STEERING ANGLE SENSOR SIGNAL CIRCUIT
AV-487
< COMPONENT DIAGNOSIS >[BOSE AUDIO WITH NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
STEERING ANGLE SENSOR SIGNAL CIRCUIT
DescriptionINFOID:0000000003765936
 Steering angle sensor signal 1, 2 detects the turning direction and quantity of the steering and transmits it to
the camera control unit.
 Steering angle sensor signal 3 detects the neutral position of the steering and transmits it to the camera con-
trol unit.
 Camera control unit performs the correction of neutral position with sensor signal 1, 2, 3 and vehicle speed
signal.
Diagnosis ProcedureINFOID:0000000003765937
1.CHECK CONTINUITY STEERING ANGLE SENSOR SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect camera control unit connector and steering angle sensor connector.
3. Check continuity between camera control unit harness connector and steering angle sensor harness con-
nector.
4. Check continuity between camera control unit harness connector and ground.
Is inspection result normal?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK SIGNAL SENSOR SIGNAL
1. Connect camera control unit connector.
2. Turn ignition switch ON.
3. Check voltage between camera control unit harness connector and ground.
Is inspection result normal?
YES >> GO TO 3.
NO >> Replace camera control unit.
3.CHECK SIGNAL SENSOR SIGNAL
1. Turn ignition switch OFF.
2. Connect steering angle sensor connector.
Camera control unit Steering angle sensor
Continuity
Connector Terminals Connector Terminals
B25123
M303
Existed 24 6
25 8
Camera control unit
GroundContinuity
Connector Terminals
B25123
Not existed 24
25
(+)
(−)Voltag e
(Approx.) Camera control unit
Connector Terminals
B25123
Ground 5.0 V 24
25

AV-488
< COMPONENT DIAGNOSIS >[BOSE AUDIO WITH NAVIGATION]
STEERING ANGLE SENSOR SIGNAL CIRCUIT
3. Turn ignition switch ON.
4. Check signal between camera control unit harness connector and ground.
Is inspection result normal?
YES >> INSPECTION END
NO >> Replace steering angle sensor.
(+)
(−) Condition Reference value Camera control unit
Connector Terminals
B25123, 24 GroundTurn the steering to the right
A: Sensor signal 1
B: Sensor signal 2
Turn the steering to the left
A: Sensor signal 1
B: Sensor signal 2
25 GroundTurn the steering around the
neutral position
A: Sensor signal 3
B: Sensor signal 1
SKIB3827E
SKIB3828E
SKIB3829E

AV
STEERING SWITCH SIGNAL A CIRCUIT
AV-489
< COMPONENT DIAGNOSIS >[BOSE AUDIO WITH NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
STEERING SWITCH SIGNAL A CIRCUIT
DescriptionINFOID:0000000003765938
Transmits the steering switch signal to AV control unit.
Diagnosis ProcedureINFOID:0000000003765939
1.CHECK STEERING SWITCH SIGNAL A CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect AV control unit connector and spiral cable connector.
3. Check continuity between AV control unit harness connector and spiral cable harness connector.
4. Check continuity between AV control unit harness connector and ground.
Is inspection result normal?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK SPIRAL CABLE
Check spiral cable.
Is inspection result normal?
YES >> GO TO 3.
NO >> Replace spiral cable.
3.CHECK AV CONTROL UNIT VOLTAGE
1. Connect AV control unit connector and spiral cable connector.
2. Turn ignition switch ON.
3. Check voltage between AV control unit harness connector.
Is inspection result normal?
YES >> GO TO 4.
NO >> Replace AV control unit.
4.CHECK STEERING SWITCH
1. Turn ignition switch OFF.
2. Check steering switch. Refer to AV-490, "
Component Inspection".
Is inspection result normal?
YES >> INSPECTION END
NO >> Replace steering switch.
AV control unit Spiral cable
Continuity
Connector Terminal Connector Terminal
M127 6 M33 24 Existed
AV control unit
GroundContinuity
Connector Terminal
M127 6 Not existed
(+) (−)
Vo l ta g e
(Approx.) AV control unit AV control unit
Connector Terminal Connector Terminal
M127 6 M127 15 3.5 V

AV-490
< COMPONENT DIAGNOSIS >[BOSE AUDIO WITH NAVIGATION]
STEERING SWITCH SIGNAL A CIRCUIT
Component Inspection
INFOID:0000000003765940
Measure the resistance between the steering switch connector ter-
minals 14 to 17 and 15 to 17.
Standard
JSNIA0502GB
Steering switch
ConditionResistance
Ω Con-
nectorTe r m i -
nalCon-
nectorTe r m i -
nal
M30314
M303 17ENTER switch ON 1983 – 2063
switch ON709 – 737
MENU DOWN switch
ON315 – 327
MENU UP switch ON 119 – 123
SOURCE switch ON 1
15 switch ON709 – 737
switch ON315 – 327
VOL UP switch ON 119 – 123
VOL DOWN switch ON 1

AV
STEERING SWITCH SIGNAL B CIRCUIT
AV-491
< COMPONENT DIAGNOSIS >[BOSE AUDIO WITH NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
STEERING SWITCH SIGNAL B CIRCUIT
DescriptionINFOID:0000000003765941
Transmits the steering switch signal to AV control unit.
Diagnosis ProcedureINFOID:0000000003765942
1.CHECK STEERING SWITCH SIGNAL B CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect AV control unit connector and spiral cable connector.
3. Check continuity between AV control unit harness connector and spiral cable harness connector.
4. Check continuity between AV control unit harness connector and ground.
Is inspection result normal?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK SPIRAL CABLE
Check spiral cable.
Is inspection result normal?
YES >> GO TO 3.
NO >> Replace spiral cable.
3.CHECK AV CONTROL UNIT VOLTAGE
1. Connect AV control unit connector and spiral cable connector.
2. Turn ignition switch ON.
3. Check voltage between AV control unit harness connector.
Is inspection result normal?
YES >> GO TO 4.
NO >> Replace AV control unit.
4.CHECK STEERING SWITCH
1. Turn ignition switch OFF.
2. Check steering switch. Refer to AV-492, "
Component Inspection".
Is inspection result normal?
YES >> INSPECTION END
NO >> Replace steering switch.
AV control unit Spiral cable
Continuity
Connector Terminal Connector Terminal
M127 16 M33 31 Existed
AV control unit
GroundContinuity
Connector Terminal
M127 16 Not existed
(+) (−)
Vo l ta g e
(Approx.) AV control unit AV control unit
Connector Terminal Connector Terminal
M127 16 M127 15 3.5 V

AV-492
< COMPONENT DIAGNOSIS >[BOSE AUDIO WITH NAVIGATION]
STEERING SWITCH SIGNAL B CIRCUIT
Component Inspection
INFOID:0000000003765943
Measure the resistance between the steering switch connector ter-
minals 14 to 17 and 15 to 17.
Standard
JSNIA0502GB
Steering switch
ConditionResistance
Ω Con-
nectorTe r m i -
nalCon-
nectorTe r m i -
nal
M30314
M303 17ENTER switch ON 1983 – 2063
switch ON709 – 737
MENU DOWN switch
ON315 – 327
MENU UP switch ON 119 – 123
SOURCE switch ON 1
15 switch ON709 – 737
switch ON315 – 327
VOL UP switch ON 119 – 123
VOL DOWN switch ON 1

AV
STEERING SWITCH SIGNAL GND CIRCUIT
AV-493
< COMPONENT DIAGNOSIS >[BOSE AUDIO WITH NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
STEERING SWITCH SIGNAL GND CIRCUIT
DescriptionINFOID:0000000003765944
Transmits the steering switch signal to AV control unit.
Diagnosis ProcedureINFOID:0000000003765945
1.CHECK STEERING SWITCH SIGNAL GND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect AV control unit connector and spiral cable connector.
3. Check continuity between AV control unit harness connector and spiral cable harness connector.
4. Connect AV control unit connector.
Is inspection result normal?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK SPIRAL CABLE
Check spiral cable.
Is inspection result normal?
YES >> GO TO 3.
NO >> Replace spiral cable.
3.CHECK GROUND CIRCUIT
1. Connect AV control unit connector.
2. Check continuity between AV control unit harness connector and ground.
Is inspection result normal?
YES >> GO TO 4.
NO >> Replace AV control unit.
4.CHECK STEERING SWITCH
Check steering switch. Refer to AV-494, "
Component Inspection".
Is inspection result normal?
YES >> INSPECTION END
NO >> Replace steering switch.
AV control unit Spiral cable
Continuity
Connector Terminal Connector Terminal
M127 15 M33 33 Existed
AV control unit
GroundContinuity
Connector Terminal
M127 15 Existed

AV-494
< COMPONENT DIAGNOSIS >[BOSE AUDIO WITH NAVIGATION]
STEERING SWITCH SIGNAL GND CIRCUIT
Component Inspection
INFOID:0000000003765946
Measure the resistance between the steering switch connector ter-
minals 14 to 17 and 15 to 17.
Standard
JSNIA0502GB
Steering switch
ConditionResistance
Ω Con-
nectorTe r m i -
nalCon-
nectorTe r m i -
nal
M30314
M303 17ENTER switch ON 1983 – 2063
switch ON709 – 737
MENU DOWN switch
ON315 – 327
MENU UP switch ON 119 – 123
SOURCE switch ON 1
15 switch ON709 – 737
switch ON315 – 327
VOL UP switch ON 119 – 123
VOL DOWN switch ON 1

AV
AV CONTROL UNIT
AV-495
< ECU DIAGNOSIS >[BOSE AUDIO WITH NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
ECU DIAGNOSIS
AV CONTROL UNIT
Reference ValueINFOID:0000000003765966
VALUES ON THE DIAGNOSIS TOOL
CONSULT-III data monitor item
TERMINAL LAYOUT
PHYSICAL VALUES
Display ItemDis-
playVehicle status Remarks
VHCL SPD SIGOn Vehicle speed >0 km/h (0 MPH)
Changes in indication may be delayed. This is nor-
mal.
Off Vehicle speed =0 km/h (0 MPH)
PKB SIGOn Parking brake is applied.
Changes in indication may be delayed. This is nor-
mal.
Off Parking brake is released.
ILLUM SIGOn Light switch ON.
—
Off Light switch OFF.
IGN SIGOn Ignition switch ON.
—
Off Ignition switch in ACC position.
REV SIGOn Selector lever in R position.
Changes in indication may be delayed. This is nor-
mal.
OffSelector lever in any position other
than R.
JPNIA1093ZZ
Te r m i n a l
(Wire color)Description
ConditionReference value
(Approx.)
+ – Signal nameInput/
Output
6
(W/G)15
(L/B)Steering switch signal A InputIgnition
switch
ONKeep pressing SOURCE
switch. 0 V
Keep pressing switch.0.8 V
Keep pressing switch.1.5 V
Keep pressing switch.2.1 V
Keep pressing ENTER
switch.2.8 V
Except for above. 3.5 V
7
(V/W)Ground ACC power supply InputIgnition
switch
ACC— Battery voltage
9
(R/L)Ground Illumination signal InputIgnition
switch
OFFLighting switch is OFF. 0 V
Lighting switch is ON. 12.0 V

AV-496
< ECU DIAGNOSIS >[BOSE AUDIO WITH NAVIGATION]
AV CONTROL UNIT
15
(L/B)GroundSteering switch signal
ground—Ignition
switch
ON—0 V
16
(GR/L)15
(L/B)Steering switch signal B InputIgnition
switch
ONKeep pressing VOL DOWN
switch.0 V
Keep pressing VOL UP
switch.0.8 V
Keep pressing switch.1.5 V
Keep pressing switch.2.1 V
Except for above. 3.5 V
19
(Y)Ground Battery power supply InputIgnition
switch
OFF— Battery voltage
20
(B/W)Ground Ground —Ignition
switch
ON—0 V
33 — FM sub Input — — —
34 — AM–FM main Input — — —
35 Ground Antenna amp. ON signal OutputIgnition
switch
ACC— 12.0 V
36
(B)Ground Composite image signal OutputIgnition
switch
ONWhen camera image or
AUX image is displayed.
37
(W)Ground Composite image ground —Ignition
switch
ON—0 V
38
(B)Ground RGB image signal (B: blue) OutputIgnition
switch
ONStart confirmation/adjust-
ment mode, and then dis-
play color bar by selecting
“Color Spectrum Bar” on
DISPLAY DIAGNOSIS
screen.
39
(R)GroundRGB image signal (G:
green)OutputIgnition
switch
ONStart confirmation/adjust-
ment mode, and then dis-
play color bar by selecting
“Color Spectrum Bar” on
DISPLAY DIAGNOSIS
screen. Terminal
(Wire color)Description
ConditionReference value
(Approx.)
+ – Signal nameInput/
Output
SKIB2251J
SKIB2237J
SKIB2236J
