BCS-90
< SYSTEM DESCRIPTION >[WITHOUT INTELLIGENT KEY SYSTEM]
DIAGNOSIS SYSTEM (BCM)
DOOR LOCK
DOOR LOCK : CONSULT Func
tion (BCM - DOOR LOCK)INFOID:0000000012432371
DATA MONITOR
ACTIVE TEST
WORK SUPPORT
* : Initial setting
REAR DEFOGGER
Monitor Item [Unit] Description
IGN ON SW [On/Off] Indicates condition of ignition switch ON position.
KEY ON SW [On/Off] Indicates condition of key switch.
CDL LOCK SW [On/Off] Indicates condition of lock signal from door lock and unlock switch.
CDL UNLOCK SW [On/Off] Indicates condition of unlock signal from door lock and unlock switch.
DOOR SW-DR [On/Off] Indicates condition of front door switch LH.
DOOR SW-AS [On/Off] Indicates condition of front door switch RH.
DOOR SW-RR [On/Off] Indicates condition of rear door switch RH.
DOOR SW-RL [On/Off] Indicates condition of rear door switch LH.
DOOR SW-BK [On/Off] Indicates condition of back door switch.
ACC ON SW [On/Off] Indicates condition of ignition switch ACC position.
KEYLESS LOCK [On/Off] Indicates condition of lock signal from keyfob.
KEYLESS UNLOCK [On/Off] Indicates condition of unlock signal from keyfob.
KEY CYL LK-SW [On/Off] Indicates condition of lock signal from door key cylinder switch.
KEY CYL UN-SW [On/Off] Indicates condition of unlock signal from door key cylinder switch.
VEHICLE SPEED [km/h/mph] Indicates vehicl e speed signal received from combination meter on CAN communication line.
Test Item Description
DOOR LOCK This test is able to check door lock operation [OTR ULK/DR UNLK/ALL UNLK/ALL LCK].
Support ItemSetting Description
DOOR LOCK-UNLOCK SET ON*
Automatic door locks function ON.
OFF Automoatic door locks function OFF.
AUTOMATIC DOOR LOCK SELECT P RANGE Doors lock automatically when shifted out of Park (P).
VH SPD* Doors lock automatically when vehicle speed reaches 24 km/h (15 mph).
AUTOMATIC DOOR UNLOCK
SELECT MODE6* Drivers door unlocks automatically when key is removed.
MODE5 Drivers door unlocks automatically when shifted into Park (P).
MODE4 Drivers door unlocks automatically when ignition is switched from ON to OFF.
MODE3 Doors unlock automatically when key is removed.
MODE2 Doors unlock automatically when shifted into Park (P).
MODE1 Doors unlock automatically when ignition is switched from ON to OFF.
AUTOMATIC LOCK/UNLOCK
SELECT Lock/Unlock* Automatic door locks function operates in lock and unlock.
Lock Only Automatic door locks function operates in lock only.
Unlock Only Automatic door locks function operates in unlock only.
Off
Automatic door locks function OFF.
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 352 of 3641
![NISSAN NOTE 2016 Service Repair Manual BCS
DIAGNOSIS SYSTEM (BCM)BCS-91
< SYSTEM DESCRIPTION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
REAR DEFOGGER : CONSULT Function (BCM - REAR DEFOGGER)INFOID:0000000012432372
DAT](/img/5/57363/w960_57363-351.png "NISSAN NOTE 2016 Service Repair Manual BCS
DIAGNOSIS SYSTEM (BCM)BCS-91
< SYSTEM DESCRIPTION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
REAR DEFOGGER : CONSULT Function (BCM - REAR DEFOGGER)INFOID:0000000012432372
DAT")
BCS
DIAGNOSIS SYSTEM (BCM)BCS-91
< SYSTEM DESCRIPTION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
REAR DEFOGGER : CONSULT Function (BCM - REAR DEFOGGER)INFOID:0000000012432372
DATA MONITOR
ACTIVE TEST
BUZZER
BUZZER : CONSULT Func
tion (BCM - BUZZER)INFOID:0000000012432373
DATA MONITOR
ACTIVE TEST
INT LAMP
INT LAMP : CONSULT Func tion (BCM - INT LAMP) INFOID:0000000012432374
DATA MONITOR
Monitor Item [Unit] Description
IGN ON SW [On/Off] Indicates condition of ignition switch ON position.
ACC ON SW [On/Off] Indicates condition of ignition switch ACC position.
REAR DEF SW [On/Off] Indicates condition of rear window defogger switch.
RR DEF TIME [On/Off] Indicates condition of rear window defogger switch timer.
Test Item Description
REAR DEFOGGER This test is able to check rear window defogger operation [Off/On].
Monitor Item [Unit] Description
IGN ON SW [On/Off] Indicates condition of ignition switch ON position.
KEY ON SW [On/Off] Indicates condition of key switch.
DOOR SW-DR [On/Off] Indicates condition of front door switch LH.
REVERSE SW CAN [On/Off] Indicates reverse switch sign al received from TCM on CAN communication line.
TAIL LAMP SW [On/Off] Indicates condition of combination switch.
FR FOG SW [On/Off] Indicates condition of front fog lamp switch.
VEHICLE SPEED [km/h/mph] Indicates vehicle speed signal received from combination meter on CAN communication line.
Test Item Description
IGN KEY WARN ALM This test is able to check key warning chime operation [On/Off].
SEAT BELT WARN TEST This test is able to check seat belt warning chime operation [On/Off].
LIGHT WARN ALM This test is able to check light warning chime operation [On/Off].
Monitor Item [Unit] Description
IGN ON SW [On/Off] Indicates condition of ignition switch ON position.
KEY ON SW [On/Off] Indicates condition of key switch.
DOOR SW-DR [On/Off] Indicates condition of front door switch LH.
DOOR SW-AS [On/Off] Indicates condition of front door switch RH.
DOOR SW-RR [On/Off] Indicates condition of rear door switch RH.
DOOR SW-RL [On/Off] Indicates condition of rear door switch LH.
DOOR SW-BK [On/Off] Indicates condition of back door switch.
CDL LOCK SW [On/Off] Indicates condition of lock signal from door lock and unlock switch.
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 353 of 3641
![NISSAN NOTE 2016 Service Repair Manual BCS-92
< SYSTEM DESCRIPTION >[WITHOUT INTELLIGENT KEY SYSTEM]
DIAGNOSIS SYSTEM (BCM)
ACTIVE TEST
WORK SUPPORT
* : Initial setting
MULTI REMOTE ENT
MULTI REMOTE ENT : CONSULT Func
tion (BCM - MULTI REM](/img/5/57363/w960_57363-352.png "NISSAN NOTE 2016 Service Repair Manual BCS-92
< SYSTEM DESCRIPTION >[WITHOUT INTELLIGENT KEY SYSTEM]
DIAGNOSIS SYSTEM (BCM)
ACTIVE TEST
WORK SUPPORT
* : Initial setting
MULTI REMOTE ENT
MULTI REMOTE ENT : CONSULT Func
tion (BCM - MULTI REM")
BCS-92
< SYSTEM DESCRIPTION >[WITHOUT INTELLIGENT KEY SYSTEM]
DIAGNOSIS SYSTEM (BCM)
ACTIVE TEST
WORK SUPPORT
* : Initial setting
MULTI REMOTE ENT
MULTI REMOTE ENT : CONSULT Func
tion (BCM - MULTI REMOTE ENT)
INFOID:0000000012432375
DATA MONITOR
CDL UNLOCK SW [On/Off] Indicates condition of unlock signal from door lock and unlock switch.
KEYLESS LOCK [On/Off] Indicates condition of lock signal from keyfob.
KEYLESS UNLOCK [On/Off] Indicates condition of unlock signal from keyfob.
KEY CYL LK-SW [On/Off] Indicates condition of lock signal from door key cylinder switch.
KEY CYL UN-SW [On/Off] Indicates condition of unlock signal from door key cylinder switch.
ACC SW [On/Off] Indicates condition of ignition switch ACC position.
Monitor Item [Unit]
Description
Te s t I t e mD e s c r i p t i o n
INT LAMP This test is able to check interior room lamp operation [On/Off].
Support ItemSetting Description
SET I/L D-UNLCK INTCON On*
Interior room lamp timer function ON.
Off Interior room lamp timer function OFF.
ROOM LAMP TIMER SET MODE 4 30 sec.
Sets the interior room lamp ON time. (Timer operating time).
MODE 3* 15 sec.
MODE 2 7.5 sec.
MODE 1 OFF
ROOM LAMP ON TIME SET MODE7 0 sec.
Sets the interior room lamp gradual brightening time.
MODE6 5 sec.
MODE5 4 sec.
MODE4 3 sec.
MODE3 2 sec.
MODE2* 1 sec.
MODE1 0.5 sec.
ROOM LAMP OFF TIME SET MODE7 0 sec.
Sets the interior room lamp gradual dimming time.
MODE6 5 sec.
MODE5 4 sec.
MODE4 3 sec.
MODE3 2 sec.
MODE2* 1 sec.
MODE1 0.5 sec.
R LAMP TIMER LOGIC SET MODE 2
Interior room lamp timer activates with all doors.
MODE 1* Interior room lamp timer activates with the driver door only.
Monitor Item [Unit] Description
IGN ON SW [On/Off] Indicates condition of ignition switch ON position.
KEY ON SW [On/Off] Indicates condition of key switch.
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 354 of 3641
![NISSAN NOTE 2016 Service Repair Manual BCS
DIAGNOSIS SYSTEM (BCM)BCS-93
< SYSTEM DESCRIPTION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
ACTIVE TEST
WORK SUPPORT
*: Initial setting
HEADLAMP
HEADLAMP : CONSULT Function](/img/5/57363/w960_57363-353.png "NISSAN NOTE 2016 Service Repair Manual BCS
DIAGNOSIS SYSTEM (BCM)BCS-93
< SYSTEM DESCRIPTION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
ACTIVE TEST
WORK SUPPORT
*: Initial setting
HEADLAMP
HEADLAMP : CONSULT Function")
BCS
DIAGNOSIS SYSTEM (BCM)BCS-93
< SYSTEM DESCRIPTION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
ACTIVE TEST
WORK SUPPORT
*: Initial setting
HEADLAMP
HEADLAMP : CONSULT Function (BCM - HEAD LAMP)INFOID:0000000012432376
DATA MONITOR
ACC ON SW [On/Off]
Indicates condition of ignition switch ACC position.
KEYLESS LOCK [On/Off] Indicates condition of lock signal from keyfob.
KEYLESS UNLOCK [On/Off] Indicates condition of unlock signal from keyfob.
DOOR SW-DR [On/Off] Indicates condition of front door switch LH.
DOOR SW-AS [On/Off] Indicates condition of front door switch RH.
DOOR SW-RR [On/Off] Indicates condition of rear door switch RH.
DOOR SW-RL [On/Off] Indicates condition of rear door switch LH.
DOOR SW-BK [On/Off] Indicates condition of back door switch.
CDL LOCK SW [On/Off] Indicates condition of lock signal from door lock and unlock switch.
CDL UNLOCK SW [On/Off] Indicates condition of unlock signal from door lock and unlock switch.
KEYLESS PANIC [On/Off] Indicates condition of panic signal from keyfob.
Monitor Item [Unit]
Description
Test ItemDescription
HORN This test is able to check the door lock tone.
INT LAMP This test is able to check interior room lamp operation [On/Off].
FLASHER This test is able to check hazard reminder operation [Off/LH/RH].
Support ItemSetting Description
REMO CONT ID REGIST —Keyfob ID code can be registered.
REMO CONT ID ERASUR —Keyfob ID code can be erased.
REMO CONT ID CONFIR —Keyfob ID code registration is displayed.
HORN CHIRP SET Off
Horn chirp function can be changed in this mode.
On*
HAZARD LAMP SET MODE4* Lock and Unlock
Hazard warning lamp function can be changed in this mode.
MODE3 Lock Only
MODE2 Unlock Only
MODE1 OFF
PANIC ALRM SET MODE3 1.5 sec
Panic alarm operation can be changed in this mode.
MODE2 OFF
MODE1* 0.5 sec
AUTO LOCK SET MODE7 5 min
Auto locking function can be changed in this mode.
MODE6 4 min
MODE5 3 min
MODE4 2 min
MODE3* 1 min
MODE2 30 sec
MODE1 OFF
Revision: August 2015
2016 Versa Note
cardiagn.com
Page 355 of 3641
![NISSAN NOTE 2016 Service Repair Manual BCS-94
< SYSTEM DESCRIPTION >[WITHOUT INTELLIGENT KEY SYSTEM]
DIAGNOSIS SYSTEM (BCM)
ACTIVE TEST
WORK SUPPORT
* : Initial setting
WIPER
WIPER : CONSULT Function (BCM - WIPER)INFOID:0000000012432377
DA](/img/5/57363/w960_57363-354.png "NISSAN NOTE 2016 Service Repair Manual BCS-94
< SYSTEM DESCRIPTION >[WITHOUT INTELLIGENT KEY SYSTEM]
DIAGNOSIS SYSTEM (BCM)
ACTIVE TEST
WORK SUPPORT
* : Initial setting
WIPER
WIPER : CONSULT Function (BCM - WIPER)INFOID:0000000012432377
DA")
BCS-94
< SYSTEM DESCRIPTION >[WITHOUT INTELLIGENT KEY SYSTEM]
DIAGNOSIS SYSTEM (BCM)
ACTIVE TEST
WORK SUPPORT
* : Initial setting
WIPER
WIPER : CONSULT Function (BCM - WIPER)INFOID:0000000012432377
DATA MONITOR
Monitor Item [Unit]
Description
IGN ON SW [On/Off] Indicates condition of ignition switch ON position.
ACC ON SW [On/Off] Indicates condition of ignition switch ACC position.
HI BEAM SW [On/Off]
Indicates condition of combination switch.
HEAD LAMP SW 1 [On/Off]
HEAD LAMP SW 2 [On/Off]
TAIL LAMP SW [On/Off]
PASSING SW [On/Off]
FR FOG SW [On/Off]
DOOR SW-DR [On/Off]
Indicates condition of front door switch LH.
DOOR SW-AS [On/Off] Indicates condition of front door switch RH.
DOOR SW-RR [On/Off] Indicates condition of rear door switch RH.
DOOR SW-RL [On/Off] Indicates condition of rear door switch LH.
DOOR SW-BK [On/Off] Indicates condition of back door switch.
TURN SIGNAL R [On/Off] Indicates condition of combination switch.
TURN SIGNAL L [On/Off]
KEY ON SW [On/Off] Indicates condition of key switch.
KEYLESS LOCK [On/Off] Indicates condition of lock signal from keyfob.
PKB SW [On/Off] Indicates park brake switch signal received from combination meter on CAN communica-
tion line.
ENGINE RUN [On/Off] Indicates engine run signal received from ECM on CAN communication line.
VEHICLE SPEED [km/h/mph] Indicates vehicle speed signal received from combination meter on CAN communication
line.
Test Item
Description
TAIL LAMP This test is able to check tail lamp operation [On/Off].
HEAD LAMP This test is able to check head lamp operation [Hi/Low/Off].
FR FOG LAMP This test is able to check front fog lamp operation [On/Off].
ILL DIM SIGNAL This test is able to check head lamp illumination dimming operation [On/Off].
Support ItemSetting Description
BATTERY SAVER SET On*
Exterior lamp battery saver function ON.
Off Exterior lamp battery saver function OFF.
Monitor Item [Unit] Description
IGN ON SW [On/Off] Indicates condition of ignition switch ON position.
IGN SW CAN [On/Off] Indicates ignition switch ON signal received from IPDM E/R on CAN communication line.
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 356 of 3641
![NISSAN NOTE 2016 Service Repair Manual BCS
DIAGNOSIS SYSTEM (BCM)BCS-95
< SYSTEM DESCRIPTION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
ACTIVE TEST
WORK SUPPORT
* : Initial setting
FLASHER
FLASHER : CONSULT Func
tion](/img/5/57363/w960_57363-355.png "NISSAN NOTE 2016 Service Repair Manual BCS
DIAGNOSIS SYSTEM (BCM)BCS-95
< SYSTEM DESCRIPTION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
ACTIVE TEST
WORK SUPPORT
* : Initial setting
FLASHER
FLASHER : CONSULT Func
tion")
BCS
DIAGNOSIS SYSTEM (BCM)BCS-95
< SYSTEM DESCRIPTION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
ACTIVE TEST
WORK SUPPORT
* : Initial setting
FLASHER
FLASHER : CONSULT Func
tion (BCM - FLASHER)INFOID:0000000012432378
DATA MONITOR
ACTIVE TEST
AIR CONDITIONER
AIR CONDITIONER : CONSULT Func tion (BCM - AIR CONDITIONER)INFOID:0000000012432379
DATA MONITOR
FR WIPER HI [On/Off]
Indicates condition of wiper operation of combination switch.
FR WIPER LOW [On/Off]
FR WIPER INT [On/Off]
FR WASHER SW [On/Off]
FR WIPER STOP [On/Off]
Indicates front wiper auto stop signal received from IPDM E/R on CAN communication
line.
INT VOLUME [1 − 7] Indicates condition of intermittent wiper operation of combination switch.
RR WIPER ON [On/Off] Indicates condition of rear wiper operation of combination switch.
RR WIPER INT [On/Off]
RR WASHER SW [On/Off]
RR WIPER STOP [On/Off] Indicates rear wiper motor auto stop input from rear wiper motor.
REVERSE SW CAN [On/Off] Indicates reverse switch sign al received from TCM on CAN communication line.
VEHICLE SPEED [km/h/mph] Indicates vehicle speed signal received from combination meter on CAN communication
line.
Monitor Item [Unit]
Description
Test ItemDescription
FR WIPER This test is able to check front wiper operation [INT/Lo/Hi/Off].
RR WIPER This test is able to check rear wiper operation [On/Off].
Support ItemSetting Description
WIPER SPEED SETTING On Front wiper intermittent time linked with vehicle speed and wiper dial position.
Off* Front wiper intermittent time linked with wiper dial position.
Monitor Item [Unit]
Description
HAZARD SW [On/Off] Indicates condition of hazard switch.
TURN SIGNAL R [On/Off] Indicates condition of turn signal function of combination switch.
TURN SIGNAL L [On/Off]
Test Item Description
FLASHER This test is able to check turn signal lamp operation [Off/LH/RH].
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 357 of 3641
![NISSAN NOTE 2016 Service Repair Manual BCS-96
< SYSTEM DESCRIPTION >[WITHOUT INTELLIGENT KEY SYSTEM]
DIAGNOSIS SYSTEM (BCM)
COMB SW
COMB SW : CONSULT Function (BCM - COMB SW)INFOID:0000000012432380
DATA MONITOR
BCM
BCM : CONSULT Function (](/img/5/57363/w960_57363-356.png "NISSAN NOTE 2016 Service Repair Manual BCS-96
< SYSTEM DESCRIPTION >[WITHOUT INTELLIGENT KEY SYSTEM]
DIAGNOSIS SYSTEM (BCM)
COMB SW
COMB SW : CONSULT Function (BCM - COMB SW)INFOID:0000000012432380
DATA MONITOR
BCM
BCM : CONSULT Function (")
BCS-96
< SYSTEM DESCRIPTION >[WITHOUT INTELLIGENT KEY SYSTEM]
DIAGNOSIS SYSTEM (BCM)
COMB SW
COMB SW : CONSULT Function (BCM - COMB SW)INFOID:0000000012432380
DATA MONITOR
BCM
BCM : CONSULT Function (BCM - BCM)INFOID:0000000012432381
ECU IDENTIFICATION
The BCM part number is displayed.
SELF DIAGNOSTIC RESULT
Refer to
BCS-115, "DTCIndex".
WORK SUPPORT
CONFIGURATION
Refer to BCS-123, "Description".
CAN DIAG SUPPORT MNTR
Refer to LAN-13, "CAN Diagnostic Support Monitor".
IMMU
Monitor Item [Unit] Description
IGN ON SW [On/Off] Indicates condition of ignition switch ON position.
FAN ON SIG [On/Off] Indicates condition of fan switch.
AIR COND SW [On/Off] Indicates condition of A/C switch.
THERMO AMP [On/Off] Indicates condition of thermo amp.
FR DEF SW [On/Off] Indicates condition of front defrost switch.
Monitor Item [Unit] Description
TURN SIGNAL R [On/Off] Indicates condition of right turn signal operation of combination switch.
TURN SIGNAL L [On/Off] Indicates condition of left turn signal operation of combination switch.
HI BEAM SW [On/Off] Indicates condition of Hi beam switch operation of combination switch.
HEAD LAMP SW 1 [On/Off] Indicates condition of head lamp switch 1 operation of combination switch.
HEAD LAMP SW 2 [On/Off] Indicates condition of head lamp switch 2 operation of combination switch.
TAIL LAMP SW [On/Off] Indicates condition of tail lamp switch operation of combination switch.
PASSING SW [On/Off] Indicates condition of passing switch operation of combination switch.
FR FOG SW [On/Off] Indicates condition of front fog lamp switch operation of combination switch.
FR WIPER HI [On/Off]
Indicates condition of front wiper operation of combination switch.
FR WIPER LOW [On/Off]
FR WIPER INT [On/Off]
FR WASHER SW [On/Off]
INT VOLUME [1 - 7]
Indicates condition of intermittent front wiper operation of combination switch.
RR WIPER ON [On/Off] Indicates condition of rear wiper operation of combination switch.
RR WIPER INT [On/Off]
RR WASHER SW [On/Off]
Support Item Setting Description
RESET SETTING VALUE Reset Returns BCM to initial value in factory shipment.
Cancel Cancels the reset function.
Revision: August 2015
2016 Versa Note
cardiagn.com
Page 358 of 3641
![NISSAN NOTE 2016 Service Repair Manual BCS
DIAGNOSIS SYSTEM (BCM)BCS-97
< SYSTEM DESCRIPTION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
IMMU : CONSULT Function (BCM - IMMU)INFOID:0000000012432382
SELF DIAGNOSTIC RESUL](/img/5/57363/w960_57363-357.png "NISSAN NOTE 2016 Service Repair Manual BCS
DIAGNOSIS SYSTEM (BCM)BCS-97
< SYSTEM DESCRIPTION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
IMMU : CONSULT Function (BCM - IMMU)INFOID:0000000012432382
SELF DIAGNOSTIC RESUL")
BCS
DIAGNOSIS SYSTEM (BCM)BCS-97
< SYSTEM DESCRIPTION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
IMMU : CONSULT Function (BCM - IMMU)INFOID:0000000012432382
SELF DIAGNOSTIC RESULT
Refer to
BCS-115, "DTCIndex".
ACTIVE TEST
WORK SUPPORT
BATTERY SAVER
BATTERY SAVER : CONSULT Function (BCM - BATTERY SAVER)INFOID:0000000012432383
DATA MONITOR
ACTIVE TEST
WORK SUPPORT
* : Initial setting
THEFT ALM
Test Item Description
THEFT IND This test is able to check security indicator operation [On/Off].
Support ItemSetting Description
CONFIRM DONGLE ID —Dongle ID code can be read.
Monitor Item [Unit] Description
IGN ON SW [On/Off] Indicates condition of ignition switch ON position.
KEY ON SW [On/Off] Indicates condition of key switch.
DOOR SW-DR [On/Off] Indicates condition of front door switch LH.
DOOR SW-AS [On/Off] Indicates condition of front door switch RH.
DOOR SW-RR [On/Off] Indicates condition of rear door switch RH.
DOOR SW-RL [On/Off] Indicates condition of rear door switch LH.
DOOR SW-BK [On/Off] Indicates condition of back door switch.
CDL LOCK SW [On/Off] Indicates condition of lock signal from door lock and unlock switch.
CDL UNLOCK SW [On/Off] Indicates condition of unlock signal from door lock and unlock switch.
KEYLESS LOCK [On/Off] Indicates condition of lock signal from keyfob.
KEYLESS UNLOCK [On/Off] Indicates condition of unlock signal from keyfob.
KEY CYL LK-SW [On/Off] Indicates condition of lock signal from door key cylinder switch.
KEY CYL UN-SW [On/Off] Indicates condition of unlock signal from door key cylinder switch.
ACC SW [On/Off] Indicates condition of ignition switch ACC position.
Test item Description
BATTERY SAVER This test is able to check battery saver operation [On/Off].
Support ItemSetting Description
ROOM LAMP TIMER SET MODE 3* 10 min.
Sets interior room lamp battery saver timer operating time.
MODE 2 60 min.
MODE 1 15 min.
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 359 of 3641
![NISSAN NOTE 2016 Service Repair Manual BCS-98
< SYSTEM DESCRIPTION >[WITHOUT INTELLIGENT KEY SYSTEM]
DIAGNOSIS SYSTEM (BCM)
THEFT ALM : CONSULT Fu nction (BCM - THEFT)
INFOID:0000000012432384
DATA MONITOR
WORK SUPPORT
*: Initial setting
RE](/img/5/57363/w960_57363-358.png "NISSAN NOTE 2016 Service Repair Manual BCS-98
< SYSTEM DESCRIPTION >[WITHOUT INTELLIGENT KEY SYSTEM]
DIAGNOSIS SYSTEM (BCM)
THEFT ALM : CONSULT Fu nction (BCM - THEFT)
INFOID:0000000012432384
DATA MONITOR
WORK SUPPORT
*: Initial setting
RE")
BCS-98
< SYSTEM DESCRIPTION >[WITHOUT INTELLIGENT KEY SYSTEM]
DIAGNOSIS SYSTEM (BCM)
THEFT ALM : CONSULT Fu nction (BCM - THEFT)
INFOID:0000000012432384
DATA MONITOR
WORK SUPPORT
*: Initial setting
RETAINED PWR
RETAINED PWR : CONSULT Function (BCM - RETAINED PWR)INFOID:0000000012432385
DATA MONITOR
WORK SUPPORT
SIGNAL BUFFER
SIGNAL BUFFER : CONSULT Func tion (BCM - SIGNAL BUFFER)INFOID:0000000012432386
DATA MONITOR
Monitor Item [Unit] Description
IGN ON SW [On/Off] Indicates condition of ignition switch ON position.
ACC ON SW [On/Off] Indicates condition of ignition switch ACC position.
KEY ON SW [On/Off] Indicates condition of key switch.
KEYLESS LOCK [On/Off] Indicates condition of lock signal from keyfob.
KEYLESS UNLOCK [On/Off] Indicates condition of unlock signal from keyfob.
DOOR SW-DR [On/Off] Indicates condition of front door switch LH.
DOOR SW-AS [On/Off] Indicates condition of front door switch RH.
DOOR SW-RR [On/Off] Indicates condition of rear door switch RH.
DOOR SW-RL [On/Off] Indicates condition of rear door switch LH.
DOOR SW-BK [On/Off] Indicates condition of back door switch.
CDL LOCK SW [On/Off] Indicates condition of lock signal from door lock and unlock switch.
CDL UNLOCK SW [On/Off] Indicates condition of unlock signal from door lock and unlock switch.
TRANSPONDER [On/Off] Indicates condition of transponder.
AUTO RELOCK [On/Off] Indicates condition of auto relock function.
Support ItemSetting Description
SECURITY ALARM SET (Siren) Off Security alarm OFF.
On* Security alarm ON.
Monitor Item [Unit]
Description
IGN ON SW [On/Off] Indicates condition of ignition ON switch.
DOOR SW-DR [On/Off] Indicates condition of front door switch LH.
DOOR SW-AS [On/Off] Indicates condition of front door switch RH.
Monitor Item [Unit] Setting Description
RETAINED PWR SET MODE 3 2 Min.
Sets the retained accessory power operating time.
MODE 2 OFF
MODE 1* 45 Sec.
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 360 of 3641
![NISSAN NOTE 2016 Service Repair Manual BCS
DIAGNOSIS SYSTEM (BCM)BCS-99
< SYSTEM DESCRIPTION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
AIR PRESSURE MONITOR
AIR PRESSURE MONITOR : CONSULT Function (BCM - AIR PRESSURE](/img/5/57363/w960_57363-359.png "NISSAN NOTE 2016 Service Repair Manual BCS
DIAGNOSIS SYSTEM (BCM)BCS-99
< SYSTEM DESCRIPTION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
AIR PRESSURE MONITOR
AIR PRESSURE MONITOR : CONSULT Function (BCM - AIR PRESSURE")
BCS
DIAGNOSIS SYSTEM (BCM)BCS-99
< SYSTEM DESCRIPTION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
AIR PRESSURE MONITOR
AIR PRESSURE MONITOR : CONSULT Function (BCM - AIR PRESSURE MONI-
TOR)
INFOID:0000000012432387
NOTE:
The Signal Tech II Tool [– (J-50190)] can be used to perform the following functions. Refer to the Signal Tech
II User Guide for additional information.
• Activate and display TPMS transmitter IDs
• Display tire pressure repor
ted by the TPMS transmitter
• Read TPMS DTCs
• Register TPMS transmitter IDs
• Test remote keyless entry keyfob relative signal strength
SELF DIAGNOSTIC RESULT
NOTE:
Before performing self diagnostic result, be sure to register the ID, or else the actual malfunction may be differ-
ent from that displayed on CONSULT.
Refer to BCS-115, "
DTCIndex".
DATA MONITOR
ACTIVE TEST
WORK SUPPORT
PANIC ALARM
Monitor Item [Unit] Description
BRAKE SW [On/Off] Indicates condition of stop lamp
switch signal received from ABS actuator and electric unit
(control unit) on CAN communication line.
Monitor Item [Unit] Description
AIR PRESS FL [kPa, kg/cm
2 or Psi] Indicates air pressure of front LH tire.
AIR PRESS FR [kPa, kg/cm
2 or Psi] Indicates air pressure of front RH tire.
AIR PRESS RR [kPa, kg/cm
2 or Psi] Indicates air pressure of rear RH tire.
AIR PRESS RL [kPa, kg/cm
2 or Psi] Indicates air pressure of rear LH tire.
ID REGST FL1 [Done/Yet] Indicates ID registration status of front LH transmitter.
ID REGST FR1 [Done/Yet] Indicates ID registration status of front RH transmitter.
ID REGST RR1 [Done/Yet] Indicates ID registration status of rear RH transmitter.
ID REGST RL1 [Done/Yet] Indicates ID registration status of rear LH transmitter.
WARNING LAMP [Off/On] Indicates condition of low tire pressure warning lamp in combination meter.
BUZZER [Off/On] Indicates condition of buzzer in combination meter.
Test Item Description
HORN This test is able to check horn operation [On].
WARNING LAMP This test is able to check tire pressure warning lamp operation [On/Off].
ID REGIST WARNING This test is able to check ID registration warning chime operation [On/Off].
FLASHER This test is able to check turn signal lamp operation [Off/LH/RH].
Support Item Description
ID READ The registered ID number is displayed.
ID REGIST Refer to WT-22, "
Description".
Revision: August 2015 2016 Versa Note
cardiagn.com
