BCS-40
< ECU DIAGNOSIS INFORMATION >[WITH INTELLIGENT KEY SYSTEM]
BCM
35
(GR) Ground OUTPUT 2
OutputCombination
switch OFF
7.0 - 8.0 V
HEADLAMP 1
1.2 V
PASSING
FR WIPER HI
FR WIPER INT
(any intermittent position)
36
(LG) Ground OUTPUT 1
OutputCombination
switch OFF
7.0 - 8.0 V
TURN RH
1.2 V
TURN LH
FR WIPER LO
FR WASHER
37
1
(R) Ground
Park position switch
signal Input Selector lever P (Park) position
0 – 1.5 V
Any position other than P
(PARK) Battery voltage
38
(G) Ground
Keyless intelligent
tuner signal Input
Push-button ig-
nition switch OFF or ACC
0 – 0.5 V
ON Battery voltage
39
(L) Ground CAN-high Input/
Output ——
40
(P) Ground CAN-low
Input/
Output ——
43
(P) Ground
Door switch (Back)
signal Input
Back door
switch OFF (back door closed)
7.0 - 8.0 V
ON (back door open) 0 V
Te r m i n a l N o .
(Wire color) Description
Condition Va l u e
(Approx.)
Signal name Input/
Output
+ −
PKIB4960J
PKIB4958J
PKIB4960J
PKIB4958J
PKIB4960J
Revision: August 2015 2016 Versa Note

cardiagn.com

BCS
BCM
BCS-41
< ECU DIAGNOSIS INFORMATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
44
(LG) Ground Rear wiper autostop
switch
InputPush-button ig-
nition switch ON Rear wiper stop position
Battery voltage
Any position other than
rear wiper stop position 0V
45
(BG) Ground
Door switch (AS)
signal Input
Front door
switch RH OFF (front RH door
closed)
7.0 - 8.0 V
ON (front RH door open) 0 V
46
(BR) Ground Door switch (RR)
signal
InputRear door
switch RH OFF (rear RH door
closed)
7.0 - 8.0 V
ON (rear RH door open) 0 V
47
(SB) Ground Door switch (DR)
signal
InputFront door
switch LH OFF (front LH door
closed)
7.0 - 8.0 V
ON (front LH door open) 0 V
48
(W) Ground Door switch (RL)
signal InputRear door
switch LH OFF (rear LH door closed)
7.0 - 8.0 V
ON (rear LH door open) 0 V
49
(L) Ground Cargo lamp control Output Back door is closed (cargo lamp turns OFF)
Battery voltage
Back door is opened (cargo lamp turns ON) 0 – 1 V
50
(G) Ground Door unlock output
(back)
Output Back door UNLOCK (Actuator is acti-
vated)
0 V
Actuator is not activated Battery voltage
51
(W) Ground
Request sw (back
door) signal Input
Back door re-
quest switch ON (Pressed)
0 – 1.5 V
OFF (Not pressed) Battery voltage
54
(R) Ground Rear wiper output Output Rear wiper OFF (stopped)
0V
ON (activated) Battery voltage
Te r m i n a l N o .
(Wire color) Description
Condition Va l u e
(Approx.)
Signal name Input/
Output
+ −
PKIB4960J
PKIB4960J
PKIB4960J
PKIB4960J
Revision: August 2015 2016 Versa Note

cardiagn.com

BCS-42
< ECU DIAGNOSIS INFORMATION >[WITH INTELLIGENT KEY SYSTEM]
BCM
55
(G) Ground Door unlock output
(RR, RL)
Output Rear doors UNLOCK (Actuator is acti-
vated)
Battery voltage
Actuator is not activated 0 V
56
(W) Ground Battery saver output Output Interior room lamp battery saver timed out
0 V
Except when interior room lamp battery sav-
er timed out Battery voltage
57
(Y) Ground Battery power sup-
ply Input Push-button ignition switch OFF
Battery voltage
59
(G) Ground Door unlock output
(AS)
Output Front RH door UNLOCK (Actuator is acti-
vated)
Battery voltage
Actuator is not activated 0 V
60
(V) Ground Flasher output
(LEFT)
OutputPush-button ig-
nition switch ON Turn signal switch OFF
0 V
Turn signal switch LH 6.5 V
61
(W) Ground Flasher output
(RIGHT)
OutputPush-button ig-
nition switch ON Turn signal switch OFF
0 V
Turn signal switch RH 6.5 V
63
(R) Ground Room lamp control Output
Interior room
lampOFF
Battery voltage
ON 0 – 1.0 V
65
(SB) Ground Door lock output Output All doors LOCK (Actuator is activat-
ed)
Battery voltage
Actuator is not activated 0 V
66
(G) Ground
Door unlock output
(DR) Output Front LH door UNLOCK (Actuator is acti-
vated)
Battery voltage
Actuator is not activated 0 V
67
(B) Ground Ground
Output Push-button ignition switch ON 0 V
68
(L) Ground Power window pow-
er supply (RAP)
Output Push-button ignition switch ON
Battery voltage
70
(G) Ground
Battery power sup-
ply Input Push-button ignition switch OFF
Battery voltage
72
(L) Ground A/C indicator
Input— —
75
(GR) Ground
Request sw (DR)
signal In
put Drive
r
door re-
quest switch ON (Pressed)
0 – 1.5 V
OFF (Not pressed) Battery voltage
Te r m i n a l N o .
(Wire color) Description
Condition Va l u e
(Approx.)
Signal name Input/
Output
+ −
PKIC6370E
PKIC6370E
Revision: August 2015 2016 Versa Note

cardiagn.com

BCS
BCM
BCS-43
< ECU DIAGNOSIS INFORMATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
76
(L) Ground Engine start sw Input
Push-button ig-
nition switchSTART pressed
0 – 1.5 V
Not pressed Battery voltage
78
(P) Ground Door antenna (DR) + Output Push-button ig-
nition switch ON
Driver door re-
quest switch
pressedIntelligent Key not in an-
tenna detection area
(Approx. 2 m)
Intelligent Key in antenna
detection area
(80 cm or less)
79
(V) Ground Door antenna (DR) - Output Push-button ig-
nition switch ON
Driver door re-
quest switch
pressedIntelligent Key not in an-
tenna detection area
(Approx. 2 m)
Intelligent Key in antenna
detection area
(80 cm or less)
80
(LG) Ground Door antenna (AS) + Output Push-button ig-
nition switch ON
Passenger door
request switch
pressedIntelligent Key not in an-
tenna detection area
(Approx. 2 m)
Intelligent Key in antenna
detection area
(80 cm or less)
Te r m i n a l N o .
(Wire color) Description
Condition Va l u e
(Approx.)
Signal name Input/
Output
+ −
JMKIA5954GB
JMKIA5955GB
JMKIA5954GB
JMKIA5955GB
JMKIA5954GB
JMKIA5955GB
Revision: August 2015 2016 Versa Note

cardiagn.com

BCS-44
< ECU DIAGNOSIS INFORMATION >[WITH INTELLIGENT KEY SYSTEM]
BCM
81
(Y) Ground Door antenna (AS) - Output Push-button ig-
nition switch ON
Passenger door
request switch
pressedIntelligent Key not in an-
tenna detection area
(Approx. 2 m)
Intelligent Key in antenna
detection area
(80 cm or less)
82
(W) Ground Outside key antenna
(rear bumper) +
OutputPush-button ig-
nition switch ON
Back door re-
quest switch
pressed Intelligent Key not in an-
tenna detection area
(Approx. 2 m)
Intelligent Key in antenna
detection area
(80 cm or less)
83
(B) Ground Outside key antenna
(rear bumper) - OutputPush-button ig-
nition switch ON
Back door re-
quest switch
pressed Intelligent Key not in an-
tenna detection area
(Approx. 2 m)
Intelligent Key in antenna
detection area
(80 cm or less)
Te r m i n a l N o .
(Wire color) Description
Condition Va l u e
(Approx.)
Signal name Input/
Output
+ −
JMKIA5954GB
JMKIA5955GB
JMKIA5954GB
JMKIA5955GB
JMKIA5954GB
JMKIA5955GB
Revision: August 2015 2016 Versa Note

cardiagn.com

BCS
BCM
BCS-45
< ECU DIAGNOSIS INFORMATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
84
(P) Ground
Inside key antenna
(instrument center) + Output
Push-button ig-
nition switch ON Intelligent Key not in an-
tenna detection area
(Approx. 2 m)
Intelligent Key in antenna
detection area
(80 cm or less)
85
(L) Ground Inside key antenna
(instrument center) -
OutputPush-button ig-
nition switch ON Intelligent Key not in an-
tenna detection area
(Approx. 2 m)
Intelligent Key in antenna
detection area
(80 cm or less)
86
(G) Ground Inside key antenna
(console) + OutputPush-button ig-
nition switch ON Intelligent Key not in an-
tenna detection area
(Approx. 2 m)
Intelligent Key in antenna
detection area
(80 cm or less)
Te r m i n a l N o .
(Wire color) Description
Condition Va l u e
(Approx.)
Signal name Input/
Output
+ −
JMKIA5951GB
JMKIA3839GB
JMKIA5951GB
JMKIA3839GB
JMKIA5951GB
JMKIA3839GB
Revision: August 2015 2016 Versa Note

cardiagn.com

BCS-46
< ECU DIAGNOSIS INFORMATION >[WITH INTELLIGENT KEY SYSTEM]
BCM
87
(R) Ground
Inside key antenna
(console) - Output
Push-button ig-
nition switch ON Intelligent Key not in an-
tenna detection area
(Approx. 2 m)
Intelligent Key in antenna
detection area
(80 cm or less)
88
(V) Ground Inside key antenna
(trunk room) +
OutputPush-button ig-
nition switch ON Intelligent Key not in an-
tenna detection area
(Approx. 2 m)
Intelligent Key in antenna
detection area
(80 cm or less)
89
(LG) Ground Inside key antenna
(trunk room) - OutputPush-button ig-
nition switch ON Intelligent Key not in an-
tenna detection area
(Approx. 2 m)
Intelligent Key in antenna
detection area
(80 cm or less)
Te r m i n a l N o .
(Wire color) Description
Condition Va l u e
(Approx.)
Signal name Input/
Output
+ −
JMKIA5951GB
JMKIA3839GB
JMKIA5951GB
JMKIA3839GB
JMKIA5951GB
JMKIA3839GB
Revision: August 2015 2016 Versa Note

cardiagn.com

BCS
BCM
BCS-47
< ECU DIAGNOSIS INFORMATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
1: With CVT
2: With M/T 90
(W) Ground Push-button ignition
switch illumination
power supply OutputPush-button ig-
nition switch il-
lumination ON
Battery voltage
OFF 0 – 1.5 V
91
(V) Ground ACC/ON indicator
lamp
OutputPush-button ig-
nition switch OFF
Battery voltage
ACC or ON 0 – 1.5 V
92
(B) Ground Push-button ignition
switch illumination
lamp Output
Push-button ig-
nition switch il-
lumination ON
5.5 V
OFF 0 – 1.5 V
93
(R) Ground Intelligent Key warn-
ing buzzer OutputIntelligent Key
warning buzzer Sounding
0 – 1.5 V
Not sounding Battery voltage
96
(SB) Ground Accessory relay
control OutputIgnition Push-
button switch OFF
0 – 0.5 V
ACC or ON Battery voltage
97
(R) Ground Starter relay control Output Push-button ig-
nition switch ONSelector lever in P (Park)
or N (Neutral) position
Battery voltage
Selector lever not in P
(Park) or N (Neutral) posi-
tion 0 – 0.5 V
98
(BG) Ground Ignition relay (IPDM
E/R) control OutputPush-button ig-
nition switch OFF or ACC
Battery voltage
ON 0 – 0.5 V
99
(GR) Ground Ignition relay (F/B)
control OutputPush-button ig-
nition switch OFF or ACC
0 – 0.5 V
ON Battery voltage
100 (L) Ground Request sw (AS)
signal InputPassenger door
request switch ON (Pressed)
0 – 1.5 V
OFF (Not pressed) Battery voltage
101 (V) Ground Clutch interlock
switch
InputClutch interlock
sw
itch OFF (c
l
utch pedal is not
depressed) 0V
ON (clutch pedal is de-
pressed) Battery voltage
102
1
(BR) Ground P/N position
Input Selector leverSelector lever in P (Park)
or N (Neutral) position
Battery voltage
Selector lever not in P
(Park) or N (Neutral) posi-
tion 0 – 1.5 V
102
2
(BR) Ground Neutral sw
Input Selector leverSelector lever in N (Neu-
tral) position
Battery voltage
Selector lever not in N
(Neutral) position 0 – 1.5 V
103
(LG) Ground Front defrost switch Input
——
104 (V) Ground CVT shift selector
(park position
switch) power sup-
ply Output Push-button ignition switch ON
Battery voltage
105
(SB) Ground Stop lamp switch 2 Input Push-button ignition switch OFF
Battery voltage
106 (Y) Ground Blower relay control Output
Push-button ig-
nition switchOFF or ACC
0 – 0.5 V
ON Battery voltage
Te r m i n a l N o .
(Wire color) Description
Condition Va l u e
(Approx.)
Signal name Input/
Output
+ −
Revision: August 2015 2016 Versa Note

cardiagn.com

BCS-48
< ECU DIAGNOSIS INFORMATION >[WITH INTELLIGENT KEY SYSTEM]
BCM
Fail-safe
INFOID:0000000012432333
BCM performs fail-safe control when the following DTCs are detected.
CONSULT Display Fail-safe Cancellation
B2192: ID DISCORD BCM-ECM Inhibit engine cranking Erase DTC
B2193: CHAIN OF BCM-ECM Inhibit engine cranking Erase DTC
B2195: ANTI SCANNING Inhibit engine cranking Ignition switch ON → OFF
B2196: DONGLE NG Inhibit engine cranking Erase DTC
B2198: NATS ANTENNA AMP Inhibit engine cranking Erase DTC
B2557: VEHICLE SPEED —When the following CAN signal status (vehicle speed signal) becomes
consistent
• Vehicle speed signal (ABS)
• Vehicle speed signal (Meter)
B2601: SHIFT P SIGNAL —500 ms after the following signal reception status becomes consistent
• Park position switch signal
• P range signal (CAN)
B2602: SHIFT P DIAG —5 seconds after the following BCM recognition conditions are fulfilled
• Ignition switch is in the ON position
• Park position switch signal: P position (push selector button) or ex-
cept P position (9 – 16 V)
• Vehicle speed: 4 km/h (2.5 MPH) or more
B2603: SHIFT POSITION —500 ms after any of the following BCM recognition conditions are fulfilled
•Status 1
- Ignition switch is in the ON position
- Park position switch signal: P position (push selector button) or ex-
cept P position (9 – 16 V)
- P/N position signal: Except P and N positions (0 – 1.5 V)
•Status 2
- Ignition switch is in the ON position
- Park position switch signal: P position (release selector button) (0 – 1.5 V)
- P/N position signal: P or N positions (9 – 16 V)
B2604: SHIFT PN DIAG CAN —500 ms after any of the following BCM recognition conditions are fulfilled
•Status 1
- Ignition switch is in the ON position
- P/N position signal: P or N position (9 – 16 V)
- Shift position signal (CAN): P or N position
•Status 2
- Ignition switch is in the ON position
- P/N position signal: Except P and N positions (0 – 1.5 V)
- Shift position signal (CAN): Except P and N position
B2605: SHIFT PN DIAG IPDM —500 ms after any of the following BCM recognition conditions are fulfilled
•Status 1
- Ignition switch is in the ON position
- P/N position signal: Except P and N positions (0 – 1.5 V)
•Status 2
- Ignition switch is in the ON position
- P/N position signal: P or N position (9 – 16 V)
B2608: STARTER RELAY Inhibit engine cranking 500 ms after the following signal communication status becomes con-
sistent
• Starter motor relay control signal
• Starter relay status signal (CAN)
B260F: ECM CAN COMM Inhibit engine cranking When any of the following conditions are fulfilled
• Ignition switch changes to ACC
• Receives engine status signal (CAN)
Revision: August 2015
2016 Versa Note

cardiagn.com

BCS
BCM
BCS-49
< ECU DIAGNOSIS INFORMATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
DTC Inspection Priority ChartINFOID:0000000012432334
If more than one DTC is displayed at the same time, perform inspections based on the following priority chart.
B26F1: IGN RELAY OFF Inhibit engine cranking
When the following conditions are fulfilled
• Ignition switch ON signal (CAN: Transmitted from BCM): ON
• Ignition switch ON signal (CAN: Transmitted from IPDM E/R): ON
B26F2: IGN RELAY ON Inhibit engine crankingWhen the following conditions are fulfilled
• Ignition switch ON signal (CAN: Transmitted from BCM): OFF
• Ignition switch ON signal (CAN: Transmitted from IPDM E/R): OFF
B26F3: START CONT RLY ON Inhibit engine cranking When the following conditions are fulfilled
• Starter control relay signal (CAN: Transmitted from BCM): OFF
• Starter control relay signal (CAN: Transmitted from IPDM E/R): OFF
B26F4: START CONT RLY OFF Inhibit engine cranking When the following conditions are fulfilled
• Starter control relay signal (CAN: Transmitted from BCM): ON
• Starter control relay signal (CAN: Transmitted from IPDM E/R): ON
B26F7: BCM Inhibit engine cranking
by Intelligent Key sys-
tem
When room antenna and luggage room antenna functions normally
U0415: VDC CAN CIR2 —When vehicle speed signal (Meter) (CAN) is received normally
CONSULT Display
Fail-safe Cancellation
Priority DTC
1 B2562: LOW VOLTAGE
2 • U1000: CAN COMM CIRCUIT
• U1010: CONTROL UNIT (CAN)
3 • B2192: ID DISCORD BCM-ECM
• B2193: CHAIN OF BCM-ECM
• B2195: ANTI SCANNING
• B2196: DONGLE NG
• B2198: NATS ANTENNA AMP
4 • B2555: STOP LAMP CIRCUIT
• B2556: ENG START SW
• B2557: VEHICLE SPEED
• B2562: LOW VOLTAGE
• B2601: SHIFT P SIGNAL
• B2602: SHIFT P DIAG
• B2603: SHIFT POSITION
• B2604: SHIFT PN DIAG CAN
• B2605: SHIFT PN DIAG IPDM
• B2608: STARTER RELAY
• B260F: ECM CAN COMM
• B2614: ACC RELAY REQ FB
• B2615: IGN RELAY3 REQ FB
• B2616: IGN RELAY2 REQ FB
• B2618: IGN RELAY1 REQ FB
• B261A: ENGINE SW
• B261F: ASCD CANCEL SW
• B2620: NEUTRAL SW
• B26E8: CLUTCH SW
• B26F1: IGN RELAY OFF
• B26F2: IGN RELAY ON
• B26F3: START CONT RLY ON
• B26F4: START CONT RLY OFF
•B26F6: BCM
•B26F7: BCM
• B26FB: CLUTCH SWITCH
• B26FC: KEY REGISTRATION
• U0415: VDC CAN CIR2
Revision: August 2015
2016 Versa Note

cardiagn.com
