NISSAN NOTE 2016 Service Repair Manual

PG-54
< WIRING DIAGRAM >
HARNESS
FRONT DOOR RH HARNESS
AAMIA0192ZZ
D101 Y/4 : To M75D112 W/2 : Front door speaker RH
D104 B/2 : Front power window motor RH D113 GR/2 : Front outside handle RH (Request switch)
D 1 0 5 W / 1 2 : Power window and door lock/unlock switch
RH
D114 GR/6 : Front door lock actuator RH
D 1 0 6 G R / 2 : Front outside handle RH (Outside key
antenna) D115 W/12 : To M81
D107 W/12 : Door mirror RH D116 W/12 : To M92
D111 Y/2 : Front door satellite sensor RH
Revision: August 2015 2016 Versa Note

cardiagn.com

PG
HARNESSPG-55
< WIRING DIAGRAM >
C
DE
F
G H
I
J
K L
B A
O P
N
REAR DOOR LH HARNESS
AAMIA0193ZZ
D201 W/10 : To B4
D205 GR/6 : Rear door lock actuator LH
D203 W/8 : Rear power window switch LH D207 W/2 : Rear door speaker LH
D204 B/2 : Rear power window motor LH
Revision: August 2015 2016 Versa Note

cardiagn.com

PG-56
< WIRING DIAGRAM >
HARNESS
REAR DOOR RH HARNESS
AAMIA0194ZZ
D301 W/10 : To B11D305 GR/6 : Rear door lock actuator RH
D303 W/8 : Rear power window switch RHD307 W/2 : Rear door speaker RH
D 3 0 4 B / 2 : R e a r power window motor RH
Revision: August 2015 2016 Versa Note

cardiagn.com

PG
HARNESSPG-57
< WIRING DIAGRAM >
C
DE
F
G H
I
J
K L
B A
O P
N
BACK DOOR HARNESS
AAMIA0384ZZ
D3 D501 B/6 : Rear view camera
C3 D506 BR/2 : Back door request switch
D3 D502 W/4 : Rear wiper motor D3 D507 BR/2 : License plate lamp LH
E3 D503 W/8 : To B53 C4 D508 BR/2 : License plate lamp RH
E 4 D 5 0 4 W / 4 : T o B 5 2 E 5 D 5 0 9 W / 3 : B a c k d o o r s w i t c h
D4 D505 W/2 : Back door lock actuator
Revision: August 2015 2016 Versa Note

cardiagn.com

PG-58
< WIRING DIAGRAM >
FUSE BLOCK - JUNCTION BOX (J/B)
FUSE BLOCK - JUNCTION BOX (J/B)
Terminal ArrangementINFOID:0000000012433124
AAMIA2767GB
Revision: August 20152016 Versa Note

cardiagn.com

PG
FUSE AND FUSIBLE LINK BOXPG-59
< WIRING DIAGRAM >
C
DE
F
G H
I
J
K L
B A
O P
N
FUSE AND FUSIBLE LINK BOX
Terminal ArrangementINFOID:0000000012433125
FUSE AND FUSIBLE LINK BOX
ABMIA7435GB
Revision: August 2015
2016 Versa Note

cardiagn.com

PG-60
< WIRING DIAGRAM >
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE
ROOM)
IPDM E/R Terminal Arrangement INFOID:0000000012433126
AAMIA0161ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

PG
BATTERYPG-61
< BASIC INSPECTION >
C
DE
F
G H
I
J
K L
B A
O P
N
BASIC INSPECTION
BATTERY
How to Handle BatteryINFOID:0000000012433127
CAUTION:
• If it becomes necessary to start the engine with
a booster battery and jumper cables, use a 12-volt
booster battery.
• After connecting battery cables, ensure that they are tightly clamped to battery terminals for good
contact.
• Never add distilled water through the hole used to check specific gravity.
METHODS OF PREVENTING OVER-DISCHARGE
The following precautions must be taken to prevent over-discharging a battery.
• The battery surface (particularly its top) should always be kept
clean and dry.
• The terminal connections should be clean and tight.
• At every routine maintenance, check the electrolyte level. This also applies to batteries designated as “low maintenance” and
“maintenance-free”.
• When the vehicle is not going to be used over a long period of time, disconnect the battery cable from the negative terminal. (If
the vehicle has an extended storage switch, turn it off.)
Work FlowINFOID:0000000012433128
BATTERY DIAGNOSIS WITH EXP-800 NI OR GR8-1200 NI
To diagnose and confirm the condition of the batte ry, use the following special service tools:
• EXP-800 NI Battery and electrical diagnostic analyzer
• GR8-1200 NI Multitasking battery and electrical diagnostic station
NOTE:
Refer to the applicable Instruction Manual for proper battery diagnosis procedures.
BATTERY DIAGNOSIS WITHOUT EXP-800 NI OR GR8-1200 NI
Checking Electrolyte Level
WARNING:
Never allow battery fluid to come in contact with skin, eyes, fabrics, or painted surfaces. After touch-
ing a battery, never touch or rub your eyes until you have thoroughly washed your hands. If acid con-
tacts eyes, skin or clothing, imme diately flush with water for 15 minutes and seek medical attention.
Failure to do this may cause personal injury or damage to clothing or the painted surfaces.
MEL040F
ELA0349D
Revision: August 2015 2016 Versa Note

cardiagn.com

PG-62
< BASIC INSPECTION >
BATTERY
• Remove the cell plug using a suitable tool.
• Add distilled water up to the MAX level.
SULFATION
•A battery will be completely discharged if it is left unattended
for a long time and the specific gravity will become less than
1.100. This may result in su lfation on the cell plates.
• To determine if a battery has been “sulfated”, note its voltage
and current when charging it. As shown in the figure, less cur-
rent and higher voltage are ob served in the initial stage of
charging sulfated batteries.
• A sulfated battery may someti mes be brought back into ser-
vice by means of a long, slow charge, 12 hours or more, fol-
lowed by a battery capacity test.
Specific Gravity Check
NOTE:
Check the charge condition of the battery.
Periodically check the specific gravity of the electr olyte. Keep a close check on charge condition to prevent
over-discharge.
1. Read hydrometer and thermometer indications at eye level.
2. Use the chart below to correct your hydrometer reading accord- ing to electrolyte temperature.
Hydrometer Temperature Correction
MEL043F
PKIA2353E
MEL042FA
Battery electrolyte temperature [° C (°F)] Add to specific gravity reading
71 (160) 0.032
66 (150) 0.028
60 (140) 0.024
54 (130) 0.020
49 (120) 0.016
43 (110) 0.012
38 (100) 0.008
32 (90) 0.004
27 (80) 0
21 (70) −0.004
16 (60) −0.008
10 (50) −0.012
Revision: August 2015 2016 Versa Note

cardiagn.com

PG
BATTERYPG-63
< BASIC INSPECTION >
C
DE
F
G H
I
J
K L
B A
O P
N
Charging The Battery
CAUTION:
• Never “quick charge” a fully discharged battery.
• Keep the battery away from open flame while it is being charged.
• When connecting the charger, connect
the leads first, then turn on the charger. Never turn on the
charger first, as this may cause a spark.
• If battery electrolyte temperature rises above 55 °C (131 °F), stop charging. Always charge battery at
a temperature below 55 °C (131 °F).
Charging Rates (Standard Charge)
Charging Rates (Quick Charge)
NOTE:
The ammeter reading on your battery charger will automatically decrease as the battery charges. This indi-
cates that the voltage of the battery is increasing norma lly as the state of charge improves. The charging amps
indicated above refer to initial charge rate.
• If, after charging, the specific gravity of any two cells varies more than 0.050, the battery should be replaced.
4 (40) −0.016
− 1 (30) −0.020
− 7 (20) −0.024
− 12 (10) −0.028
− 18 (0) −0.032
Battery electrolyte temperature [
°C ( °F)] Add to specific gravity reading
Corrected specific gravity Approximate charge condition
1.260 - 1.280 Fully charged
1.230 - 1.250 3/4 charged
1.200 - 1.220 1/2 charged
1.170 - 1.190 1/4 charged
1.140 - 1.160 Almost discharged
1.110 - 1.130 Completely discharged
Approximate charge condi-
tion Charge current (A)
Charge time (h)
Fully charged
72
3/4 charged 2.5
1/2 charged 5
1/4 charged 7.5
Almost discharged 9
Completely discharged 10
Approximate charge condi- tion Charge current (A)
Charge time (h)
Fully charged ——
3/4 charged 16
0.5
1/2 charged
33
1/4 charged
Almost discharged
Completely discharged ——
