NISSAN TEANA 2008 Service Manual

RF-90
< ON-VEHICLE REPAIR >
SUNROOF UNIT ASSEMBLY
2. Install the windshield molding.
 Cut off the adhesive (2) of the windshield glass (1) top side as
shown in the figure.
 Apply paint primer to adhesive contact surface of the windshield molding.
 Apply the groove with adhesive, and stick windshield molding.
3. Clean bonded area on sunroof frame and roof panel with white gasoline.
4. Apply paint primer along the entire circumference of sunroof frame.
CAUTION:
There are 2 types of primer. Never confuse the application methods.
Paint primer: for painted surfaces
Glass primer: for glass
5. Apply paint primer on areas where adhesive contacts on the side of vehicle body.
CAUTION:
If paint primer adheres to a painted surface other than bonding area, or if it overflows, quickly
remove it with white gasoline.
6. After applying primers, apply the adhesive along the entire circumference of the sunroof unit assembly as
shown in the figure, and within the time specified in the instructions for the adhesive.
Open adhesive by cutting off the nozzle tip and set it in a sealant gun.
7. Align matching marks on body and sunroof unit assembly. Install sunroof unit assembly to the body.
8. Press entire surface of glass lightly to fit it completely.
9. Using a spatula, repair any adhesive overflow or shortage to make the surface smooth.
10. Remove protective tape.
11. Temporarily tighten the mounting bolts and nuts to the sunroof unit assembly.
12. Tighten the installation points diagonally around the roof opening.
13. Install the glass lid. Refer to RF-80, "
Removal and Installation".
NOTE:
After installation, carry out fitting adjustment. Refer to RF-81, "
Adjustment".
14. Install the headlining. Refer to INT-54, "
SUNROOF : Removal and Installation".
15. Check for water leaks.
NOTE:
 Perform the water leakage check more than 2 hours after sunroof unit assembly installation.
 After glass lid fitting adjustment, carry out water leakage check by spreading water on the whole roof.
Disassembly and AssemblyINFOID:0000000003812893
DISASSEMBLY
1. Remove the wind deflector. Refer to RF-97, "Removal and Installation".
2. Remove the front sunshade and rear sunshade. Refer to RF-99, "
Removal and Installation".
3. Remove the weather-strip.
ASSEMBLY
Assemble in the reverse order of disassembly.
JMKIA2552ZZ

FRONT SUNROOF GLASS
RF-91
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
L
MA
B
RF
N
O
P
FRONT SUNROOF GLASS
Exploded ViewINFOID:0000000003812894
Removal and InstallationINFOID:0000000003812895
REMOVAL
1. Remove the roof side finisher. Refer to RF-88, "Removal and Installation".
2. Fully open the glass lid.
3. Remove the windshield molding. Refer to GW-11, "
Removal and Installation".
4. Paint matching marks on body before removing the front sunroof glass.
1. Weather-strip 2. Front sunroof glass 3. Windshield glass
4. Windshield molding 5. Adhesive 6. Sunroof frame
7. Primer
Refer to GI-4, "
Components" for symbols in the figure.
JMKIA2508GB

RF-92
< ON-VEHICLE REPAIR >
FRONT SUNROOF GLASS
5. Apply protective tape around the roof panel and windshield to protect the surface from damage.
6. Remove weather-strip.
7. Cut adhesive.
 Pass piano wire though the adhesive with a wire pierce.
 Tie both ends of piano wire to wire grip.
 Pull piano wire in turn and cut off adhesive.
8. Remove front sunroof glass from vehicle.
WARNING:
Always use safety glasses and heavy gloves to help prevent glass splinters from entering your eyes
or cutting your hands when cutting the glass from the vehicle.
CAUTION:
Never reuse the front sunroof glass which has been removed once.
INSTALLATION
WARNING:
 Keep heat and open flames away as primers and adhesive are flammable.
 The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Never let
them in contact with the skin and eyes.
 Use in an open, well ventilated location. Never breathe the vapors. They may be harmful if inhaled.
Move immediately to an area with fresh air if affected by vapor inhalation.
NOTE:
 Use a genuine Nissan Urethane Adhesive Kit (if available) or an equivalent and follow the instructions fur-
nished with it.
 Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely
cured (approximately 24 hours). Curing time varies with temperature and humidity.
1. Using a knife or spatula, trim the adhesive (sealant) remaining
on body down to approximately 2 mm thick (a) so that the con-
tour becomes smooth.
CAUTION:
If bonded area on sunroof frame is scratched, always repair
it with 2-component urethane. Never use lacquer.
2. Install the windshield molding.
 Cut off the adhesive (2) of the windshield glass (1) top side as
shown in the figure.
 Apply paint primer to adhesive contact surface of the windshield molding.
 Apply the groove with adhesive, and stick windshield molding.
3. Clean bonded area on glass with white gasoline.
4. Apply glass primer along the entire circumference of glass.
CAUTION:
There are 2 types of primer. Never confuse the application methods.
Paint primer: for painted surfaces
Glass primer: for glass
JMKIA0307ZZ
JMKIA2552ZZ

FRONT SUNROOF GLASS
RF-93
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
L
MA
B
RF
N
O
P
5. Apply paint primer on areas where adhesive contacts on the side of sunroof frame.
CAUTION:
If paint primer adheres to a painted surface other than bonding area, or if it overflows, quickly
remove it with white gasoline.
6. After applying primers, apply the adhesive along the entire circumference of the glass as shown in the fig-
ure, and within the time specified in the instructions for the adhesive.
Open adhesive by cutting off the nozzle tip and set it in a sealant gun.
7. After setting suction lifter to glass, align matching marks on sunroof frame and glass. Install glass to the
sunroof frame.
8. Press glass till positioning ribs (1) faces sunroof frame (2).
9. Using a spatula, repair any adhesive overflow or shortage to make the surface smooth.
10. Remove protective tape.
11. Install roof side finisher. Refer to RF-88, "
Removal and Installation".
JMKIA2553ZZ

RF-94
< ON-VEHICLE REPAIR >
REAR SUNROOF GLASS
REAR SUNROOF GLASS
Exploded ViewINFOID:0000000003812896
Removal and InstallationINFOID:0000000003812897
REMOVAL
1. Remove the roof side finisher. Refer to RF-88, "Removal and Installation".
2. Remove the glass lid. Refer to RF-80, "
Removal and Installation".
3. Paint matching marks on body before removing the rear sunroof glass.
4. Apply protective tape around the roof panel and sunroof unit to protect the surface from damage.
1. Rear sunroof glass 2. Weather-strip 3. Adhesive
4. Sunroof frame 5. Primer 6. Roof panel
7. Rear window glass
Refer to GI-4, "
Components" for symbols in the figure.
JMKIA2509GB

REAR SUNROOF GLASS
RF-95
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
L
MA
B
RF
N
O
P
5. Remove weather-strip.
6. Cut adhesive.
 Cut the resin part of the rear sunroof glass rear using cutter
(A).
 Pass piano wire though the adhesive with a wire pierce.
 Tie both ends of piano wire to wire grip.
 Pull piano wire in turn and cut off adhesive.
7. Remove rear sunroof glass from vehicle using suction lifter.
WARNING:
Always use safety glasses and heavy gloves to help prevent glass splinters from entering your eyes
or cutting your hands when cutting the glass from the vehicle.
CAUTION:
Never reuse the rear sunroof glass which has been removed once.
INSTALLATION
WARNING:
 Keep heat and open flames away as primers and adhesive are flammable.
 The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Never let
them in contact with the skin and eyes.
 Use in an open, well ventilated location. Never breathe the vapors. They may be harmful if inhaled.
Move immediately to an area with fresh air if affected by vapor inhalation.
CAUTION:
After installing the rear sunroof glass, perform the leak test and check that there is no malfunction.
NOTE:
 Use a genuine Nissan Urethane Adhesive Kit (if available) or an equivalent and follow the instructions fur-
nished with it.
 Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely
cured (approximately 24 hours). Curing time varies with temperature and humidity.
1. Using a knife or spatula, trim the adhesive (sealant) remaining
on body down to approximately 2 mm thick (a) so that the con-
tour becomes smooth.
CAUTION:
If bonded area on sunroof frame is scratched, always repair
it with 2-component urethane. Never use lacquer.
2. Clean bonded area on glass with white gasoline.
3. Apply glass primer along the entire circumference of glass.
CAUTION:
There are 2 types of primer. Never confuse the application methods.
Paint primer: for painted surfaces
Glass primer: for glass
4. Apply paint primer on areas where adhesive contacts on the side of sunroof frame.
CAUTION:
JMKIA2510ZZ
JMKIA0307ZZ

RF-96
< ON-VEHICLE REPAIR >
REAR SUNROOF GLASS
If paint primer adheres to a painted surface other than bonding area, or if it overflows, quickly
remove it with white gasoline.
5. After applying primers, apply the adhesive along the entire circumference of the glass as shown in the fig-
ure, and within the time specified in the instructions for the adhesive.
Open adhesive by cutting off the nozzle tip and set it in a sealant gun.
6. After setting suction lifter to glass, align matching marks on sunroof frame and glass. Install glass to the
sunroof frame.
7. Press glass till positioning ribs (1) faces sunroof frame (2).
8. Using a spatula, repair any adhesive overflow or shortage to make the surface smooth.
9. Remove protective tape.
10. Install glass lid. Refer to RF-80, "
Removal and Installation".
11. Install roof side finisher. Refer to RF-88, "
Removal and Installation".
12. Check for water leaks.
NOTE:
 Perform the water leakage check more than 2 hours after rear sunroof glass installation.
 After glass lid fitting adjustment, carry out water leakage check by spreading water on the whole roof.
JMKIA2554ZZ

WIND DEFLECTOR
RF-97
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
L
MA
B
RF
N
O
P
WIND DEFLECTOR
Exploded ViewINFOID:0000000003812898
Removal and InstallationINFOID:0000000003812899
REMOVAL
1. Fully open the glass lid.
2. Remove the lnner blind. Rerer to RF-80, "
Removal and Installation".
3. Remove the wind deflector.
1. Weather-strip 2. Wind deflector 3. Sunroof frame
4. Front sunshade 5. Sunshade cover 6. Rear sunshade
Refer to GI-4, "
Components" for symbols in the figure.
JMKIA2489GB

RF-98
< ON-VEHICLE REPAIR >
WIND DEFLECTOR
 Push and slide the fastener as shown by the arrows (1) and
(2) in the figure to remove.
 Remove the screws (A), and then remove wind deflector (1).
INSTALLATION
Install in the reverse order of removal.
: Vehicle front
JMKIA2192ZZ
JMKIA2514ZZ

SUNSHADE
RF-99
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
L
MA
B
RF
N
O
P
SUNSHADE
Exploded ViewINFOID:0000000003843880
Removal and InstallationINFOID:0000000003812901
REMOVAL
1. Remove the headlining. Refer to INT-54, "SUNROOF : Removal and Installation".
2. Remove the sunshade cover.
Remove the screws, and then sunshade cover.
CAUTION:
Be careful not to deform the sunshade covers during removal or installation.
3. Remove the front sunshade and rear sunshade.
1. Weather-strip 2. Wind deflector 3. Sunroof frame
4. Front sunshade 5. Sunshade cover 6. Rear sunshade
Refer to GI-4, "
Components" for symbols in the figure.
JMKIA2489GB
