NISSAN TEANA 2008 Service Manual

AV
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
AV-437
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITH NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
 AV COMM CIRCUIT [U1300]
 DVD DECK CONN [U1248]When either one of the following items is
detected:
 DVD player power supply and ground cir-
cuits are malfunctioning.
 AV communication circuits between
BOSE amp. and DVD player are mal-
functioning.
 AV communication signal between AV
control unit and DVD player is malfunc-
tioning. DVD player power supply and ground cir-
cuits.
Refer to AV- 4 6 8 , "DVD PLAYER : Diag-
nosis Procedure".
 AV communication circuits between
BOSE amp. and DVD player.
 AV COMM CIRCUIT [U1300]
 AMP CONN [U124E]When either one of the following items is
detected:
 BOSE amp. power supply and ground
circuits are malfunctioning.
 AV communication signal between AV
control unit and BOSE amp. is malfunc-
tioningBOSE amp. power supply and ground cir-
cuits.
Refer to AV- 4 6 6 , "
BOSE AMP. : Diagnosis
Procedure".
 AV COMM CIRCUIT [U1300]
 REAR-CAMERA LAN CONN [U1252]When either one of the following items is
detected:
 camera control unit power supply and
ground circuits are malfunctioning.
 AV communication signal between AV
control unit and camera control unit is
malfunctioning.Camera control unit power supply and
ground circuits.
Refer to AV- 4 6 7 , "
CAMERA CONTROL
UNIT : Diagnosis Procedure".
 AV COMM CIRCUIT [U1300]
 DVD NAVI CONN [U125D]NAVI control unit power supply and ground
circuits are malfunctioning.NAVI control unit power supply and ground
circuits.
Refer to AV- 4 6 4 , "
NAVI CONTROL UNIT :
Diagnosis Procedure".
 AV COMM CIRCUIT [U1300]
 DVD DECK CONN [U1248]
 AMP CONN [U124E]When either one of the following items is
detected:
 AV communication circuits between
NAVI control unit and BOSE amp is mal-
functioning.
 AV communication signal between AV
control unit and BOSE amp. is maifunc-
tioning.AV communication circuits between NAVI
control unit and BOSE amp.
 AV COMM CIRCUIT [U1300]
 DVD DECK CONN [U1248]
 AMP CONN [U124E]
 DVD NAVI CONN [U125D]When either one of the following items is
detected:
 AV communication circuits between cam-
era control unit and NAVI control unit is
malfunctioning.
 AV communication signal between AV
control unit and NAVI control unit is mal-
functioning.AV communication circuits between cam-
era control unit and NAVI control unit. Error item Detection logic Possible malfunction factor/Action to take

AV-438
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITH NAVIGATION]
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
DATA MONITOR
ALL SIGNALS
 Displays the status of the following vehicle signals inputted to the AV control unit.
 For each signal, actual signal can be compared with the condition recognized on the system.
SELECTION FROM MENU
Allows the technician to select which vehicle signals should be displayed and displays the status of the
selected vehicle signals.
 AV COMM CIRCUIT [U1300]
 DVD DECK CONN [U1248]
 AMP CONN [U124E]
 REAR-CAMERA LAN CONN [U1252]
 DVD NAVI CONN [U125D]With rear control switch
When either one of the following items is
detected:
 malfunction is detected in AV communi-
cation circuits between rear control
switch and camera control unit.
 malfunction is detected in AV communi-
cation circuits between camera control
unit and NAVI control unit.  AV communication circuits between mul-
tifunction switch and rear control switch.
 AV communication circuits between rear
control switch and camera control unit.
Without rear control switch
When either one of the following items is
detected:
 malfunction is detected in AV communi-
cation circuits between multifunction
switch and camera control unit.
 malfunction is detected in AV communi-
cation circuits between camera control
unit and NAVI control unit.AV communication circuits between multi-
function switch and camera control unit.
 AV COMM CIRCUIT [U1300]
 SWITCH CONN [U1240]
 DVD DECK CONN [U1248]
 AMP CONN [U124E]
 REAR-CAMERA LAN CONN [U1252]
 DVD NAVI CONN [U125D]When either one of the following items is
detected:
 AV communication circuits between AV
control unit and multifunction switch are
malfunctioning.
 AV communication signal between AV
control unit and multifunction switch is
malfunctioning.AV communication circuits between AV
control unit and multifunction switch. Error item Detection logic Possible malfunction factor/Action to take
Display ItemDis-
playVehicle status Remarks
VHCL SPD SIGOn Vehicle speed >0 km/h (0 MPH)
Changes in indication may be delayed. This is nor-
mal. Off Vehicle speed =0 km/h (0 MPH)
PKB SIGOn Parking brake is applied.
Off Parking brake is released.
ILLUM SIGOn Light switch ON.
— Off Light switch OFF.
IGN SIGOn Ignition switch ON.
Off Ignition switch in ACC position.
REV SIGOn Selector lever in R position.
Changes in indication may be delayed. This is nor-
mal.
OffSelector lever in any position other
than R.

AV
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
AV-439
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITH NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
Item to be selected Description
VHCL SPD SIG
The same as when “ALL SIGNALS”
is selected. PKB SIG
ILLUM SIG
IGN SIG
REV SIG

AV-440
< COMPONENT DIAGNOSIS >[BOSE AUDIO WITH NAVIGATION]
U1000 CAN COMM CIRCUIT
COMPONENT DIAGNOSIS
U1000 CAN COMM CIRCUIT
DescriptionINFOID:0000000003765851
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Many elec-
tronic control units are equipped onto a vehicle, and each control unit shares information and links with other
control units during operation (not independent). In CAN communication, control units are connected with 2
communication lines (CAN-H, CAN-L) allowing a high rate of information transmission with less wiring. Each
control unit transmits/receives data but selectively reads required data only.
CAN Communication Signal Chart. Refer to LAN-22, "
CAN Communication Signal Chart".
DTC LogicINFOID:0000000003765852
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000003765853
1.PERFORM SELF DIAGNOSTIC
1. Turn ignition switch ON and wait for 2 seconds or more.
2. Check “Self Diagnostic Result” of “MULTI AV”.
Is
“CAN COMM CIRCUIT” displayed?
YES >> Refer to “LAN system”. Refer to LAN-14, "Trouble Diagnosis Flow Chart".
NO >> Refer to GI section. Refer to GI-35, "
Intermittent Incident".
DTCDisplay contents of CON-
SULT-IIIDiagnostic item is detected when... Probable malfunction location
U1000 CAN COMM CIRCUITWhen AV control unit is not transmitting or re-
ceiving CAN communication signal for 2 sec-
onds or more.CAN communication system

AV
U1010 CONTROL UNIT (CAN)
AV-441
< COMPONENT DIAGNOSIS >[BOSE AUDIO WITH NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
U1010 CONTROL UNIT (CAN)
DescriptionINFOID:0000000003765854
Initial diagnosis of AV control unit.
DTC LogicINFOID:0000000003765855
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000003765856
1.REPLACE AV CONTROL UNIT
When DTC U1010 is detected, replace AV control unit.
>> INSPECTION END
DTCDisplay contents of CON-
SULT-IIIDiagnostic item is detected when... Probable malfunction location
U1010 CONTROL UNIT (CAN) CAN initial diagnosis malfunction is detected. AV control unit

AV-442
< COMPONENT DIAGNOSIS >[BOSE AUDIO WITH NAVIGATION]
U1310 AV CONTROL UNIT
U1310 AV CONTROL UNIT
DescriptionINFOID:0000000003765857
Replace the AV control unit if this DTC is displayed. Refer to AV-648, "Removal and Installation".
DTC LogicINFOID:0000000003765858
DTC DETECTION LOGIC
Part name Description
AV CONTROL UNIT It is the master unit of the MULTI AV system, and it is connected to each control
unit by communication. It operates each system according to communication
signals from the AV control unit.
 AV control unit includes audio function and vehicle information function.
 It is connected to ECM and combination meter. via CAN communication to ob-
tain necessary information for the vehicle information function.
 It is connected to BCM via CAN communication transmitting/receiving for the
vehicle settings function.
 Composite image signal (AUX and DVD images) is input from DVD player.
 Camera image signal is input from camera control unit.
 Composite image (DVD, AUX and camera images) signal is output to display
unit.
 Sound signal (DVD and AUX sounds) is input from the DVD player.
DTCDisplay contents of
CONSULT-IIIDTC Detection Condition Action to take
U1310CONTROL UNIT (AV)
[U1310]AV communication circuit initial diagnosis malfunction is
detected.Replace AV control unit.

AV
U1200 AV CONTROL UNIT
AV-443
< COMPONENT DIAGNOSIS >[BOSE AUDIO WITH NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
U1200 AV CONTROL UNIT
DescriptionINFOID:0000000003820986
Replace the AV control unit if this DTC is displayed. Refer to AV-648, "Removal and Installation".
DTC LogicINFOID:0000000003765860
DTC DETECTION LOGIC
Part name Description
AV CONTROL UNIT It is the master unit of the MULTI AV system, and it is connected to each control
unit by communication. It operates each system according to communication
signals from the AV control unit.
 AV control unit includes audio function and vehicle information function.
 It is connected to ECM and combination meter. via CAN communication to ob-
tain necessary information for the vehicle information function.
 It is connected to BCM via CAN communication transmitting/receiving for the
vehicle settings function.
 Composite image signal (AUX and DVD images) is input from DVD player.
 Camera image signal is input from camera control unit.
 Composite image (DVD, AUX and camera images) signal is output to display
unit.
 Sound signal (DVD and AUX sounds) is input from the DVD player.
DTCDisplay contents of
CONSULT-IIIDTC Detection Condition Action to take
U1200Cont Unit
FLASH- ROM
[U1200]AV control unit malfunction is detected. (FLASH-ROM). Replace AV control unit.

AV-444
< COMPONENT DIAGNOSIS >[BOSE AUDIO WITH NAVIGATION]
U1216 AV CONTROL UNIT
U1216 AV CONTROL UNIT
DescriptionINFOID:0000000003820987
Replace the AV control unit if this DTC is displayed. Refer to AV-648, "Removal and Installation".
DTC LogicINFOID:0000000003765862
Part name Description
AV CONTROL UNIT It is the master unit of the MULTI AV system, and it is connected to each control
unit by communication. It operates each system according to communication
signals from the AV control unit.
 AV control unit includes audio function and vehicle information function.
 It is connected to ECM and combination meter. via CAN communication to ob-
tain necessary information for the vehicle information function.
 It is connected to BCM via CAN communication transmitting/receiving for the
vehicle settings function.
 Composite image signal (AUX and DVD images) is input from DVD player.
 Camera image signal is input from camera control unit.
 Composite image (DVD, AUX and camera images) signal is output to display
unit.
 Sound signal (DVD and AUX sounds) is input from the DVD player.
DTCDisplay contents of
CONSULT-IIIDTC Detection Condition Action to take
U1216CAN CONT
[U1216]Internal malfunction of AV control unit (CAN controller) is
detected.Replace AV control unit.

AV
U1231 BOSE AMP.
AV-445
< COMPONENT DIAGNOSIS >[BOSE AUDIO WITH NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
U1231 BOSE AMP.
DescriptionINFOID:0000000003900426
Replace the BOSE amp. if this DTC is displayed. Refer to AV-657, "Removal and Installation".
DTC LogicINFOID:0000000003900427
Part name Description
BOSE AMP.Inputs sound signal from AV control unit and DVD player, and outputs sound sig-
nal to woofer and each speaker.
DTCDisplay contents of
CONSULT-IIIDTC Detection Condition Action to take
U1231AMP TEMP
[U1231]Internal malfunction of BOSE amp. is detected. Replace BOSE amp.

AV-446
< COMPONENT DIAGNOSIS >[BOSE AUDIO WITH NAVIGATION]
U1243 DISPLAY UNIT
U1243 DISPLAY UNIT
DescriptionINFOID:0000000003765863
DTC LogicINFOID:0000000003765864
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000003765865
1.CHECK DISPLAY UNIT POWER SUPPLY AND GROUND CIRCUIT
Check display unit power supply and ground circuit. Refer to AV-465, "
DISPLAY UNIT : Diagnosis Procedure".
Is inspection result normal?
YES >> GO TO 2.
NO >> Repair malfunctioning parts.
2.CHECK CONTINUITY COMMUNICATION CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect display unit connector and AV control unit connector.
3. Check continuity between display unit harness connector and AV control unit harness connector.
4. Check continuity between display unit harness connector and ground.
Is inspection result normal?
YES >> GO TO 3.
NO >> Repair harness or connector.
Part name Description
DISPLAY UNIT Display image is controlled by the serial communication from AV control unit.
 RGB image signal is input from AV control unit (RGB, RGB area and RGB syn-
chronizing).
 Composite image (DVD, AUX and camera images) signal is input from AV con-
trol unit.
 Synchronize signal (HP, VP) is output to AV control unit.
 Touch panel function can be operated for each system by touching a display
directly.
DTCDisplay contents of
CONSULT-IIIDTC Detection Condition Possible causes
U1243FRONT DISP CONN
[U1243]When either one of the following items is detected:
 display unit power supply and ground circuits are mal-
functioning.
 serial communication circuits between display unit and
AV control unit are malfunctioning.
 serial communication signal between display unit and
AV control unit is malfunctioning. Display unit power supply and
ground circuits.
 Serial communication circuits be-
tween display unit and AV control
unit
Display unit AV control unit
Continuity
Connector Terminals Connector Terminals
M4911
M12956
Existed
22 44
Display unit
GroundContinuity
Connector Terminals
M4911
Not existed
22
