NISSAN TIIDA 2007 Service Repair Manual

DLK-472
< BASIC INSPECTION >[WITHOUT I-KEY & SUPER LOCK]
INSPECTION AND ADJUSTMENT
INSPECTION AND ADJUSTMENT
ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT
ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : Description
INFOID:0000000001396986
Perform the system initialization when replacing or registering Keyfob and ignition key.
ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : Special Repair Re-
quirement
INFOID:0000000001396987
Refer to the CONSULT-III Operation Manual-NATS.

DOOR LOCK FUNCTION
DLK-473
< FUNCTION DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
FUNCTION DIAGNOSIS
DOOR LOCK FUNCTION
DOOR LOCK AND UNLOCK SWITCH
DOOR LOCK AND UNLOCK SWITCH : System DiagramINFOID:0000000001396988
DOOR LOCK AND UNLOCK SWITCH OPERATION
DOOR LOCK AND UNLOCK SWITCH : System DescriptionINFOID:0000000001396989
DOOR LOCK AND UNLOCK SWITCH OPERATION
Functions are available by operating the door lock and unlock switch on center console. Interlocked with the
lock/unlock operation of door lock and unlock switch, door lock actuators of all doors are locked/unlocked.
Operation Condition
If the following conditions are not satisfied, door lock/unlock operation is not performed even if the door lock
and unlock switch is operated.
NOTE:
When the door lock is locked with keyfob, door lock and unlock switch operation will be invalid until either of
the following conditions is satisfied.
 Turn ignition switch ON.
 Unlock operation by keyfob.
ALKIA0710GB
Door lock and unlock switch Operation condition
Lock operationAll the following conditions are satisfied.
 Except driver side, doors are closed.
 Doors are not locked with keyfob.
Unlock operationAll the following all conditions are satisfied.
 Doors are not locked with keyfob.

DLK-474
< FUNCTION DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK]
DOOR LOCK FUNCTION
DOOR LOCK AND UNLOCK SWITCH : Component Parts Location
INFOID:0000000001396990
ALKIA0812ZZ
1. BCM M18, M19, M20
(view with glove box removed)2. Front door switch (driver side) B34
(Passenger side) B273. Front door lock actuator (driver side)
D14
(Passenger side) D114
Door unlock sensor (driver side) D14
4. Rear door switch LH B71
RH B535. Rear door lock actuator LH D205
RH D3056. Key switch and key lock solenoid
M27
7. Main power window and door lock/unlock
switch D7, D88. Back door lock assembly (back
door switch) D405 (hatchback view
with back door open)9. Back door opener switch (hatchback)
D408
10. Trunk lid opener switch (sedan) B61

DOOR LOCK FUNCTION
DLK-475
< FUNCTION DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
DOOR LOCK AND UNLOCK SWITCH : Component DescriptionINFOID:0000000001396991
REMOTE KEYLESS ENTRY
REMOTE KEYLESS ENTRY : System DiagramINFOID:0000000001396992
KEYFOB OPERATION
REMOTE KEYLESS ENTRY : System DescriptionINFOID:0000000001396993
KEYFOB OPERATION
The multi remote control system can be locked and unlocked by pressing door lock and unlock button of key-
fob.
DOOR LOCK AND UNLOCK OPERATION
When door lock and unlock button of keyfob is pressed, door lock
and unlock signal transmits from keyfob to BCM. When BCM
receives the door lock and unlock signal, it operates door lock actua-
tor.
1. Integrated door lock keyfob.
2. Integrated ignition key/emergency key.
3. Key number plate.
OPERATION CONDITION
OPERATION AREA
To ensure that the keyfob works effectively, use within 100 cm range of each door, however the operable
range may differ according to surroundings.
Item Function
BCM Controls the door lock and unlock function.
Door switch Detects door state (open or closed).
Door lock and unlock switchTransmits door lock and unlock signal to BCM. Door lock and unlock switch indicator is built
in door lock and unlock switch.
Door lock actuator Receives door lock and unlock signal from BCM and locks and unlocks each door.
ALKIA0836GB
ALKIA0821ZZ
Remote controller operation Operation condition
Lock/unlock Key switch is OFF (key is removed from ignition key cylinder).

DLK-476
< FUNCTION DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK]
DOOR LOCK FUNCTION
ANTI-HIJACK MODE
When door lock is unlocked, pressing LOCK button on keyfob once will lock all doors. When door lock is
locked, pressing UNLOCK button on keyfob will unlock driver side door. Pressing UNLOCK button on keyfob
second time within 5 seconds from the first time will unlock all doors and back door can be opened with back
door opener switch.
NOTE:
Anti-hijack mode can be set to ON or OFF with CONSULT-III. For the setting information, refer to DLK-490,
"MULTIREMOTE ENT : CONSULT-III Function (BCM - MULTIREMOTE ENT)".
REMOTE KEYLESS ENTRY : Component Parts LocationINFOID:0000000001396994
ALKIA0817ZZ
1. BCM M18, M19, M20
(view with glove box removed)2. Front door switch (driver side) B34
(Passenger side) B273. Rear door switch LH B71
RH B53
4. Back door lock assembly (back door switch)
D405 (hatchback view with back door open)5. Key switch and key lock solenoid
M276. Trunk lid opener switch (sedan) B61
7. Back door opener switch (hatchback) D408

DOOR LOCK FUNCTION
DLK-477
< FUNCTION DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
REMOTE KEYLESS ENTRY : Component DescriptionINFOID:0000000001396995
Item Function
BCM Controls the door lock function.
Key switch Detects that ignition key is inserted into ignition key cylinder.
Door lock actuator Receives lock and unlock signal from BCM and locks and unlocks each door.

DLK-478
< FUNCTION DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK]
BACK DOOR OPENER FUNCTION
BACK DOOR OPENER FUNCTION
BACK DOOR OPENER SWITCH
BACK DOOR OPENER SWITCH : System DiagramINFOID:0000000001530579
BACK DOOR OPENER OPERATION
BACK DOOR OPENER SWITCH : System DescriptionINFOID:0000000001530580
BACK DOOR OPENER OPERATION
When back door opener switch is pressed, BCM opens back door opener actuator.
NOTE:
Back door opener actuator is not for locking the back door. The function is only to open the back door.
OPERATION CONDITION
If the following conditions are not satisfied, back door opener operation is not performed.
BACK DOOR OPENER SWITCH : Component Parts LocationINFOID:0000000001530581
JMKIA0402GB
Back door opener switch operation Operation condition
Back door open Vehicle speed is less than 5 km/h (3 MPH).
 All doors are unlocked.
1. BCM M18, M20 2. Back door lock assembly (back door switch)
D405
(hatchback view with back door open)3. Back door opener switch D408
ALKIA0818ZZ

BACK DOOR OPENER FUNCTION
DLK-479
< FUNCTION DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
BACK DOOR OPENER SWITCH : Component DescriptionINFOID:0000000001530582
Item Function
BCM Controls the back door opener function.
Back door opener switch Transmits back door opener switch operation signal to BCM.
Back door opener actuator Opens the back door with the back door open signal from BCM.
Combination meter Transmits vehicle speed signal to BCM via CAN communication.

DLK-480
< FUNCTION DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK]
TRUNK LID OPENER
TRUNK LID OPENER
TRUNK LID OPENER SWITCH
TRUNK LID OPENER SWITCH : System DiagramINFOID:0000000001530583
TRUNK LID OPENER OPERATION
TRUNK LID OPENER SWITCH : System DescriptionINFOID:0000000001530584
TRUNK LID OPENER OPERATION
When trunk lid opener switch is pressed, BCM opens trunk release solenoid.
NOTE:
Trunk release solenoid is not for locking the back door. The function is only to open the trunk.
OPERATION CONDITION
If the following conditions are not satisfied, trunk release operation is not performed.
TRUNK LID OPENER SWITCH : Component Parts LocationINFOID:0000000001530585
ALKIA0717GB
Trunk lid opener switch operation Operation condition
Trunk release solenoid Vehicle speed is less than 5 km/h (3 MPH).
 All doors are unlocked.
ALKIA0819ZZ
1. BCM
M18, M202. Trunk lamp switch and trunk release solenoid
B663. Trunk lid opener switch B61

TRUNK LID OPENER
DLK-481
< FUNCTION DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
TRUNK LID OPENER SWITCH : Component DescriptionINFOID:0000000001530586
Item Function
BCM Controls the trunk lid opener switch function.
Trunk lid opener switch Transmits trunk lid opener switch operation signal to BCM.
Trunk release solenoid Opens the trunk with the trunk release solenoid signal from BCM.
Combination meter Transmits vehicle speed signal to BCM via CAN communication.
