POWER SUPPLY AND GROUND CIRCUIT
COMBINATION METER
COMBINATION METER : Diagnosis ProcedureINFOID:0000000012432574
Regarding Wiring Diagram information, refer to MWI-26, "Wiring Diagram".
1.CHECK FUSE
Check that the following fuses are not blown.
Is the fuse blown?
YES >> Replace the blown fuse after repairing the affected circuit.
NO >> GO TO 2.
2.POWER SUPPLY CIRCUIT CHECK
1. Disconnect combination meter connector.
2. Check voltage between combination meter harness connector M82, terminals 27, 28, 15 and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness or connector.
3.GROUND CIRCUIT CHECK
1. Turn ignition switch OFF.
2. Disconnect combination meter connector.
3. Check continuity between combination meter harness connector M82, terminals 21, 22, 23 and ground.
Is the inspection result normal?
YES >> Inspection End.
NO >> Repair or replace harness or connector.
BCM (BODY CONTROL MODULE)
Power source Fuse No.
Battery 8
Ignition switch ON or START 3
Ignition switch ACC or ON 18
TerminalsIgnition switch position
(+) (–)OFF ACC ONSTART
Connector Terminal
M82 27
GroundBattery voltage Battery voltage Battery voltage Battery voltage
28 0V0VBattery voltage Battery voltage
15 0V Battery voltage Battery voltage 0V
Te r m i n a l s
Continuity
(+)
(–)
Connector Terminal
M82 21
Ground Yes
22
23
Revision: August 2015 2016 Versa Note

cardiagn.com

MWI-44
< DTC/CIRCUIT DIAGNOSIS >[TYPE A]
POWER SUPPLY AND GROUND CIRCUIT
BCM (BODY CONTROL MODULE) : Diagnosis Procedure
INFOID:0000000012542950
Regarding Wiring Diagram information, refer to BCS-117, "Wiring Diagram".
1.CHECK FUSES AND FUSIBLE LINK
Check that the following fuses and fusible link are not blown.
Is the fuse blown?
YES >> Replace the blown fuse or fusible link after repairing the affected circuit.
NO >> GO TO 2.
2.CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM connectors.
3. Check voltage between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair harness or connector.
3.CHECK GROUND CIRCUIT
Check continuity between BCM connector and ground.
Is the inspection result normal?
YES >> Inspection End.
NO >> Repair harness or connector.
Terminal No. Signal nameFuses and fusible link No.
37 Battery power supply 8 (10A)
42 12 (10A)
50 G (40A)
11 Ignition switch ACC or ON 18 (10A)
38 Ignition switch ON or START 2 (10A)
BCMGround Ignition switch position
Connector Terminal
—OFF
ACC ON
M18 11
0 V
Battery voltage
Battery voltage
37
Battery voltage
38 0 V0 V
M19 42
Battery voltage Battery voltage
50
BCM GroundContinuity
Connector Terminal
M19 55—Yes
Revision: August 2015 2016 Versa Note

cardiagn.com

MWI
FUEL LEVEL SENSOR SIGNAL CIRCUITMWI-45
< DTC/CIRCUIT DIAGNOSIS > [TYPE A]
C
D
E
F
G H
I
J
K L
M B A
O P
FUEL LEVEL SENSOR SIGNAL CIRCUIT
DescriptionINFOID:0000000012432576
The fuel level sensor unit and fuel pump detects the approx imate fuel level in the fuel tank and transmits the
fuel level signal to the combination meter.
Component Function CheckINFOID:0000000012432577
1.COMBINATION METER INPUT SIGNAL
1. Select METER/M&A on CONSULT.
2. Using FUEL METER of DATA MONITOR, compare the DATA MONITOR value with the fuel gauge posi- tion.
Does monitor value match fuel gauge reading?
YES >> Inspection End.
NO >> Replace combination meter. Refer to MWI-54, "
Removal and Installation".
Diagnosis ProcedureINFOID:0000000012432578
Regarding Wiring Diagram information, refer to MWI-26, "Wiring Diagram".
1.CHECK HARNESS CONNECTOR
1. Turn ignition switch OFF.
2. Check combination meter and fuel level sensor unit terminals (meter-side and harness-side) for poor con- nection.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace terminals or connectors.
2.CHECK FUEL LEVEL SENSOR UNIT CIRCUIT
1. Disconnect combination meter harness connector M82 and fuel level sensor unit and fuel pump harness
connector B44.
2. Check continuity between combination meter harness connector M82 terminal 6 and fuel level sensor unit
and fuel pump harness connector B44 terminal 2.
3. Check continuity between fuel level sensor unit and fuel pump harness connector B44 terminal 2 and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair harness or connector.
Fuel gauge indication position Reference value of data monitor [L]
1A pp ro x. 3 9.8
3/4 Approx. 31.2
1/2 Approx. 20.8
1/4 Approx. 10.8
0A ppro x. 2 .9
Connector TerminalConnector Terminal Continuity
M82 6B44 2Yes
Connector Terminal
GroundContinuity
B44 2 No
Revision: August 2015 2016 Versa Note

cardiagn.com

MWI-46
< DTC/CIRCUIT DIAGNOSIS >[TYPE A]
FUEL LEVEL SENSOR SIGNAL CIRCUIT
3.CHECK FUEL LEVEL SENSOR GROUND CIRCUIT
1. Disconnect ECM connector F11.
2. Check continuity between combination meter har ness connector M82 terminal 24 and fuel level sensor
unit and fuel pump harness connector B44 terminal 5.
3. Check continuity between fuel level sensor unit and fuel pump harness connector B44 terminal 5 and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair harness or connector.
4.CHECK INSTALLATION CONDITION
Check fuel level sensor unit installation, and verify t he float arm does not interfere or bind with the internal
components in the fuel tank.
Is the inspection result normal?
YES >> Inspection End.
NO >> Install the fuel level sensor unit properly.
Component InspectionINFOID:0000000012432579
1.REMOVE FUEL LEVEL SENSOR UNIT
Remove the fuel level sensor unit. Refer to FL-6, "
Removal and Installation".
>> GO TO 2.
2.CHECK FUEL LEVEL SENSOR UNIT
Check the resistance between fuel level sensor unit and fuel pump.
*: When float rod is in contact with stopper.
Is inspection result OK?
YES >> Inspection End.
NO >> Replace fuel level sensor unit and fuel pump. Refer to
FL-6, "
Removal and Installation".
Connector TerminalConnector Terminal Continuity
M82 24B44 5Yes
Connector Terminal
GroundContinuity
B44 5 No
Te r m i n a l s
ConditionResistance (Ω
)
(Approx.) Height [mm (in)]
Fuel level sensor unit
25 Full
* (A)
51 171.4 (6.75)
Empty
* (B) 283 18.5 (0.73)
JPNIA0841ZZ
Revision: August 2015
2016 Versa Note

cardiagn.com

MWI
WASHER FLUID LEVEL SWITCH CIRCUITMWI-47
< DTC/CIRCUIT DIAGNOSIS > [TYPE A]
C
D
E
F
G H
I
J
K L
M B A
O P
WASHER FLUID LEVEL SWITCH CIRCUIT
DescriptionINFOID:0000000012432580
Transmits the washer fluid level switch signal to the combination meter.
Diagnosis ProcedureINFOID:0000000012432581
Regarding Wiring Diagram information, refer to MWI-26, "Wiring Diagram".
1.CHECK WASHER FLUID LEVEL SWITCH SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect combination meter connector and washer fluid level switch connector.
3. Check continuity between combination meter harness connector M82 terminal 17 and washer fluid level switch harness connector E50 terminal 1.
4. Check continuity between combination meter harness connector M82 terminal 17 and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace harness or connector.
2.CHECK WASHER FLUID LE VEL SWITCH GROUND CIRCUIT
Check continuity between washer fluid level switch harness connector E50 terminal 2 and ground.
Is the inspection result normal?
YES >> Inspection End.
NO >> Repair or replace harness or connector.
Component InspectionINFOID:0000000012432582
1.CHECK WASHER FLUID LEVEL SWITCH
Check continuity between washer fluid level switch terminals 1 and 2.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace washer fluid level switch. Refer to WW-59, "
Removal and Installation".
ConnectorTerminalConnector Terminal Continuity
M82 17E50 1Yes
Connector Terminal
GroundContinuity
M82 17 No
ConnectorTerminal
GroundContinuity
E50 2 Yes
TerminalWasher fluid level Continuity
1 - 2 Low
Yes
High No
Revision: August 2015 2016 Versa Note

cardiagn.com

MWI-48
< SYMPTOM DIAGNOSIS >[TYPE A]
THE FUEL GAUGE INDICATOR DOES NOT OPERATE
SYMPTOM DIAGNOSIS
THE FUEL GAUGE INDICATOR DOES NOT OPERATE
DescriptionINFOID:0000000012432583
Fuel gauge will not indicate from a certain position.
Diagnosis ProcedureINFOID:0000000012432584
1.CHECK COMBINATION METER INPUT SIGNAL
1. Select METER/M&A on CONSULT.
2. Using DATA MONITOR, compare the monitor value with the fuel gauge reading on the combination meter. Refer to MWI-45, "
Component Function Check".
Does monitor value match fuel gauge reading?
YES >> GO TO 2.
NO >> Replace combination meter. Refer to MWI-54, "
Removal and Installation".
2.CHECK FUEL LEVEL SENSOR SIGNAL CIRCUIT
Check the fuel level sensor signal circuit. Refer to MWI-45, "
DiagnosisProcedure".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair harness or connector.
3.COMPONENT INSPECTION
Perform a component inspection on the fuel level sensor unit. Refer to MWI-46, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace fuel level sensor unit. Refer to FL-6, "
Removal and Installation".
4.CHECK FLOAT INTERFERENCE
Check that the float arm does not interfere or bind with components in the fuel tank.
Is the inspection result normal?
YES >> Replace combination meter. Refer to MWI-54, "Removal and Installation".
NO >> Repair or replace malfunctioning parts.
Revision: August 2015 2016 Versa Note

cardiagn.com

MWI
THE OIL PRESSURE WARNING LAMP DOES NOT TURN ON
MWI-49
< SYMPTOM DIAGNOSIS > [TYPE A]
C
D
E
F
G H
I
J
K L
M B A
O P
THE OIL PRESSURE WARNING LAMP DOES NOT TURN ON
DescriptionINFOID:0000000012432585
The engine oil pressure warning lamp stays off when the ignition switch is turned ON.
Diagnosis ProcedureINFOID:0000000012432586
1.CHECK COMBINATION METER ENGINE OIL PRESSURE WARNING LIGHT
1. Select METER/M&A on CONSULT.
2. Observe OIL W/L DATA MONITOR while operating the ignition switch.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace combination meter. Refer to MWI-54, "
Removal and Installation".
Component ConditionCONSULT
Engine oil pressure warning light Ignition ON
ON
Ignition OFF OFF
Revision: August 2015 2016 Versa Note

cardiagn.com

MWI-50
< SYMPTOM DIAGNOSIS >[TYPE A]
THE OIL PRESSURE WARNING
LAMP DOES NOT TURN OFF
THE OIL PRESSURE WARNING LA MP DOES NOT TURN OFF
DescriptionINFOID:0000000012432587
The engine oil pressure warning lamp remains on while the engine is running (normal oil pressure).
Diagnosis ProcedureINFOID:0000000012432588
1.CHECK COMBINATION METER INPUT SIGNAL
1. Start the engine and select METER/M&A on CONSULT.
2. Observe OIL W/L DATA MONITOR and the operation of the engine oil pressure warning lamp on the com- bination meter.
Is the inspection result normal?
YES >> Replace combination meter. Refer to MWI-54, "Removal and Installation".
NO >> Perform ECM self-diagnosis. Refer to EC-60, "
CONSULT Function".
Component Condition CONSULT
Engine oil pressure warning light Engine runningOFF
Revision: August 2015 2016 Versa Note

cardiagn.com

MWI
THE DOOR OPEN WARNING CONTINUES DISPLAYING, OR DOES NOT DIS-
PLAY
MWI-51
< SYMPTOM DIAGNOSIS > [TYPE A]
C
D
E
F
G H
I
J
K L
M B A
O P
THE DOOR OPEN WARN ING CONTINUES DISPLAYING, OR DOES NOT
DISPLAY
DescriptionINFOID:0000000012432589
• The door ajar warning is displayed even though all of the doors are closed.
• The door ajar warning is not displayed even though a door is ajar.
Diagnosis ProcedureINFOID:0000000012432590
1.CHECK BCM INPUT SIGNAL
Check the BCM input signal. Refer to DLK-232, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 3.
2.CHECK COMBINATION METER INPUT SIGNAL
Select the METER/M&A Data Monitor and check t he DOOR W/L monitor value while opening and closing
doors.
Is the inspection result normal?
YES >> Replace combination meter. Refer to MWI-54, "Removal and Installation".
NO >> Replace BCM. Refer to BCS-137, "
Removal and Installation".
3.CHECK DOOR SWITCH SIGNAL CIRCUIT
Check the door switch signal circuit. Refer to DLK-232, "
Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness or connector.
4.CHECK DOOR SWITCH
Check the door switch. Refer to DLK-234, "
Component Inspection".
Is the inspection result normal?
YES >> Replace combination meter. Refer to MWI-54, "Removal and Installation".
NO >> Replace applicable door switch. Refer to DLK-308, "
Removal and Installation".
Monitor itemCondition Status
DOOR W/L Door open
ON
Door closed OFF
Revision: August 2015 2016 Versa Note

cardiagn.com

MWI-52
< SYMPTOM DIAGNOSIS >[TYPE A]
THE PARKING BRAKE RELEASE WARNING CONTINUES DISPLAYING, OR
DOES NOT DISPLAY
THE PARKING BRAKE RELEASE WARNING CONTINUES DISPLAYING,
OR DOES NOT DISPLAY
DescriptionINFOID:0000000012432591
• The parking brake warning is displayed while drivi ng the vehicle even though the parking brake is released.
• The parking brake warning is not displayed while driving the vehicle even though the parking brake is applied.
Diagnosis ProcedureINFOID:0000000012432592
1.CHECK PARKING BRAKE WARNING LAMP OPERATION
1. Start engine.
2. Check the operation of the brake warning lamp while operating the parking brake.
Is the inspection result normal?
YES >> Replace combination meter. Refer to MWI-54, "Removal and Installation".
NO >> GO TO 2.
2.CHECK PARKING BRAKE SWITCH
Check the parking brake switch. Refer to WCS-43, "
TYPE A : Component Inspection".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace parking brake switch. Refer to PB-9, "
Removal and Installation".
3.CHECK PARKING BRAKE SWITCH SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Check the parking brake switch signal circuit. Refer to WCS-42, "
TYPE A : Diagnosis Procedure".
Is the inspection result normal?
YES >> Replace combination meter. Refer to MWI-54, "Removal and Installation".
NO >> Repair or replace harness or connector.
Condition Warning lamp status
Parking brake applied ON
Parking brake released OFF
Revision: August 2015 2016 Versa Note

cardiagn.com
