HEADLINING
Without Sunroof
Removal and InstallationINFOID:0000000009461363
REMOVAL
1. Remove the front pillar finishers (LH/RH). Refer to INT-21, "FRONT PILLAR FINISHER : Removal and
Installation".
2. Remove the center pillar upper finishers (LH/RH). Refer to INT-24, "CENTER PILLAR UPPER FINISHER
: Removal and Installation".
3. Remove the rear pillar finishers (LH/RH). Refer to INT-25, "REAR PILLAR FINISHER : Removal and
Installation".
4. Remove the rear seat bolsters (LH/RH). Refer to SE-38, "Removal and Installation - Rear Seat Bolster"
.
5. Remove the sun visor caps (1) (LH/RH) using a suitable tool.
ALJIA0908ZZ
1. Headlining 2. Rear assist grip (RH) 3. Front assist grip (RH)
4. Sun visor (RH) 5. Front room/map lamp assembly 6. Sun visor (LH)
7. Rear assist grip (LH) Front
ALJIA0905ZZ
Revision: November 20132014 Altima NAM

HEADLININGINT-31
< REMOVAL AND INSTALLATION >
C
D E
F
G H
I
K L
M A
B
INT
N
O P
6. Remove the sun visor screws (A) (LH/RH).
7. Disconnect the harness connector from the sun visors (LH/RH) and remove.
8. Insert a suitable tool (A) at approximately a 30 degree angle into the sun visor holder notch on the front of the sun visor holder
(1). Press in to release the locking tab (B). While holding in lock-
ing tab (B), turn the sun visor holder (1) 90 degrees to release it
from the headliner.
• If the sun visor holder (1) does not fully rotate, make sure that the suitable tool (A) is pressing in on the locking tab (B) and is
not positioned under locking tab (B). Reinsert the suitable tool
(A) as necessary to release the locking tab (B).
• : Front
CAUTION:
Do not force the sun visor ho lder when removing as the
locking tab may be damaged if the suitable tool is not posi-
tioned correctly.
9. Remove all assist grips.
a. Disengage assist grip clip (1) using a suitable tool (A). Slide assist grip clip forward and remove.
: Clip
b. Slide assist grip (2) forward and remove.
10. Remove the front room/map lamp assembly. Refer to INL-63, "Removal and Installation"
.
11. Partially remove the front body side welts (LH/RH). Refer to INT-23, "BODY SIDE WELT : Removal and
Installation - Front Body Side Welt".
12. Partially remove the rear body side welts (LH/RH). Refer to INT-23, "BODY SIDE WELT : Removal and
Installation - Rear Body Side Welt".
13. Remove the windshield glass. Refer to GW-12, "Removal and Installation"
.
14. Disconnect the harness connectors from the headlin ing, then remove the headlining through the wind-
shield opening.
INSTALLATION
ALJIA0906ZZ
ALJIA0537ZZ
JMJIA4398ZZ
Revision: November 20132014 Altima NAM

INT-32
< REMOVAL AND INSTALLATION >
HEADLINING
Installation is in the reverse order of removal.
Revision: November 20132014 Altima NAM

TRUNK ROOM TRIM & TRUNK LID FINISHERINT-33
< REMOVAL AND INSTALLATION >
C
D E
F
G H
I
K L
M A
B
INT
N
O P
TRUNK ROOM TRIM & TRUNK LID FINISHER
Exploded ViewINFOID:0000000009461364
TRUNK LID FINISHER
TRUNK LID FINISHER : Re moval and InstallationINFOID:0000000009461365
REMOVAL
1. Release the trunk lid finisher clips.
: Clip
2. Remove the trunk lid finisher.
INSTALLATION
Installation is in the reverse order of removal.
TRUNK FLOOR CARPET
TRUNK FLOOR CARPET : Re moval and InstallationINFOID:0000000009461366
REMOVAL
1. Remove the rear seat back. Refer to SE-36, "Removal and Installation - Seat Assembly".
1. Trunk lid finisher 2. Trunk side finisher (LH) 3. Trunk cargo net (if equipped)
4. Trunk rear finisher 5. Trunk floor carpet 6. Trunk side finisher (RH)
Front
ALJIA0915ZZ
ALJIA0919ZZ
Revision: November 20132014 Altima NAM

INT-34
< REMOVAL AND INSTALLATION >
TRUNK ROOM TRIM & TRUNK LID FINISHER
2. Remove the trunk floor carpet clips.: Clip
3. Remove the trunk floor carpet.
INSTALLATION
Installation is in the reverse order of removal.
TRUNK SIDE FINISHER
TRUNK SIDE FINISHER : Removal and InstallationINFOID:0000000009461367
REMOVAL
1. Lower the rear seat back.
2. Remove the rear seat bolster. Refer to SE-38, "Removal and Installation - Rear Seat Bolster"
.
3. Remove the trunk rear finisher. Refer to INT-35, "TRUNK REAR FINISHER : Removal and Installation"
.
4. Remove the trunk side finisher clips. : Clip
5. Remove the trunk side finisher.
INSTALLATION
Installation is in the reverse order of removal.
TRUNK CARGO NET
TRUNK CARGO NET : Remo val and InstallationINFOID:0000000009461368
REMOVAL
1. Unclip the trunk cargo net from the trunk cargo net fasteners (A).
2. Remove the trunk cargo net.
ALJIA0920ZZ
ALJIA0918ZZ
ALJIA0917ZZ
Revision: November 20132014 Altima NAM

TRUNK ROOM TRIM & TRUNK LID FINISHERINT-35
< REMOVAL AND INSTALLATION >
C
D E
F
G H
I
K L
M A
B
INT
N
O P
INSTALLATION
Installation is in the reverse order of removal.
TRUNK REAR FINISHER
TRUNK REAR FINISHER : Removal and InstallationINFOID:0000000009461369
REMOVAL
1. Release the trunk rear finisher clips.
: Metal clip
: Clip
2. Remove the trunk rear finisher.
INSTALLATION
Installation is in the reverse order of removal.
ALJIA0916ZZ
Revision: November 20132014 Altima NAM
