NISSAN TEANA 2008 Service Manual

B2623 INSIDE KEY ANTENNA 3
DLK-55
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
2. Check continuity between BCM harness connector and inside key antenna (trunk room) harness connec-
tor.
3. Check continuity between BCM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness.
3.CHECK INSIDE KEY ANTENNA INPUT SIGNAL 2
1. Replace inside key antenna (trunk room). (New antenna or other antenna)
2. Connect BCM and inside key antenna (trunk room) connector.
3. Check signal between BCM harness connector and ground with oscilloscope.
Is the inspection result normal?
YES >> Replace inside key antenna (trunk room). Refer to DLK-237, "TRUNK ROOM : Removal and
Installation".
NO >> Replace BCM. Refer to BCS-78, "
Removal and Installation".
4.CHECK INTERMITTENT INCIDENT
Refer to GI-35, "
Intermittent Incident".
>> INSPECTION END
BCM Inside key antenna
Continuity
Connector Terminal Connector Terminal
M12134
B862
Existed
35 1
BCM
GroundContinuity
Connector Terminal
M12134
Not existed
35
(+)
(–) ConditionSignal
(Reference value.) BCM
Connector Terminal
M121 34, 35 GroundPlace Intelligent Key inside the ve-
hicle.
Place Intelligent Key outside the
vehicle.
JMKIA0062GB
JMKIA0063GB

DLK-56
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
POWER SUPPLY AND GROUND CIRCUIT
POWER SUPPLY AND GROUND CIRCUIT
BCM (BODY CONTROL MODULE)
BCM (BODY CONTROL MODULE) : Diagnosis ProcedureINFOID:0000000003794832
1.CHECK FUSE AND FUSIBLE LINK
1. Turn ignition switch OFF.
2. Check that the following fuse and fusible link are not fusing.
Is the fuse fusing?
YES >> Replace the blown fuse or fusible link after repairing the affected circuit if a fuse or fusible link is
blown.
NO >> GO TO 2.
2.CHECK POWER SUPPLY CIRCUIT
1. Disconnect BCM connectors.
2. Check voltage between BCM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness.
3.CHECK GROUND CIRCUIT
Check continuity between BCM harness connector and ground.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Repair or replace harness.
Terminal No. Signal name Fuse and fusible link No.
1
Battery power supplyI (40A)
1110 (10A)
(+)
(−)Vo l ta g e
(Approx.) BCM
Connector Terminal
M118 1
Ground Battery voltage
M119 11
BCM
GroundContinuity
Connector Terminal
M119 13 Existed

DOOR SWITCH
DLK-57
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
DOOR SWITCH
DescriptionINFOID:0000000003794834
Detects door open/close condition.
Component Function CheckINFOID:0000000003794835
1.CHECK FUNCTION
With CONSULT-III
Check door switches (“DOOR SW-DR”, “DOOR SW-AS”, “DOOR SW-RL”, “DOOR SW-RR” and “DOOR SW-
BK”) in Data Monitor” mode with CONSULT-III.
Is the inspection result normal?
YES >> Door switch is OK.
NO >> Refer to DLK-57, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000003794836
1.CHECK DOOR SWITCH INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect malfunctioning door switch connector.
3. Check signal between malfunctioning door switch harness connector and ground with oscilloscope.
Monitor item Condition
DOOR SW-DR
CLOSE → OPEN: OFF → ON DOOR SW-AS
DOOR SW-RL
DOOR SW-RR

DLK-58
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR SWITCH
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK DOOR SWITCH CIRCUIT
1. Disconnect BCM connector.
2. Check continuity between BCM harness connector and door switch harness connector.
3. Check continuity between BCM harness connector and ground.
(+)
(–)Signal
(Reference value) Door switch
Connector Terminal
Driver side B34 2
Ground Passenger side B220 2
Rear LH B71 2
Rear RH B221 2
JPMIA0011GB
JPMIA0011GB
JPMIA0011GB
JPMIA0011GB
BCM Door switch
Continuity
Connector Terminal Connector Terminal
M123150 B34 (Driver side)
2 Existed 124 B220 (Passenger side)
M12169 B71 (Rear LH)
68 B221 (Rear RH)

DOOR SWITCH
DLK-59
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-78, "Removal and Installation".
NO >> Repair or replace harness.
3.CHECK DOOR SWITCH
Refer to DLK-59, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace malfunctioning door switch. Refer to DLK-234, "
Removal and Installation".
4.CHECK INTERMITTENT INCIDENT
Refer to GI-35, "
Intermittent Incident".
>> INSPECTION END
Component InspectionINFOID:0000000003896358
1.CHECK DOOR SWITCH
1. Turn ignition switch OFF.
2. Disconnect malfunction front door switch connector.
3. Check front door switch.
Is the inspection result normal?
YES >> Door switch is OK.
NO >> Replace malfunctioning door switch. Refer to DLK-234, "
Removal and Installation".
BCM
GroundContinuity
Connector Terminal
M123150 (Driver side)
Not existed 124 (Passenger side)
M12169 (Rear LH)
68 (Rear RH)
(+)
(-) Condition Continuity Door switch
Connector Terminal
Driver side B34
2Ground
part of front
door switch Door switch pressed Not exists
released Exists
Passenger side B220 pressed Not exists
released Exists
Rear LH B71 pressed Not exists
released Exists
Rear RH B221 pressed Not exists
released Exists

DLK-60
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR LOCK AND UNLOCK SWITCH
DOOR LOCK AND UNLOCK SWITCH
DescriptionINFOID:0000000003794842
Transmits door lock/unlock operation to BCM.
Component Function CheckINFOID:0000000003794843
1.CHECK FUNCTION
With CONSULT-III
Check (“CDL LOCK SW ”, “CDL UNLOCK SW”) in Data Monitor mode with CONSULT-III.
Is the inspection result normal?
YES >> Door lock and unlock switch is OK.
NO >> Refer to DLK-60, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000003794844
1.CHECK POWER WINDOW MAIN SWITCH
1. Turn ignition switch ON.
2. Check door lock and unlock operation.
Is the inspection result normal?
YES >> Replace power window main switch.
NO >> Go to PWC-74, "
Diagnosis Procedure".
Monitor item Condition
CDL LOCK SW LOCK : ON
UNLOCK : OFF
CDL UNLOCK SW LOCK : OFF
UNLOCK : ON

DOOR LOCK ACTUATOR
DLK-61
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
DOOR LOCK ACTUATOR
DRIVER SIDE
DRIVER SIDE : DescriptionINFOID:0000000003794848
Locks/unlocks the door with the signal from BCM.
DRIVER SIDE : Component Function CheckINFOID:0000000003794849
1.CHECK FUNCTION
1. Use CONSULT-III to perform Active Test (“DOOR LOCK”).
2. Touch “ALL LCK” or “ALL UNLK” to check that it works normally.
Is the inspection result normal?
YES >> Door lock actuator is OK.
NO >> Refer to DLK-61, "
DRIVER SIDE : Diagnosis Procedure".
DRIVER SIDE : Diagnosis ProcedureINFOID:0000000003794850
1.CHECK DOOR LOCK ACTUATOR OUTPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect front door lock assembly (driver side) connector.
3. Check voltage between front door lock assembly (driver side) harness connector and ground.
Is the inspection result normal?
YES >> Replace front door lock assembly (driver side). Refer to DLK-202, "DOOR ASSEMBLY : Removal
and Installation".
NO >> GO TO 2.
2.CHECK DOOR LOCK ACTUATOR CIRCUIT
1. Disconnect BCM connector.
2. Check continuity between BCM harness connector and front door lock assembly (driver side) harness
connector.
3. Check continuity between BCM harness connector and ground.
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-78, "Removal and Installation".
NO >> Repair or replace harness.
PASSENGER SIDE
(+)
(–) ConditionVoltage (V)
(Approx.) Front door lock assembly (driver side)
Connector Terminal
D91
GroundDoor lock and un-
lock switchLOCK 0 → Battery voltage → 0
2 UNLOCK 0 → Battery voltage → 0
BCM Front door lock assembly (driver side)
Continuity
Connector Terminal Connector Terminal
M1198
D91
Existed
92
BCM
GroundContinuity
Connector Terminal
M1198
Not existed
9

DLK-62
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR LOCK ACTUATOR
PASSENGER SIDE : Description
INFOID:0000000003794851
Locks/unlocks the door with the signal from BCM.
PASSENGER SIDE : Component Function CheckINFOID:0000000003794852
1.CHECK FUNCTION
1. Use CONSULT-III to perform Active Test (“DOOR LOCK”).
2. Touch “ALL LCK” or “ALL UNLK” to check that it works normally.
Is the inspection result normal?
YES >> Door lock actuator is OK.
NO >> Refer to DLK-62, "
PASSENGER SIDE : Diagnosis Procedure".
PASSENGER SIDE : Diagnosis ProcedureINFOID:0000000003794853
1.CHECK DOOR LOCK ACTUATOR OUTPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect front door lock assembly (passenger side).
3. Check voltage between front door lock assembly (passenger side) harness connector and ground.
Is the inspection result normal?
YES >> Replace front door lock assembly (passenger side). Refer to DLK-222, "DOOR LOCK : Removal
and Installation".
NO >> GO TO 2.
2.CHECK DOOR LOCK ACTUATOR CIRCUIT
1. Disconnect BCM connector.
2. Check continuity between BCM harness connector and front door lock assembly (passenger side) har-
ness connector.
3. Check continuity between BCM harness connector and ground.
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-78, "Removal and Installation".
NO >> Repair or replace harness.
REAR LH
REAR LH : DescriptionINFOID:0000000003794854
Locks/unlocks the door with the signal from BCM.
(+)
(–) ConditionVoltage (V)
(Approx.) Front door lock assembly (passenger side)
Connector Terminal
D481
GroundDoor lock and
unlock switchUNLOCK 0 → Battery voltage → 0
2LOCK0 → Battery voltage → 0
BCM Front door lock assembly (passenger side)
Continuity
Connector Terminal Connector Terminal
M1195
D481
Existed
82
BCM
GroundContinuity
Connector Terminal
M1195
Not existed
8

DOOR LOCK ACTUATOR
DLK-63
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
REAR LH : Component Function CheckINFOID:0000000003794855
1.CHECK FUNCTION
1. Use CONSULT-III to perform Active Test (“DOOR LOCK”).
2. Touch “ALL LCK” or “ALL UNLK” to check that it works normally.
Is the inspection result normal?
YES >> Door lock actuator is OK.
NO >> Refer to DLK-63, "
REAR LH : Diagnosis Procedure".
REAR LH : Diagnosis ProcedureINFOID:0000000003794856
1.CHECK DOOR LOCK ACTUATOR OUTPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect rear door lock assembly LH.
3. Check voltage between rear door lock assembly LH harness connector and ground.
Is the inspection result normal?
YES >> Replace rear door lock assembly LH. Refer to DLK-202, "DOOR ASSEMBLY : Removal and
Installation".
NO >> GO TO 2.
2.CHECK DOOR LOCK ACTUATOR CIRCUIT
1. Disconnect BCM connector.
2. Check continuity between BCM harness connector and rear door lock assembly LH harness connector.
3. Check continuity between BCM harness connector and ground.
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-78, "Removal and Installation".
NO >> Repair or replace harness.
REAR RH
REAR RH : DescriptionINFOID:0000000003794857
Locks/unlocks the door with the signal from BCM.
REAR RH : Component Function CheckINFOID:0000000003794858
1.CHECK FUNCTION
(+)
(–) ConditionVoltage (V)
(Approx.) Rear door lock assembly LH
Connector Terminal
D851
GroundDoor lock and
unlock switchLOCK 0 → Battery voltage → 0
2 UNLOCK 0 → Battery voltage → 0
BCM Rear door lock assembly LH
Continuity
Connector Terminal Connector Terminal
M1198
D851
Existed
10 2
BCM
GroundContinuity
Connector Terminal
M1198
Not existed
10

DLK-64
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR LOCK ACTUATOR
1. Use CONSULT-III to perform Active Test (“DOOR LOCK”).
2. Touch “ALL LCK” or “ALL UNLK” to check that it works normally.
Is the inspection result normal?
YES >> Door lock actuator is OK.
NO >> Refer to DLK-64, "
REAR RH : Diagnosis Procedure".
REAR RH : Diagnosis ProcedureINFOID:0000000003794859
1.CHECK DOOR LOCK ACTUATOR OUTPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect rear door lock assembly RH.
3. Check voltage between rear door lock assembly RH harness connector and ground.
Is the inspection result normal?
YES >> Replace rear door lock assembly RH. Refer to DLK-208, "DOOR ASSEMBLY : Removal and
Installation".
NO >> GO TO 2.
2.CHECK DOOR LOCK ACTUATOR CIRCUIT
1. Disconnect BCM connector.
2. Check continuity between BCM harness connector and rear door lock assembly RH harness connector.
3. Check continuity between BCM harness connector and ground.
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-78, "Removal and Installation".
NO >> Repair or replace harness.
(+)
(–)Condition of door lock and
unlock switchVoltage (V)
(Approx.) Rear door lock assembly RH
Connector Terminal
D1051
GroundUNLOCK 0 → Battery voltage → 0
2LOCK0 → Battery voltage → 0
BCM Rear door lock assembly RH
Continuity
Connector Terminal Connector Terminal
M1198
D1052
Existed
10 1
BCM
GroundContinuity
Connector Terminal
M1198
Not Existed
10
