STARTING SYSTEMSTR-21
< SYMPTOM DIAGNOSIS >
C
D E
F
G H
I
J
K L
M A
STR
NP
O
SYMPTOM DIAGNOSIS
STARTING SYSTEM
Symptom TableINFOID:0000000009461233
Symptom Reference
No normal cranking Refer to STR-12, "Work Flow (With GR8-1200 NI)"
or STR-16,
"Work Flow (Without GR8-1200 NI)".
Starter motor does not rotate
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 4212 of 4801
STR-22
< REMOVAL AND INSTALLATION >
STARTER MOTOR
REMOVAL AND INSTALLATION
STARTER MOTOR
QR25DE
QR25DE : Exploded ViewINFOID:0000000009461234
QR25DE : Removal and InstallationINFOID:0000000009461235
REMOVAL
1. Remove the core support cover clips (A), then remove the coresupport (1).
2. Remove front air duct. Refer to EM-29, "Exploded View"
.
3. Remove battery and battery tray support. Refer to PG-73, "Exploded View"
.
4. Disconnect the harness connectors from the starter motor.
5. Remove the two starter motor bolts using power tools.
6. Remove the starter motor.
1. Converter housing 2. “B” terminal harness 3. “S” connector
4. Starter motor
AWBIA1296GB
ALKIA2602ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 4213 of 4801
STARTER MOTORSTR-23
< REMOVAL AND INSTALLATION >
C
D E
F
G H
I
J
K L
M A
STR
NP
O
INSTALLATION
Installation is in the reverse order of removal.
VQ35DE
VQ35DE : Exploded ViewINFOID:0000000009461236
VQ35DE : Removal
and InstallationINFOID:0000000009461237
REMOVAL
1. Remove the battery and battery tray support. Refer to PG-73, "Exploded View".
2. Remove the core support cover clips (A), then remove the core support (1).
3. Disconnect the "S" connector and the "B" terminal.
4. Remove the two starter motor bolts using power tools.
5. Remove the starter motor.
INSTALLATION
1. Converter housing 2. “B” terminal harness 3. “B” terminal nut
4. Starter motor bolt 5. Starter motor 6. “S” connector
7. Shim
ALBIA0932ZZ
ALKIA2602ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 4214 of 4801
STR-24
< REMOVAL AND INSTALLATION >
STARTER MOTOR
Installation is in the reverse order of removal.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 4215 of 4801
STARTER MOTORSTR-25
< SERVICE DATA AND SPECIFICATIONS (SDS)
C
D E
F
G H
I
J
K L
M A
STR
NP
O
SERVICE DATA AND SPECIFICATIONS (SDS)
STARTER MOTOR
StarterINFOID:0000000009461238
*: Always check with the Parts Department for the latest parts information. Application
QR25DE VQ35DE
CVT model
Manufacturer Melco
Model number* M000TB0071ZC M000TA0073ZC
Typ e Reduction gear type
System voltage 12V
No-load Terminal voltage 11V
Current Less than 90A
Revolution More than 2,370 rpm More than 2,400 rpm
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
