NISSAN PATHFINDER 2017 R52 / 4.G Navigation Manual

StepSetting item Action
Scroll map and touch [
]. [New Destination] Set a location scrolled to on the map as the destination
Push . [NissanConnect Ser-
vices][Connect to Voice Menu] Connects to the NissanConnectSMServices Interactive Voice Menu.
[Sync All Feeds] Updates information list by connecting to the NissanConnect
SM
Services Data Center.
[Connected Search] Input a keyword of a point of interest and connect and search the NissanConnect
SMServices Data Center.“Searching by connecting Data Center” (page 4-16)
[Send to Car] Search for a location using Google maps, and download the information to set the destination via the NissanConnect
SMServices
Data Center.
“Using Google send-to-car” (page 4-17)
[Destination Send to Car] Search for destinations from a point of interest (POI) database accessed within the NissanConnect
SMportal website.“Using Destination Send to Car” (page 4-17)
[Journey Planner] Sets a route plan downloaded from the NISSAN Owner’s Portal Website.
“Using Journey Planner” (page 4-12)
[History] The information feeds that were previously referred to are displayed.
Push IVR soft button.
Speak your choice, or ask the NissanConnect
SMServices Response Specialists directly to
search for your destination. Set the destination with the assistance of a NissanConnect
SM
Services Response Specialist.
4-5
4. Setting destination

INFO:
. If the route is already set, the selected location becomes a waypoint.
. After setting a destination, the location of the destination can be adjusted and the location can be stored in the Address Book, etc.
“Procedures after setting route” (page 4-18)
. The destination can be deleted.
“Canceling Route” (page 5-7)
4-6
4. Setting destination

FINDING ADDRESS
Searches for a destination by address.
1. Push.
2. Touch [Street Address]. A number input screen is displayed.
3. Input the street address.
.When [City] is selected , a city can bespecified by typing the city name.
.When [City Center] is touched while a cityis selected, the center of the city
becomes the target of the search.
.Touch [Intersection] to enter the intersec-tion.
.If the house number is not available, touch[No House #].
4. When information about house number, street, city, and state are entered, the destination is proposed on the display.
Touch [OK].
INFO:
.Touch [State/Province:] or [City] to nar-
row down the specified region and city.
“Changing region” (page 4-2)
5. Enter the name of the street. After finishing the entry, touch [List]. A list of streets is
displayed.
6. Touch the street of the destination from the list.
INFO:
Touch [
] to return to the previous screen.
7. Touch [Start] to start route guidance.
INFO:
.The [Street Address] can also be set by pushing and then touching
[Destination Menu].
.After setting a destination, the location of
the destination can be adjusted and the
location can be stored in the Address
Book, etc.
“Procedures after setting route” (page 4-18)
Voice command
1. Push <
>located on the steering-wheel.
2. After the tone sounds, speak a command.
To searches for a destination by address:
“Navigation”, "Street Address”
4-7
4. Setting destination

FINDING POINTS OF INTEREST
This allows you to find a facility by name or by
category. Specify the region and city of the
destination to find it more quickly.
NOTE:
Locations and business hours of facilities
are subject to change, which may not be
reflected in the map data. Double-check
this information before you go to an
emergency facility to ensure that you can
receive the proper support. Otherwise, you
may not receive emergency help when you
arrive at the destination.
A confirmation message also appears on
the navigation screen. Follow the displayed
instructions and check the items required.
SEARCHING BY A LANDMARK
NAME
1. Push .
2. Touch [Points of Interest].
3. Touch [Spell Name]. A character input screen is displayed.
INFO:
Touch [City] and touch [Last 5 Cities] to
display the last five cities recently set as
destinations.
4. Enter the name of the destination facility. After finishing the entry, touch [List]. A list
screen is displayed.
5. Touch the preferred destination facility from the list.
Narrow down conditions:
.[Sort]:
— [By Distance]: Shows a list of facilities that are near the
current vehicle location.
— [By Name]: Shows a list of facilities sorted alphabe-
tically by name order.
.[By Category]:Display the list that summarizes the
entered names into categories. Select
the category to narrow down the search.
Touch [Show Related] to display the
related facility on the narrowed down
category list.
.[City/Area]:
— [Within a City]: Input the city to narrow down the target
city.
— [Near Destination]: When the destination is set, this indicates
a list of facilities around the destination.
— [Show Along Route]: The system displays the facilities located
along the route.
4-8
4. Setting destination

INFO:
.Touch [] in the list screen to display
the detailed information about the POI
that is selected. Touch [Call] to make a
call to the facility.
6. Whole route map is displayed. Touch [Start] to start route guidance.
INFO:
. The [Points of Interest] can also be set by
pushing and then touching [Desti-
nation Menu].
. If [Space] is touched and a keyword is
inputted, a search will be possible after
entering two or more words.
. After setting a destination, the location of the
destination can be adjusted and the location
can be stored in the Stored Locations, etc.
“Procedures after setting route”
(page 4-18)
SEARCHING FROM THE LANDMARK
CATEGORY
1. Push .
2. Touch [Points of Interest]. The main category menu is displayed.
3. Touch the main category. The subcategory list is displayed.
4. Touch the subcategory. A list screen is displayed.
Narrow down conditions:
.[Sort]:
— [By Distance]: Shows a list of facilities that are near the
current vehicle location.
— [By Name]: Shows a list of facilities sorted alphabe-
tically by name order.
.[Spell Name]:Enter the facilities name to narrow down
the search.
.[City/Area]:
— [Within a City]: Input the city to narrow down the target
city.
— [Near Destination]: When the destination is set, this indicates
a list of facilities around the destination.
— [Show Along Route]: The system displays the facilities located
along the route.
5. Touch the preferred destination facility from the list.
Touch [Start] to start route guidance.
INFO:
. After setting a destination, the location of the
destination can be adjusted.
“Procedures after setting route”
(page 4-18)
. If the nearest POI cannot be searched, a
message asking whether to search from an
extended area will be displayed. When [Yes]
is selected, the system starts to search for
4-9
4. Setting destination

POI in a wider area.SETTING HOME AS DESTINA-
TION
The home location can be set as the destination
if the home location is stored in advance. This
function is especially useful when searching for a
route to return to the home location.
1. Push.
2. Touch [Home].
3. The home location is displayed, and the system sets the home location as the
destination.
INFO:
If the home location is not stored yet, the
system will automatically display a screen for
storing it.
“Storing home location” (page 6-2)
4. Touch [Start] to start route guidance.
INFO:
The [Home] can also be set by pushing
and then touching [Destination Menu].
Voice command
1. Push <
>located on the steering-wheel.
2. After the tone sounds, speak a command.
To set the home location as the destination:
“Home”
4-10
4. Setting destination

FINDING NEARBY PLACE
A facility located near the current vehicle location
or another location that you move to by scrolling
the map can be set as the destination. This
allows you to set the destination to a facility
located near the current vehicle location or
another location that you move to by scrolling
the map.
1. Push.
2. Touch [Destination Menu].
3. Touch [Nearby Places]. The category list is displayed.
4. Select [RESTAURANT] for example.
5. Select preferred category from the sub category list.
6. Touch the preferred destination from the list. The position of the selected location is
displayed in the preview.
INFO:
.If the suggested route is already set, bytouching [Show Along Route], the system
displays only the facilities located along
the route.
.A maximum of 100 facilities can bedisplayed on the list screen.
7. Touch [Start] to start route guidance.
INFO:
You can also set the destination by touching
[
] when scrolling the map and selecting
[Nearby Places] from the shortcut menu.
SEARCHING FROM STORED
LOCATIONS
Storing frequently used destinations in the
Address Book makes it easy to set a destination.
Locations should be stored in the Address Book
before using this function.
“Storing location” (page 6-2)
1. Push .
2. Touch [Destination Menu].
3. Touch [Stored Locations].
4. Touch the preferred location from the list.
INFO:
.Selecting [Sort] displays a list of various sort functions.
— [By Number]: The Address Book entries are displayed
in ascending numerical order.
4-11
4. Setting destination

— [By Name]:The Address Book entries are displayed
in alphabetic order.
— [By Icon]: By selecting a particular icon, a list that
contains only the Address Book entries
associated with that icon is displayed.
— [By Group]: By selecting a particular group (family,
friends, leisure, etc.) , the selected group
is displayed at the top of the list.
.When [Store] is touched, a new locationcan be stored.
5. Touch [Start] to start route guidance.
Voice command
1. Push <
>located on the steering-wheel.
2. After the tone sounds, speak a command.
To set the destination from the Stored Locations:
“ Stored Locations”
SEARCHING FROM HISTORY
A previous destination can be set as the
destination. Up to 100 previous destinations will be
automatically stored. If the number of previous
destinations exceeds 100, the oldest one will be
replaced by the newest one.
1. Push .
2. Touch [Destination Menu].
3. Touch [Previous Destinations]. A list screen is displayed.
4. Touch the previous start point or the previous destination from the list.
5. Touch [Start] to start route guidance.
Voice command
1. Push <
>located on the steering-wheel.
2. After the tone sounds, speak a command.
To display the previous destinations list:
“Previous Destinations”
USING JOURNEY PLANNER
It is possible to set the route according to the
route plan created in advance by the NISSAN
Owner’s Portal Website.
INFO:
Use of NissanConnect
SMServices features is
dependent upon a valid subscription and the
telematics device being in operative condition, as
well as cellular connectivity, navigation map data
and GPS satellite signal reception being avail-
able.
1. Push .
2. Touch [Destination Menu].
3. Touch [Journey Planner]. The system will connect to the NissanConnect
SMServices
Data Center and display the Journey Planner
list screen.
4-12
4. Setting destination

4. Select the preferred route plan from the list.
INFO:
.Touch [Update List] to update the listinformation.
.Touch [Details] to preview the route.
.Touchto display facility information.
5. The selected route plan is displayed. Touch [Start] after confirming the location of the
displayed destination.
INFO:
. The Journey Planner can also be set by
pushing and then touching [Nis-
sanConnect Services].
. Journey Planner is a NissanConnect
SM
Services feature. Subscription is required
to use the NissanConnectSMServices.
. Journey Planner cannot be used if [Decline]
is touched on the Start-up Screen.
. Refer to the NISSAN Owner’s Portal Web-
site for how to set the destination using
Journey Planner.
SETTING INTERSECTION
It is possible to set an intersection of any two
streets as the destination and have the system
calculate a route.
1. Push .
2. Touch [Destination Menu] and touch [Inter- section].
3. The first street input screen is displayed.
INFO:
Touch [State/Province], [Country] or [City] to
narrow down the specified country and city.
4. Enter the name of the first street. After finishing the entry, touch [List]. A list screen
is displayed.
INFO:
If the country or city is changed after
selecting the first street, the first street that
was selected will be canceled.
5. Touch a street as the first street from the list.
6. The second street input screen is displayed.
7. Enter the name of the second street. After finishing the entry, touch [List]. A list screen
is displayed.
INFO:
Touch [Map] on the list to preview the
location of the selected junction.
8. Touch a street as the second street from the list.
9. Whole route map is displayed. Touch [Start] to start route guidance.
4-13
4. Setting destination

SETTING FREEWAY ENTRANCE/
EXIT
It is possible to set the destination to an entrance
or exit of a freeway.
1. Push.
2. Touch [Destination Menu].
3. Touch [Freeway Entrance/Exit]. A character input screen is displayed.
4. Enter the name of the freeway. After finishing entry, touch [List].
5. Touch the preferred freeway.
6. Touch [Entrance] /[Exit]. A list screen is displayed.
7. Touch the preferred destination from the list. The selected location is displayed in the
preview.
INFO:
Touch [Sort] and touch [By Distance] to sort
the list by the nearest distance. Touch [By
Road No.] to sort by the road no.
8. Touch [Start] to start route guidance.SETTING CITY CENTER
It is possible to set the center of a specified city
as a destination.
1. Push .
2. Touch [Destination Menu].
3. Touch [City Center]. A character input screen is displayed.
4. Enter the name of the city and touch [List]. A list screen is displayed.
INFO:
Touch [Last 5 Cities] to display the last five
cities recently set as destinations.
5. Touch the preferred destination from the list.
INFO:
Touch [Map] to preview on the display.
6. The selected destination is displayed. Touch [Start] after confirming the location of the
displayed destination.
4-14
4. Setting destination
