NISSAN NOTE 2016 Service Manual PDF

AV-56
< REMOVAL AND INSTALLATION >[BASE AUDIO]
BLUETOOTH® CONTROL UNIT
BLUETOOTH® CONTROL UNIT
Removal and InstallationINFOID:0000000012432893
REMOVAL
1. Remove the luggage side lower finisher (RH). Refer to
INT-34, "LUGGAGE SIDE LOWER FINISHER :
Removal and Installation".
2. Disconnect the harness connectors fr om the Bluetooth® control unit.
3. Remove the Bluetooth® ant enna screws (A) and the Bluetooth®
antenna (1).
4. Remove the Bluetooth® control unit bracket screws (A) and the Bluetooth® control unit (1).
5. Remove the Bluetooth® control unit screws (A) and separate the Bluetooth® control unit (1) from the bracket (2).
INSTALLATION
Installation is in the reverse order of removal.
AWNIA3095ZZ
AWNIA3122ZZ
AWNIA3097ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

AV
BLUETOOTH® ANTENNAAV-57
< REMOVAL AND INSTALLATION > [BASE AUDIO]
C
D
E
F
G H
I
J
K L
M B A
O P
BLUETOOTH® ANTENNA
Removal and Installation INFOID:0000000012432894
REMOVAL
1. Remove the luggage side lower finisher (RH). Refer to INT-34, "LUGGAGE SIDE LOWER FINISHER :
Removal and Installation".
2. Disconnect the Bluetooth® antenna harness connec tor from the Bluetooth® control unit.
3. Remove the Bluetooth® antenna screws (A) and the Bluetooth® antenna (1).
INSTALLATION
Installation is in the reverse order of removal.
AWNIA3095ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

AV-58
< REMOVAL AND INSTALLATION >[BASE AUDIO]
STEERING SWITCH
STEERING SWITCH
Removal and InstallationINFOID:0000000012432895
REMOVAL
1. Remove the steering wheel. Refer to ST-8, "Removal and Installation".
2. Remove the steering wheel rear finisher (1) by releasing pawls (A).
3. Remove the steering wheel audio control switch screws (A) from the back of the steering wheel.
4. Remove the steering wheel audio control switches from the steering wheel.
INSTALLATION
Installation is in the reverse order of removal.
AWNIA3063ZZ
AWNIA3064ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

AV
MICROPHONEAV-59
< REMOVAL AND INSTALLATION > [BASE AUDIO]
C
D
E
F
G H
I
J
K L
M B A
O P
MICROPHONE
Removal and InstallationINFOID:0000000012432896
REMOVAL
1. Remove the microphone finisher from the headlining by releas- ing pawls (A) using a suitable tool.
2. Disconnect the harness connector from microphone and remove.
3. Separate the microphone from the finisher by releasing pawls (A) using a suitable tool.
INSTALLATION
Installation is in the reverse order of removal.
NOTE:
• Make sure to align the rib on the finisher with the slot in the microphone.
• Make sure to install the microphone with the arrows pointing toward the RH side of the vehicle.
AWNIA3153ZZ
AWNIA3154ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

AV-60
< REMOVAL AND INSTALLATION >[BASE AUDIO]
ROD ANTENNA
ROD ANTENNA
Exploded ViewINFOID:0000000012432897
Removal and InstallationINFOID:0000000012432898
REMOVAL
1. Lower the rear portion of the headlining. Refer to
INT-31, "Removal and Installation".
2. Disconnect the harness connectors from t he antenna (satellite radio model shown).
3. Remove the antenna nut (A) and remove the antenna.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
If the antenna nut is tightened less than the specified torque this will lower the sensitivity of the
antenna. If the antenna nut is tightened more than the specified torque this will deform the roof panel.
AWNIA3124ZZ
1. Antenna rod 2. Antenna base A. Antenna nut
AWNIA3115ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

AV
ANTENNA FEEDERAV-61
< REMOVAL AND INSTALLATION > [BASE AUDIO]
C
D
E
F
G H
I
J
K L
M B A
O P
ANTENNA FEEDER
Feeder LayoutINFOID:0000000012432899
1. Antenna base (antenna amp.) 2. Rod Antenna 3. M351
4. M67, M350 5. M107
AWNIA3114ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

AV-62
< PRECAUTION >[DISPLAY AUDIO]
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint Syst
em (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000012432945
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harn esses can be identified by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or electri c power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers , always switch the Ignition OFF, disconnect the
battery and wait at least three minutes before performing any service.
Precaution for Trouble DiagnosisINFOID:0000000012432946
AV COMMUNICATION SYSTEM
• Do not apply voltage of 7.0 V or higher to the measurement terminals.
• Use the tester with its open terminal voltage being 7.0 V or less.
• Be sure to turn ignition switch OFF and disconnect the battery cable from\
the negative terminal before checking the circuit.
Precaution for Harness RepairINFOID:0000000012432947
AV COMMUNICATION SYSTEM
• Solder the repaired parts, and wrap with tape. [Frays of twisted line
must be within 110 mm (4.33 in).]
PKIA0306E
Revision: August 2015 2016 Versa Note

cardiagn.com

AV
PRECAUTIONSAV-63
< PRECAUTION > [DISPLAY AUDIO]
C
D
E
F
G H
I
J
K L
M B A
O P
• Do not perform bypass wire connections for the repair parts. (The spliced wire will become separated and the characteristics of
twisted line will be lost.)
Precaution for WorkINFOID:0000000012432948
• When removing or disassembling each component, be ca reful not to damage or deform it. If a component
may be subject to interference, be sure to protect it with a shop cloth.
• When removing (disengaging) components with a screwdriver or similar tool, be sure to wrap the component with a shop cloth or vinyl tape to protect it.
• Protect the removed parts with a shop cloth and prevent them from being dropped.
• Replace a deformed or damaged clip.
• If a part is specified as a non-reusabl e part, always replace it with a new one.
• Be sure to tighten bolts and nuts securely to the specified torque.
• After installation is complete, be sure to check that each part works properly.
• Follow the steps below to clean components:
- Water soluble dirt:
• Dip a soft cloth into lukewarm water, wring the water out of the cloth and wipe the dirty area.
• Then rub with a soft, dry cloth.
-Oily dirt:
• Dip a soft cloth into lukewarm water with mild detergent (concentration: within 2 to 3%) and wipe the dirty area.
• Then dip a cloth into fresh water, wring the water out of the cloth and wipe the detergent off.
• Then rub with a soft, dry cloth.
- Do not use organic solvent such as thinner, benzene, alcohol or gasoline.
- For genuine leather seats, use a genuine leather seat cleaner.
PKIA0307E
Revision: August 2015 2016 Versa Note

cardiagn.com

AV-64
< PREPARATION >[DISPLAY AUDIO]
PREPARATION
PREPARATION
PREPARATION
Special Service ToolsINFOID:0000000012432949
The actual shape of the tools may differ from those illustrated here.
Commercial Service ToolsINFOID:0000000012432950
Tool number
(TechMate No.)
Tool name Description
—
(J-46534)
Trim Tool Set Removing trim components
AWJIA0483ZZ
Tool name
Description
Power tool Loosening nuts, screws and bolts
PIIB1407E
Revision: August 2015 2016 Versa Note

cardiagn.com

AV
COMPONENT PARTSAV-65
< SYSTEM DESCRIPTION > [DISPLAY AUDIO]
C
D
E
F
G H
I
J
K L
M B A
O P
SYSTEM DESCRIPTION
COMPONENT PARTS
Component Parts LocationINFOID:0000000012432951
Audio UnitINFOID:0000000012432952
Description
A. Front of headliner B. Center of back door
AWNIA3637ZZ
No.Component Function
1. Rod antenna Refer to AV- 6 7 , "
Rod Antenna, Antenna Amp., Satellite Antenna and Antenna
Feeder".
2. Antenna base (antenna amp. and satellite
antenna)
3. Rear door speaker RH
Refer to AV- 6 6 , "
Sp ea ke r".
4. Front door speaker RH
5. Front door speaker LH
6. Rear door speaker LH
7. Audio unit
Refer to AV- 6 5 , "
Audio Unit".
8. Steering wheel audio control switches Refer to AV- 6 7 , "
Steering Wheel Audio Control Switches".
9. USB interface and AUX in jack Refer to AV- 6 6 , "
USB Interface and AUX In Jack".
10. Microphone Refer to AV- 6 7 , "
Microphone".
11. Rear view camera Refer to AV- 6 7 , "
Rear View Camera".
