![NISSAN NOTE 2016 Service Repair Manual BCS-30
< ECU DIAGNOSIS INFORMATION >[WITH INTELLIGENT KEY SYSTEM]
BCM
ECU DIAGNOSIS INFORMATION
BCM
Reference ValueINFOID:0000000012432332
NOTE:
The Signal Tech II Tool [– (J-50190)] can be used to NISSAN NOTE 2016 Service Repair Manual BCS-30
< ECU DIAGNOSIS INFORMATION >[WITH INTELLIGENT KEY SYSTEM]
BCM
ECU DIAGNOSIS INFORMATION
BCM
Reference ValueINFOID:0000000012432332
NOTE:
The Signal Tech II Tool [– (J-50190)] can be used to](/img/5/57363/w960_57363-290.png)
BCS-30
< ECU DIAGNOSIS INFORMATION >[WITH INTELLIGENT KEY SYSTEM]
BCM
ECU DIAGNOSIS INFORMATION
BCM
Reference ValueINFOID:0000000012432332
NOTE:
The Signal Tech II Tool [– (J-50190)] can be used to perform the following functions. Refer to the Signal Tech
II User Guide for additional information.
• Activate and display TPMS transmitter IDs
• Display tire pressure reported by the TPMS transmitter
• Read TPMS DTCs
• Register TPMS transmitter IDs
• Check Intelligent Key relative signal strength
• Confirm vehicle Intelligent Key antenna signal strength
VALUES ON THE DIAGNOSIS TOOL
Monitor Item
Condition Value/Status
AIR COND SW A/C switch OFF
Off
A/C switch ON On
AIR PRESS FL Front left tire air pressure value
kPa, kg/cm
2, psi
AIR PRESS FR Front right tire air pressure value
kPa, kg/cm
2, psi
AIR PRESS RL Rear left tire air pressure value
kPa, kg/cm
2, psi
AIR PRESS RR Rear right tire air pressure value
kPa, kg/cm
2, psi
BRAKE SW 1 When the brake pedal is released
On
When the brake pedal is depressed Off
BRAKE SW2 Brake pedal released
Off
Brake pedal depressed On
BUZZER Buzzer in combination meter OFF
Off
Buzzer in combination meter ON On
CDL LOCK SW Door lock/unlock switch does not operate
Off
Press door lock/unlock switch to the LOCK side On
CDL UNLOCK SW Door lock/unlock switch does not operate
Off
Press door lock/unlock switch to the UNLOCK side On
CLUCH SW Clutch pedal depressed
On
Clutch pedal released Off
CONFRM ID ALL The key ID does not match any key ID registered to BCM. Yet
The key ID matches any key ID registered to BCM.
DONE
CONFIRM ID4 The key ID does not match the fourth key ID registered to BCM. Yet
The key ID matches the fourth key ID registered to BCM.
DONE
CONFIRM ID3 The key ID does not match the third key ID registered to BCM. Yet
The key ID matches the third key ID registered to BCM.
DONE
CONFIRM ID2 The key ID does not match the second key ID registered to BCM. Yet
The key ID matches the second key ID registered to BCM. DONE
CONFIRM ID1 The key ID does not match the first key ID registered to BCM. Yet
The key ID matches the first key ID registered to BCM.
DONE
DETE SW -IPDM When selector lever is in P position
Off
When selector lever is in any position other than P On
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 292 of 3641
![NISSAN NOTE 2016 Service Repair Manual BCS
BCM
BCS-31
< ECU DIAGNOSIS INFORMATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
DETE/CANCL SW
When selector lever is in P position Off
When selector lever is in any position o NISSAN NOTE 2016 Service Repair Manual BCS
BCM
BCS-31
< ECU DIAGNOSIS INFORMATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
DETE/CANCL SW
When selector lever is in P position Off
When selector lever is in any position o](/img/5/57363/w960_57363-291.png)
BCS
BCM
BCS-31
< ECU DIAGNOSIS INFORMATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
DETE/CANCL SW
When selector lever is in P position Off
When selector lever is in any position other than P
On
DOOR STAT-AS Passenger door LOCK status
LOCK
Passenger door UNLOCK status UNLK
Wait with selective UNLOCK operation (5 seconds) READY
DOOR STAT-DR Driver door LOCK status
LOCK
Driver door UNLOCK status UNLK
Wait with selective UNLOCK operation (5 seconds) READY
DOOR SW-AS Front door RH closed
Off
Front door RH opened On
DOOR SW-BK Back door closed
Off
Back door opened On
DOOR SW-DR Front door LH closed
Off
Front door LH opened On
DOOR SW-RL Rear door LH closed
Off
Rear door LH opened On
DOOR SW-RR Rear door RH closed
Off
Rear door RH opened On
ENGINE STATE Engine stopped
Stop
While the engine stalls Stall
At engine cranking Crank
Engine running Run
FAN O N SIG Blower motor fan switch OFF
Off
Blower motor fan switch ON On
FR FOG SW Front fog lamp switch OFF
Off
Front fog lamp switch ON On
FR WASHER SW Front washer switch OFF
Off
Front washer switch ON On
FR WIPER LOW Front wiper switch OFF
Off
Front wiper switch LO On
FR WIPER HI Front wiper switch OFF
Off
Front wiper switch HI On
FR WIPER INT Front wiper switch OFF
Off
Front wiper switch INT On
FR WIPER STOP Any position other than front wiper stop position
Off
Front wiper stop position On
HAZARD SW When hazard switch is not pressed
Off
When hazard switch is pressed On
HEAD LAMP SW 1 Headlamp switch OFF
Off
Headlamp switch 1st On
HEAD LAMP SW 2 Headlamp switch OFF
Off
Headlamp switch 1st On
HI BEAM SW High beam switch OFF
Off
High beam switch HI On
Monitor Item
Condition Value/Status
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 293 of 3641
![NISSAN NOTE 2016 Service Repair Manual BCS-32
< ECU DIAGNOSIS INFORMATION >[WITH INTELLIGENT KEY SYSTEM]
BCM
ID OK FLAGIgnition switch ACC or ON Reset
Ignition switch OFF
Set
ID REGST FL1 ID registration of front left tire incomplete
YET
I NISSAN NOTE 2016 Service Repair Manual BCS-32
< ECU DIAGNOSIS INFORMATION >[WITH INTELLIGENT KEY SYSTEM]
BCM
ID OK FLAGIgnition switch ACC or ON Reset
Ignition switch OFF
Set
ID REGST FL1 ID registration of front left tire incomplete
YET
I](/img/5/57363/w960_57363-292.png)
BCS-32
< ECU DIAGNOSIS INFORMATION >[WITH INTELLIGENT KEY SYSTEM]
BCM
ID OK FLAGIgnition switch ACC or ON Reset
Ignition switch OFF
Set
ID REGST FL1 ID registration of front left tire incomplete
YET
ID registration of front left tire complete DONE
ID REGST FR1 ID registration of front right tire incomplete
YET
ID registration of front right tire complete DONE
ID REGST RL1 ID registration of rear left tire incomplete
YET
ID registration of rear left tire complete DONE
ID REGST RR1 ID registration of rear
right tire incomplete YET
ID registration of rear right tire complete DONE
IGN RLY1 F/B Ignition switch OFF or ACC
Off
Ignition switch ON On
INT VOLUME Wiper intermittent dial is in a dial position 1 - 7 1 - 7
KEY CYL LK-SW Door key cylinder LOCK position
On
Door key cylinder other than LOCK position Off
KEY CYL UN-SW Door key cylinder UNLOCK position
On
Door key cylinder other than UNLOCK position Off
PASSING SW Other than lighting switch PASS
Off
Lighting switch PASS On
PRMT ENG STRT When the engine start is prohibited
Reset
When the engine start is permitted Set
PUSH SW Return ignition switch to LOCK position
Off
Press ignition switch On
PUSH SW-IPDM When engine switch (push switch) is not pressed
Off
When engine switch (push switch) is pressed On
REAR DEF SW Rear window defogger switch OFF
Off
Rear window defogger switch ON On
REQ SW -AS When passenger door request switch is not pressed
Off
When passenger door request switch is pressed On
REQ SW -BD/TR When back door request switch is not pressed
Off
When back door request switch is pressed On
REQ SW -DR When driver door request switch is not pressed
Off
When driver door request switch is pressed On
RKE-LOCK When LOCK button of Intelligent Key is not pressed
Off
When LOCK button of Intelligent Key is pressed On
RKE-MODE CHG When LOCK/UNLOCK button of Intelligent Key is not pressed and
held simultaneously
Off
When LOCK/UNLOCK button of Intelligent Key is pressed and held
simultaneously On
RKE OPE COUN1 Operation frequency of Intelligent Key 0-19
RKE OPE COUN2 Operation frequency of Intelligent Key 0-19
RKE-PANIC When PANIC button of Intelligent Key is not pressed
Off
When PANIC button of Intelligent Key is pressed On
RKE-UNLOCK When UNLOCK button of Intelligent Key is not pressed
Off
When UNLOCK button of Intelligent Key is pressed On
Monitor Item
Condition Value/Status
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 294 of 3641
![NISSAN NOTE 2016 Service Repair Manual BCS
BCM
BCS-33
< ECU DIAGNOSIS INFORMATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
RR WASHER SW
Rear washer switch OFF Off
Rear washer switch ON
On
RR WIPER INT Rear wiper switch NISSAN NOTE 2016 Service Repair Manual BCS
BCM
BCS-33
< ECU DIAGNOSIS INFORMATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
RR WASHER SW
Rear washer switch OFF Off
Rear washer switch ON
On
RR WIPER INT Rear wiper switch](/img/5/57363/w960_57363-293.png)
BCS
BCM
BCS-33
< ECU DIAGNOSIS INFORMATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
RR WASHER SW
Rear washer switch OFF Off
Rear washer switch ON
On
RR WIPER INT Rear wiper switch OFF
Off
Rear wiper switch INT On
RR WIPER ON Rear wiper switch OFF
Off
Rear wiper switch ON On
RR WIPER STOP Any position other than rear wiper stop position
Off
Rear wiper stop position On
SFT N-MET When selector lever is in any position other than N
Off
When selector lever is in N position On
SFT P-MET When selector lever is in any position other than P
Off
When selector lever is in P position On
SFT PN -IPDM When selector lever is in any position other than P or N
Off
When selector lever is in P or N position On
SFT PN/N SW When selector lever is in any position other than P or N
Off
When selector lever is in P or N position On
TAIL LAMP SW Other than lighting switch 1ST and 2ND
Off
Lighting switch 1ST or 2ND On
TP 4 The ID of fourth key is not registered to BCM
Yet
The ID of fourth key is registered to BCM DONE
TP 3 The ID of third key is not registered to BCM
Yet
The ID of third key is registered to BCM DONE
TP 2 The ID of second key is not registered to BCM
Yet
The ID of second key is registered to BCM DONE
TP 1 The ID of first key is not registered to BCM
Yet
The ID of first key is registered to BCM DONE
TURN SIGNAL L Turn signal switch OFF
Off
Turn signal switch LH On
TURN SIGNAL R Turn signal switch OFF
Off
Turn signal switch RH On
UNLK SEN-DR Driver door UNLOCK status
Off
Driver door LOCK status On
VEH SPEED 1 While driving, equivalent to speedometer reading mph, km/h
VEH SPEED 2 While driving, equivalent to speedometer reading mph, km/h
WARNING LAMP Low tire pressure warning lamp in combination meter OFF Off
Low tire pressure warning lamp in combination meter ON
On
Monitor Item
Condition Value/Status
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 295 of 3641
![NISSAN NOTE 2016 Service Repair Manual BCS-34
< ECU DIAGNOSIS INFORMATION >[WITH INTELLIGENT KEY SYSTEM]
BCM
TERMINAL LAYOUT
PHYSICAL VALUES
JMMIA1063ZZ
Te r m i n a l N o .
(Wire color) Description
Condition Va l u e
(Approx.)
Signal nam NISSAN NOTE 2016 Service Repair Manual BCS-34
< ECU DIAGNOSIS INFORMATION >[WITH INTELLIGENT KEY SYSTEM]
BCM
TERMINAL LAYOUT
PHYSICAL VALUES
JMMIA1063ZZ
Te r m i n a l N o .
(Wire color) Description
Condition Va l u e
(Approx.)
Signal nam](/img/5/57363/w960_57363-294.png)
BCS-34
< ECU DIAGNOSIS INFORMATION >[WITH INTELLIGENT KEY SYSTEM]
BCM
TERMINAL LAYOUT
PHYSICAL VALUES
JMMIA1063ZZ
Te r m i n a l N o .
(Wire color) Description
Condition Va l u e
(Approx.)
Signal name Input/
Output
+ −
1
(GR) Ground Rear window
defogger relay
control Input
Rear window
defogger switch OFF
Battery voltage
ON 0 – 0.5 V
2
(BR) Ground INPUT 5 signal Input
Combination
switchOFF
0 V
TURN RH
1.0 V
HEADLAMP 1
HI BEAM
TAIL LAMP
PKIB4958J
Revision: August 2015
2016 Versa Note
cardiagn.com
Page 296 of 3641
![NISSAN NOTE 2016 Service Repair Manual BCS
BCM
BCS-35
< ECU DIAGNOSIS INFORMATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N3
(Y) Ground INPUT 4 signal Input Combination
switchOFF
0 V
TURN LH
1.0 V
PASSING
HEADLAMP 2
FR NISSAN NOTE 2016 Service Repair Manual BCS
BCM
BCS-35
< ECU DIAGNOSIS INFORMATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N3
(Y) Ground INPUT 4 signal Input Combination
switchOFF
0 V
TURN LH
1.0 V
PASSING
HEADLAMP 2
FR](/img/5/57363/w960_57363-295.png)
BCS
BCM
BCS-35
< ECU DIAGNOSIS INFORMATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N3
(Y) Ground INPUT 4 signal Input Combination
switchOFF
0 V
TURN LH
1.0 V
PASSING
HEADLAMP 2
FR FOG
4
(L) Ground INPUT 3 signal Input Combination
switchOFF
0 V
FR WIPER LO
1.0 V
FR WIPER INT
(any intermittent position)
5
(G) Ground INPUT 2 signal Input Combination
switchOFF
0 V
FR WASHER
1.0 V
RR WASHER
Wiper intermittent dial 1
Wiper intermittent dial 5
Wiper intermittent dial 6
RR WIPER ON
6
(R) Ground INPUT 1 signal Input Combination
switchOFF
0 V
FR WIPER HI
1.0 V
Wiper intermittent dial 1
Wiper intermittent dial 2
Wiper intermittent dial 3
Wiper intermittent dial 6
Wiper intermittent dial 7
RR WIPER INT
7
(W) Ground
Key cylinder unlock
sw signal Input
Key cylinder
switch N position
7.0 - 8.0 V
UNLOCK position 0 V
Te r m i n a l N o .
(Wire color) Description
Condition Va l u e
(Approx.)
Signal name Input/
Output
+ −
PKIB4958J
PKIB4958J
PKIB4958J
PKIB4958J
PKIB4960J
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 297 of 3641
![NISSAN NOTE 2016 Service Repair Manual BCS-36
< ECU DIAGNOSIS INFORMATION >[WITH INTELLIGENT KEY SYSTEM]
BCM
8
(GR) Ground Key cylinder lock sw
signal
InputKey cylinder
switch N position
7.0 - 8.0 V
LOCK position 0 V
9
(LG) Ground Stop l NISSAN NOTE 2016 Service Repair Manual BCS-36
< ECU DIAGNOSIS INFORMATION >[WITH INTELLIGENT KEY SYSTEM]
BCM
8
(GR) Ground Key cylinder lock sw
signal
InputKey cylinder
switch N position
7.0 - 8.0 V
LOCK position 0 V
9
(LG) Ground Stop l](/img/5/57363/w960_57363-296.png)
BCS-36
< ECU DIAGNOSIS INFORMATION >[WITH INTELLIGENT KEY SYSTEM]
BCM
8
(GR) Ground Key cylinder lock sw
signal
InputKey cylinder
switch N position
7.0 - 8.0 V
LOCK position 0 V
9
(LG) Ground Stop lamp switch 1 Input Stop lamp
switchOFF (Brake pedal
released)
0 V
ON (Brake pedal
depressed) Battery voltage
12
(GR) Ground
Central door lock sw
signal Input
Door lock and
unlock switch NEUTRAL position
1.0 - 1.5 V
LOCK position 0 V
13
(BR) Ground
Central door unlock
sw signal Input
Door lock and
unlock switch NEUTRAL position
1.0 - 1.5 V
UNLOCK position 0 V
15
(G) Ground Rear defogger
switch signal
InputRear window
defogger switch Not pressed
1.0 - 1.5 V
Pressed 0 V
18
(V) Ground
Keyless tuner
ground Input Push-button ignition switch ON
0 V
Te r m i n a l N o .
(Wire color) Description
Condition Va l u e
(Approx.)
Signal name Input/
Output
+ −
PKIB4960J
JPMIA0012GB
JPMIA0012GB
JPMIA0012GB
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 298 of 3641
![NISSAN NOTE 2016 Service Repair Manual BCS
BCM
BCS-37
< ECU DIAGNOSIS INFORMATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N19
(LG) Ground
Keyless tuner power
supply OutputPush-button ignition switch OFF
Push-button ign NISSAN NOTE 2016 Service Repair Manual BCS
BCM
BCS-37
< ECU DIAGNOSIS INFORMATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N19
(LG) Ground
Keyless tuner power
supply OutputPush-button ignition switch OFF
Push-button ign](/img/5/57363/w960_57363-297.png)
BCS
BCM
BCS-37
< ECU DIAGNOSIS INFORMATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N19
(LG) Ground
Keyless tuner power
supply OutputPush-button ignition switch OFF
Push-button ignition switch ACC or ON
5 V
20
(G) Ground Keyless tuner signal Input Push-button ig-
nition switch
OFFWaiting
When operating either
button on Intelligent Key
21
(P) Ground Immobilizer one way
communication
(CLOCK) signal Input/
Output Intelligent Key
battery is re-
moved Brake pedal depressed
NOTE:
Waveform varies each
time when brake pedal is
depressed
Brake pedal released
Battery voltage
22
(W) Ground Keyless tuner RSSI
signal
InputPush-button ig-
nition switch
OFF Waiting
When pressing and hold-
ing either button on Intelli-
gent Key
Te r m i n a l N o .
(Wire color) Description
Condition Va l u e
(Approx.)
Signal name Input/
Output
+ −
JMKIA3838GB
JMKIA3838GB
JMKIA3841GB
JMKIA6232JP
JMKIA5952GB
JMKIA5953GB
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 299 of 3641
![NISSAN NOTE 2016 Service Repair Manual BCS-38
< ECU DIAGNOSIS INFORMATION >[WITH INTELLIGENT KEY SYSTEM]
BCM
23
(GR) Ground Security indicator
output
OutputSecurity indica-
tor lamp ON
0 – 0.5 V
Blinking (push-button igni-
tion switch O NISSAN NOTE 2016 Service Repair Manual BCS-38
< ECU DIAGNOSIS INFORMATION >[WITH INTELLIGENT KEY SYSTEM]
BCM
23
(GR) Ground Security indicator
output
OutputSecurity indica-
tor lamp ON
0 – 0.5 V
Blinking (push-button igni-
tion switch O](/img/5/57363/w960_57363-298.png)
BCS-38
< ECU DIAGNOSIS INFORMATION >[WITH INTELLIGENT KEY SYSTEM]
BCM
23
(GR) Ground Security indicator
output
OutputSecurity indica-
tor lamp ON
0 – 0.5 V
Blinking (push-button igni-
tion switch OFF) 12.0 V
OFF Battery voltage
24
(SB) Ground Audio dongle link
(SERIAL) Input/
Output Push-button ignition switch OFF
5 V
25
(LG) Ground Immobilizer two way
communication sig-
nal Input/
Output During waiting Brake pedal depressed
NOTE:
Waveform varies each
time when brake pedal is
depressed
Brake pedal released
Battery voltage
26
(O) Ground THERMO amp. sig-
nal
InputPush-button ig-
nition switch ON
and blower fan
switch ON A/C switch OFF
Battery voltage
A/C switch ON 0 V
27
(V) Ground Air con sw signal Input Push-button ig-
nition switch ON
and blower fan
switch ONA/C switch OFF
Battery voltage
A/C switch ON 0 V
28
(SB) Ground Blower fan sw signal Input Fan switch OFF
0 V
ON 7.0 - 8.0 V
29
(BG) Ground Hazard sw signal Input Hazard switch OFF
Battery voltage
ON 0 – 1.5 V
31
(Y) Ground
Driver door lock sta-
tus Input Front door LH LOCK status
11 . 8 V
UNLOCK status 0V
Te r m i n a l N o .
(Wire color) Description
Condition Va l u e
(Approx.)
Signal name Input/
Output
+ −
JPMIA0590GB
JMKIA6233JP
PKIB4960J
JPMIA0011GB
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 300 of 3641
![NISSAN NOTE 2016 Service Repair Manual BCS
BCM
BCS-39
< ECU DIAGNOSIS INFORMATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
32
(P) Ground OUTPUT 5
OutputCombination
switch OFF
7.0 - 8.0 V
FR FOG
1.0 V
RR WIPER ON
Wiper NISSAN NOTE 2016 Service Repair Manual BCS
BCM
BCS-39
< ECU DIAGNOSIS INFORMATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
32
(P) Ground OUTPUT 5
OutputCombination
switch OFF
7.0 - 8.0 V
FR FOG
1.0 V
RR WIPER ON
Wiper](/img/5/57363/w960_57363-299.png)
BCS
BCM
BCS-39
< ECU DIAGNOSIS INFORMATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
32
(P) Ground OUTPUT 5
OutputCombination
switch OFF
7.0 - 8.0 V
FR FOG
1.0 V
RR WIPER ON
Wiper intermittent dial 1
Wiper intermittent dial 2
Wiper intermittent dial 6
Wiper intermittent dial 7
33
(V) Ground OUTPUT 4
OutputCombination
switch OFF
7.0 - 8.0 V
TAIL LAMP
1.2 V
Wiper intermittent dial 1
Wiper intermittent dial 5
Wiper intermittent dial 6
RR WIPER INT
34
(W) Ground OUTPUT 3
OutputCombination
switch OFF
7.0 - 8.0 V
HI BEAM
1.2 V
HEADLAMP 2
RR WASHER
Wiper intermittent dial 1
Wiper intermittent dial 2
Wiper intermittent dial 3
Te r m i n a l N o .
(Wire color) Description
Condition Va l u e
(Approx.)
Signal name Input/
Output
+ −
PKIB4960J
PKIB4956J
PKIB4960J
PKIB4958J
PKIB4960J
PKIB4958J
Revision: August 2015 2016 Versa Note
cardiagn.com
