NISSAN NOTE 2016 Service Repair Manual

MWI
THE LOW WASHER FLUID WARNING CONTINUES DISPLAYING, OR DOES
NOT DISPLAY
MWI-53
< SYMPTOM DIAGNOSIS > [TYPE A]
C
D
E
F
G H
I
J
K L
M B A
O P
THE LOW WASHER FLUID WARNING CONTINUES DISPLAYING, OR
DOES NOT DISPLAY
DescriptionINFOID:0000000012432593
• The warning is still displayed even after washer fluid is added.
• The warning is not displayed even though the washer tank is empty.
Diagnosis ProcedureINFOID:0000000012432594
1.CHECK WASHER FLUID LEVEL SWITCH
Check the washer fluid level switch. Refer to MWI-47, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace washer fluid level switch. Refer to WW-59, "
Removal and Installation".
2.CHECK WASHER FLUID LEVEL SWITCH SIGNAL CIRCUIT
Check the washer fluid level switch signal circuit. Refer to MWI-47, "
Diagnosis Procedure".
Is the inspection result normal?
YES >> Replace combination meter. Refer to MWI-54, "Removal and Installation".
NO >> Repair or replace harness or connector.
Revision: August 2015 2016 Versa Note

cardiagn.com

MWI-54
< REMOVAL AND INSTALLATION >[TYPE A]
COMBINATION METER
REMOVAL AND INSTALLATION
COMBINATION METER
Removal and InstallationINFOID:0000000012432595
REMOVAL
1. Disconnect negative battery terminal. Refer to
PG-70, "Removal and Installation (Battery)".
2. Remove cluster lid A. Refer to IP-21, "
Removal and Installation".
3. Remove combination meter screws (A).
4. Pull the combination meter straight out to release clips. NOTE:
Back side of the combination meter shown for clip position ( )
clarity.
5. Disconnect the harness connector from the combination meter.
INSTALLATION
Installation is in the reverse order of removal.
ALNIA1519ZZ
JSNIA3895ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

MWI
APPLICATION NOTICEMWI-55
< HOW TO USE THIS MANUAL > [TYPE B]
C
D
E
F
G H
I
J
K L
M B A
O P
HOW TO USE THIS MANUAL
APPLICATION NOTICE
InformationINFOID:0000000012432596
Service information Design of combination meter
TYPE A
TYPE B
JSNIA3947ZZ
AWNIA3632ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

MWI-56
< PRECAUTION >[TYPE B]
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint Syst
em (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000012432597
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harn esses can be identified by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or electri c power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers , always switch the Ignition OFF, disconnect the
battery and wait at least three minutes before performing any service.
Revision: August 2015 2016 Versa Note

cardiagn.com

MWI
PREPARATIONMWI-57
< PREPARATION > [TYPE B]
C
D
E
F
G H
I
J
K L
M B A
O P
PREPARATION
PREPARATION
Commercial Service ToolsINFOID:0000000012432598
Tool name Description
Power Tool Loosening nuts, screws and bolts
PIIB1407E
Revision: August 2015 2016 Versa Note

cardiagn.com

MWI-58
< SYSTEM DESCRIPTION >[TYPE B]
COMPONENT PARTS
SYSTEM DESCRIPTION
COMPONENT PARTS
METER SYSTEM
METER SYSTEM : Component Parts LocationINFOID:0000000012432599
A. Steering wheel
B. Combination meter C. View with rear lower seat cushion pad
and inspection hole cover removed.
No. Component Function
1. Parking brake switch Transmits the parking brake switch signal to the combination meter.
2. ABS actuator and electric unit (control unit) Transmits the vehicle speed signal to the combination meter via CAN communica-
tion.
Refer to BRC-7, "
Component Parts Location" for detailed installation location.
ALNIA1658GB
Revision: August 2015
2016 Versa Note

cardiagn.com

MWI
COMPONENT PARTSMWI-59
< SYSTEM DESCRIPTION > [TYPE B]
C
D
E
F
G H
I
J
K L
M B A
O P
METER SYSTEM : Combination MeterINFOID:0000000012432600
The combination meter controls the following items a ccording to the signals received from each unit via CAN
communication and the signals from switches and sensors:
• Measuring instruments
• Indicator lamps
• Warning lamps
• Meter illumination control
• Information display
ARRANGEMENT OF COMBINATION METER
3. Washer fluid level switch Transmits the washer fluid level switch signal to the combination meter (for Cana-
da).
Refer to
WW-6, "
Component Parts Location" for detailed installation location.
4. Engine oil pressure sensor Transmits the engine oil pressure sensor signal to the ECM.
Refer to
EM-93, "
Exploded View" for detailed installation location.
5. Ambient sensor Transmits the ambient sensor signal to the combination meter.
6. TCM Transmits the shift position signal to the combination meter via CAN communica-
tion (with CVT).
Refer to
TM-61, "
CVT CONTROL SYSTEM : Component Parts Location" for de-
tailed installation location.
7. ECM Transmits the following signals to the combination meter via CAN communication:
• Engine speed signal
• Engine coolant temperature signal
• Fuel consumption monitor signal
• Engine oil pressure sensor signal
Refer to
EC-14, "
ENGINE CONTROL SYSTEM : ComponentPartsLocation" for
detailed installation location.
8. BCM Transmits the following signals to the combination meter via CAN communication:
• Door switch signal
• Buzzer signal
Refer to
BCS-6, "
BODY CONTROL SYSTEM : Component Parts Location" (with
Intelligent Key system) or BCS-77, "
BODY CONTROL SYSTEM : Component
Parts Location" (without Intelligent Key system) for detailed installation location.
9. Steering wheel audio control switches
(meter control switch) Transmits the meter control switch signal to the combination meter.
10. Combination meter Refer to MWI-59, "
METER SYSTEM : Combination Meter".
11 . Fuel level sensor unit and fuel pump (fuel
level sensor) Transmits the fuel level sensor signal to the combination meter.
No.
Component Function
AWNIA3630ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

MWI-60
< SYSTEM DESCRIPTION >[TYPE B]
COMPONENT PARTS
U: USA
EU: Except USA
Revision: August 2015 2016 Versa Note

cardiagn.com

MWI
SYSTEMMWI-61
< SYSTEM DESCRIPTION > [TYPE B]
C
D
E
F
G H
I
J
K L
M B A
O P
SYSTEM
METER SYSTEM
METER SYSTEM : System DescriptionINFOID:0000000012432601
SYSTEM DIAGRAM
