WW-46
< DTC/CIRCUIT DIAGNOSIS >
REAR WIPER MOTOR CIRCUIT
REAR WIPER MOTOR CIRCUIT
Component Function CheckINFOID:0000000012433225
1. CHECK REAR WIPER ON OPERATION
CONSULT ACTIVE TEST
1. Select "RR WIPER" of BCM active test item.
2. While operating the test item, check rear wiper operation.
Is rear wiper operation normal?
YES >> Rear wiper motor circuit is normal.
NO >> Refer to WW-46, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012433226
Regarding Wiring Diagram information, refer to WW-28, "Wiring Diagram".
1. CHECK REAR WIPER MOTOR OUTPUT VOLTAGE
CONSULT ACTIVE TEST
1. Turn the ignition switch OFF.
2. Disconnect rear wiper motor.
3. Turn the ignition switch ON.
4. Select RR WIPER of BCM active test item.
5. While operating the test item, check voltage between BCM harness connector and ground.
With Intelligent Key system
Without Intelligent Key system
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 3.
2. CHECK REAR WIPER MOTOR GROUND CIRCUIT
1. Turn the ignition switch OFF.
2. Check continuity between rear wiper motor harness connector and ground.
Is the inspection result normal?
YES >> Replace rear wiper motor. Refer to WW-72, "Removal and Installation".
NO >> Repair or replace harness. ON : Rear wiper ON operation
OFF : Stop the rear wiper.
BCM
GroundTe s t i t e m
Vo l ta g e
(Approx.)
Connector Terminal REAR WIPER
M100 54 ON
Battery voltage
OFF 0V
BCM GroundTe s t i t e m
Vo l ta g e
(Approx.)
Connector Terminal REAR WIPER
M20 68 ON
Battery voltage
OFF 0V
Rear wiper motor
GroundContinuity
Connector Terminal
D502 4 Yes
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 3612 of 3641

REAR WIPER MOTOR CIRCUITWW-47
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G H
I
J
K
M A
B
WW
N
O P
3. CHECK REAR WIPER MOTOR OPEN CIRCUIT
Check continuity between BCM harness connector and rear wiper motor harness connector.
With Intelligent Key system
Without Intelligent Key system
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness.
4. CHECK REAR WIPER MOTOR SHORT CIRCUIT
Check continuity between BCM harness connector and ground.
With Intelligent Key system
Without Intelligent Key system
Is the inspection result normal?
YES >> Repair or replace harness.
NO >> Replace BCM. Refer to BCS-74, "
Removal and Installation" (with Intelligent Key system) or BCS-
137, "Removal and Installation" (without Intelligent Key system).
BCM Rear wiper motor
Continuity
Connector TerminalConnector Terminal
M100 54D502 2Yes
BCM Rear wiper motor
Continuity
Connector TerminalConnector Terminal
M20 68D502 2Yes
BCM
GroundContinuity
Connector Terminal
M100 54 No
BCM GroundContinuity
Connector Terminal
M20 68 No
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 3613 of 3641

WW-48
< DTC/CIRCUIT DIAGNOSIS >
REAR WIPER AUTO STOP SIGNAL CIRCUIT
REAR WIPER AUTO STOP SIGNAL CIRCUIT
Component Function CheckINFOID:0000000012433227
1. CHECK REAR WIPER (AUTO STOP) OPERATION
CONSULT DATA MONITOR
1. Select WIPER of BCM data monitor item.
2. Operate the rear wiper.
3. Check that RR WIPER STOP changes to ON and OFF linked with the wiper operation.
Is the inspection result normal?
YES >> Rear wiper auto stop signal circuit is normal.
NO >> Refer to WW-48, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012433228
Regarding Wiring Diagram information, refer to WW-28, "Wiring Diagram".
1. CHECK REAR WIPER MOTOR AUTO STOP CIRCUITS FOR OPEN
1. Turn ignition switch OFF.
2. Disconnect BCM and rear wiper motor.
3. Check continuity between BCM harness connector terminal and rear wiper motor harness connector ter- minal.
With Intelligent Key system
Without Intelligent Key system
Is inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace harness.
2. CHECK AUTO STOP CIRCUITS FOR SHORT TO GROUND
Check continuity between BCM harness connector terminal and ground.
With Intelligent Key system
Without Intelligent Key system
Monitor item ConditionMonitor status
RR WIPER STOP Rear wiper motorStop position
ON
Except stop position OFF
BCM Rear wiper motor
Continuity
Connector Terminal Connector Terminal
M100 44D502 3Yes
BCM Rear wiper motor
Continuity
Connector Terminal Connector Terminal
M20 56D502 3Yes
BCM
GroundContinuity
Connector Terminal
M100 44 No
BCM GroundContinuity
Connector Terminal
M20 56 No
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 3614 of 3641

REAR WIPER AUTO STOP SIGNAL CIRCUITWW-49
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G H
I
J
K
M A
B
WW
N
O P
Is inspection result normal?
YES >> Replace BCM. Refer to BCS-74, "Removal and Installation" (with Intelligent Key system) or BCS-
137, "Removal and Installation" (with Intelligent Key system).
NO >> Repair or replace harness.
