NISSAN TIIDA 2007 Service Repair Manual

EC-632
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
REFRIGERANT PRESSURE SENSOR
REFRIGERANT PRESSURE SENSOR
DescriptionINFOID:0000000001693449
The refrigerant pressure sensor is installed at the condenser of the air conditioner system. The sensor uses an
electrostatic volume pressure transducer to convert refrigerant pressure to voltage. The voltage signal is sent
to ECM, and ECM controls cooling fan system.
Component Function CheckINFOID:0000000001693450
1.CHECK REFRIGERANT PRESSURE SENSOR OVERALL FUNCTION
1. Start engine and warm it up to normal operating temperature.
2. Turn A/C switch and blower fan switch ON.
3. Check the voltage between ECM harness connector terminals as follows.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to EC-632, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001693451
1.CHECK GROUND CONNECTION
1. Turn A/C switch and blower fan switch OFF.
2. Stop engine.
3. Turn ignition switch OFF.
4. Check ground connection E15. Refer to Ground Inspection in GI-58, "
Circuit Inspection".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace ground connection.
2.CHECK REFRIGERANT PRESSURE SENSOR POWER SUPPLY CIRCUIT
1. Disconnect refrigerant pressure sensor harness connector.
2. Turn ignition switch ON.
3. Check the voltage between refrigerant pressure sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
PBIB2657E
(+) (–)
Voltage
Connector Terminal Connector Terminal
F1141
(Refrigerant pressure sensor signal)F11 48 1.0 - 4.0V
Refrigerant pressure sensor
Ground Voltage
Connector Terminal
E17 3 Ground Approx. 5V

REFRIGERANT PRESSURE SENSOR
EC-633
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
3.DETECT MALFUNCTIONING PART
Check the following.
 Harness connectors E8, F8
 Harness for open or short between ECM and refrigerant pressure sensor
>> Repair open circuit or short to ground or short to power in harness or connectors.
4.CHECK REFRIGERANT PRESSURE SENSOR GROUND CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between refrigerant pressure sensor harness connector and ECM harness connec-
tor.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 6.
NO >> GO TO 5.
5.DETECT MALFUNCTIONING PART
Check the following.
 Harness connectors E8, F8
 Harness for open or short between ECM and refrigerant pressure sensor
>> Repair open circuit or short to ground or short to power in harness or connectors.
6.CHECK REFRIGERANT PRESSURE SENSOR INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Check the continuity between ECM harness connector and refrigerant pressure sensor harness connec-
tor.
2. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 8.
NO >> GO TO 7.
7.DETECT MALFUNCTIONING PART
Check the following.
 Harness connectors E8, F8
 Harness for open or short between ECM and refrigerant pressure sensor
>> Repair open circuit or short to ground or short to power in harness or connectors.
8.CHECK INTERMITTENT INCIDENT
Refer to GI-55, "
Intermittent Incident".
Is the inspection result normal?
YES >> Replace refrigerant pressure sensor.
NO >> Repair or replace.
Refrigerant pressure sensor ECM
Continuity
Connector Terminal Connector Terminal
E17 1 F11 48 Existed
Refrigerant pressure sensor ECM
Continuity
Connector Terminal Connector Terminal
E17 2 F11 41 Existed

EC-634
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
VSS
VSS
DescriptionINFOID:0000000001697511
The vehicle speed signal is sent to the combination meter from the “ABS actuator and electric unit (control
unit)” by CAN communication line. The combination meter then sends a signal to the ECM by CAN communi-
cation line.
Diagnosis ProcedureINFOID:0000000001697512
1.INSPECTION START
Do you have CONSULT-III?
Do you have CONSULT-III?
YES >> GO TO 2.
NO >> GO TO 3.
2.PERFORM COMPONENT FUNCTION CHECK
1. Turn ignition switch OFF.
2. Lift up the vehicle.
3. Start engine and let it idle.
4. Select “VHCL SPEED SE” in “DATA MONITOR” mode with CONSULT-III.
5. Select “VHCL SPEED SE” indication whe n rotating wheels with suitable gear position.
Is the inspection result normal?
YES >> INSPECTION END
NO >> GO TO 3.
3.CHECK DTC WITH “ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)”
Refer to BRC-25, "
CONSULT-III Function (ABS)" (with ABS) or BRC-105, "CONSULT-III Function (ABS)" (with
ESP/TCS/ABS).
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace.
4.CHECK COMBINATION METER FUNCTION
Refer to MWI-25, "
DTC Logic".
>> INSPECTION END “VHCL SPEED SE” indication should
exceed 10 km/h (6 MPH).

ECM
EC-635
< ECU DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
ECU DIAGNOSIS
ECM
Reference ValueINFOID:0000000001693499
VALUES ON THE DIAGNOSIS TOOL
Remarks:
 Specification data are reference values.
 Specification data are output/input values which are detected or supplied by the ECM at the connector.
*Specification data may not be directly related to their components signals/values/operations.
I.e. Adjust ignition timing with a timing light before monitoring IGN TIMING, because the monitor may show the
specification data in spite of the ignition timing not being adjusted to the specification data. this IGN TIMING
monitors the data calculated by the ECM according to the signals input from the camshaft position sensor and
other ignition timing related sensors.
Monitor Item Condition Values/Status
ENG SPEED  Run engine and compare CONSULT-III value with the tachometer indication.Almost the same speed as
the tachometer indication.
MAS A/F SE-B1 See EC-477, "
Diagnosis Procedure".
B/FUEL SCHDL See EC-477, "
Diagnosis Procedure".
A/F ALPHA-B1 See EC-477, "
Diagnosis Procedure".
COOLAN TEMP/S  Engine: After warming up More than 70°C (158F)
HO2S1 (B1)  Engine: After warming up Maintaining engine speed at 2,000 rpm0 - 0.3V ←→ Approx. 0.6 -
1.0V
HO2S2 (B1) Revving engine from idle up to 3,000 rpm quickly after the following conditions
are met.
- Engine: After warming up
- After keeping engine speed between 3,500 and 4,000 rpm for 1 minute and at
idle for 1 minute under no load0 - 0.3V ←→ Approx. 0.6 -
1.0V
HO2S1 MNTR (B1)  Engine: After warming up Maintaining engine speed at 2,000 rpmLEAN ←→ RICH
Changes more than 5 times
during 10 seconds
HO2S2 MNTR (B1) Revving engine from idle up to 3,000 rpm quickly after the following conditions
are met.
- Engine: After warming up
- After keeping engine speed between 3,500 and 4,000 rpm for 1 minute and at
idle for 1 minute under no loadLEAN ←→ RICH
VHCL SPEED SE Turn drive wheels and compare CONSULT-III value with the speedometer in-
dication.Almost the same speed as
speedometer indication
BATTERY VOLT  Ignition switch: ON (Engine stopped) 11 - 14V
ACCEL SEN 1 Ignition switch: ON
(Engine stopped)Accelerator pedal: Fully released 0.6 - 0.9V
Accelerator pedal: Fully depressed 4.0 - 4.8V
ACCEL SEN 2 Ignition switch: ON
(Engine stopped)Accelerator pedal: Fully released 0.6 - 0.9V
Accelerator pedal: Fully depressed 3.9 - 4.8V
THRL SEN 1-B1 Ignition switch: ON
(Engine stopped)
 Shift lever: D (A/T) or 1st (M/T)Accelerator pedal: Fully released More than 0.36V
Accelerator pedal: Fully depressed Less than 4.75V
THRL SEN 2-B1 Ignition switch: ON
(Engine stopped)
 Shift lever: D (A/T) or 1st (M/T)Accelerator pedal: Fully released More than 0.36V
Accelerator pedal: Fully depressed Less than 4.75V
START SIGNAL  Ignition switch: ON → START → ON OFF → ON → OFF
CLSD THL POS Ignition switch: ON
(Engine stopped)Accelerator pedal: Fully released ON
Accelerator pedal: Slightly depressed OFF

EC-636
< ECU DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
ECM
AIR COND SIG Engine: After warming up, idle the
engineAir conditioner switch: OFF OFF
Air conditioner switch: ON
(Compressor operates.)ON
P/N POSI SW  Ignition switch: ONShift lever: P or N (A/T), Neutral (M/T) ON
Shift lever: Except above OFF
PW/ST SIGNAL Engine: After warming up, idle the
engineSteering wheel: Not being turned OFF
Steering wheel: Being turned ON
LOAD SIGNAL  Ignition switch: ONRear window defogger switch: ON
and/or Lighting switch: 2nd positionON
Rear window defogger switch and lighting
switch: OFFOFF
IGNITION SW  Ignition switch: ON → OFF → ON ON → OFF → ON
HEATER FAN SW Engine: After warming up, idle the
engineHeater fan switch: ON ON
Heater fan switch: OFF OFF
BRAKE SW  Ignition switch: ONBrake pedal: Fully released OFF
Brake pedal: Slightly depressed ON
INJ PULSE-B1 Engine: After warming up
 Shift lever: P or N (A/T), Neutral
(M/T)
 Air conditioner switch: OFF
No loadIdle 2.0 - 3.0 msec
2,000 rpm 1.9 - 2.9 msec
IGN TIMING Engine: After warming up
 Shift lever: P or N (A/T), Neutral
(M/T)
 Air conditioner switch: OFF
No loadIdle 10° - 20° BTDC
2,000 rpm 25° - 45° BTDC
PURG VOL C/V Engine: After warming up
 Shift lever: P or N (A/T), Neutral
(M/T)
 Air conditioner switch: OFF
No loadIdle 0%
2,000 rpm 0% - 50%
INT/V TIM (B1) Engine: After warming up
 Shift lever: P or N (A/T), Neutral
(M/T)
 Air conditioner switch: OFF
No loadIdle−5° - 5°CA
2,000 rpm Approx. 0° - 40°CA
INT/V SOL (B1) Engine: After warming up
 Shift lever: P or N (A/T), Neutral
(M/T)
 Air conditioner switch: OFF
No loadIdle 0% - 2%
2,000 rpm Approx. 0% - 90%
AIR COND RLY Engine: After warming up, idle the
engineAir conditioner switch: OFF OFF
Air conditioner switch: ON
(Compressor operates)
ON
FUEL PUMP RLY For 1 seconds after turning ignition switch: ON
 Engine running or crankingON
 Except above OFF
THRTL RELAY  Ignition switch: ON ONMonitor Item Condition Values/Status

ECM
EC-637
< ECU DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P OCOOLING FAN  Engine: After warning up, idle the
engine
 Air conditioner switch: OFFEngine coolant temperature is 98°C
(208F) or lessOFF
Engine coolant temperature is between
98°C (208°F) and 99°C (210°F)LOW
Engine coolant temperature is 100°C
(212°F) or moreHIGH
HO2S1 HTR (B1) Engine: After warming up
 Engine speed: Below 3,600rpmON
 Engine speed: Above 3,600 rpm OFF
HO2S2 HTR (B1) Engine speed: Below 3,900 rpm after the following conditions are met.
- Engine: After warming up
- Keeping the engine speed between 3,500 and 4,000 rpm for 1 minute and at
idle for 1 minute under no loadON
VEHICLE SPEED Turn drive wheels and compare CONSULT-III value with the speedometer in-
dication.Almost the same speed as
the speedometer indication
IDL A/V LEARN  Engine: runningIdle air volume learning has not been per-
formed yet.YET
Idle air volume learning has already been
performed successfully.CMPLT
TRVL AFTER MIL  Ignition switch: ONVehicle has traveled after MI has turned
ON.0 - 65,535 km
(0 - 40,723 miles)
O2 SEN HTR DTY Engine coolant temperature when engine started: More than 80°C (176F)
 Engine speed: Below 3,600 rpmApprox. 30%
AC PRESS SEN Engine: Idle
 Both A/C switch and blower fan switch: ON (Compressor operates)1.0 - 4.0V
VHCL SPEED SE Turn drive wheels and compare CONSULT-III value with the speedometer in-
dication.Almost the same speed as
the speedometer indication
SET VHCL SPD  Engine: Running ASCD: OperatingThe preset vehicle speed is
displayed
MAIN SW  Ignition switch: ONMAIN switch: Pressed ON
MAIN switch: Released OFF
CANCEL SW  Ignition switch: ONCANCEL switch: Pressed ON
CANCEL switch: Released OFF
RESUME/ACC SW  Ignition switch: ONRESUME/ACCELERATE switch:
PressedON
RESUME/ACCELERATE switch: Re-
leasedOFF
SET SW  Ignition switch: ONSET/COAST switch: Pressed ON
SET/COAST switch: Released OFF
BRAKE SW1
(ASCD brake switch) Ignition switch: ON Brake pedal: Fully released (A/T)
 Brake pedal and clutch pedal: Fully re-
leased (M/T)ON
 Brake pedal: Slightly depressed (A/T)
 Brake pedal and/or clutch pedal: Slight-
ly depressed (M/T)OFF
BRAKE SW2
(Stop lamp switch) Ignition switch: ONBrake pedal: Fully released OFF
Brake pedal: Slightly depressed ON
VHCL SPD CUT  Ignition switch: ON NON
LO SPEED CUT  Ignition switch: ON NON
AT OD MONITOR  Ignition switch: ON OFF
AT OD CANCEL  Ignition switch: ON OFFMonitor Item Condition Values/Status

EC-638
< ECU DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
ECM
*: Accelerator pedal position sensor 2 signal and throttle position sensor 2 signal are converted by ECM internally. Thus, they differ from
ECM terminals voltage signal.
TERMINAL LAYOUT
PHYSICAL VALUES
NOTE:
 ECM is located in the engine room left side near battery.
 Specification data are reference values and are measured between each terminal and ground.
 Pulse signal is measured by CONSULT-III.
CAUTION:
Do not use ECM ground terminals when measuring input/output voltage. Doing so may result in dam-
age to the ECMs transistor. Use a ground other than ECM terminals, such as the ground.
CRUISE LAMP  Ignition switch: ONMAIN switch: Pressed at the 1st time →
at the 2nd timeON → OFF
SET LAMP MAIN switch: ON
 When vehicle speed: Between 40
km/h (25 MPH) and 153 km/h (95
MPH)ASCD: Operating ON
ASCD: Not operating OFF Monitor Item Condition Values/Status
PBIA9221J
Te r m i n a l N o .
Wire
colorDescription
ConditionVa l u e
(Approx.)
+ -– Signal nameInput/
Output
1GroundL/WThrottle control motor
(Open)Output[Ignition switch: ON]
 Engine stopped
 Shift lever: D (A/T) or 1st (M/
T)
 Accelerator pedal: Fully de-
pressed3.2V
2GroundR/YThrottle control motor relay
power supplyInput [Ignition switch: ON]BATTERY VOLTAGE
(11 - 14V)
3GroundLG/RHeated oxygen sensor 1
heaterOutput[Engine is running]
 Warm up condition
 Engine speed: Below 3,600
rpmApproximately 3.2V
[Engine is running]
 Warm-up condition
 Idle speed
[Engine is running]
 Engine speed: Above 3,600
rpmBATTERY VOLTAGE (11 - 14V)
PBIA8150J
PBIA8148J

ECM
EC-639
< ECU DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
4GroundPThrottle control motor
(Close)Output[Ignition switch: ON]
 Engine stopped
 Shift lever: D (A/T) or 1st (M/
T)
 Accelerator pedal: Fully re-
leased0 - 14V
5GroundRHeated oxygen sensor 2
heaterOutput[Engine is running]
 Engine speed: Below 3,900
rpm after the following con-
ditions are met
- Engine: after warming up
- Keeping the engine speed
between 3,500 and 4,000
rpm for 1 minute and at idle
for 1 minute under no load10V
[Ignition switch: ON]
 Engine stopped
[Engine is running]
 Engine speed: Above 3,900
rpmBATTERY VOLTAGE
(11 - 14V)
9GroundW/BEVAP canister purge volume
control solenoid valveOutput[Engine is running]
 Idle speedBATTERY VOLTAGE
(11 - 14V)
[Engine is running]
 Engine speed: About 2,000
rpm (More than 100 sec-
onds after starting engine.)BATTERY VOLTAGE
(11 - 14V)
10
11GroundB
B/WECM ground —[Engine is running]
 Idle speedBody ground
15 Ground G/L Throttle control motor relay Output[Ignition switch: OFF]BATTERY VOLTAGE
(11 - 14V)
[Ignition switch: ON] 0 - 1.0V Terminal No.
Wire
colorDescription
ConditionVa l u e
(Approx.)
+ -– Signal nameInput/
Output
PBIA8149J
PBIA8148J
PBIB0050E
PBIB0520E

EC-640
< ECU DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
ECM
17
18
21
22GroundL/Y
BR/Y
R/G
SBIgnition signal No. 1
Ignition signal No. 2
Ignition signal No. 4
Ignition signal No. 3Output[Engine is running]
 Warm-up condition
 Idle speed
NOTE:
The pulse cycle changes de-
pending on rpm at idle0 - 0.3V
[Engine is running]
 Warm-up condition
 Engine speed: 2,500 rpm0.2 - 0.5V
23 Ground B/O Fuel pump relay Output[Ignition switch: ON]
 For 1 second after turning
ignition switch ON
[Engine is running]0 - 1.0V
[Ignition switch: ON]
 More than a few seconds af-
ter turning ignition switch
ONBATTERY VOLTAGE
(11 - 14V)
25
29
30
31GroundR/O
Y
O
LFuel injector No. 4
Fuel injector No. 3
Fuel injector No. 2
Fuel injector No. 1Output[Engine is running]
 Warm-up condition
 Idle speed
NOTE:
The pulse cycle changes de-
pending on rpm at idleBATTERY VOLTAGE
(11 - 14V)
[Engine is running]
 Warm-up condition
 Engine speed: 2,000 rpmBATTERY VOLTAGE
(11 - 14V)
32 Ground Y/LECM relay
(Self shut-off)Output[Engine is running]
[Ignition switch: OFF]
 A few seconds after turning
ignition switch OFF0 - 1.0V
[Ignition switch: OFF]
 More than a few seconds af-
ter turning ignition switch
OFFBATTERY VOLTAGE
(11 - 14V) Te r m i n a l N o .
Wire
colorDescription
ConditionVa l u e
(Approx.)
+ -– Signal nameInput/
OutputPBIA9265J
PBIA9266J
PBIB0529E
PBIA4943J

ECM
EC-641
< ECU DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
33 Ground L/R Throttle position sensor 1 Input[Ignition switch: ON]
 Engine stopped
 Shift lever: D (A/T) or 1st (M/
T)
 Accelerator pedal: Fully re-
leasedMore than 0.36V
[Ignition switch: ON]
 Engine stopped
 Shift lever: D (A/T) or 1st (M/
T)
 Accelerator pedal: Fully de-
pressedLess than 4.75V
34 Ground L/O Throttle position sensor 2 Input[Ignition switch: ON]
 Engine stopped
 Shift lever: D (A/T) or 1st (M/
T)
 Accelerator pedal: Fully re-
leasedLess than 4.75V
[Ignition switch: ON]
 Engine stopped
 Shift lever: D (A/T) or 1st (M/
T)
 Accelerator pedal: Fully de-
pressedMore than 0.36V
36 Ground V/WSensor ground
(Throttle position sensor)—[Engine is running]
 Warm-up condition
 Idle speed0V
37 Ground W Knock sensor Input[Engine is running]
 Idle speed2.5V
38 Ground GR/BEngine coolant temperature
sensorInput [Engine is running]0 - 4.8V
Output voltage varies with engine
coolant temperature.
40 Ground —Sensor ground
(Knock sensor)—[Engine is running]
 Warm-up condition
 Idle speed0V
41 Ground G/P Refrigerant pressure sensor Input[Engine is running]
 Warm-up condition
 Both A/C switch and blower
fan motor switch: ON (Com-
pressor operates)1.0 - 4.0V
44 Ground BSensor ground
(Engine coolant temperature
sensor)—[Engine is running]
 Warm-up condition
 Idle speed0V
45 Ground BR Mass air flow sensor Input[Ignition switch ON]
 Engine stopped0.4V
[Engine is running]
 Warm-up condition
 Idle speed1.0 - 1.3V
[Engine is running]
 Warm-up condition
 Engine is revving from idle
to about 4,000 rpm1.0 - 1.3 to 2.4V (Check for linear
voltage rise in response to en-
gine being increased to about
4,000 rpm.)
46 Ground VIntake air temperature sen-
sorInput [Engine is running]0 - 4.8V
Output voltage varies with intake
air temperature. Terminal No.
Wire
colorDescription
ConditionVa l u e
(Approx.)
+ -– Signal nameInput/
Output
