NISSAN TERRANO 2002 Service Repair Manual

Circuit Diagram for Quick Pinpoint Check
YBR244
TROUBLE DIAGNOSES
BR-49

Wiring Diagram Ð ABS Ð
LHD MODELS
YBR245
TROUBLE DIAGNOSES
BR-50

YBR246
TROUBLE DIAGNOSES
Wiring Diagram Ð ABS Ð (Cont'd)
BR-51

YBR247
TROUBLE DIAGNOSES
Wiring Diagram Ð ABS Ð (Cont'd)
BR-52

YBR248
TROUBLE DIAGNOSES
Wiring Diagram Ð ABS Ð (Cont'd)
BR-53

RHD MODELS
YBR249
TROUBLE DIAGNOSES
Wiring Diagram Ð ABS Ð (Cont'd)
BR-54

YBR250
TROUBLE DIAGNOSES
Wiring Diagram Ð ABS Ð (Cont'd)
BR-55

YBR251
TROUBLE DIAGNOSES
Wiring Diagram Ð ABS Ð (Cont'd)
BR-56

YBR252
TROUBLE DIAGNOSES
Wiring Diagram Ð ABS Ð (Cont'd)
BR-57

CONSULT-II
CONSULT-II APPLICATION TO ABS
ITEMSELF-DIAGNOSTIC
RESULTSDATA MONITOR ACTIVE TEST
Front right wheel sensor X X Ð
Front left wheel sensor X X Ð
Rear right wheel sensor X X Ð
Rear left wheel sensor X X Ð
G switch (G sensor) X X X
Stop lamp switch Ð X Ð
Front right inlet solenoid valve X X X
Front right outlet solenoid valve X X X
Front left inlet solenoid valve X X X
Front left outlet solenoid valve X X X
Rear inlet solenoid valve X X X
Rear outlet solenoid valve X X X
Actuator solenoid valve relay X X Ð
Actuator motor relay
(ABS MOTOR is shown on the Data Monitor
screen.)XXX
ABS warning lamp Ð X Ð
Brake warning lamp Ð X Ð
Battery voltage X X Ð
ABS Operating Signal Ð Ð Ð
X: Applicable
Ð: Not applicable
ECU (ABS control unit) part number mode
Ignore the ECU part number displayed in the ECU PART NUMBER MODE. Refer to parts catalog to order
the ECU.
TROUBLE DIAGNOSES
BR-58
