NISSAN TEANA 2008 Service Manual

TM-208
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
U1000 CAN COMM CIRCUIT
COMPONENT DIAGNOSIS
U1000 CAN COMM CIRCUIT
DescriptionINFOID:0000000003806376
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent malfunction detection ability.
Many electronic control units are equipped onto a vehicle, and each control unit shares information and links
with other control units during operation (not independent). In CAN communication, control units are con-
nected with 2 communication lines (CAN-H and CAN-L) allowing a high rate of information transmission with
less wiring. Each control unit transmits/receives data but selectively reads required data only.
DTC LogicINFOID:0000000003806377
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
NOTE:
If “DTC CONFIRMATION PROCEDURE” has been previously performed, always turn ignition switch
OFF. Then wait at least 10 seconds before performing the next test.
Perform the following procedure to confirm the malfunction is eliminated after the repair.
1.CHECK DTC DETECTION
With CONSULT-III
1. Turn ignition switch ON.
2. Start engine and wait for at least 6 seconds.
3. Select “Self Diagnostic Results” mode for “TRANSMISSION”.
With GST
Follow the procedure “With CONSULT-III”.
Is
“U1000 CAN COMM CIRCUIT” detected?
YES >> Go to TM-208, "Diagnosis Procedure".
NO >> Check intermittent incident. Refer to GI-35, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000003806378
1.CHECK CAN COMMUNICATION CIRCUIT
With CONSULT-III
1. Turn ignition switch ON and start engine.
2. Select “Self Diagnostic Results” mode for “TRANSMISSION”.
Is
“U1000 CAN COMM CIRCUIT” indicated?
YES >> Go to LAN section. Refer to LAN-22, "CAN System Specification Chart".
NO >> Check intermittent incident. Refer to GI-35, "
Intermittent Incident".
DTCItem
(CONSULT-III screen term)Malfunction is detected
when...Possible cause
U1000 CAN COMM CIRCUITWhen TCM is not transmitting
or receiving CAN communica-
tion signal for 2 seconds or
more.Harness or connectors
(CAN communication line is
open or shorted.)

U1010 CONTROL UNIT (CAN)
TM-209
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
U1010 CONTROL UNIT (CAN)
DescriptionINFOID:0000000003806379
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent malfunction detection ability.
Many electronic control units are equipped onto a vehicle, and each control unit shares information and links
with other control units during operation (not independent). In CAN communication, control units are con-
nected with 2 communication lines (CAN-H and CAN-L) allowing a high rate of information transmission with
less wiring. Each control unit transmits/receives data but selectively reads required data only.
DTC LogicINFOID:0000000003806380
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
NOTE:
If “DTC CONFIRMATION PROCEDURE” has been previously performed, always turn ignition switch
OFF. Then wait at least 10 seconds before performing the next test.
Perform the following procedure to confirm the malfunction is eliminated after the repair.
1.CHECK DTC DETECTION
With CONSULT-III
1. Turn ignition switch ON.
2. Start engine and wait for at least 6 seconds.
3. Select “Self Diagnostic Results” mode for “TRANSMISSION”.
Is
“U1010 CONTROL UNIT (CAN)” detected?
YES >> Go to TM-209, "Diagnosis Procedure".
NO >> Check intermittent incident. Refer to GI-35, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000003806381
1.CHECK CAN COMMUNICATION CIRCUIT
With CONSULT-III
1. Turn ignition switch ON and start engine.
2. Select “Self Diagnostic Results” mode for “TRANSMISSION”.
Is
“U1010 CONTROL UNIT (CAN)” indicated?
YES >> Replace the TCM. Refer to TM-315, "Exploded View".
NO >> Check intermittent incident. Refer to GI-35, "
Intermittent Incident".
DTCItem
(CONSULT-III screen term)Malfunction is detected when... Possible cause
U1010 CONTROL UNIT (CAN)When detecting error during the
initial diagnosis of CAN control-
ler to TCM.Harness or connectors
(CAN communication line is
open or shorted.)

TM-210
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
P0703 STOP LAMP SWITCH
P0703 STOP LAMP SWITCH
DescriptionINFOID:0000000003806382
BCM detects ON/OFF state of the stop lamp switch and transmits the data to the CVT control unit via CAN
communication by converting the data to a signal.
DTC LogicINFOID:0000000003806383
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC CONFIRMATION PROCEDURE” has been previously performed, always turn ignition switch
OFF. Then wait at least 10 seconds before performing the next test.
Perform the following procedure to confirm the malfunction is eliminated after the repair.
1.CHECK DTC DETECTION
With CONSULT-III
1. Turn ignition switch ON.
2. Start engine.
3. Drive vehicle for at least 3 consecutive seconds.
4. Select “Self Diagnostic Results” mode for “TRANSMISSION”.
Is
“P0703 BRAKE SW/CIRC” detected?
YES >> Go to TM-210, "Diagnosis Procedure".
NO >> Check intermittent incident. Refer to GI-35, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000003806384
1.CHECK STOP LAMP SWITCH CIRCUIT
1. Check and adjust the installation position of stop lamp switch. Refer to BR-6, "
Inspection and Adjustment".
2. Disconnect BCM connector.
3. Check voltage between BCM vehicle side harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 2.
2.CHECK HARNESS BETWEEN STOP LAMP SWITCH AND BCM (PART 1)
1. Disconnect stop lamp switch connector.
2. Check continuity between stop lamp switch vehicle side harness connector terminal and BCM vehicle side
harness connector terminal.
DTCItem
(CONSULT-III screen term)Malfunction is detected when... Possible cause
P0703 BRAKE SW/CIRCWhen the brake switch does
not switch to ON or OFF. Harness or connectors
- (Stop lamp switch, and BCM
circuit are open or shorted.)
- (CAN communication line is
open or shorted.)
 Stop lamp switch
BCM vehicle side harness connector
GroundCondition Voltage (Approx.)
Connector Terminal
M123 118Depressed brake pedal Battery voltage
Released brake pedal 0 V

P0703 STOP LAMP SWITCH
TM-211
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace damaged parts.
3.CHECK HARNESS BETWEEN STOP LAMP SWITCH AND BCM (PART 2)
Check continuity between BCM vehicle side harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace damaged parts.
4.CHECK STOP LAMP SWITCH
Check stop lamp switch. Refer to TM-211, "
Component Inspection (Stop Lamp Switch)".
Is the inspection result normal?
YES >> Check the following.
 Harness for short or open between battery and stop lamp switch
 10 A fuse (No. 7, located in the fuse and fusible link block)
NO >> Repair or replace damaged parts.
5.CHECK BCM
With CONSULT-III
1. Turn ignition switch OFF.
2. Connect BCM connector.
3. Turn ignition switch ON.
4. Select “BRAKE SW 1” in “Data Monitor” mode for “BCM” and verify the proper operation of ON/OFF. Refer
to BCS-42, "
Reference Value".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Replace BCM. Refer to BCS-78, "
Exploded View".
6.DETECT MALFUNCTIONING ITEMS
Check TCM connector pin terminals for damage or loose connection with harness connector.
Is the inspection result normal?
YES >> Replace TCM. Refer to TM-315, "Exploded View".
NO >> Repair or replace damaged parts.
Component Inspection (Stop Lamp Switch)INFOID:0000000003806385
1.CHECK STOP LAMP SWITCH
Check continuity between stop lamp switch connector terminals.
Is the inspection result normal?
YES >> INSPECTION END
Stop lamp switch vehicle side harness connector BCM vehicle side harness connector
Continuity
Connector Terminal Connector Terminal
E115 2 M123 118 Existed
BCM vehicle side harness connector
GroundContinuity
Connector Terminal
M123 118 Not existed
Stop lamp switch connector
Condition Continuity
Connector Terminal
E115 1 2Depressed brake pedal Existed
Released brake pedal Not existed

TM-212
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
P0703 STOP LAMP SWITCH
NO >> Repair or replace the stop lamp switch. Refer to BR-17, "Exploded View".

P0705 PARK/NEUTRAL POSITION SWITCH
TM-213
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
P0705 PARK/NEUTRAL POSITION SWITCH
DescriptionINFOID:0000000003806386
The PNP switch detects the selector lever position and sends a signal to the TCM.
DTC LogicINFOID:0000000003806387
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC CONFIRMATION PROCEDURE” has been previously performed, always turn ignition switch
OFF. Then wait at least 10 seconds before performing the next test.
Perform the following procedure to confirm the malfunction is eliminated after the repair.
1.CHECK DTC DETECTION
With CONSULT-III
1. Turn ignition switch ON.
2. Select “Data Monitor” mode for “TRANSMISSION”.
3. Start engine.
4. Drive vehicle and maintain the following conditions for at least 2 consecutive seconds.
With GST
Follow the procedure “With CONSULT-III”.
Is
“P0705 PNP SW/CIRC” detected?
YES >> Go to TM-213, "Diagnosis Procedure".
NO >> Check intermittent incident. Refer to GI-35, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000003806388
1.CHECK POWER SOURCE
1. Turn ignition switch OFF.
2. Disconnect PNP switch connector.
3. Turn ignition switch ON.
4. Check voltage between PNP switch vehicle side harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Check the following. If NG, repair or replace damaged parts.
 Harness for short or open between ignition switch and PNP switch
 10 A fuse (No. 4, located in the fuse block J/B)
DTCItem
(CONSULT-III screen term)Malfunction is detected when... Possible cause
P0705 PNP SW/CIRCTCM does not receive the cor-
rect voltage signal (based on
the gear position) from the
switch. Harness or connectors
(PNP switches circuit is open
or shorted.)
 PNP switch
VEHICLE SPEED : More than 10 km/h (6 MPH)
ENG SPEED : More than 450 rpm
ACC PEDAL OPEN : More than 1.0/8
PNP switch vehicle side harness connector
GroundVoltage (Approx.)
Connector Terminal
Battery voltage
F57 3

TM-214
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
P0705 PARK/NEUTRAL POSITION SWITCH
 Ignition switch
2. CHECK HARNESS BETWEEN TCM AND PNP SWITCH (PART 1)
1. Turn ignition switch OFF.
2. Disconnect TCM connector.
3. Check continuity between TCM vehicle side harness connector terminals and PNP switch vehicle side
harness connector terminals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace damaged parts.
3. CHECK HARNESS BETWEEN TCM AND PNP SWITCH (PART 2)
Check continuity between TCM vehicle side harness connector terminals and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace damaged parts.
4.CHECK PNP SWITCH
1. Remove control cable from manual lever. Refer to TM-319, "
Exploded View".
2. Check PNP switch. Refer to TM-214, "
Component Inspection (Park/Neutral Position Switch)".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace damaged parts.
5. DETECT MALFUNCTIONING ITEM
Check TCM connector pin terminals for damage or loose connection with harness connector.
Is the inspection result normal?
YES >> Replace TCM. Refer to TM-315, "Exploded View".
NO >> Repair or replace damaged parts.
Component Inspection (Park/Neutral Position Switch)INFOID:0000000003806389
1.CHECK PNP SWITCH
Check continuity of PNP switch connector terminals.
TCM vehicle side harness connector PNP switch vehicle side harness connector
Continuity
Connector Terminal Connector Terminal
F231
F575
Existed 26
37
48
11 4
TCM vehicle side harness connector
GroundContinuity
Connector Terminal
F231
Not existed 2
3
4
11

P0705 PARK/NEUTRAL POSITION SWITCH
TM-215
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace CVT assembly. Refer to TM-332, "
Exploded View".
PNP switch connector
Condition Continuity
Connector Terminal
F5712
Manual lever in “P” position
Existed
*
*Continuity should not exist in positions
other than the specified positions. 34
3 5 Manual lever in “R” position
12
Manual lever in “N” position
36
3 7 Manual lever in “D” position
3 8 Manual lever in “L” position

TM-216
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
P0710 CVT FLUID TEMPERATURE SENSOR
P0710 CVT FLUID TEMPERATURE SENSOR
DescriptionINFOID:0000000003806390
The CVT fluid temperature sensor detects the CVT fluid temperature and sends the signal to the TCM.
DTC LogicINFOID:0000000003806391
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC CONFIRMATION PROCEDURE” has been previously performed, always turn ignition switch
OFF. Then wait at least 10 seconds before performing the next test.
Perform the following procedure to confirm the malfunction is eliminated after the repair.
1.CHECK DTC DETECTION
With CONSULT-III
1. Turn ignition switch ON.
2. Select “Data Monitor” mode for “TRANSMISSION”.
3. Start engine and maintain the following conditions for at least 10 minutes (total).
With GST
Follow the procedure “With CONSULT-III”.
Is
“P0710 ATF TEMP SEN/CIRC” detected?
YES >> Go to TM-216, "Diagnosis Procedure".
NO >> Check intermittent incident. Refer to GI-35, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000003806392
1. CHECK CVT FLUID TEMPERATURE SENSOR CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect the TCM connector.
3. Check resistance between TCM vehicle side harness connector terminals.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 2.
2. CHECK HARNESS BETWEEN TCM AND CVT UNIT (CVT FLUID TEMPERATURE SENSOR) (PART 1)
DTCItem
(CONSULT-III screen term)Malfunction is detected when... Possible cause
P0710 ATF TEMP SEN/CIRCDuring running, the CVT fluid
temperature sensor signal volt-
age is excessively high or low. Harness or connectors
(Sensor circuit is open or
shorted.)
 CVT fluid temperature sensor
VEHICLE SPEED : 10 km/h (6 MPH) or more
ENG SPEED : 450 rpm more than
ACC PEDAL OPEN : More than 1.0/8
RANGE : “D” position
TCM vehicle side harness connector
Condition Resistance (Approx.)
Connector Terminal
F23 13 25When CVT fluid temperature is 20°C (68°F) 6.5 kΩ
When CVT fluid temperature is 80°C (176°F) 0.9 kΩ

P0710 CVT FLUID TEMPERATURE SENSOR
TM-217
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
1. Disconnect CVT unit connector.
2. Check continuity between TCM vehicle side harness connector terminals and CVT unit vehicle side har-
ness connector terminals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace damaged parts.
3. CHECK HARNESS BETWEEN TCM AND CVT UNIT (CVT FLUID TEMPERATURE SENSOR) (PART 2)
Check continuity between TCM vehicle side harness connector terminals and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace damaged parts.
4. CHECK CVT FLUID TEMPERATURE SENSOR
Check CVT fluid temperature sensor. Refer to TM-217, "
Component Inspection (CVT Fluid Temperature Sen-
sor)".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace damaged parts.
5.CHECK TCM
Check TCM connector pin terminals for damage or loose connection with harness connector.
Is the inspection result normal?
YES >> Replace the TCM. Refer to TM-315, "Exploded View".
NO >> Repair or replace damaged parts.
Component Inspection (CVT Fluid Temperature Sensor)INFOID:0000000003806393
1.CHECK CVT FLUID TEMPERATURE SENSOR
Check resistance between CVT unit harness connector terminals.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace the transaxle assembly. Refer to TM-332, "
Exploded View".
TCM vehicle side harness connector CVT unit vehicle side harness connector
Continuity
Connector Terminal Connector Terminal
F2313
F2417
Existed
25 19
TCM vehicle side harness connector
GroundContinuity
Connector Terminal
F2313
Not existed
25
CVT unit harness connector
Condition Resistance (Approx.)
Connector Terminal
F24 17 19When CVT fluid temperature is 20°C (68°F) 6.5 kΩ
When CVT fluid temperature is 80°C (176°F) 0.9 kΩ
