BCS-60
< BASIC INSPECTION >[WITH INTELLIGENT KEY SYSTEM]
CONFIGURATION (BCM)
>> GO TO 4.
4.OPERATION CHECK
Confirm that each function controlled by BCM operates normally.
>> WORK END
Configuration ListINFOID:0000000012432341
CAUTION:
• Thoroughly read and understand the vehicle speci fication. ECU control may not operate normally if
the setting is not correct.
• The “setting value” of this vehicle is as follows: Never select any other value than the setting value
shown below. (If there is only 1 item in “setting value” that means that item is the only choice for this
certain vehicle.)
⇔ : Items which confirm vehicle specifications SETTING ITEM
NOTE
Items Setting value
I-KEY SYS FREQUENCY TYPE MODE2 ⇔ MODE3 • MODE2: 315 MHz
• MODE3: 433.92 MHz
TRANSMISSION AT with ABS ⇔ MT with ABS • AT with ABS: CVT models
• MT with ABS: M/T models
THEFT ALM AREA MODE2 ⇔ WITHOUT • MODE2: With vehicle security system
• WITHOUT: Without vehicle security system
ASCD CANCEL SW TYPE MODE1 ⇔ MODE2 • MODE1: With ASCD and CVT
• MODE2: With ASCD and M/T
AUTO DOOR LOCK SELECT WITH ⇔ WITHOUT • WITH: With automatic door lock function
• WITHOUT: Without automatic door lock function
I-KEY TUNING MODE2 —
DTRL MODE2 ⇔ WITHOUT • MODE2: With daytime running lamps
• WITHOUT: Without daytime running lamps
Revision: August 2015
2016 Versa Note

cardiagn.com

BCS
SHIPPING MODE CANCEL OPERATION
BCS-61
< BASIC INSPECTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
SHIPPING MODE CANCEL OPERATION
Work ProcedureINFOID:0000000012432342
1.SHIPPING MODE CANCEL OPERATION
1. Turn ignition switch OFF.
2. Press in (turn on) the extended storage switch. Refer to PG-65, "
How To Check".
3. Turn ignition switch ON.
4. Turn ignition switch OFF and wait at least 2 seconds.
>> GO TO 2.
2.SHIPPING MODE CANCEL CHECK
1. Turn ignition switch ON.
2. Check that extended storage warning message is not displayed in combination meter or display.
>> WORK END
Revision: August 2015 2016 Versa Note

cardiagn.com

BCS-62
< BASIC INSPECTION >[WITH INTELLIGENT KEY SYSTEM]
TRANSIT MODE CANCEL OPERATION
TRANSIT MODE CANCEL OPERATION
Work ProcedureINFOID:0000000012432343
1.TRANSIT MODE CANCEL OPERATION
1. Turn ignition switch OFF.
2. Do the following at the same time for 2 seconds:
- Move front wiper switch to HI position (all the way down)
- Move turn signal switch to left position (all the way down)
>> GO TO 2.
2.TRANSIT MODE CANCEL CHECK
1. Turn front wiper switch and turn signal switch OFF.
2. Turn ignition switch ON.
3. Check that turn signal indicators in combination meter do not turn ON.
>> Work End.
Revision: August 2015 2016 Versa Note

cardiagn.com

BCS
U1000 CAN COMM CIRCUITBCS-63
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
DTC/CIRCUIT DIAGNOSIS
U1000 CAN COMM CIRCUIT
DescriptionINFOID:0000000012432344
Refer to
LAN-25, "CAN COMMUNICATION SYSTEM : System Description".
DTC LogicINFOID:0000000012432345
DTC DETECTION LOGIC
NOTE:
U1000 can be set if a module harness was disconnected and reconnected, perhaps during a repair. Confirm
that there are actual CAN diagnostic symptoms and a present DTC by performing the Self Diagnostic Result
procedure.
Diagnosis ProcedureINFOID:0000000012432346
1. PERFORM SELF DIAGNOSTIC RESULT
1. Turn ignition switch ON and wait for 2 second or more.
2. Perform “Self Diagnostic Result” of “BCM” using CONSULT.
Is
“CAN COMM CIRCUIT” displayed?
YES >> Perform CAN Diagnosis as described in DI AGNOSIS section of CONSULT Operation manual.
NO >> Refer to GI-42, "
Intermittent Incident".
CONSULT Display DTC Detection Condition Possible Cause
CAN COMM CIRCUIT
[U1000] When any listed module cannot communicate
with CAN communication signal continuously for
2 seconds or more with ignition switch ON In CAN communication system, any item (or
items) of the following listed below is malfunc-
tioning.
•Transmission
• Receiving (ECM)
• Receiving (VDC/TCS/ABS)
• Receiving (METER/M&A)
• Receiving (TCM)
• Receiving (IPDM E/R)
Revision: August 2015
2016 Versa Note

cardiagn.com

BCS-64
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
U1010 CONTROL UNIT (CAN)
U1010 CONTROL UNIT (CAN)
DTC LogicINFOID:0000000012432347
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000012432348
1.REPLACE BCM
When DTC “U1010” is detected, replace BCM.
>> Replace BCM. Refer to BCS-74, "
Removal and Installation".
CONSULT Display DTC Detection Condition Possible Cause
CONTROL UNIT (CAN)
[U1010] BCM detected internal CAN communication cir-
cuit malfunction.
BCM
Revision: August 2015
2016 Versa Note

cardiagn.com

BCS
U0415 VEHICLE SPEEDBCS-65
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
U0415 VEHICLE SPEED
DTC LogicINFOID:0000000012432349
DTC DETECTION LOGIC
NOTE:
• If DTC U0415 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
BCS-63, "
DTC Logic".
• If DTC U0415 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to BCS-64, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1. DTC CONFIRMATION
1. Erase the DTC.
2. Turn ignition switch OFF.
3. Perform Self Diagnostic Result of BCM with CONSULT, after the ignition switch has been turned ON for 2
seconds or more.
Is any DTC detected?
YES >> Refer to BCS-65, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012432350
1. ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) SELF DIAGNOSTIC RESULT
Perform “Self Diagnostic Result” of “ABS” with CONSULT. Refer to BRC-31, "
CONSULT Function (ABS)".
Is any DTC detected?
YES >> Perform the trouble diagnosis related to the detected DTC. Refer to BRC-43, "DTC Index".
NO >> GO TO 2.
2. CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) POWER SUPPLY AND GROUND
CIRCUIT
Check ABS actuator and electric unit (control unit) power and ground. Refer to BRC-121, "
Diagnosis Proce-
dure".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness or connectors.
3. COMBINATION METER SE LF DIAGNOSTIC RESULT
Perform “Self Diagnostic Result” of “ME TER M&A” with CONSULT. Refer to MWI-71, "
CONSULT Function
(METER/M&A)".
Is any DTC detected?
YES >> Perform the trouble diagnosis related to the detected DTC. Refer to MWI-77, "DTC Index".
NO >> Refer to GI-42, "
Intermittent Incident".
CONSULT Display DTC Detection Condition Probable Cause
VDC CAN CIR2
[U0415] When the vehicle speed signal received from the
ABS actuator and electric
unit (control unit) re-
mains abnormal for 2 seconds or more. • ABS system
• Combination meter system
• CAN bus harness
Revision: August 2015
2016 Versa Note

cardiagn.com

BCS-66
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2562 LOW VOLTAGE
B2562 LOW VOLTAGE
DTC LogicINFOID:0000000012432351
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1. DTC CONFIRMATION
1. Erase DTC.
2. Turn ignition switch OFF.
3. Perform the “Self Diagnostic Result” of “BCM” with CONSULT, after the ignition switch has been turned
ON for 120 seconds or more.
Is any DTC detected?
YES >> Refer to BCS-66, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012432352
1. CHECK BATTERY VOLTAGE
Check battery voltage.
Is battery voltage less than 8.8V?
YES >> Charge battery and retest. Refer to PG-61, "Work Flow".
NO >> GO TO 2.
2. CHECK POWER SUPPLY AND GROUND CIRCUIT
Check BCM power supply and ground circuit. Refer to BCS-67, "
Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness or connectors.
3. BCM SELF DIAGNOSTIC RESULT
Perform “Self Diagnostic Result” of “BCM” with CONSULT. Refer to BCS-25, "
BCM : CONSULT Function
(BCM - BCM)".
Is DTC B2562 CRNT?
YES >> Replace BCM. Refer to BCS-74, "Removal and Installation".
NO >> Refer to GI-42, "
Intermittent Incident".
CONSULT Display DTC Detection Condition Possible Cause
LOW VOLTAGE
[B2562] When the power supply voltage to BCM remains
less than 8.8 V for 120 seconds or more • Harness or connector (power supply circuit)
• Vehicle battery
Revision: August 2015
2016 Versa Note

cardiagn.com

BCS
POWER SUPPLY AND GROUND CIRCUITBCS-67
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
POWER SUPPLY AND GROUND CIRCUIT
Diagnosis ProcedureINFOID:0000000012432353
Regarding Wiring Diagram information, refer to
BCS-52, "Wiring Diagram".
1.CHECK FUSES AND FUSIBLE LINK
Check that the following fuses and fusible link are not blown.
Is the fuse blown?
YES >> Replace the blown fuse or fusible link after repairing the affected circuit.
NO >> GO TO 2.
2.CHECK POWER SUPPLY CIRCUIT
1. Disconnect BCM connector M99.
2. Check voltage between BCM connector M99 and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair harness or connector.
3.CHECK GROUND CIRCUIT
Check continuity between BCM connector M99 and ground.
Is the inspection result normal?
YES >> Inspection End.
NO >> Repair harness or connector.
Terminal No. Signal nameFuses and fusible link No.
57 Battery power supply 12 (10A)
70 G (40A)
BCM
Ground Voltage
Connector Terminal
M99 57
— Battery voltage
70
BCM GroundContinuity
Connector Terminal
M99 67—Yes
Revision: August 2015 2016 Versa Note

cardiagn.com

BCS-68
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
COMBINATION SWITCH INPUT CIRCUIT
COMBINATION SWITCH INPUT CIRCUIT
Diagnosis ProcedureINFOID:0000000012432354
Regarding Wiring Diagram information, refer to
BCS-52, "Wiring Diagram".
1.CHECK INPUT 1 - 5 CIRCUIT FOR OPEN
1. Turn ignition switch OFF.
2. Disconnect BCM and combination switch connectors.
3. Check continuity between BCM connector and combination switch connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair harness or connectors.
2.CHECK INPUT 1 - 5 CIRCUIT FOR SHORT
Check for continuity between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair harness or connectors.
3.CHECK BCM OUTPUT VOLTAGE
1. Connect BCM connector.
2. Check voltage between BCM connector and ground.
Combination switch signal BCM
Combination switch
Continuity
Connector TerminalConnector Terminal
INPUT 1
M9736
M28 11
Ye s
INPUT 2
359
INPUT 3 347
INPUT 4 3310
INPUT 5 3213
Combination switch
signal BCM
GroundContinuity
Connector Terminal
INPUT 1
M9736
No
INPUT 2
35
INPUT 3 34
INPUT 4 33
INPUT 5 32
Revision: August 2015 2016 Versa Note

cardiagn.com

BCS
COMBINATION SWITCH INPUT CIRCUITBCS-69
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
Is the inspection result normal?
YES >> Replace combination switch. Refer to
BCS-75, "Removal and Installation".
NO >> Replace BCM. Refer to BCS-74, "
Removal and Installation".
BCM signal Te r m i n a l s
Vo l ta g e
(+)
(− )
BCM
Ground
Connector
Terminal
OUTPUT 1
M9736
Refer to BCS-30, "
Refer-
ence Value".
OUTPUT 2
35
OUTPUT 3 34
OUTPUT 4 33
OUTPUT 5 32
