NISSAN TIIDA 2007 Service Repair Manual

EC-292
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
P2127, P2128 APP SENSOR
7.CHECK COMPONENTS
Check the following.
 Crankshaft position sensor (POS) (Refer to EC-200, "
Component Inspection".)
 Refrigerant pressure sensor (Refer to EC-326, "
Diagnosis Procedure".)
Is the inspection result normal?
YES >> GO TO 14.
NO >> Replace malfunctioning component.
8.CHECK APP SENSOR 2 GROUND CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between APP sensor harness connector and ECM harness connector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 10.
NO >> GO TO 9.
9.DETECT MALFUNCTIONING PART
Check the following.
 Harness or connectors E7, M69, M25, M201 (RHD models).
 Harness for open or short between ECM and APP sensor.
>> Repair open circuit or short to ground or short to power in harness or connectors.
10.CHECK APP SENSOR 2 INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Check the continuity between APP sensor harness connector and ECM harness connector.
2. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 12.
NO >> GO TO 11.
11 .DETECT MALFUNCTIONING PART
Check the following.
 Harness or connectors E7, M69, M25, M201.
 Harness for open or short between ECM and APP sensor.
>> Repair open circuit or short to ground or short to power in harness or connectors.
12.CHECK APP SENSOR
Refer to EC-293, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 14.
NO >> GO TO 13.
APP sensor ECM
Continuity
Connector Terminal Connector Terminal
E12 (LHD models)
M204 (RHD models)1 E16 104 Existed
APP sensor ECM
Continuity
Connector Terminal Connector Terminal
E12 (LHD models)
M204 (RHD models)6 E16 103 Existed

P2127, P2128 APP SENSOR
EC-293
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
13.REPLACE ACCELERATOR PEDAL ASSEMBLY
1. Replace accelerator pedal assembly.
2. Go to EC-293, "
Special Repair Requirement".
>> INSPECTION END
14.CHECK INTERMITTENT INCIDENT
Refer to GI-55, "
Intermittent Incident".
>> INSPECTION END
Component InspectionINFOID:0000000001671071
1.CHECK ACCELERATOR PEDAL POSITION SENSOR
1. Reconnect all harness connectors disconnected.
2. Turn ignition switch ON.
3. Check the voltage between ECM harness connector and ground.
Is the inspection result normal?
YES >> INSPECTION END
NO >> GO TO 2.
2.REPLACE ACCELERATOR PEDAL ASSEMBLY
1. Replace accelerator pedal assembly.
2. Go to EC-293, "
Special Repair Requirement".
>> INSPECTION END
Special Repair RequirementINFOID:0000000001671072
1.PERFORM ACCELERATOR PEDAL RELEASED POSITION LEARNING
Refer to EC-26, "
ACCELERATOR PEDAL RELEASED POSITION LEARNING : Special Repair Requirement".
>> GO TO 2.
2.PERFORM THROTTLE VALVE CLOSED POSITION LEARNING
Refer to EC-27, "
THROTTLE VALVE CLOSED POSITION LEARNING : Special Repair Requirement".
>> GO TO 3.
3.PERFORM IDLE AIR VOLUME LEARNING
Refer to EC-27, "
IDLE AIR VOLUME LEARNING : Special Repair Requirement".
>> END
(+) (–)
Condition Voltage
Connector Terminal Connector Terminal
E1611 0
(APP sensor 1 signal)
E16111
Accelerator pedalFully released 0.6 - 0.9V
Fully depressed 3.9 - 4.7V
103
(APP sensor 2 signal)104Fully released 0.3 - 0.6V
Fully depressed 1.95 - 2.4V

EC-294
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
P2135 TP SENSOR
P2135 TP SENSOR
DescriptionINFOID:0000000001671073
Electric throttle control actuator consists of throttle control motor,
throttle position sensor, etc. The throttle position sensor responds to
the throttle valve movement.
The throttle position sensor has two sensors. These sensors are a
kind of potentiometers which transform the throttle valve position into
output voltage, and emit the voltage signal to the ECM. In addition,
these sensors detect the opening and closing speed of the throttle
valve and feed the voltage signals to the ECM. The ECM judges the
current opening angle of the throttle valve from these signals and the
ECM controls the throttle control motor to make the throttle valve
opening angle properly in response to driving condition.
DTC LogicINFOID:0000000001671074
DTC DETECTION LOGIC
NOTE:
If DTC P2135 is displayed with DTC P1229, first perform the trouble diagnosis for DTC P1229. Refer to
EC-265, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is more than 8V at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and let it idle for 1 second.
2. Check DTC.
Is DTC detected?
YES >> Go to EC-294, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000001671075
1.CHECK GROUND CONNECTION
1. Turn ignition switch OFF.
2. Check ground connection E15. Refer to Ground Inspection in GI-58, "
Circuit Inspection".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace ground connection.
2.CHECK THROTTLE POSITION SENSOR POWER SUPPLY CIRCUIT-I
1. Disconnect electric throttle control actuator harness connector.
PBIB0145E
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P2135Throttle position sensor
circuit range/perfor-
manceRationally incorrect voltage is sent to ECM
compared with the signals from TP sensor 1
and TP sensor 2. Harness or connector
(TP sensor 1 and 2 circuit is open or
shorted.)
 Electric throttle control actuator
(TP sensor 1 and 2)

P2135 TP SENSOR
EC-295
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
2. Turn ignition switch ON.
3. Check the voltage between electric throttle control actuator harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
3.CHECK THROTTLE POSITION SENSOR POWER SUPPLY CIRCUIT-II
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between electric throttle control actuator harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair open circuit.
4.CHECK THROTTLE POSITION SENSOR GROUND CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between electric throttle control actuator harness connector and ground.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
5.CHECK THROTTLE POSITION SENSOR INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Check the continuity between electric throttle control actuator harness connector and ground.
2. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
6.CHECK THROTTLE POSITION SENSOR
Refer to EC-296, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 8.
NO >> GO TO 7.
Electric throttle control actuator
Ground Voltage
Connector Terminal
F7 1 Ground Approx. 5V
Electric throttle control actuator ECM
Continuity
Connector Terminal Connector Terminal
F7 1 F11 72 Existed
Electric throttle control actuator ECM
Continuity
Connector Terminal Connector Terminal
F7 4 F11 36 Existed
Electric throttle control actuator ECM
Continuity
Connector Terminal Connector Terminal
F72
F1133
Existed
334

EC-296
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
P2135 TP SENSOR
7.REPLACE ELECTRIC THROTTLE CONTROL ACTUATOR
1. Replace electric throttle control actuator.
2.EC-296, "
Special Repair Requirement"
>> INSPECTION END
8.CHECK INTERMITTENT INCIDENT
Refer to GI-55, "
Intermittent Incident".
>> INSPECTION END
Component InspectionINFOID:0000000001671076
1.CHECK THROTTLE POSITION SENSOR
1. Turn ignition switch OFF.
2. Reconnect all harness connectors disconnected.
3. Perform EC-296, "
Special Repair Requirement".
4. Turn ignition switch ON.
5. Set shift lever to D (A/T), 1st (M/T) position.
6. Check the voltage between ECM harness connector terminals as follows.
Is the inspection result normal?
YES >> INSPECTION END
NO >> GO TO 2.
2.REPLACE ELECTRIC THROTTLE CONTROL ACTUATOR
1. Replace electric throttle control actuator.
2. Go to EC-296, "
Special Repair Requirement".
>> INSPECTION END
Special Repair RequirementINFOID:0000000001671077
1.PERFORM THROTTLE VALVE CLOSED POSITION LEARNING
Refer to EC-27, "
THROTTLE VALVE CLOSED POSITION LEARNING : Special Repair Requirement"
>> GO TO 2.
2.PERFORM IDLE AIR VOLUME LEARNING
Refer to EC-27, "
IDLE AIR VOLUME LEARNING : Special Repair Requirement"
>> END
(+) (–)
Condition Voltage
Connector Terminal Connector Terminal
F1133
(TP sensor 1 signal)
F11 36 Accelerator pedalFully released More than 0.36V
Fully depressed Less than 4.75V
34
(TP sensor 2 signal)Fully released Less than 4.75V
Fully depressed More than 0.36V

P2138 APP SENSOR
EC-297
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
P2138 APP SENSOR
DescriptionINFOID:0000000001671078
The accelerator pedal position sensor is installed on the upper end
of the accelerator pedal assembly. The sensor detects the accelera-
tor position and sends a signal to the ECM.
Accelerator pedal position sensor has two sensors. These sensors
are a kind of potentiometers which transform the accelerator pedal
position into output voltage, and emit the voltage signal to the ECM.
In addition, these sensors detect the opening and closing speed of
the accelerator pedal and feed the voltage signals to the ECM. The
ECM judges the current opening angle of the accelerator pedal from
these signals and controls the throttle control motor based on these
signals.
Idle position of the accelerator pedal is determined by the ECM
receiving the signal from the accelerator pedal position sensor. The ECM uses this signal for the engine oper-
ation such as fuel cut.
DTC LogicINFOID:0000000001671079
DTC DETECTION LOGIC
NOTE:
If DTC P2138 is displayed with DTC P1229, first perform the trouble diagnosis for DTC P1229. Refer to
EC-265, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is more than 10V at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and let it idle for 1 second.
2. Check DTC.
Is DTC detected?
YES >> Go to EC-297, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000001671080
1.CHECK GROUND CONNECTION
1. Turn ignition switch OFF.
PBIB1741E
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P2138Accelerator pedal posi-
tion sensor circuit range/
performanceRationally incorrect voltage is sent to ECM
compared with the signals from APP sensor 1
and APP sensor 2. Harness or connector
(APP sensor 1 and 2 circuit is open or
shorted.)
[Crankshaft position sensor (POS) circuit
is shorted.)
(Refrigerant pressure sensor circuit is
shorted.)
 Accelerator pedal position sensor
(APP sensor 1 and 2)
 Crankshaft position sensor (POS)
 Refrigerant pressure sensor

EC-298
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
P2138 APP SENSOR
2. Check ground connection E15. Refer to Ground Inspection in GI-58, "Circuit Inspection".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace ground connection.
2.CHECK APP SENSOR 1 POWER SUPPLY CIRCUIT
1. Disconnect accelerator pedal position (APP) sensor harness connector.
2. Turn ignition switch ON.
3. Check the voltage between APP sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
3.DETECT MALFUNCTINING PART
 Harness or connectors E7, M69, M25, M201 (RHD models).
 Harness for open or short between ECM and APP sensor.
>> Repair open circuit or short to ground or shot to power in harness or connectors.
4.CHECK APP SENSOR 2 POWER SUPPLY CIRCUIT-I
1. Turn ignition switch ON.
2. Check the voltage between APP sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 9.
NO >> GO TO 5.
5.CHECK APP SENSOR 2 POWER SUPPLY CIRCUIT-II
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between APP sensor harness connector and ECM harness connector.
Is the inspection result normal?
YES >> GO TO 7.
NO >> GO TO6.
6.DETECT MALFUNCTINING PART
 Harness or connectors E7, M69, M25, M201 (RHD models).
 Harness for open or short between ECM and APP sensor.
>> Repair open circuit or short to ground or shot to power in harness or connectors.
APP sensor
Ground Voltage
Connector Terminal
E12 (LHD models)
M204 (RHD models)4 Ground Approx. 5V
APP sensor
Ground Voltage
Connector Terminal
E12 (LHD models)
M204 (RHD models)5 Ground Approx. 5V
APP sensor ECM
Continuity
Connector Terminal Connector Terminal
E12 (LHD models)
M204 (RHD models)5 E16 102 Existed

P2138 APP SENSOR
EC-299
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
7.CHECK APP SENSOR 2 POWER SUPPLY CIRCUIT-III
Check harness for short to power and short to ground, between the following terminals.
Is the inspection result normal?
YES >> GO TO 8.
NO >> Repair short to ground or short to power in harness or connectors.
8.CHECK COMPONENTS
Check the following.
 Crankshaft position sensor (POS) (Refer to EC-200, "
Component Inspection".)
 Refrigerant pressure sensor (Refer to EC-326, "
Diagnosis Procedure".)
Is the inspection result normal?
YES >> GO TO 15.
NO >> Replace malfunctioning component.
9.CHECK APP SENSOR GROUND CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between APP sensor harness connector and ECM harness connector as follows.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 11.
NO >> Repair open circuit or short to ground or shot to power in harness or connectors.
10.DETECT MALFUNCTINING PART
 Harness or connectors E7, M69, M25, M201 (RHD models).
 Harness for open or short between ECM and APP sensor.
>> Repair open circuit or short to ground or shot to power in harness or connectors.
11 .CHECK APP SENSOR INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Check the continuity between APP sensor harness connector and ECM harness connector as follows.
2. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 13.
NO >> GO TO 12.
ECM Sensor
Connector Terminal Item Connector Terminal
F1174 Refrigerant pressure sensor E17 3
75 CKP sensor (POS) F15 1
E16 102 APP sensorE12 (LHD models)
M204 (RHD models)5
APP sensor ECM
Continuity
Connector Terminal Connector Terminal
E12 (LHD models)
M204 (RHD models)2
E16111
Existed
1104
APP sensor ECM
Continuity
Connector Terminal Connector Terminal
E12 (LHD models)
M204 (RHD models)3
E1611 0
Existed
6103

EC-300
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
P2138 APP SENSOR
12.DETECT MALFUNCTINING PART
 Harness or connectors E7, M69, M25, M201 (RHD models).
 Harness for open or short between ECM and APP sensor.
>> Repair open circuit or short to ground or shot to power in harness or connectors.
13.CHECK APP SENSOR
Refer to EC-300, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 15.
NO >> GO TO 14.
14.REPLACE ACCELERATOR PEDAL ASSEMBLY
1. Replace accelerator pedal assembly.
2. Go to EC-300, "
Special Repair Requirement".
>> INSPECTION END
15.CHECK INTERMITTENT INCIDENT
Refer to GI-55, "
Intermittent Incident".
>> INSPECTION END
Component InspectionINFOID:0000000001671081
1.CHECK ACCELERATOR PEDAL POSITION SENSOR
1. Reconnect all harness connectors disconnected.
2. Turn ignition switch ON.
3. Check the voltage between ECM harness connector terminals as follows.
Is the inspection result normal?
YES >> INSPECTION END
NO >> GO TO 2.
2.REPLACE ACCELERATOR PEDAL ASSEMBLY
1. Replace accelerator pedal assembly.
2. Go to EC-300, "
Special Repair Requirement".
>> INSPECTION END
Special Repair RequirementINFOID:0000000001671082
1.PERFORM ACCELERATOR PEDAL RELEASED POSITION LEARNING
Refer to EC-26, "
ACCELERATOR PEDAL RELEASED POSITION LEARNING : Special Repair Requirement".
>> GO TO 2.
2.PERFORM THROTTLE VALVE CLOSED POSITION LEARNING
(+) (–)
Condition Voltage
Connector Terminal Connector Terminal
E1611 0
(APP sensor 1 signal)
E16111
Accelerator pedalFully released 0.6 - 0.9V
Fully depressed 3.9 - 4.7V
103
(APP sensor 2 signal)104Fully released 0.3 - 0.6V
Fully depressed 1.95 - 2.4V

P2138 APP SENSOR
EC-301
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
Refer to EC-27, "THROTTLE VALVE CLOSED POSITION LEARNING : Special Repair Requirement".
>> GO TO 3.
3.PERFORM IDLE AIR VOLUME LEARNING
Refer to EC-27, "
IDLE AIR VOLUME LEARNING : Special Repair Requirement".
>> END
