NISSAN TEANA 2008 Service Manual

KEY WARNING LAMP
DLK-95
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
KEY WARNING LAMP
DescriptionINFOID:0000000003794915
Performs operation method guide and warning together with buzzer.
Component Function CheckINFOID:0000000003794916
1.CHECK FUNCTION
Check the operation with “INDICATOR” in “Active Test” mode with CONSULT-III.
Is the inspection result normal?
YES >> Key warning lamp in combination meter is OK.
NO >> Refer to DLK-95, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000003794917
1.CHECK KEY WARNING LAMP
Refer toMWI-4, "
Work flow".
Is the inspection result normal?
Yes >> GO TO 2.
No >> Repair or replace key warning lamp circuit.
2.CHECK INTERMITTENT INCIDENT
Refer to GI-35, "
Intermittent Incident".
>> INSPECTION END
Test item Condition
INDICATORRED ON Key warning lamp (red) illuminates
RED IND Key warning lamp (red) flashes

DLK-96
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
HAZARD FUNCTION
HAZARD FUNCTION
DescriptionINFOID:0000000003794918
Perform answer-back for each operation with number of blinks.
Component Function CheckINFOID:0000000003794919
1.CHECK FUNCTION
Check hazard warning lamp (“FLASHER”) in Active Test.
Is the inspection result normal?
YES >> Hazard warning lamp circuit is OK.
NO >> Refer to DLK-96, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000003794920
1.CHECK HAZARD SWITCH CIRCUIT
Refer to EXL-90, "
Wiring Diagram - TURN AND HAZARD WARNING LAMPS -" (For xenon type) or EXL-262,
"Wiring Diagram - TURN AND HAZARD WARNING LAMPS -" (For halogen type)
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace hazard warning switch circuit. Refer to EXL-328, "
Symptom Table".
2.CHECK INTERMITTENT INCIDENT
Refer to GI-35, "
Intermittent Incident".
>> INSPECTION END

POWER DOOR LOCK SYSTEM
DLK-97
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
POWER DOOR LOCK SYSTEM
Wiring Diagram - POWER DOOR LOCK SYSTEM -INFOID:0000000003940917
JCKWM1180GB

DLK-98
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
POWER DOOR LOCK SYSTEM
JCKWM1181GB

POWER DOOR LOCK SYSTEM
DLK-99
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
JCKWM1182GB

DLK-100
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
POWER DOOR LOCK SYSTEM
JCKWM1183GB

POWER DOOR LOCK SYSTEM
DLK-101
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
JCKWM1184GB

DLK-102
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
POWER DOOR LOCK SYSTEM
JCKWM1185GB

POWER DOOR LOCK SYSTEM
DLK-103
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
JCKWM1186GB

DLK-104
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
INTELLIGENT KEY SYSTEM
INTELLIGENT KEY SYSTEM
Wiring Diagram - INTELLIGENT KEY SYSTEM -INFOID:0000000003940918
JCKWM1187GB
