DOOR SWITCH
2. Check continuity between BCM connector (A) M18 terminal 30
and passenger door switch connector (B) B27 terminal 2.
3. Check continuity between BCM connector (A) M18 terminal 30
and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness between BCM and door switch.
3.CHECK DOOR SWITCH
Check door switch.
Refer to DLK-502, "
PASSENGER SIDE : Component Inspection".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace front door switch (passenger side). Refer to XX-XX, "*****"
.
4.CHECK INTERMITTENT INCIDENT
Refer to @@@.
>> INSPECTION END
PASSENGER SIDE : Component InspectionINFOID:0000000001530629
1.CHECK DOOR SWITCH
1. Turn ignition switch OFF.
2. Check passenger door switch.
Is the inspection result normal?
YES >> Door switch is OK.
NO >> Replace front door switch (passenger side). Refer to XX-XX, "*****"
.
REAR LH
BCM connector TerminalDoor switch
connectorTerminal Continuity
M18 30 B27 2 Yes
BCM connector Terminal
GroundContinuity
M18 30 No
ALKIA0748ZZ
ALKIA0747ZZ
Te r m i n a l
Door switch condition Continuity
Door switch
2 Ground part of door switchPressed Yes
Released No

DOOR SWITCH
DLK-503
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
REAR LH : DescriptionINFOID:0000000001530630
Detects door open/closed condition.
REAR LH : Component Function CheckINFOID:0000000001530631
1.CHECK FUNCTION
With CONSULT-III
Check door switches “DOOR SW-RL” in “Data Monitor” mode with CONSULT-III.
Is the inspection result normal?
YES >> Door switch is OK.
NO >> Refer to DLK-503, "
REAR LH : Diagnosis Procedure".
REAR LH : Diagnosis ProcedureINFOID:0000000001530632
1.CHECK DOOR SWITCH INPUT SIGNAL
1. Turn ignition switch OFF.
2. Check signal between BCM connector and ground with oscillo-
scope.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 2.
2.CHECK DOOR SWITCH CIRCUIT
1. Disconnect BCM connector and rear door switch LH.
Monitor item Condition
DOOR SW-RLOPEN :ON
CLOSE :OFF
ALKIA0750ZZ
Te r m i n a l s
Door conditionVoltage (V)
(Approx.) (+)
(–)
BCM
connectorTe r m i n a l
M19 59 GroundOPEN 0
CLOSE
JPMIA0011GB

DLK-504
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK]
DOOR SWITCH
2. Check continuity between BCM connector (A) M19 terminal 59
and rear door switch LH connector (B) B71 terminal 1.
3. Check continuity between BCM connector (A) M19 terminal 59
and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness between BCM and rear door switch LH.
3.CHECK DOOR SWITCH
Check door switch.
Refer to DLK-504, "
REAR LH : Component Inspection".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace rear door switch LH. Refer to XX-XX, "*****"
.
4.CHECK INTERMITTENT INCIDENT
Refer to @@@.
>> INSPECTION END
REAR LH : Component InspectionINFOID:0000000001530633
1.CHECK DOOR SWITCH
1. Turn ignition switch OFF.
2. Check rear door switch LH.
Is the inspection result normal?
YES >> Door switch is OK.
NO >> Replace rear door switch LH. Refer to XX-XX, "*****"
.
REAR RH
BCM connector TerminalRear door switch LH
connectorTerminal Continuity
M19 59 B71 1 Yes
BCM connector Terminal
GroundContinuity
M19 59 No
ALKIA0751ZZ
ALKIA0752ZZ
Te r m i n a l
Door switch condition Continuity
Door switch
1Ground part of door
switchPressed Yes
Released No

DOOR SWITCH
DLK-505
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
REAR RH : DescriptionINFOID:0000000001530634
Detects door open/close condition.
REAR RH : Component Function CheckINFOID:0000000001530635
1.CHECK FUNCTION
With CONSULT-III
Check door switches “DOOR SW-RR” in “Data Monitor” mode with CONSULT-III.
Is the inspection result normal?
YES >> Door switch is OK.
NO >> Refer to DLK-505, "
REAR RH : Diagnosis Procedure".
REAR RH : Diagnosis ProcedureINFOID:0000000001530636
1.CHECK DOOR SWITCH INPUT SIGNAL
1. Turn ignition switch OFF.
2. Check signal between BCM connector and ground with oscillo-
scope.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 2.
2.CHECK DOOR SWITCH CIRCUIT
1. Disconnect BCM connector.
Monitor item Condition
DOOR SW-RROPEN :ON
CLOSE :OFF
ALKIA0754ZZ
Te r m i n a l s
Door conditionVoltage (V)
(Approx.) (+)
(–)
BCM
connectorTe r m i n a l
M19 60 GroundOPEN 0
CLOSE
JPMIA0011GB

DLK-506
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK]
DOOR SWITCH
2. Check continuity between BCM connector (A) M19 terminal 60
and rear door switch RH connector (B) B53 terminal 1.
3. Check continuity between BCM connector (A) M19 terminal 60
and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness between BCM and rear door switch RH.
3.CHECK DOOR SWITCH
Check door switch.
Refer to DLK-506, "
REAR RH : Component Inspection".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace rear door switch RH. Refer to XX-XX, "*****"
.
4.CHECK INTERMITTENT INCIDENT
Refer to @@@.
>> INSPECTION END
REAR RH : Component InspectionINFOID:0000000001530637
1.CHECK DOOR SWITCH
1. Turn ignition switch OFF.
2. Check rear door switch RH.
Is the inspection result normal?
YES >> Door switch is OK.
NO >> Replace rear door switch RH. Refer to XX-XX, "*****"
.
BACK DOOR
BCM connector TerminalRear door switch
RH connectorTerminal Continuity
M19 60 B53 1 Yes
BCM connector Terminal
GroundContinuity
M19 60 No
ALKIA0753ZZ
ALKIA0752ZZ
Te r m i n a l
Door switch condition Continuity
Door switch
1 Ground part of door switchPressed Yes
Released No

DOOR SWITCH
DLK-507
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
BACK DOOR : DescriptionINFOID:0000000001530638
Detects back door open condition.
BACK DOOR : Component Function CheckINFOID:0000000001530639
1.CHECK FUNCTION
With CONSULT-III
Check “BACK DOOR SW” in “Data Monitor” mode with CONSULT-III.
Is the inspection result normal?
YES >> Back door lock assembly (door switch) is OK.
NO >> Refer to DLK-507, "
BACK DOOR : Diagnosis Procedure".
BACK DOOR : Diagnosis ProcedureINFOID:0000000001530640
1.CHECK BACK DOOR LOCK ASSEMBLY (DOOR SWITCH) INPUT SIGNAL
1. Turn ignition switch OFF.
2. Check voltage between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO >> GO TO 2.
2.CHECK BACK DOOR LOCK ASSEMBLY (DOOR SWITCH) CIRCUIT
1. Disconnect BCM connector and back door lock assembly.
Monitor item Condition
BACK DOOR SWOPEN : ON
CLOSE : OFF
ALKIA0755ZZ
Te r m i n a l s
Back door
conditionVoltage (V)
(Approx.) (+)
(–)
BCM connector Terminal
M18 10 GroundOPEN 0
CLOSE Battery voltage

DLK-508
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK]
DOOR SWITCH
2. Check continuity between BCM connector (A) M18 terminal 10
and back door lock assembly (door switch) connector (B) D405
terminal 3.
3. Check continuity between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness between BCM and back door lock assembly.
3.CHECK BACK DOOR LOCK ASSEMBLY GROUND CIRCUIT
Check continuity between back door lock assembly connector and
ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace back door lock assembly ground circuit.
4.CHECK BCM OUTPUT SIGNAL
1. Connect BCM connector.
ALKIA0756ZZ
BCM connector TerminalBack door lock assembly
(door switch) connectorTerminal Continuity
M18 10 D405 3 Yes
BCM connector Terminal
GroundContinuity
M18 10 No
ALKIA0757ZZ
Back door lock assembly
(door switch) connectorTe r m i n a l
GroundContinuity
D405 4 Yes

DOOR SWITCH
DLK-509
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
2. Check voltage between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 6.
5.CHECK BACK DOOR LOCK ASSEMBLY (DOOR SWITCH)
Check back door lock assembly (door switch).
Refer to DLK-509, "
BACK DOOR : Component Inspection".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Replace back door lock assembly (door switch). Refer to XX-XX, "*****"
and XX-XX, "*****".
6.CHECK INTERMITTENT INCIDENT
Refer to @@@.
>> INSPECTION END
BACK DOOR : Component InspectionINFOID:0000000001530641
1.CHECK BACK DOOR LOCK ASSEMBLY (DOOR SWITCH)
1. Turn ignition switch OFF.
2. Check back door lock assembly (door switch).
Is the inspection result normal?
ALKIA0755ZZ
Te r m i n a l s
Voltage (V)
(Approx.) (+)
(–)
BCM connector Terminal
M18 10 Ground Battery voltage
ALKIA0758ZZ
Te r m i n a l
Back door condition Continuity
Back door lock assembly (door switch)
34OPEN Yes
CLOSE No

DLK-510
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK]
DOOR SWITCH
YES >> Back door lock assembly (door switch) is OK.
NO >> Replace back door lock assembly (door switch). Refer to XX-XX, "*****"
and XX-XX, "*****".

KEY SWITCH
DLK-511
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
KEY SWITCH
DescriptionINFOID:0000000001530642
Key switch detects that mechanical key is inserted into the key cylinder, and then transmits the signal to BCM.
Component Function CheckINFOID:0000000001530643
1.CHECK KEY SWITCH INPUT SIGNAL
Check key switch (“KEY SW”) in “Data Monitor” mode with CONSULT-III. Refer to DLK-50, "
DOOR LOCK :
CONSULT-III Function (BCM - DOOR LOCK)".
Is the inspection result normal?
YES >> Key switch is OK.
NO >> Refer to DLK-511, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001530644
1.CHECK KEY SWITCH INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect BCM connector.
3. Check voltage between BCM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 2.
2.CHECK KEY SWITCH POWER SUPPLY CIRCUIT
1. Remove mechanical key from key cylinder.
2. Disconnect key switch connector.
Monitor item Condition
KEY SWInsert mechanical key into key cylinder : ON
Remove mechanical key from key cylinder : OFF
ALKIA0838ZZ
Te r m i n a l s
ConditionVoltage (V)
(Approx.) (+)
(–)
BCM connector Terminal
M18 3 GroundInsert mechanical key into key
cylinderBattery voltage
Remove mechanical key from
key cylinder0
