DLK-72
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2626 OUTSIDE ANTENNA
3. Check continuity between BCM harness connector and outside key antenna (LH) harness connector.
4. Check continuity between BCM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness.
3.CHECK OUTSIDE KEY ANTENNA INPUT SIGNAL 2
1. Replace outside key antenna (LH). (New antenna or other antenna)
2. Connect BCM connector and outside key antenna (LH) connector.
3. Turn ignition switch ON.
4. Check signal between BCM harness connector and ground using oscilloscope.
Is the inspection result normal?
YES >> Replace outside key antenna (LH). Refer to DLK-184, "OUTSIDE HANDLE : Removal and Instal-
lation".
NO >> Replace BCM. Refer to BCS-74, "
Removal and Installation".
BCM Outside key antenna (LH)
Continuity
Connector TerminalConnector Terminal
M98 78
D6 1
Ye s
79 2
BCM
GroundContinuity
Connector Terminal
M98 78
No
79
(+)
(–) Condition Signal
(Reference value)
BCM
Connector Terminal
M98 78
79Ground When the driver side
door request switch is
operated with ignition
switch OFF. When Intelligent
Key is in the an-
tenna detection
area. (The dis-
tance between
Intelligent Key
and antenna: 80
cm or less.)
When Intelligent
Key is not in the
antenna detec-
tion area. (The
distance be-
tween Intelligent
Key and anten-
na: Approx. 2 m.)
JMKIA5955GB
JMKIA5954GB
Revision: August 2015
2016 Versa Note

cardiagn.com

B2627 OUTSIDE ANTENNADLK-73
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
B2627 OUTSIDE ANTENNA
DTC LogicINFOID:0000000012430003
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Check “Self Diagnostic Result” of “BCM” using CONSULT.
Is DTC detected?
YES >> Refer to DLK-73, "Diagnosis Procedure".
NO >> Outside key antenna (RH) is OK.
Diagnosis ProcedureINFOID:0000000012430004
Regarding Wiring Diagram information, refer to DLK-46, "Wiring Diagram".
1.CHECK OUTSIDE KEY ANTENNA INPUT SIGNAL 1
1. Turn ignition switch ON.
2. Check signal between BCM harness connector and ground using oscilloscope.
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-74, "Removal and Installation".
NO >> GO TO 2.
2.CHECK OUTSIDE KEY ANTENNA CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM connector and outside key antenna (RH) connector.
DTC CONSULT display de-
scription DTC detecting condition
Possible cause
B2627 OUTSIDE ANTENNA
2 An excessive high or low voltage from outside key an-
tenna (RH) is sent to BCM. • Outside key antenna (RH)
• Between BCM and Outside key an-
tenna (RH)
(+)
(–) Condition Signal
(Reference value)
BCM
Connector Terminal
M98 80
81Ground When the passenger
door request switch is
operated with ignition
switch OFF. When Intelligent
Key is in the an-
tenna detection
area. (The dis-
tance between In-
telligent Key and
antenna: 80 cm
or less.)
When Intelligent
Key is not in the
antenna detec-
tion area. (The
distance between
Intelligent Key
and antenna: Ap-
prox. 2 m.)
JMKIA5955GB
JMKIA5954GB
Revision: August 2015
2016 Versa Note

cardiagn.com

DLK-74
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2627 OUTSIDE ANTENNA
3. Check continuity between BCM harness connector and outside key antenna (RH) harness connector.
4. Check continuity between BCM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness.
3.CHECK OUTSIDE KEY ANTENNA INPUT SIGNAL 2
1. Replace outside key antenna (RH). (New antenna or other antenna)
2. Connect BCM connector and outside key antenna (RH) connector.
3. Turn ignition switch ON.
4. Check signal between BCM harness connector and ground using oscilloscope.
Is the inspection result normal?
YES >> Replace outside key antenna (RH). Refer to DLK-184, "OUTSIDE HANDLE : Removal and Instal-
lation".
NO >> Replace BCM. Refer to BCS-74, "
Removal and Installation".
BCM Outside key antenna (RH)
Continuity
Connector TerminalConnector Terminal
M98 80
D106 1
Ye s
81 2
BCM
GroundContinuity
Connector Terminal
M98 80
No
81
(+)
(–) Condition Signal
(Reference value)
BCM
Connector Terminal
M98 80
81Ground When the passenger
door request switch is
operated with ignition
switch OFF. When Intelligent
Key is in the an-
tenna detection
area. (The dis-
tance between In-
telligent Key and
antenna: 80 cm or
less.)
When Intelligent
Key is not in the
antenna detection
area. (The dis-
tance between In-
telligent Key and
antenna: Approx.
2 m.)
JMKIA5955GB
JMKIA5954GB
Revision: August 2015
2016 Versa Note

cardiagn.com

B2628 OUTSIDE ANTENNADLK-75
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
B2628 OUTSIDE ANTENNA
DTC LogicINFOID:0000000012430007
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Check “Self Diagnostic Result” of “BCM” using CONSULT.
Is outside key antenna DTC detected?
YES >> Refer to DLK-75, "Diagnosis Procedure".
NO >> Outside key antenna (rear bumper) is OK.
Diagnosis ProcedureINFOID:0000000012430008
Regarding Wiring Diagram information, refer to DLK-46, "Wiring Diagram".
1.CHECK OUTSIDE KEY ANTENNA INPUT SIGNAL 1
1. Turn ignition switch ON.
2. Check signal between BCM harness connector and ground using oscilloscope.
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-74, "Removal and Installation".
NO >> GO TO 2.
2.CHECK OUTSIDE KEY ANTENNA CIRCUIT
1. Turn ignition switch OFF.
DTC CONSULT display
description DTC detecting condition
Possible cause
B2628 OUTSIDE ANTENNA
3 An excessive high or low voltage from outside key
antenna (rear bumper) is sent to BCM. • Outside key antenna (rear
bumper)
• Between BCM – Outside key an- tenna (rear bumper)
(+)
(–) Condition Signal
(Reference value)
BCM
Connector Terminal
M98 82
83
Ground When the back
door request
switch is operat-
ed with ignition
switch OFF. When Intelligent
Key is in the an-
tenna detection
area. (The dis-
tance between
Intelligent Key
and antenna: 80
cm or less.)
When Intelligent
Key is not in the
antenna detec-
tion area. (The
distance be-
tween Intelli-
gent Key and
antenna: Ap-
prox. 2 m.)
JMKIA5955GB
JMKIA5954GB
Revision: August 2015
2016 Versa Note

cardiagn.com

DLK-76
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2628 OUTSIDE ANTENNA
2. Disconnect BCM connector and outside key antenna (rear bumper) connector.
3. Check continuity between BCM harness connector and outside key antenna (rear bumper) harness con-
nector.
4. Check continuity between BCM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness.
3.CHECK OUTSIDE KEY ANTENNA INPUT SIGNAL 2
1. Replace outside key antenna (rear bumper). (New antenna or other antenna)
2. Connect BCM and outside key antenna (rear bumper) connector.
3. Turn ignition switch ON.
4. Check signal between BCM harness connector and ground using oscilloscope.
Is the inspection result normal?
YES >> Replace outside key antenna (rear bumper). Refer to DLK-184, "REAR BUMPER : Removal and
Installation".
NO >> Replace BCM. Refer to BCS-74, "
Removal and Installation".
BCM Outside key antenna (rear bumper)
Continuity
Connector TerminalConnector Terminal
M98 82
B49 1
Ye s
83 2
BCM GroundContinuity
Connector Terminal
M98 82
No
83
(+)
(–) Condition Signal
(Reference value)
BCM
Connector Terminal
M98 82
83Ground When the back
door request
switch is operat-
ed with ignition
switch OFF. When Intelligent
Key is in the an-
tenna detection
area. (The dis-
tance between
Intelligent Key
and antenna: 80
cm or less.)
When Intelligent
Key is not in the
antenna detec-
tion area. (The
distance be-
tween Intelli-
gent Key and
antenna: Ap-
prox. 2 m.)
JMKIA5955GB
JMKIA5954GB
Revision: August 2015
2016 Versa Note

cardiagn.com

POWER SUPPLY AND GROUND CIRCUITDLK-77
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
POWER SUPPLY AND GROUND CIRCUIT
BCM
BCM : Diagnosis ProcedureINFOID:0000000012542547
Regarding Wiring Diagram information, refer to BCS-52, "Wiring Diagram".
1.CHECK FUSES AND FUSIBLE LINK
Check that the following fuses and fusible link are not blown.
Is the fuse blown?
YES >> Replace the blown fuse or fusible link after repairing the affected circuit.
NO >> GO TO 2.
2.CHECK POWER SUPPLY CIRCUIT
1. Disconnect BCM connector M99.
2. Check voltage between BCM connector M99 and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair harness or connector.
3.CHECK GROUND CIRCUIT
Check continuity between BCM connector M99 and ground.
Is the inspection result normal?
YES >> Inspection End.
NO >> Repair harness or connector.
Terminal No. Signal nameFuses and fusible link No.
57 Battery power supply 12 (10A)
70 G (40A)
BCM
Ground Voltage
Connector Terminal
M99 57
— Battery voltage
70
BCM GroundContinuity
Connector Terminal
M99 67—Yes
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-78
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
COMBINATION METER BUZZER
COMBINATION METER BUZZER
Component Function CheckINFOID:0000000012430010
1.CHECK FUNCTION
1. Select “INTELLIGENT KEY” of “BCM” using CONSULT.
2. Select “INSIDE BUZZER” in “Active Test”.
3. Touch “Key”, “Knob” or “Take Out” to check that it works normally.
Is the inspection result normal?
Yes >> Combination meter buzzer is OK.
No >> Refer to DLK-78, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012430011
1.CHECK METER BUZZER CIRCUIT
Refer to WCS-38, "
Component Function Check".
Is the inspection result normal?
Ye s > > G O T O 2 .
No >> Repair or replace harness.
2.CHECK INTERMITTENT INCIDENT
Refer to GI-42, "
Intermittent Incident".
>> Inspection End.
Revision: August 2015 2016 Versa Note

cardiagn.com

DOOR LOCK ACTUATORDLK-79
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
DOOR LOCK ACTUATOR
DRIVER SIDE
DRIVER SIDE : Comp onent Function CheckINFOID:0000000012430012
1.CHECK FUNCTION
1. Select “DOOR LOCK” of “BCM” using CONSULT.
2. Select “DOOR LOCK” in “Active Test”.
3. Touch “ALL LOCK” or “ALL UNLK” to check that it works normally.
Is the inspection result normal?
YES >> Door lock actuator is OK.
NO >> Refer to DLK-79, "
DRIVER SIDE : Diagnosis Procedure".
DRIVER SIDE : Diag nosis ProcedureINFOID:0000000012430013
Regarding Wiring Diagram information, refer to DLK-36, "Wiring Diagram".
1.CHECK DOOR LOCK ACTUATOR INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect front door lock actuator LH connector.
3. Check voltage between front door lock actuator LH harness connector and ground.
Is the inspection result normal?
YES >> Replace front door lock actuator LH .
NO >> GO TO 2.
2.CHECK DOOR LOCK ACTUATOR CIRCUIT
1. Disconnect BCM connector and all door lock actuator connectors.
2. Check continuity between BCM harness connector and front door lock actuator LH harness connector.
3. Check continuity between BCM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness.
3.CHECK BCM OUTPUT SIGNAL
(+)
(–) Condition Voltag e
(Approx.)
Front door lock actuator
LH
Connector Terminal
D14 1
Ground Door lock and unlock switch Lock
Battery voltage
2 Unlock
BCMFront door lock actuator LH
Continuity
Connector TerminalConnector Terminal
M99 65
D14 1
Ye s
66 2
BCM GroundContinuity
Connector Terminal
M99 65
No
66
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-80
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR LOCK ACTUATOR
1. Connect BCM connector.
2. Check voltage between front door lock
actuator LH harness connector and ground.
Is the inspection result normal?
YES >> Check for internal short of each door lock actuator.
NO >> Replace BCM. Refer to BCS-74, "
Removal and Installation".
PASSENGER SIDE
PASSENGER SIDE : Component Function CheckINFOID:0000000012430014
1.CHECK FUNCTION
1. Select “DOOR LOCK” of “BCM” using CONSULT.
2. Select “DOOR LOCK” in “Active Test”.
3. Touch “ALL LOCK” or “ALL UNLK” to check that it works normally.
Is the inspection result normal?
YES >> Door lock actuator is OK.
NO >> Refer to DLK-80, "
PASSENGER SIDE : Diagnosis Procedure".
PASSENGER SIDE : Diagnosis ProcedureINFOID:0000000012430015
Regarding Wiring Diagram information, refer to DLK-36, "Wiring Diagram".
1.CHECK DOOR LOCK ACTUATOR INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect front door lock actuator RH connector.
3. Check voltage between front door lock actuator RH harness connector and ground.
Is the inspection result normal?
YES >> Replace front door lock actuator RH.
NO >> GO TO 2.
2.CHECK DOOR LOCK ACTUATOR CIRCUIT
1. Disconnect BCM connector and all door lock actuators.
2. Check continuity between BCM harness connector and front door lock actuator RH harness connector.
3. Check continuity between BCM harness connector and ground.
(+) (–) Condition Vo l ta g e
(Approx.)
BCM
Connector Terminal
M99 65
Ground Door lock and unlock switch Lock
Battery voltage
66 Unlock
(+)
(–) Condition Voltag e
(Approx.)
Front door lock actuator
RH
Connector Terminal
D114 2
Ground Door lock and unlock switch Lock
Battery voltage
1U nlo ck
BCM Front door lock actuator RH
Continuity
Connector TerminalConnector Terminal
M99 65
D114 2
Ye s
59 1
Revision: August 2015 2016 Versa Note

cardiagn.com

DOOR LOCK ACTUATORDLK-81
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness.
3.CHECK BCM OUTPUT SIGNAL
1. Connect BCM connector.
2. Check voltage between front door lock actuator RH harness connector and ground.
Is the inspection result normal?
YES >> Check for internal short of each door lock actuator.
NO >> Replace BCM. Refer to BCS-74, "
Removal and Installation".
REAR LH
REAR LH : Component Function CheckINFOID:0000000012430016
1.CHECK FUNCTION
1. Select “DOOR LOCK” of “BCM” using CONSULT.
2. Select “DOOR LOCK” in “Active Test”.
3. Touch “ALL LOCK” or “ALL UNLK” to check that it works normally.
Is the inspection result normal?
YES >> Door lock actuator is OK.
NO >> Refer to DLK-81, "
REAR LH : Diagnosis Procedure".
REAR LH : Diagnosis ProcedureINFOID:0000000012430017
Regarding Wiring Diagram information, refer to DLK-36, "Wiring Diagram".
1.CHECK DOOR LOCK ACTUATOR INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect rear door lock actuator LH connector.
3. Check voltage between rear door lock actuator LH harness connector and ground.
Is the inspection result normal?
YES >> Replace rear door lock actuator LH. Refer to DLK-172, "Exploded View".
NO >> GO TO 2.
BCM
GroundContinuity
Connector Terminal
M99 65
No
59
(+)
(–) Condition Vo l ta g e
(Approx.)
BCM
Connector Terminal
M99 65
Ground Door lock and unlock switch Lock
Battery voltage
59 Unlock
(+)
(–) Condition Vo l ta g e
(Approx.)
Rear door lock actuator LH
Connector Terminal
D205 1
Ground Door lock and unlock switch Lock
Battery voltage
2 Unlock
Revision: August 2015 2016 Versa Note

cardiagn.com
