turned to ON. It turns off soon
after the engine is started.
If the AWD system malfunctions or the revolu-
tion, or radius of the front and the rear wheel
WARNING/INDICATOR LIGHTS
AND AUDIBLE REMINDERS
Instruments and controls
2-9
04.8.3/Z50-D/V5.0
Page 77 of 321
differs, the warning light will either remain illumi-
nated or blink. See “Using all wheel drive
(AWD)” in the “5. Starting and driving” section.
CAUTION
If the warning light comes on while
driving, AWD mode will change to
2WD mode. Reduce the vehicle speed
and have your vehicle checked by a
NISSAN dealer as soon as possible.
Do not drive on dry hard surface
roads in the LOCK mode.
If the AWD warning light blinks when
you are driving:
•blinks rapidly (about twice a sec-
ond):
Pull off the road in a safe area, and
idle the engine. The driving mode
will change to 2WD to prevent the
AWD system from malfunctioning.
If the warning light turns off, you
can drive again.
•blinks slowly (about once every 2
seconds):Pull off the road in a safe area, and
idle the engine. Check that all tire
sizes are the same, tire pressure is
correct and tires are not worn.
If the warning light is still on after the
above operation, have your vehicle
checked by a NISSAN dealer as soon as
possible.
or
Anti-lock brake
system (ABS)
warning light
After turning the ignition switch to the ON
position, the light will illuminate. The light will turn
off after about 2 seconds if the system is
operational.
If the light comes on while the engine is running,
it may indicate that the anti-lock brake system is
not functioning properly. Have the system
checked by a NISSAN dealer.
If an abnormality occurs in the system, the
anti-lock function will cease but the ordinary
brakes will continue to operate normally. See
“Anti-lock brake system (ABS)” in the “5. Start-
ing and driving” section for further details.If the light comes on while you are driving,
contact a NISSAN dealer for repair.
or
Brake warning light
This light functions for both the parking brake
and the foot brake systems.
Parking brake indicator:
When the ignition switch is in the ON position,
the light comes on when the parking brake is
applied.
Low brake fluid warning light:
The light warns of a low brake fluid level. If the
light comes on while the engine is running with
the parking brake not applied, stop the vehicle
and perform the following:
1. Check the brake fluid level. Add brake fluid as
necessary. See “Brake fluid” in the “8. Main-
tenance and do-it-yourself” section.
2. If the brake fluid level is correct, have the
warning system checked by a NISSAN
dealer. Avoid high speed driving and abrupt
braking.
If both the brake warning light and the anti-
lock brake warning light come on simulta-
neously, it may indicate the anti-lock brake
system is not functioning properly. See “Anti-
2-10
Instruments and controls
04.8.3/Z50-D/V5.0
Page 78 of 321
lock brake system (ABS) warning light” ear-
lier in this section.
WARNING
Your brake system may not be work-
ing properly if the warning light is on.
Driving could be dangerous. If you
judge it to be safe, drive carefully to
the nearest service station for re-
pairs. Otherwise, have your vehicle
towed because driving it could be
dangerous.
Pressing the brake pedal with the
engine stopped and/or a low brake
fluid level may increase your stop-
ping distance and braking will re-
quire greater pedal effort as well as
pedal travel.
If the brake fluid level is below the
MINIMUM mark on the brake fluid
reservoir, do not drive until the brake
system has been checked at a
NISSAN dealer.
Charge warning light
If the light comes on while the engine is running,
it may indicate that the charging system is not
functioning properly. Turn the engine off and
check the generator belt. If the belt is loose,
broken, missing or if the light remains on, see a
NISSAN dealer immediately.
CAUTION
Do not continue driving if the generator
belt is loose, broken or missing.
Door open warning light
This light comes on when any of the doors are
not closed securely while the ignition switch is
ON.
Engine oil pressure warning
light
This light warns of low engine oil pressure. If the
light blinks or comes on during normal driving,
pull off the road in a safe area, stop the engine
immediatelyand call a NISSAN dealer or other
authorized repair shop.
The oil pressure warning light is not de-
signed to indicate a low oil level. Use the
dipstick to check the oil level.See “Engineoil” in the “8. Maintenance and do-it-yourself”
section.
CAUTION
Running the engine with the engine oil
pressure warning light on could cause
serious damage to the engine almost
immediately. Turn off the engine as
soon as it is safe to do so.
Intelligent Key warning light
(for Intelligent Key system) (if
so equipped)
This light comes on in green when it is possible
to turn the ignition switch.
When the light comes on in red, it is not possible
to turn the ignition switch.
The warning light blinks in red when the
Intelligent Key is outside the vehicle with the
ignition switch in the ACC or ON position.
Confirm the location of the key as soon as
possible when the warning light blinks in red.
Be sure to carry the Intelligent Key with you
while driving the vehicle.
The warning light goes off about 10 seconds
Instruments and controls
2-11
04.8.3/Z50-D/V5.0
Page 79 of 321
after the Intelligent Key is brought inside the
vehicle.
Low fuel warning light
This light comes on when the fuel in the tank is
getting low. Refuel as soon as it is convenient,
preferably before the fuel gauge reaches E.
There will be a small reserve of fuel re-
maining in the tank when the fuel gauge
needle reaches E.
Low tire pressure warning light
(if so equipped)
After the ignition switch is turned ON, this light
comes on for about 1 second and then turns off.
This light warns of low tire pressure.
NISSAN’s low tire pressure warning system is a
tire pressure monitoring system. It monitors tire
pressure of all tires except the spare. When the
tire pressure monitoring system warning light is
lit, one or more of your tires is significantly
under-inflated. You should stop and check your
tires as soon as possible, and inflate them to the
proper pressure as indicated on the vehicle’s tire
information placard. Driving on a significantly
under-inflated tire causes the tire to overheat
and can lead to tire failure.
Under-inflation also reduces fuel efficiency andtire tread life, and may affect the vehicle’s han-
dling and stopping ability. Each tire, including
the spare, should be checked monthly when
cold and set to the recommended inflation pres-
sure as specified in the vehicle placard and
Owner’s Manual. The recommended inflation
pressure may also be found on the Tire and
Loading Information label.
Low tire pressure warning:
If the vehicle is being driven with a low tire
pressure (lower than 27 psi, 190 kPa), the light
will illuminate and the chime will sound for about
10 seconds. If you select the tire pressure in the
display, the FLAT TIRE warning message will be
displayed.
For additional information, see “Low tire pres-
sure warning system” in the “5. Starting and
driving” section and “Flat tire” in the “6. In case
of emergency” section. Also, you can check the
pressure of all 4 tires on the display screen. See
“Tire pressure information” in the “4. Display
screen, heater, air conditioner and audio sys-
tems” section.
WARNING
If the light does not come on with the
key switch turned ON, have the ve-
hicle checked by a NISSAN dealer as
soon as possible.
If the light comes on while driving,
avoid sudden steering maneuvers or
abrupt braking, reduce vehicle speed,
pull off the road to a safe locationand
stop the vehicle as soon as possible.
Serious vehicle damage could occur
and may lead to an accident and
could result in serious personal in-
jury. Check the tire pressure for all
four tires. Adjust the tire pressure to
the recommended COLD tire pres-
sure shown on the Tire and Loading
Information label to turn the low tire
pressure warning light OFF. If the
light still comes on while driving after
adjusting the tire pressure, a tire may
be flat. If you have a flat tire, replace
it with a spare tire as soon as
possible.
2-12
Instruments and controls
04.8.3/Z50-D/V5.0
Page 80 of 321
When a spare tire is mounted or a
wheel is replaced, the pressure of
that tire will not be indicated and the
low tire pressure warning system will
not function. Contact a NISSAN
dealer as soon as possible for tire
replacement and/or system
resetting.
CAUTION
The low tire pressure warning system
is not a substitute for the regular tire
pressure check. Be sure to check the
tire pressure regularly.
If the vehicle is being driven at
speeds of less than 20 MPH (32
km/h), the low tire pressure warning
system may not operate correctly.
Be sure to install the specified size of
tires to the 4 wheels correctly.
Low washer fluid warning light
This light comes on when the washer tank fluid is
at a low level. Add washer fluid as necessary.
See “Window washer fluid” in the “8. Mainte-
nance and do-it-yourself” section.
P position selecting warning
light (for Intelligent Key system)
(if so equipped)
The light blinks in red and warning buzzer beeps
when the shift lever is not in the P position and
you are outside the vehicle with the Intelligent
Key.
When the warning light blinks, move the shift
lever to the P position and return the ignition
switch to the LOCK position.
Seat belt warning light
The light and chime remind you to fasten seat
belts. The light illuminates whenever the ignition
switch key is turned to ON, and will remain
illuminated until the driver’s seat belt is fastened.
At the same time, the chime will sound for about
6 seconds unless the driver’s seat belt is se-
curely fastened.
See “Seat belts” in the “1. Safety — seats, seat
belts and supplemental restraint system” section
for precautions on seat belt usage.
Supplemental air bag warning
light
After turning the ignition switch to the ON
position, the supplemental air bag warning light
will illuminate. The supplemental air bag warning
light will turn off after about 7 seconds if the
system is operational.
If any of the following conditions occur, the
supplemental front air bag, supplemental side air
bag and curtain side-impact air bag systems,
and pre-tensioner seat belt needs servicing and
your vehicle must be taken to a NISSAN dealer.
The supplemental air bag warning light re-
mains on after approximately 7 seconds.
The supplemental air bag warning light
flashes intermittently.
The supplemental air bag warning light does
not come on at all.
Unless checked and repaired, the Supplemental
Restraint System and/or the pre-tensioner seat
belt may not function properly. For additional
information, see “Supplemental restraint system”
in the “1. Safety — seats, seat belts and supple-
mental restraint system” section.
Instruments and controls
2-13
04.8.3/Z50-D/V5.0
