NISSAN NOTE 2016 Service Repair Manual

TM-100
< ECU DIAGNOSIS INFORMATION >[CVT: RE0F11A]
TCM
TOTAL GEAR RATIOAuxiliary gearbox: 1GR
Counter gear ratio
×Pulley ratio Auxiliary
gearbox gear ratio
Auxiliary gearbox: 2GR Counter gear ratio ×Pulley ratio
PULLEY GEAR RATIO In driving (forward)
2.20 − 0.55
In driving (reverse) 2.20
AUX GEARBOX Vehicle started with selector lever in “L” position
1st
Release the accelerator pedal after the follow-
ing conditions are satisfied
• Selector lever: “D” position
• Accelerator pedal position: 1/8 or less
• Vehicle speed: 50 km/h (31 MPH) or more 2nd
In gear shifting of auxiliary gearbox 1st ⇔ 2nd
G SPEED Vehicle stopped
0.00 G
During acceleration The value changes to the positive side
along with acceleration.
During deceleration The value changes to the positive side
along with deceleration.
ACCEL POSI SEN 1 Accelerator pedal released
0.00 deg
Accelerator pedal fully depressed 80.00 deg
VENG TRQ While driving The value changes along with acceleration/
deceleration.
PRI TRQ While driving The value changes along with acceleration/
deceleration.
TRQ RTO While driving The value changes along with acceleration/
deceleration.
LINE PRESSURE Selector lever: “P” position 0.575 MPa
FLUID TEMP Ignition switch ON. Displays the CVT fluid temperature.
DSR REV While driving It varies along with the driving condition.
TRGT GEAR RATIO While driving It varies along with the driving condition.
TGT PLLY GR RATIO In driving (forward)
2.20 − 0.55
In driving (reverse) 2.20
TRGT AUX GEARBOX Vehicle started with selector lever in “L” position
1st
Release the accelerator pedal after the follow-
ing conditions are satisfied
• Selector lever: “D” position
• Accelerator pedal position: 1/8 or less
• Vehicle speed: 50 km/h (31 MPH) or more 2nd
In gear shifting of auxiliary gearbox Display gear position after gear shifting
LU PRS • Engine started
• Vehicle is stopped.
−
0.500 MPa
• Selector lever: “D” position
• Accelerator pedal position: 1/8 or less
• Vehicle speed: 20 km/h (12 MPH) or more 0.450 MPa
LINE PRS • After engine warm up
• Selector lever: “N” position
•At idle
0.500 MPa
• After engine warming up
• Selector lever: “D” position
• Depress the accelerator pedal fully 4.930 – 5.430 MPa
TRGT PRI PRESSURE • Selector lever: “L” position
• Vehicle speed: 20 km/h (12 MPH) 0.325 MPa
Monitor item
ConditionValue/Status (Approx.)
Revision: August 2015 2016 Versa Note

cardiagn.com

TCM
TM-101
< ECU DIAGNOSIS INFORMATION > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
TRGT HC/RB PRESS • Selector lever: “L” position
• Vehicle speed: 20 km/h (12 MPH)
0.000 MPa
Release the accelerator pedal after the follow-
ing conditions are satisfied
• Selector lever: “D” position
• Accelerator pedal position: 1/8 or less
• Vehicle speed: 50 km/h (31 MPH) or more 0.400 MPa
TRGT LB PRESSURE • Selector lever: “L” position
• Vehicle speed: 20 km/h (12 MPH)
0.325 MPa
Release the accelerator pedal after the follow-
ing conditions are satisfied
• Selector lever: “D” position
• Accelerator pedal position: 1/8 or less
• Vehicle speed: 50 km/h (31 MPH) or more 0.000 MPa
ISOLT1 ——
ISOLT2 — —
PRI SOLENOID ——
HC/RB SOLENOID ——
L/B SOLENOID ——
SOLMON1 ——
SOLMON2 ——
PRI SOL MON ——
HC/RB SOL MON ——
L/B SOL MON ——
D POSITION SW Selector lever: “D” position
On
Other than the above Off
N POSITION SW Selector lever: “N” position
On
Other than the above Off
R POSITION SW Selector lever: “R” position
On
Other than the above Off
P POSITION SW Selector lever: “P” position
On
Other than the above Off
BRAKESW Brake pedal is depressed
On
Brake pedal is released Off
L POSITION SW Selector lever: “L” position
On
Other than the above Off
IDLE SW Accelerator pedal is released
On
Accelerator pedal is fully depressed Off
SPORT MODE SW Press the overdrive control switch
On
Release the overdrive control switch Off
STRDWNSW Always Off
STRUPSW Always Off
DOWNLVR Always Off
UPLVR Always Off
NONMMODE Always Off
MMODE Always Off
INDLRNG Selector lever: “L” position
On
Other than the above Off
Monitor item
ConditionValue/Status (Approx.)
Revision: August 2015 2016 Versa Note

cardiagn.com

TM-102
< ECU DIAGNOSIS INFORMATION >[CVT: RE0F11A]
TCM
INDDRNGSelector lever: “D” position
On
Other than the above Off
INDNRNG Selector lever: “N” position
On
Other than the above Off
INDRRNG Selector lever: “R” position
On
Other than the above Off
INDPRNG Selector lever: “P” position
On
Other than the above Off
CVT LAMP In overdrive OFF
On
Other than the above Off
SPORT MODE IND In overdrive OFF
On
Other than the above Off
MMODE IND Always Off
VDC ON Always Off
TCS ON Always Off
ABS FAIL SIGNAL When ABS malfunction signal is received
On
Other than the above Off
ABS ON ABS is activated
On
Other than the above Off
RANGE Selector lever: “P”
and “N” positions N/P
Selector lever: “R” position R
Selector lever: “D” posi tion (OD OFF indicator
lamp OFF) D
Selector lever: “D” posi tion (OD OFF indicator
lamp ON) S
Selector lever: “L” position L
M GEAR POS Always 1
G SEN SLOPE Flat road
0%
Uphill gradient The value changes to the positive side
along with uphill gradient. (Maximum
40.45%)
Downhill gradient The value changes to the negative side
along with downhill gradient. (Minimum
−
40.45%)
ENGBRKLVL When the engine brake level of “ENGINE
BRAKE ADJ”. in “Work Support” is ON
On
When the engine brake level of “ENGINE
BRAKE ADJ”. in “Work Support” is OFF Off
PVIGN VOLT Ignition switch: ON 10 – 16 V
TRGT AUX GR RATIO Vehicle started with selector lever in “L” position
1.80
Release the accelerator pedal after the follow-
ing conditions are satisfied
• Selector lever: “D” position
• Accelerator pedal position: 1/8 or less
• Vehicle speed: 50 km/h (31 MPH) or more 1.00
G SEN CALIBRATION When G sensor calibration is completed
DONE
When G sensor calibration is not completed YET
Monitor item
ConditionValue/Status (Approx.)
Revision: August 2015 2016 Versa Note

cardiagn.com

TCM
TM-103
< ECU DIAGNOSIS INFORMATION > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
*: These monitor items do not use.
TERMINAL LAYOUT
INPUT/OUTPUT SIGNAL STANDARD
N IDLE STATUS When idle neutral control is operated On
When idle neutral control is not operated
Off
CVT-B* ——
CVT-A* ——
Monitor item
ConditionValue/Status (Approx.)
JSDIA2713ZZ
Te r m i n a l N o .
(Wire color) Description
ConditionValue (Approx.)
+ − Signal Input/
Output
2
(R/B) Ground L range switch Input
Ignition
switch
ONSelector lever:
“L” position 10 − 16 V
Other than the above 0 V
4
(W/B) Ground D range switch Input Selector lever:
“D” position 10 − 16 V
Other than the above 0 V
5
(L/B) Ground N range switch Input Selector lever:
“N” position 10 − 16 V
Other than the above 0 V
6
(O) Ground R range switch Input Selector lever:
“R” position 10 − 16 V
Other than the above 0 V
7
(Y) Ground P range switch Input Selector lever:
“P” position 10 − 16 V
Other than the above 0 V
11
(LG) Ground Sensor ground Input
Always0 V
12
(G/W) Ground
CVT fluid tempera-
ture sensor IntputIgnition
switch
ON CVT fluid: Approx. 20
°C 2.01 – 2.05 V
CVT fluid: Approx. 50 °C 1.45 – 1.50 V
CVT fluid: Approx. 80 °C 0.90 – 0.94 V
14
(G/R) Ground G sensor
InputIgnition
switch
ON When the vehicle stops on
a flat road
2.5 V
15* (V) —— — —
—
16
(L/R) Ground Secondary pres-
sure sensor
Input• Selector lever: “N” position
• At idle
0.88 – 0.92 V
21
(R/W) —
ROM ASSY
(CHIP SELECT) ——
—
22
(V) —R
OM ASSY
(D A

TA I/O) ——
—
Revision: August 2015 2016 Versa Note

cardiagn.com

TM-104
< ECU DIAGNOSIS INFORMATION >[CVT: RE0F11A]
TCM
23
(P/L) —CAN-L
Input/
Output ——
24
(BR) Ground Output speed sen-
sor
Input• Selector lever:
“L” position
• Vehicle speed: 20 km/h (12 MPH) 200 Hz
26
(O/W) Ground Sensor power sup-
ply OutputIgnition switch: ON
5.0 V
Ignition switch: OFF 0 V
30
(BR/B) GroundLine pressure sole-
noid valve
Output• After engine warming up
• Selector lever:
“N” position
• At idle
• After engine warming up
• Selector lever: “D” position
• Depress the acce lerator pedal fully
31
(L/W) —
ROM ASSY
(CLOCK) ——
—
33
(L/G) —CAN-H Input/
Output ——
34
(W) Ground Secondary speed
sensor
Input• Selector lever:
“L” position
• Vehicle speed: 20 km/h (12 MPH) 700 Hz
35
(LG/R) GroundPrimary speed sen-
sor Input• Selector lever:
“L” position
• Vehicle speed: 20 km/h (12 MPH) 1,100 Hz
Te r m i n a l N o .
(Wire color) Description
ConditionValue (Approx.)
+ − Signal Input/
Output
JSDIA1904GB
JSDIA1897GB
JSDIA1898GB
JSDIA1905GB
JSDIA1906GB
Revision: August 2015 2016 Versa Note

cardiagn.com

TCM
TM-105
< ECU DIAGNOSIS INFORMATION > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P37
(BR/W) GroundHigh clutch & re-
verse brake sole-
noid valve OutputIn driving at “L” position
Release the accelerator pedal after
the following conditions are satisfied
• Selector lever: “D” position
• Accelerator pedal position: 1/8 or
less
• Vehicle speed: 50 km/h (31 MPH) or more
38
(G) Ground Torque converter
clutch solenoid
valve Output• Selector lever: “D” position
• Accelerator pedal position: 1/8 or
less
• Vehicle speed: 20 km/h (12 MPH) or more
• Engine started
• Vehicle is stopped
39
(G/B) Ground
Low brake solenoid
valve Output• Selector lever: “L” position
• Vehicle speed: 20 km/h (12 MPH)
Release the accelerator pedal after
the following conditions are satisfied
• Selector lever: “D” position
• Accelerator pedal position: 1/8 or
less
• Vehicle speed: 50 km/h (31 MPH) or more
Te r m i n a l N o .
(Wire color) Description
ConditionValue (Approx.)
+ − Signal Input/
OutputJSDIA1897GB
JSDIA3653GB
JSDIA1900GB
JSDIA1901GB
JSDIA1902GB
JSDIA1903GB
Revision: August 2015 2016 Versa Note

cardiagn.com

TM-106
< ECU DIAGNOSIS INFORMATION >[CVT: RE0F11A]
TCM
*: This harness is not used.
Fail-safeINFOID:0000000012431034
TCM has a fail-safe mode. The mode functions so that
operation can be continued even if the signal circuit of
the main electronically contro lled input/output parts is damaged.
If the vehicle shows following behaviors including “poor acceleration”, a malfunction of the applicable system
is detected by TCM and the vehicle may be in a fail-sa fe mode. At this time, check the DTC code and perform
inspection and repair according to the malfunction diagnosis procedures.
Fail-safe function
40
(Y/B) Ground Primary pressure
solenoid valve Output• Selector lever:
“L” position
• Vehicle speed: 20 km/h (12 MPH)
41
(B) Ground Ground
OutputAlways 0 V
42
(B) Ground Ground
OutputAlways 0 V
45
(LG) Ground Battery power sup-
ply (memory back-
up) Input
Always 10 − 16 V
46
(LG) Ground Battery power sup-
ply (memory back-
up)
Input
Always 10 − 16 V
47
(R/W) Ground
Ignition power sup-
ply InputIgnition switch: ON
10 − 16 V
Ignition switch: OFF 0 V
48
(R) Ground
Ignition power sup-
ply InputIgnition switch: ON
10 − 16 V
Ignition switch: OFF 0 V
Te r m i n a l N o .
(Wire color) Description
ConditionValue (Approx.)
+ − Signal Input/
Output
JSDIA1897GB
DTC Vehicle behavior Conditions of vehicle
P062F Not changed from normal driving —
P0705 • Shift position indicator on combination meter is not dis-
played.
• Selector shock is large
•Start is slow
• Acceleration is slow
• Lock-up is not performed —
P0706 • Shift position indicator on combination meter is not dis-
played.
• Selector shock is large
•Start is slow
• Acceleration is slow
• Lock-up is not performed —
Revision: August 2015
2016 Versa Note

cardiagn.com

TCM
TM-107
< ECU DIAGNOSIS INFORMATION > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0711 Acceleration is slow
Engine coolant temperature when engine start: Temp.
≥
10 °C (50 °F)
• Selector shock is large
•Start is slow Engine coolant temperature when engine start: −
35°C ( −
31 °F) ≤Te m p . < 1 0 °C (50 °F)
• Selector shock is large
•Start is slow Engine coolant temperature when engine start: Temp. <
−
35 °C ( −31 °F)
P0712 Acceleration is slow
Engine coolant temperature when engine start: Temp.
≥
10 °C (50 °F)
• Selector shock is large
•Start is slow Engine coolant temperature when engine start: −
35°C ( −
31 °F) ≤Te m p . < 1 0 °C (50 °F)
• Selector shock is large
•Start is slow Engine coolant temperature when engine start: Temp. <
−
35 °C ( −31 °F)
P0713 Acceleration is slow
Engine coolant temperature when engine start: Temp.
≥
10 °C (50 °F)
• Selector shock is large
•Start is slow Engine coolant temperature when engine start: −
35°C ( −
31 °F) ≤Te m p . < 1 0 °C (50 °F)
• Sel
ec

tor shock is large
•Start is slow Engine coolant temperature when engine start: Temp. <
−
35 °C ( −31 °F)
P0715 • Selector shock is large
•Start is slow
• Acceleration is slow
• Vehicle speed is not increased
• Lock-up is not performed —
P0720 • Selector shock is large
•Start is slow
• Acceleration is slow
• Lock-up is not performed —
P0740 Lock-up is not performed —
P0743 Lock-up is not performed —
P0744 Lock-up is not performed —
P0746 • Selector shock is large
•Start is slow
• Acceleration is slow
• Vehicle speed is not increased
• Lock-up is not performed
—
P0846 •Start is slow
• Acceleration is slow
—
P0847 Acceleration is slow —
P0848 •Start is slow
• Acceleration is slow —
P0863 Not changed from normal driving —
P0890 • Selector shock is large
•Start is slow
• Acceleration is slow
• Lock-up is not performed —
P0962 • Selector shock is large
•Start is slow
• Acceleration is slow
• Lock-up is not performed —
P0963 • Selector shock is large
•Start is slow
• Acceleration is slow
• Lock-up is not performed —
DTC
Vehicle behavior Conditions of vehicle
Revision: August 2015 2016 Versa Note

cardiagn.com

TM-108
< ECU DIAGNOSIS INFORMATION >[CVT: RE0F11A]
TCM
P0965• Selector shock is large
•Start is slow
• Acceleration is slow
• Lock-up is not performed —
P0966 • Selector shock is large
•Start is slow
• Acceleration is slow
• Lock-up is not performed —
P0967 • Selector shock is large
•Start is slow
• Acceleration is slow
• Lock-up is not performed —
P0998 •Start is slow
• Lock-up is not performed —
P0999 •Start is slow
• Lock-up is not performed
Wire disconnection
• Vehicle speed is not increased
• Lock-up is not performed Voltage shorting
P099B Start is slow —
P099C •Start is slow
• Lock-up is not performed
Wire disconnection
• Vehicle speed is not increased
• Lock-up is not performed Voltage shorting
P1586 Idle neutral control is not performed —
P1588 Idle neutral control is not performed —
P2765 • Selector shock is large
•Start is slow
• Acceleration is slow
• Vehicle speed is not increased
• Lock-up is not performed —
P2857 •Start is slow
• Lock-up is not performed —
P2858 • Vehicle speed is not increased
• Lock-up is not performed
—
P2859 Vehicle speed is not increased —
P285A Start is slow —
U0073 • Selector shock is large
•Start is slow
• Acceleration is slow
• Lock-up is not performed —
U0100 • Selector shock is large
•Start is slow
• Acceleration is slow
• Lock-up is not performed —
U0140 Not changed from normal driving —
U0141 Not changed from normal driving —
U0155 Not changed from normal driving —
U0300 • Selector shock is large
•Start is slow
• Acceleration is slow
• Lock-up is not performed —
U1000 Not changed from normal driving —
U1114 Not changed from normal driving —
U1117 Not changed from normal driving —
DTC
Vehicle behavior Conditions of vehicle
Revision: August 2015 2016 Versa Note

cardiagn.com

TCM
TM-109
< ECU DIAGNOSIS INFORMATION > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
Protection Control INFOID:0000000012431035
The TCM becomes the protection control status temporarily to protect the safety when the safety of TCM and
transmission is lost. It automatically returns to the normal status if the safety is secured.
The TCM has the following protection control.
CONTROL FOR WHEEL SPIN
CONTROL WHEN FLUID TEMPERATURE IS HIGH
TORQUE IS REDUCED WHEN DRIVING WITH THE REVERSE GEAR
REVERSE PROHIBIT CONTROL
DTC Inspection Priority ChartINFOID:0000000012431036
If multiple malfunction codes are detected at the same time, check each code according to the DTC check pri-
ority list below.
Control When a wheel spin is detected, the engine output and gear ratio are limited and the line pressure is increased.
At the 1GR, the clutch pressure is increased.
Vehicle behavior in
control If the accelerator is kept depressing during wheel spin, the engine revolution and vehicle speed are limited to
a certain degree. From the 1GR, upshift to a certain gear ratio is only allowed.
Normal return condi-
tion Wheel spin convergence returns the control to the normal control.
ControlWhen the CVT fluid temperature is high, the gear shift permission maximum revolution and the maximum
torque are reduced than usual to prevent increase of the oil temperature.
Vehicle behavior in
control Power performance may be lowered, compared to normal control.
Normal return condi-
tion The control returns to the normal control when CVT fluid temperature is lowered.
Control
Engine output is controlled according to a vehicle speed while reversing the vehicle.
Vehicle behavior in
control Power performance may be lowered while reversing the vehicle.
Normal return condi-
tion Torque returns to normal by positioning the selector lever in a range ot
her than “R” position.
ControlThe reverse brake is controlled to avoid becoming engaged when the selector lever is set in “R” position while
driving in forward direction at more than the specified speed.
Vehicle behavior in
control If the selector lever is put at “R” position when driving with the forward gear, the gear becomes neutral, not
reverse.
Normal return condi-
tion The control returns to normal control when the vehicle is driven at low speeds. (The reverse brake becomes
engaged.)
Priority
DTC (Diagnostic Trouble Code) Reference
1 P0863 CONTROL UNIT (CAN)
TM-181
U0073 COMM BUS A OFFTM-135
U0100 LOST COMM (ECM A)TM-136
U0140 LOST COMM (BCM)TM-137
U0141 LOST COMM (BCM A)TM-138
U0155 LOST COMM (IPC)TM-139
U0300 CAN COMM DATA TM-140
U1000 CAN COMM CIRCTM-141
U1117 LOST COMM (ABS)TM-142
Revision: August 2015 2016 Versa Note

cardiagn.com
