EXCESSIVE ABS FUNCTION OPERATION FREQUENCYBRC-133
< SYMPTOM DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
EXCESSIVE ABS FUNCTION OPERATION FREQUENCY
Diagnosis ProcedureINFOID:0000000012430918
1.CHECK START
Check front and rear brake force di stribution using a brake tester.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Check brake system.
2.CHECK FRONT AND REAR AXLE
Make sure that there is no excessive play in the front and rear axles. Refer to front: FA X - 7 , "
Inspection", rear:
RAX-5, "
Inspection".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace malfunctioning components.
3.CHECK WHEEL SENSOR AND SENSOR ROTOR
Check the following:
• Wheel sensor installation for damage
• Sensor rotor installation for damage
• Wheel sensor connector
• Wheel sensor harness
Is the inspection result normal?
YES >> GO TO 4.
NO >> • Replace wheel sensor BRC-140, "
FRONT WHEEL SENSOR : Removal and Installation" (front)
or BRC-141, "
REAR WHEEL SENSOR : Removal and Installation" (rear).
• Replace sensor rotor BRC-143, "
FRONT SENSOR ROTOR : Removal and Installation" (front)
or BRC-143, "
REAR SENSOR ROTOR : Removal and Installation" (rear).
• Repair harness.
4.CHECK ABS WARNING LAMP DISPLAY
Make sure that the ABS warning lamp is turned off af ter the ignition switch is turned ON or when driving.
Is the inspection result normal?
YES >> Inspection End.
NO >> Perform “Self Diagnostic Result”. Refer to BRC-31, "
CONSULT Function (ABS)".
Revision: August 2015 2016 Versa Note

cardiagn.com

BRC-134
< SYMPTOM DIAGNOSIS >[VDC/TCS/ABS]
UNEXPECTED PEDAL REACTION
UNEXPECTED PEDAL REACTION
Diagnosis ProcedureINFOID:0000000012430919
1.CHECK BRAKE PEDAL STROKE
Check brake pedal stroke. Refer to BR-9, "
Inspection and Adjustment".
Is the stroke too big?
YES >> • Bleed air from brake line and hose. Refer to BR-13, "Bleeding Brake System".
• Check brake pedal, brake booster, and master cylinder for mount play, looseness, brake system fluid leakage, etc. Refer to brake pedal: BR-9, "
Inspection and Adjustment" or brake booster
assembly BR-15, "
Inspection".
NO >> GO TO 2.
2.CHECK ABS FUNCTION
1. Disconnect ABS actuator and electric unit (control unit) connector to deactivate ABS.
2. Check if braking force is normal in this condition.
3. Reconnect connector after inspection.
Is the inspection result normal?
YES >> Inspection End.
NO >> Check brake system.
Revision: August 2015 2016 Versa Note

cardiagn.com

THE BRAKING DISTANCE IS LONGBRC-135
< SYMPTOM DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
THE BRAKING DISTANCE IS LONG
Diagnosis ProcedureINFOID:0000000012430920
CAUTION:
The stopping distance on slippery road surfaces might be longer with the ABS operating than when
the ABS is not operating.
1.CHECK ABS FUNCTION
1. Turn ignition switch OFF.
2. Disconnect ABS actuator and el ectric unit (control unit) connector to deactivate ABS.
3. Check stopping distance.
4. After inspection, reconnect connector.
Is the inspection result normal?
YES >> Inspection End.
NO >> Check brake system.
Revision: August 2015 2016 Versa Note

cardiagn.com

BRC-136
< SYMPTOM DIAGNOSIS >[VDC/TCS/ABS]
ABS FUNCTION DOES NOT OPERATE
ABS FUNCTION DOES NOT OPERATE
Diagnosis ProcedureINFOID:0000000012430921
CAUTION:
ABS does not operate when speed
is 10 km/h (6 MPH) or lower.
1.CHECK ABS WARNING LAMP DISPLAY
Make sure that the ABS warning lamp turns OFF af ter ignition switch is turned ON or when driving.
Is the inspection result normal?
YES >> Inspection End.
NO >> Perform “Self Diagnostic Result”. Refer to BRC-31, "
CONSULT Function (ABS)".
Revision: August 2015 2016 Versa Note

cardiagn.com

PEDAL VIBRATION OR ABS OPERATION SOUND OCCURS
BRC-137
< SYMPTOM DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
PEDAL VIBRATION OR ABS OPERATION SOUND OCCURS
Diagnosis ProcedureINFOID:0000000012430922
CAUTION:
Under the following conditions, ABS is activated an d vibration is felt when brake pedal is lightly
depressed (just place a foot on it). However, this is normal.
• When shifting gears
• When driving on slippery road
• During cornering at high speed
• When passing over bumps or grooves [approximately 50 mm (1.97 in) or more]
• When pulling away just after starting engine [at approximately 10 km/h (6 MPH) or higher]
1.SYMPTOM CHECK 1
Check that there are pedal vibrat ions when the engine is started.
Do symptoms occur?
YES >> GO TO 2.
NO >> Inspect the brake pedal.
2.SYMPTOM CHECK 2
Check that there are ABS operation noises when the engine is started.
Do symptoms occur?
YES >> GO TO 3.
NO >> Perform “Self Diagnostic Result”. Refer to BRC-31, "
CONSULT Function (ABS)".
3.SYMPTOM CHECK 3
Check symptoms when electrical component (headlamps, etc.) switches are operated.
Do symptoms occur?
YES >> Check if there is a radio, antenna, antenna lead wire, or wiring close to the control unit. If there is,
move it farther away.
NO >> Inspection End.
Revision: August 2015 2016 Versa Note

cardiagn.com

BRC-138
< SYMPTOM DIAGNOSIS >[VDC/TCS/ABS]
VEHICLE JERKS DURING VDC/TCS/ABS CONTROL
VEHICLE JERKS DURING
VDC/TCS/ABS CONTROL
Diagnosis ProcedureINFOID:0000000012430923
1.SYMPTOM CHECK
Check if the vehicle jerks during VDC/TCS/ABS control.
Is the inspection result normal?
YES >> Inspection End.
NO >> GO TO 2.
2.CHECK SELF DIAGNOSTIC RESULT
Perform “Self Diagnostic Result” of “ABS” actuator and electric unit (control unit). Refer to BRC-31, "
CON-
SULT Function (ABS)".
Are self diagnostic results indicated?
YES >> Check corresponding items, make repairs, and perform ABS actuator and electric unit (control
unit) “Self Diagnostic Result” again. Refer to BRC-31, "
CONSULT Function (ABS)".
NO >> GO TO 3.
3.CHECK CONNECTOR
1. Turn ignition switch OFF.
2. Disconnect ABS actuator and electric unit (control unit) connector.
3. Check terminals for deformati on, disconnection, looseness, etc.
4. Securely reconnect connector and perform “Self Diagnostic Result” of “ABS”. Refer to BRC-31, "
CON-
SULT Function (ABS)".
Are self diagnostic results indicated?
YES >> If poor contact, damage, open or short circuit of connector terminal is found, repair or replace.
NO >> GO TO 4.
4.CHECK ECM AND TCM SELF DIAGNOSTIC RESULT
1. Perform ECM “Self Diagnostic Result”. Refer to EC-60, "
CONSULT Function".
2. Perform TCM “Self Diagnostic Result”. Refer to TM-93, "
CONSULT Function".
Are self diagnostic results indicated?
YES >> Check the corresponding items. • ECM: Refer to EC-87, "
DTCIndex".
• TCM: Refer to TM-93, "
CONSULT Function".
NO >> Replace ABS actuator and electric unit (control unit). Refer to BRC-144, "
Removal and Installa-
tion".
Revision: August 2015 2016 Versa Note

cardiagn.com

NORMAL OPERATING CONDITIONBRC-139
< SYMPTOM DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
NORMAL OPERATING CONDITION
DescriptionINFOID:0000000012430924
Symptom Result
Slight vibrations are felt on the brake pedal and operation noises occur when VDC, TCS or ABS is activated. This is a normal condi-
tion due to the VDC,
TCS or ABS activation.
Stopping distance is longer than that of vehicles without ABS when the vehicle drives on rough, gravel, or
snow-covered (fresh, deep snow) roads.
The brake pedal moves and generates noises when TCS or VDC is activated due to rapid acceleration or
sharp turn.
The brake pedal vibrates and motor operation noises occur from the engine room after the engine starts and
just after the vehicle starts.
This is normal, and it is
caused by the ABS op-
eration check.
Depending on the road conditions, the driver may experience a sluggish feel in the brake pedal. This is normal, because
TCS places the highest
priority on the optimum
traction (stability).
TCS may activate momentarily if wheel speed changes when driving where road friction coefficient varies,
when downshifting, or when fully depressing accelerator pedal.
The ABS warning lamp and SLIP
indicator lamp may turn ON when the vehicle is subject to strong shaking
or large vibration, such as when the vehicle is rotating on a turntable or located on a ship while the engine
is running. In this case, restart the
engine on a normal
road. If the normal con-
dition is restored, there
is no malfunction. At
that time, erase the self-
diagnostic result memo-
ry.
VDC may not operate normally or th
e ABS warning lamp, and SLIP indicato r lamp may illuminate when driv-
ing on a road that is extremely slanted (e.g., bank in a circuit course).
A malfunction may occur in the yaw rate/side/decel G sensor system when the vehicle turns sharply, such
as during a spin turn, axle turn, or drift driving, while the VDC function is OFF (VDC OFF indicator lamp illu-
minated).
The vehicle speed will not increase even though the accelerator pedal is depressed, when inspecting the
speedometer on a 2-wheel chassis dynamometer. Normal (Deactivate the
VDC/TCS function be-
fore performing an in-
spection on a chassis
dynamometer.)
SLIP indicator lamp may simultaneously turn ON when low tire pressure warning lamp turns ON. This is not a VDC sys-
tem error but results
from characteristic
change of tire.
Revision: August 2015
2016 Versa Note

cardiagn.com

BRC-140
< REMOVAL AND INSTALLATION >[VDC/TCS/ABS]
WHEEL SENSOR
REMOVAL AND INSTALLATION
WHEEL SENSOR
FRONT WHEEL SENSOR
FRONT WHEEL SENSOR : Exploded ViewINFOID:0000000012430925
FRONT WHEEL SENSOR : Removal and InstallationINFOID:0000000012430926
CAUTION:
• Be careful not to damage front wheel
sensor edge and sensor rotor teeth.
• When removing the front wheel hub, first remove the front wheel sensor from the steering knuckle.
Failure to do so may result in damage to the fr ont wheel sensor, making the front wheel sensor inop-
erative.
• Pull out the front wheel sensor, bein g careful to turn it as little as possible. Do not pull on the front
wheel sensor harness.
• Before installation, check if foreign objects, such as iron fragments, are adhered to the pick-up part
of the front wheel sensor or to the inside of the hole in the steer ing knuckle for the front wheel sen-
sor, or if a foreign object is caught in the surface of the sensor rotor. Fix as necessary and then
install the front wheel sensor.
REMOVAL
1. Remove wheel and tire using power tool. Refer to WT-48, "Removal and Installation".
2. Remove fender protector. Refer to EXT-38, "
Removal and Installation".
3. Disconnect the harness connector fr om the front wheel sensor.
4. Remove bolt and front wheel sensor from steering knuckle.
5. Release front wheel sensor harness clips from the vehicle.
INSTALLATION
Installation is in the reverse order of the removal.
1. Front wheel sensor 2. Harness connector Front
AWFIA0865GB
Revision: August 2015 2016 Versa Note

cardiagn.com

WHEEL SENSORBRC-141
< REMOVAL AND INSTALLATION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
CAUTION:
Do not twist front wheel sensor harness when installing front
wheel sensor. Check that grommet (2) is fully inserted to
bracket (1). Check that front wheel sensor harness is not
twisted after installation.
REAR WHEEL SENSOR
REAR WHEEL SENSOR : Exploded ViewINFOID:0000000012430927
REAR WHEEL SENSOR : Re moval and InstallationINFOID:0000000012430928
CAUTION:
• Be careful not to damage rear wheel sensor edge and sensor rotor teeth.
• When removing the rear wheel hub, first remove the rear wheel sensor from the back plate. Failure to
do so may result in damage to the rear wheel sensor, making the rear wheel sensor inoperative.
• Pull out the rear wheel sensor, be ing careful to turn it as little as possible. Do not pull on the rear
wheel sensor harness.
• Before installation, check if foreig n objects, such as iron fragments, are adhered to the pick-up part
of the rear wheel sensor or to the inside of the hole in the back plate for the rear wheel sensor, or if a
foreign object is caught in the surface of the sensor rotor. Fix as necessary and then install the rear
wheel sensor.
REMOVAL
JPFIC0209ZZ
1. Rear wheel sensor 2. Harness connector Front
AWFIA0866GB
Revision: August 2015 2016 Versa Note

cardiagn.com

BRC-142
< REMOVAL AND INSTALLATION >[VDC/TCS/ABS]
WHEEL SENSOR
1. Remove bolts (A) and support bracket (1) (LH side only).
2. Disconnect the harness connector fr
om the rear wheel sensor.
3. Release rear wheel sensor harness clips from the vehicle.
4. Remove bolts and rear wheel sensor from back plate.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
Do not twist rear wheel sensor harness when installing rear
wheel sensor. Check that grommet (2) is fully inserted to
bracket (1). Check that rear wheel sensor harness is not twisted
after installation.
ALFIA0391ZZ
JPFIC0209ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com
