NISSAN PATROL 1998 Y61 / 5.G Heather And Air Conditioner Workshop Manual Insufficient Heating
TROUBLE DIAGNOSIS PROCEDURE FOR INSUFFICIENT HEATING
SYMPTOM:
+Insufficient heating.
Inspection ¯ow
*1: HA-70
*2: HA-64
*3: HA-65
*4: HA-67*5: HA-75
*6: HA-85
*7: HA-89*8: HA-94

Page 102 of 128

NISSAN PATROL 1998 Y61 / 5.G Heather And Air Conditioner Workshop Manual Noise
TROUBLE DIAGNOSIS PROCEDURE FOR NOISE
SYMPTOM:
+Noise
Inspection ¯ow
*1: HA-123
*2: HA-125*3: HA-114 *4: HA-70
SHA896EA
TROUBLE DIAGNOSESAUTO
HA-100

Page 103 of 128

NISSAN PATROL 1998 Y61 / 5.G Heather And Air Conditioner Workshop Manual Self-diagnosis
TROUBLE DIAGNOSIS PROCEDURE FOR SELF-DIAGNOSIS
SYMPTOM:
+Self-diagnosis cannot be performed.
Inspection ¯ow
*1: HA-74
*2: HA-103
*3: HA-105*4: HA-107
*5: HA-110
*6: HA-79*7: HA-70
*8:

Page 104 of 128

NISSAN PATROL 1998 Y61 / 5.G Heather And Air Conditioner Workshop Manual Memory Function
TROUBLE DIAGNOSIS PROCEDURE FOR MEMORY FUNCTION
SYMPTOM:
+Memory function does not operate.
Inspection ¯ow
*1: HA-74 *2: HA-70 *3: HA-64
SHA027F
TROUBLE DIAGNOSESAUTO
HA-102

Page 105 of 128

NISSAN PATROL 1998 Y61 / 5.G Heather And Air Conditioner Workshop Manual Ambient Sensor
COMPONENT DESCRIPTION
The ambient sensor is attached in front of the drivers side con-
denser. It detects ambient temperature and converts it into a resis-
tance value which is then in

Page 106 of 128

NISSAN PATROL 1998 Y61 / 5.G Heather And Air Conditioner Workshop Manual DIAGNOSTIC PROCEDURE
SYMPTOM: Ambient sensor circuit is open or shorted. (orA/C LEDis indicated on auto amp. as a result of conducting
Self-diagnosis STEP 2.)
CHECK AMBIENT SENSOR CIRCUIT
BETWEEN AMBI

Page 107 of 128

NISSAN PATROL 1998 Y61 / 5.G Heather And Air Conditioner Workshop Manual COMPONENT INSPECTION
Ambient sensor
After disconnecting ambient sensor harness connector, measure
resistance between terminalsj
9andj24at sensor harness side,
using the table below.
Temperature ÉC (�

Page 108 of 128

NISSAN PATROL 1998 Y61 / 5.G Heather And Air Conditioner Workshop Manual DIAGNOSTIC PROCEDURE
SYMPTOM: In-vehicle sensor circuit is open or shorted.
(
orA/C LEDis indicated on auto amp. as a result of con-
ducting Self-diagnosis STEP 2.)
CHECK IN-VEHICLE SENSOR CIRCUIT
BET

Page 109 of 128

NISSAN PATROL 1998 Y61 / 5.G Heather And Air Conditioner Workshop Manual COMPONENT INSPECTION
In-vehicle sensor
After disconnecting in-vehicle sensor harness connector, measure
resistance between terminalsj
8andj24at sensor harness side,
using the table below.
Temperature

Page 110 of 128

NISSAN PATROL 1998 Y61 / 5.G Heather And Air Conditioner Workshop Manual DIAGNOSTIC PROCEDURE
SYMPTOM: Sunload sensor circuit is open or shorted. (orA/C LEDis indicated on auto amp. as a result of conducting
Self-diagnosis STEP 2.)
CHECK SUNLOAD SENSOR CIRCUIT
BETWEEN SUNL
