< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
P0776 PRESSURE CONTROL SOLENOID B PERFORMANCE (SEC PRESSURE
SOLENOID VALVE)
P0776 PRESSURE CONTROL SOLENOID B PERFORMANCE (SEC PRES-
SURE SOLENOID VALVE)
DescriptionINFOID:0000000003806423
The pressure control solenoid valve B (secondary pressure solenoid valve) regulates the secondary pressure
to suit the driving condition in response to a signal sent from the TCM.
DTC LogicINFOID:0000000003806424
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC CONFIRMATION PROCEDURE” has been previously performed, always turn ignition switch
OFF. Then wait at least 10 seconds before performing the next test.
Perform the following procedure to confirm the malfunction is eliminated after the repair.
1.CHECK DTC DETECTION
With CONSULT-III
1. Turn ignition switch ON.
2. Select “Data Monitor” mode for “TRANSMISSION”.
3. Start engine and maintain the following conditions for at least 30 consecutive seconds.
With GST
Follow the procedure “With CONSULT-III”.
Is
“P0776 PRS CNT SOL/B FCTN” detected?
YES >> Go to TM-238, "Diagnosis Procedure".
NO >> Check intermittent incident. Refer to GI-35, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000003806425
1.CHECK LINE PRESSURE
Perform line pressure test. Refer to TM-308, "
Inspection and Judgment".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace damaged parts. Refer to TM-308, "
Inspection and Judgment".
DTCItem
(CONSULT-III screen term)Malfunction is detected when... Possible cause
P0776 PRS CNT SOL/B FCTNSecondary pressure is too high
or too low compared with the
commanded value while driv-
ing. Harness or connectors
(Solenoid circuit is open or
shorted.)
 Pressure control solenoid
valve B (secondary pressure
solenoid valve system)
 Transmission fluid pressure
sensor A (secondary pres-
sure sensor)
 Line pressure control system
ATF TEMP SEN : 1.0 − 2.0 V
ACC PEDAL OPEN : More than 1.0/8
RANGE : “D” position
VEHICLE SPEED : 10 km/h (6 MPH) More than
Driving location : Driving the vehicle uphill (increased engine load) will help maintain the
driving conditions required for this test.

P0776 PRESSURE CONTROL SOLENOID B PERFORMANCE (SEC PRESSURE
SOLENOID VALVE)
TM-239
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
2.CHECK PRESSURE CONTROL SOLENOID VALVE B (SECONDARY PRESSURE SOLENOID VALVE)
Check pressure control solenoid valve B (Secondary pressure solenoid valve). Refer to TM-239, "
Component
Inspection [Pressure Control Solenoid Valve B (Secondary Pressure Solenoid Valve)]".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace damaged parts.
3.CHECK PRESSURE CONTROL SOLENOID VALVE A (LINE PRESSURE SOLENOID VALVE)
Check pressure control solenoid valve A (Line pressure solenoid valve). Refer to TM-239, "
Component
Inspection [Pressure Control Solenoid Valve A (Line Pressure Solenoid Valve)]".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace damaged parts.
4.CHECK TRANSMISSION FLUID PRESSURE SENSOR A (SECONDARY PRESSURE SENSOR) SYS-
TEM
Check transmission fluid pressure sensor A (secondary pressure sensor) system. Refer to TM-242, "
DTC
Logic".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace damaged parts.
5.DETECT MALFUNCTIONING ITEMS
Check TCM connector pin terminals for damage or loose connection with harness connector.
Is the inspection result normal?
YES >> Replace the TCM. Refer to TM-315, "Exploded View".
NO >> Repair or replace damaged parts.
Component Inspection [Pressure Control Solenoid Valve A (Line Pressure Solenoid
Va l v e ) ]
INFOID:0000000003806426
1.CHECK PRESSURE CONTROL SOLENOID VALVE A (LINE PRESSURE SOLENOID VALVE)
Check resistance between CVT unit harness connector terminal and ground.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace the transaxle assembly. Refer to TM-332, "
Exploded View".
Component Inspection [Pressure Control Solenoid Valve B (Secondary Pressure So-
lenoid Valve)]
INFOID:0000000003806427
1.CHECK PRESSURE CONTROL SOLENOID VALVE B (SECONDARY PRESSURE SOLENOID VALVE)
Check resistance between CVT unit harness connector terminal and ground.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace the transaxle assembly. Refer to TM-332, "
Exploded View".
CVT unit harness connector
GroundResistance (Approx.)
Connector Terminal
F24 2 3.0 – 9.0 Ω
CVT unit harness connector
GroundResistance (Approx.)
Connector Terminal
F24 3 3.0 – 9.0 Ω

TM-240
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
P0778 PRESSURE CONTROL SOLENOID B ELECTRICAL (SEC PRESSURE
SOLENOID VALVE)
P0778 PRESSURE CONTROL SOLENOID B ELECTRICAL (SEC PRES-
SURE SOLENOID VALVE)
DescriptionINFOID:0000000003806428
The pressure control solenoid valve B (secondary pressure solenoid valve) regulates the oil pump discharge
pressure to suit the driving condition in response to the signal sent from the TCM.
DTC LogicINFOID:0000000003806429
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
NOTE:
If “DTC CONFIRMATION PROCEDURE” has been previously performed, always turn ignition switch
OFF. Then wait at least 10 seconds before performing the next test.
Perform the following procedure to confirm the malfunction is eliminated after the repair.
1.CHECK DTC DETECTION
With CONSULT-III
1. Start engine.
2. Drive vehicle for at least 5 consecutive seconds.
3. Select “Self Diagnostic Results” mode for “TRANSMISSION”.
With GST
Follow the procedure “With CONSULT-III”.
Is
“P0778 PRS CNT SOL/B CIRC” detected?
YES >> Go to TM-240, "Diagnosis Procedure".
NO >> Check intermittent incident. Refer to GI-35, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000003806430
1.CHECK PRESSURE CONTROL SOLENOID VALVE B (SECONDARY PRESSURE SOLENOID VALVE)
CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect TCM connector.
3. Check resistance between TCM vehicle side harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 2.
2.CHECK HARNESS BETWEEN TCM AND CVT UNIT [PRESSURE CONTROL SOLENOID VALVE B (SEC-
ONDARY PRESSURE SOLENOID VALVE)] (PART 1)
1. Disconnect CVT unit connector.
DTCItem
(CONSULT-III screen term)Malfunction is detected when... Possible cause
P0778 PRS CNT SOL/B CIRC Normal voltage is not applied
to solenoid due to cut line,
short, etc.
 TCM detects as irregular by
comparing target value with
monitor value. Harness or connectors
(Sensor circuit is open or
shorted.)
 Pressure control solenoid
valve B (secondary pressure
solenoid valve)
TCM vehicle side harness connector
GroundResistance (Approx.)
Connector Terminal
F23 39 3.0 – 9.0 Ω

P0778 PRESSURE CONTROL SOLENOID B ELECTRICAL (SEC PRESSURE
SOLENOID VALVE)
TM-241
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
2. Check continuity between TCM vehicle side harness connector terminal and CVT unit vehicle side har-
ness connector terminal.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace damaged parts.
3.CHECK HARNESS BETWEEN TCM AND CVT UNIT [PRESSURE CONTROL SOLENOID VALVE B (SEC-
ONDARY PRESSURE SOLENOID VALVE)] (PART 2)
Check continuity between TCM vehicle side harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace damaged parts.
4.CHECK PRESSURE CONTROL SOLENOID VALVE B (SECONDARY PRESSURE SOLENOID VALVE)
Check pressure control solenoid valve B (secondary pressure solenoid valve). Refer to TM-241, "
Component
Inspection [Pressure Control Solenoid Valve B (Secondary Pressure Solenoid Valve)]".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace damaged parts.
5.DETECT MALFUNCTIONING ITEMS
Check TCM connector pin terminals for damage or loose connection with harness connector.
Is the inspection result normal?
YES >> Replace TCM. Refer to TM-315, "Exploded View".
NO >> Repair or replace damaged parts.
Component Inspection [Pressure Control Solenoid Valve B (Secondary Pressure So-
lenoid Valve)]
INFOID:0000000003806431
1.CHECK PRESSURE CONTROL SOLENOID VALVE B (SECONDARY PRESSURE SOLENOID VALVE)
Check resistance between CVT unit harness connector terminal and ground.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace the transaxle assembly. Refer to TM-332, "
Exploded View".
TCM vehicle side harness connector CVT unit vehicle side harness connector
Continuity
Connector Terminal Connector Terminal
F2339F24 3Existed
TCM vehicle side harness connector
GroundContinuity
Connector Terminal
F23 39 Not existed
CVT unit harness connector
GroundResistance (Approx.)
Connector Terminal
F24 3 3.0 – 9.0 Ω

TM-242
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
P0840 TRANSMISSION FLUID PRESSURE SENSOR A (SEC PRESSURE SEN-
SOR)
P0840 TRANSMISSION FLUID PRESSURE SENSOR A (SEC PRESSURE
SENSOR)
DescriptionINFOID:0000000003806436
The transmission fluid pressure sensor A (secondary pressure sensor) detects secondary pressure of CVT
and sends the signal to the TCM.
DTC LogicINFOID:0000000003806437
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
NOTE:
If “DTC CONFIRMATION PROCEDURE” has been previously performed, always turn ignition switch
OFF. Then wait at least 10 seconds before performing the next test.
Perform the following procedure to confirm the malfunction is eliminated after the repair.
1.CHECK DTC DETECTION
With CONSULT-III
1. Turn ignition switch ON.
2. Select “Data Monitor” mode for “TRANSMISSION”.
3. Make sure that output voltage of line temperature sensor is within the range specified below.
4. Start engine and wait for at least 5 consecutive seconds.
With GST
Follow the procedure “With CONSULT-III”.
Is
“P0840 TR PRS SENS/A CIRC” detected?
YES >> Go to TM-242, "Diagnosis Procedure".
NO >> Check intermittent incident. Refer to GI-35, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000003806438
1.CHECK INPUT SIGNAL
1. Start engine.
2. Check voltage between TCM connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 8.
NO >> GO TO 2.
2.CHECK POWER AND SENSOR GROUND
DTCItem
(CONSULT-III screen term)Malfunction is detected when... Possible cause
P0840 TR PRS SENS/A CIRCSignal voltage of the transmis-
sion fluid pressure sensor A
(secondary pressure sensor) is
too high or too low while driving. Transmission fluid pressure
sensor A (secondary pres-
sure sensor)
 Harness or connectors
(Switch circuit is open or
shorted.)
ATF TEMP SEN : 1.0 – 2.0 V
If it is out of range, drive the vehicle to decrease the voltage (warm up the fluid) or stop engine to increase the
voltage (cool down the fluid)
TCM connector
GroundCondition Voltage (Approx.)
Connector Terminal
F23 15 “N” position idle 1.0 V

P0840 TRANSMISSION FLUID PRESSURE SENSOR A (SEC PRESSURE SEN-
SOR)
TM-243
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Check voltage between TCM connector terminals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 5.
3.CHECK HARNESS BETWEEN TCM AND CVT UNIT [TRANSMISSION FLUID PRESSURE SENSOR A
(SECONDARY PRESSURE SENSOR)] (PART 1)
1. Turn ignition switch OFF.
2. Disconnect TCM connector and CVT unit connector.
3. Check continuity between TCM vehicle side harness connector terminal and CVT unit vehicle side har-
ness connector terminal.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace damaged parts.
4.CHECK HARNESS BETWEEN TCM AND CVT UNIT [TRANSMISSION FLUID PRESSURE SENSOR A
(SECONDARY PRESSURE SENSOR)] (PART 2)
Check continuity between TCM vehicle side harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace damaged parts.
5. CHECK HARNESS BETWEEN TCM AND CVT UNIT (SENSOR POWER AND SENSOR GROUND) (STEP
1)
1. Turn ignition switch OFF.
2. Disconnect TCM connector and CVT unit connector.
3. Check continuity between TCM vehicle side harness connector terminals and CVT unit vehicle side har-
ness connector terminals.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace damaged parts.
6.CHECK HARNESS BETWEEN TCM AND CVT UNIT (SENSOR POWER AND SENSOR GROUND) (STEP
2)
Check continuity between TCM vehicle side harness connector terminals and ground.
TCM connector
Voltage (Approx.)
ConnectorTe r m i n a l
(+) (−)
F23 26 25 5.0 V
TCM vehicle side harness connector CVT unit vehicle side harness connector
Continuity
Connector Terminal Connector Terminal
F2315F2423Existed
TCM vehicle side harness connector
GroundContinuity
Connector Terminal
F23 15 Not existed
TCM vehicle side harness connector CVT unit vehicle side harness connector
Continuity
Connector Terminal Connector Terminal
F2325
F2419
Existed
26 20

TM-244
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
P0840 TRANSMISSION FLUID PRESSURE SENSOR A (SEC PRESSURE SEN-
SOR)
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace damaged parts.
7.CHECK TCM
1. Replace with the same type of TCM. Refer to TM-315, "
Exploded View".
2. Connect each connector.
3. Perform “DTC CONFIRMATION PROCEDURE”. Refer to TM-242, "
DTC Logic".
Is
“P0840 TR PRS SENS/A CIRC” detected?
YES >> Replace transaxle assembly. Refer to TM-332, "Exploded View".
NO >> Replace TCM. Refer to TM-315, "
Exploded View".
8.DETECT MALFUNCTIONING ITEMS
Check TCM connector pin terminals for damage or loose connection with harness connector.
Is the inspection result normal?
YES >> Replace TCM. Refer to TM-315, "Exploded View".
NO >> Repair or replace damaged parts.
TCM vehicle side harness connector
GroundContinuity
Connector Terminal
F2325
Not existed
26

P0841 PRESSURE SENSOR FUNCTION
TM-245
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
P0841 PRESSURE SENSOR FUNCTION
DescriptionINFOID:0000000003806439
Using the engine load (throttle position), the primary pulley revolution speed, and the secondary pulley revolu-
tion speed as input signals, TCM changes the operating pressure of the primary pulley and the secondary pul-
ley and changes the groove width of the pulley to control the gear ratio.
DTC LogicINFOID:0000000003806440
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC CONFIRMATION PROCEDURE” has been previously performed, always turn ignition switch
OFF. Then wait at least 10 seconds before performing the next test.
Perform the following procedure to confirm the malfunction is eliminated after the repair.
1.CHECK DTC DETECTION
With CONSULT-III
1. Turn ignition switch ON.
2. Select “Data Monitor” mode for “TRANSMISSION”.
3. Start engine and maintain the following conditions for at least 12 consecutive seconds.
Is
“P0841 PRESS SEN/FNCTN” detected?
YES >> Go to TM-245, "Diagnosis Procedure".
NO >> Check intermittent incident. Refer to GI-35, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000003806441
1.CHECK LINE PRESSURE
Perform line pressure test. Refer to TM-308, "
Inspection and Judgment".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace damaged parts. Refer to TM-308, "
Inspection and Judgment".
2.CHECK TRANSMISSION FLUID PRESSURE SENSOR A (SECONDARY PRESSURE SENSOR) SYS-
TEM
Check transmission fluid pressure sensor A (secondary pressure sensor) system. Refer to TM-242, "
Descrip-
tion".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace damaged parts.
3.CHECK PRESSURE CONTROL SOLENOID VALVE A (LINE PRESSURE SOLENOID VALVE)
DTCItem
(CONSULT-III screen term)Malfunction is detected when... Possible cause
P0841 PRESS SEN/FNCTNSecondary pressure became
higher than line pressure. Transmission fluid pressure
sensor A (secondary pres-
sure sensor)
 Harness or connectors
(Sensor circuit is open or
shorted.)
VEHICLE SPEED : 40 km/h (25 MPH) More than
RANGE : “D” position

TM-246
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
P0841 PRESSURE SENSOR FUNCTION
Check line pressure solenoid valve. Refer to TM-246, "Component Inspection [Pressure Control Solenoid
Valve A (Line Pressure Solenoid Valve)]".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace damaged parts.
4.CHECK PRESSURE CONTROL SOLENOID VALVE B (SECONDARY PRESSURE SOLENOID VALVE)
Check secondary pressure solenoid valve. Refer to TM-246, "
Component Inspection [Pressure Control Sole-
noid Valve B (Secondary Pressure Solenoid Valve)]".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace damaged parts.
5.CHECK STEP MOTOR SYSTEM
Check step motor system. Refer to TM-261, "
Description".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace damaged parts.
6.DETECT MALFUNCTIONING ITEMS
Check TCM connector pin terminals for damage or loose connection with harness connector.
Is the inspection result normal?
YES >> Replace TCM. Refer to TM-315, "Exploded View".
NO >> Repair or replace damaged parts.
Component Inspection [Pressure Control Solenoid Valve A (Line Pressure Solenoid
Va l v e ) ]
INFOID:0000000003806442
1.CHECK PRESSURE CONTROL SOLENOID VALVE A (LINE PRESSURE SOLENOID VALVE)
Check resistance between CVT unit harness connector terminal and ground.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace the transaxle assembly. Refer to TM-332, "
Exploded View".
Component Inspection [Pressure Control Solenoid Valve B (Secondary Pressure So-
lenoid Valve)]
INFOID:0000000003806443
1.CHECK PRESSURE CONTROL SOLENOID VALVE B (SECONDARY PRESSURE SOLENOID VALVE)
Check resistance between CVT unit harness connector terminal and ground.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace the transaxle assembly. Refer to TM-332, "
Exploded View".
CVT unit harness connector
GroundResistance (Approx.)
Connector Terminal
F24 2 3.0 – 9.0 Ω
CVT unit harness connector
GroundResistance (Approx.)
Connector Terminal
F24 3 3.0 – 9.0 Ω

P0868 SECONDARY PRESSURE DOWN
TM-247
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
P0868 SECONDARY PRESSURE DOWN
DescriptionINFOID:0000000003806444
The pressure control solenoid valve B (secondary pressure solenoid valve) regulates the secondary pressure
to suit the driving condition in response to the signal sent from the TCM.
DTC LogicINFOID:0000000003806445
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC CONFIRMATION PROCEDURE” has been previously performed, always turn ignition switch
OFF. Then wait at least 10 seconds before performing the next test.
Perform the following procedure to confirm the malfunction is eliminated after the repair.
1.CHECK DTC DETECTION
With CONSULT-III
1. Turn ignition switch ON.
2. Select “Data Monitor” mode for “TRANSMISSION”.
3. Make sure that output voltage of CVT fluid temperature sensor is within the range specified below.
4. Start engine and maintain the following conditions for at least 10 consecutive seconds.
Is
“P0868 SEC/PRESS DOWN” detected?
YES >> Go to TM-247, "Diagnosis Procedure".
NO >> Check intermittent incident. Refer to GI-35, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000003806446
1.CHECK LINE PRESSURE
Perform line pressure test. Refer to TM-308, "
Inspection and Judgment".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace damaged parts. Refer to TM-308, "
Inspection and Judgment".
DTCItem
(CONSULT-III screen term)Malfunction is detected when... Possible cause
P0868 SEC/PRESS DOWNSecondary fluid pressure is too
low compared with the com-
manded value while driving. Harness or connectors
(Solenoid circuit is open or
shorted.)
 Pressure control solenoid
valve B (secondary pressure
solenoid valve) system
 Transmission fluid pressure
sensor A (secondary pres-
sure sensor)
 Line pressure control system
ATF TEMP SEN : 1.0 – 2.0 V
If it is out of range, drive the vehicle to decrease the voltage (warm up the fluid) or stop engine to increase the
voltage (cool down the fluid)
VEHICLE SPEED (accelerate
slowly): 0 → 50 km/h (31 MPH)
ACC PEDAL OPEN : 0.5/8 – 1.0/8
RANGE : “D” position
