AV
U1243 DISPLAY UNIT
AV-447
< COMPONENT DIAGNOSIS >[BOSE AUDIO WITH NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
3.CHECK COMMUNICATION SIGNAL
1. Connect display unit connector and AV control unit connector.
2. Turn ignition switch ON.
3. Check signal between display unit harness connector terminal and ground using an oscilloscope.
Is inspection result normal?
YES >> GO TO 4.
NO >> Replace AV control unit.
4.CHECK COMMUNICATION SIGNAL
Check signal between display unit harness connector terminal and ground using an oscilloscope.
Is inspection result normal?
YES >> INSPECTION END
NO >> Replace display unit.
(+)
(−) Condition Reference value Display unit
Connector Terminal
M49 11 GroundWhen adjusting display bright-
ness.
PKIB5039J
(+)
(−) Condition Reference value Display unit
Connector Terminal
M49 22 GroundWhen adjusting display bright-
ness.
PKIB5039J
Page 592 of 5121
![NISSAN TEANA 2008 Service Manual AV-448
< COMPONENT DIAGNOSIS >[BOSE AUDIO WITH NAVIGATION]
U1250 CAMERA CONTROL UNIT
U1250 CAMERA CONTROL UNIT
DescriptionINFOID:0000000003821336
DTC LogicINFOID:0000000003821337
Diagnosis ProcedureIN NISSAN TEANA 2008 Service Manual AV-448
< COMPONENT DIAGNOSIS >[BOSE AUDIO WITH NAVIGATION]
U1250 CAMERA CONTROL UNIT
U1250 CAMERA CONTROL UNIT
DescriptionINFOID:0000000003821336
DTC LogicINFOID:0000000003821337
Diagnosis ProcedureIN](/img/5/57391/w960_57391-591.png)
AV-448
< COMPONENT DIAGNOSIS >[BOSE AUDIO WITH NAVIGATION]
U1250 CAMERA CONTROL UNIT
U1250 CAMERA CONTROL UNIT
DescriptionINFOID:0000000003821336
DTC LogicINFOID:0000000003821337
Diagnosis ProcedureINFOID:0000000003821341
1.CHECK CONTINUITY RECOGNITION SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect AV control unit connector and camera control unit connector.
3. Check continuity between AV control unit harness connector and camera control unit harness connector.
4. Check continuity between display unit harness connector and ground.
Is inspection result normal?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK AV CONTROL UNIT VOLTAGE
1. Connect AV control unit connector and camera control unit connector.
2. Turn ignition switch ON.
3. Check signal between AV control unit harness connector terminal and ground using an oscilloscope.
Is inspection result normal?
YES >> Replace AV control unit.
Part name Description
CAMERA CONTROL UNIT Camera image signal is input from rear view camera. Camera image signal
output to AV control unit.
Power supply is transmitted to rear view camera.
AV control unit recognizes the presence of camera system with camera con-
nection recognition signal.
Camera control unit is connected via AV communication.
DTCDisplay contents of
CONSULT-IIIDTC Detection Condition Possible causes
U1250CAMERA CONT. CONN
[U1250]Malfunction is detected in camera connection recogni-
tion signal circuit.Camera connection recognition sig-
nal circuit.
AV control unit Camera control unit
Continuity
Connector Terminals Connector Terminals
M130 68 B251 14 Existed
AV c o n t r o l u n i t
GroundContinuity
Connector Terminals
M130 68 Not existed
(+)
(−) ConditionVol tag e
(Approx.) AV c o n t r o l u n i t
Connector Terminal
M130 68 GroundConnected camera
control unit connector0 V
Disconnect camera
control unit connector5 V
