P0604 ECM
DTC LogicINFOID:0000000009462329
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following pro cedure, confirm that battery voltage is 11 V or more with ignition
switch ON.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON (engine stopped) and wait least 20 minutes. CAUTION:
Never start engine during this procedure.
2. Turn ignition switch OFF and wait at least 10 seconds.
3. Turn ignition switch ON.
4. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-401, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009462330
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Erase DTC.
3. Perform DTC confirmation procedure. Refer to EC-401, "DTC Logic"
.
Is the 1st trip DTC
P0604 displayed again?
YES >> Replace ECM. Refer to EC-540, "Removal and Installation".
NO >> INSPECTION END
DTC No. CONSULT screen terms
(Trouble diagnosis content) DTC detecting condition Possible cause
P0604 ECM
[Internal control module
random access memory
(RAM) error] Malfunction in the internal RAM of ECM. ECM
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-402
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P0605 ECM
P0605 ECM
DTC LogicINFOID:0000000009462331
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm th at battery voltage is 11 V or more with ignition
switch ON.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON (engine stopped) and wait least 20 minutes. CAUTION:
Never start engine during this procedure.
2. Turn ignition switch OFF and wait at least 10 seconds.
3. Turn ignition switch ON.
4. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-402, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009462332
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Erase DTC.
3. Perform DTC confirmation procedure. Refer to EC-401, "DTC Logic"
.
Is the 1st trip DTC
P0605 displayed again?
YES >> Replace ECM. Refer to EC-540, "Removal and Installation".
NO >> INSPECTION END
DTC No. CONSULT screen terms
(Trouble diagnosis content) DTC detecting condition Possible cause
P0605 ECM
[Internal control module
read only memory (ROM)
error] Malfunction in the internal ROM of ECM. ECM
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

P0606 ECMEC-403
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P0606 ECM
DTC LogicINFOID:0000000009561259
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following pro cedure, confirm that battery voltage is 11 V or more with ignition
switch ON.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE-I
1. Turn ignition switch ON (engine stopped) and wait at least 10 seconds. CAUTION:
Never start engine during this procedure.
2. Turn ignition switch OFF and wait at least 10 seconds.
3. Turn ignition switch ON.
4. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-403, "Diagnosis Procedure".
NO >> GO TO 3.
3.PERFORM DTC CONFIRMATION PROCEDURE-II
1. Start engine.
2. Rev up the engine quickly to approximately 3,000 rpm under unloaded condition and completely release the accelerator pedal.
3. Let the engine idle and wait at least 10 seconds.
4. Turn ignition switch OFF and wait at least 10 seconds.
5. Turn ignition switch ON.
6. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-403, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009561260
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Erase DTC.
3. Perform DTC confirmation procedure for 3 times. Refer to EC-403, "DTC Logic"
.
Is the 1st trip DTC
P0606 displayed again?
YES >> Replace ECM. Refer to EC-540, "Removal and Installation".
NO >> INSPECTION END
DTC No. CONSULT screen terms
(Trouble diagnosis content) DTC detecting condition Possible cause
P0606 CONTROL MODULE
(Control module processor) Malfunction in ECM processor. ECM
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-404
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P0607 ECM
P0607 ECM
DTC LogicINFOID:0000000009462333
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm th at battery voltage is 11 V or more with ignition
switch ON.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON (engine stopped) and wait least 10 seconds.
2. Turn ignition switch OFF and wait at least 10 seconds.
3. Turn ignition switch ON.
4. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-404, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009462334
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Erase DTC.
3. Perform DTC confirmation procedure. Refer to EC-401, "DTC Logic"
.
Is the 1st trip DTC
P0607 displayed again?
YES >> Replace ECM. Refer to EC-540, "Removal and Installation".
NO >> INSPECTION END
DTC No. CONSULT screen terms
(Trouble diagnosis content) DTC detecting condition Possible cause
P0607 ECM
(Control module perfor-
mance) ECM internal communication system is malfunc-
tioning. ECM
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

P060A ECMEC-405
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P060A ECM
DTC LogicINFOID:0000000009561261
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following pro cedure, confirm that battery voltage is 11 V or more with ignition
switch ON.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and wait at least 10 seconds.
2. Turn ignition switch OFF and wait at least 10 seconds.
3. Repeat step 1 and 2 for 5 times.
4. Turn ignition switch ON.
5. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-405, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009561262
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Erase DTC.
3. Perform DTC confirmation procedure. Refer to EC-405, "DTC Logic"
.
Is the 1st trip DTC
P060A displayed again?
YES >> Replace ECM. Refer to EC-540, "Removal and Installation".
NO >> INSPECTION END
DTC No. CONSULT screen terms
(Trouble diagnosis content) DTC detecting condition Possible cause
P060A CONTROL MODULE
(Internal control module
monitoring processor per-
formance) ECM internal monitoring processor is malfunction-
ing. ECM
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-406
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P060B ECM
P060B ECM
DTC LogicINFOID:0000000009561263
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm th at battery voltage is 11 V or more with ignition
switch ON.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON (engine stopped) and wait least 10 seconds.
2. Turn ignition switch OFF and wait at least 10 seconds.
3. Turn ignition switch ON.
4. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-406, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009561264
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Erase DTC.
3. Perform DTC confirmation procedure. Refer to EC-406, "DTC Logic"
.
Is the 1st trip DTC
P060B displayed again?
YES >> Replace ECM. Refer to EC-540, "Removal and Installation".
NO >> INSPECTION END
DTC No. CONSULT screen terms
(Trouble diagnosis content) DTC detecting condition Possible cause
P060B CONTROL MODULE
(Internal control module A/
D processing performance) ECM internal analog/digital conversion processing
system is malfunctioning. ECM
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

P0643 SENSOR POWER SUPPLYEC-407
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P0643 SENSOR POWER SUPPLY
DescriptionINFOID:0000000009462335
ECM supplies a voltage of 5 V to some of the sensors systematically divided into 2 groups, respectively.
Accordingly, when a short circuit develops in a sensor power source, a malfunction may occur simultaneously
in the sensors belonging to the same group as the short-circuited sensor.
Sensor power supply 1
• APP sensor 1
• Battery current sensor
• CKP sensor (POS)
• Intake manifold runner control valve position sensor
• Refrigerant pressure sensor
• TP sensor
NOTE:
If sensor power supply 1 circuit is malfunctioning, DTC P0643 is displayed.
Sensor power supply 2
• APP sensor 2
• CMP sensor (PHASE)
• EVT control position sensor
• EOP sensor
• MAF sensor
DTC LogicINFOID:0000000009462336
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always perform the following procedure
before conducting the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is more than 10 V at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
DTC No. CONSULT screen terms
(Trouble diagnosis content) DTC detecting condition Possible cause
P0643 SENSOR POWER/CIRC
(Sensor reference voltage ″A ″
circuit high) ECM detects that the voltage of sensor
power supply 1 is excessively low or high. • Harness or connectors
(APP sensor 1 circuit is shorted.)
(Battery current sensor circuit is shorted.)
(CKP sensor (POS) circuit is shorted.)
(Intake manifold runner control valve posi-
tion sensor circuit is shorted.)
(TP sensor circuit is shorted.)
(Refrigerant pressure sensor circuit is
shorted.)
• Accelerator pedal position sensor
• Battery current sensor
• CKP sensor (POS)
• Intake manifold runner control valve posi- tion sensor
• Throttle position sensor
• Refrigerant pressure sensor
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-408
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P0643 SENSOR POWER SUPPLY
1. Start engine and let it idle for 1 second.
2. Check DTC.
Is DTC detected?
YES >> Refer to EC-408, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009462337
1.CHECK GROUND CONNECTION
1. Turn ignition switch OFF.
2. Check ground connection M95. Refer to Ground Inspection in GI-46, "Circuit Inspection"
.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace ground connection.
2.CHECK ACCELERATOR PEDAL POSITION SENSOR 1 POWER SUPPLY CIRCUIT
1. Disconnect accelerator pedal position (APP) sensor harness connector.
2. Turn ignition switch ON.
3. Check the voltage between APP sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 3.
3.CHECK SENSOR POWER SUPPLY CIRCUITS
Check harness for short to power and short to ground, between the following terminals.
*1: Except for California
*2: For California
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair short to ground or short to power in harness or connectors.
4.CHECK COMPONENTS
Check the following.
• Battery current sensor (Refer to EC-429, "Component Inspection"
.)
• Crankshaft position sensor (POS) (Refer to EC-328, "Component Inspection (Crankshaft Position sensor)"
.)
• Intake manifold runner control valve position sensor (Refer to EC-465, "Diagnosis Procedure"
.)
• Refrigerant pressure sensor (Refer to EC-523, "Diagnosis Procedure"
.)
• TP sensor (Refer to EC-250, "Component Inspection"
.)
Is the inspection result normal?
+
-Voltag e
(Approx.)
APP sensor
Connector Terminal E40 4 Ground 5 V
ECM Sensor
Connector Terminal Name Connector Terminal
F13
*1
F90*2
64 Battery current sensor F5 1
72 CKP sensor (POS) F30 1
80 Electric throttle control actuator F57 2
84 Intake manifold runner control valve po-
sition sensor F52 1
E10
*1
E31*2
104 Refrigerant pressure sensor E219 1
122 APP sensor E40 4
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

P0643 SENSOR POWER SUPPLYEC-409
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
YES >> GO TO 5.
NO >> Repair or replace malfunctioning component.
5.CHECK APP SENSOR
Refer to EC-484, "Component Inspection"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Replace accelerator pedal assembly. Refer to ACC-3, "Removal and Installation"
.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-410
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P0850 PNP SWITCH
P0850 PNP SWITCH
DescriptionINFOID:0000000009462338
Transmission range switch is turn ON when the selector lever is P or N.
ECM detects the position because the c ontinuity of the line (the ON) exists.
DTC LogicINFOID:0000000009462339
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.INSPECTION START
Do you have CONSULT?
Do you have CONSULT?
YES >> GO TO 2.
NO >> GO TO 5.
2.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always perform the following procedure
before conducting the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
>> GO TO 3.
3.CHECK PNP SIGNAL FUNCTION
With CONSULT
1. Turn ignition switch ON.
2. Select “P/N POSI SW” in “DATA MONITOR” mode of “ENGINE” using CONSULT. Then check the “P/N
POSI SW” signal as per the following conditions.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Proceed to EC-411, "Diagnosis Procedure"
.
4.PERFORM DTC CONFIRMATION PROCEDURE
1. Select “DATA MONITOR” mode of “ENGINE” using CONSULT.
2. Start engine and warm it up to normal operating temperature.
3. Maintain the following conditions for at least 60 consecutive seconds.
CAUTION:
Always drive vehicle at a safe speed.
DTC No. CONSULT screen terms
(Trouble diagnosis content) DTC detecting condition Possible cause
P0850 P-N POS SW/CIRCUIT
(Park/neutral switch input
circuit) The signal of transmission range switch is
not changed in the process of engine start-
ing and driving. • Harness or connectors
(The transmission range switch circuit is
open or shorted.)
• Transmission range switch
Selector lever position Known-good signal
N or P position ON
Except above position OFF
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
