NISSAN TIIDA 2007 Service Repair Manual

EC-592
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
ASCD INDICATOR
ASCD INDICATOR
DescriptionINFOID:0000000001693421
ASCD indicator lamp illuminates to indicate ASCD operation status. Lamp has two indicators, CRUISE and
SET, and is integrated in combination meter.
CRUISE lamp illuminates when MAIN switch on ASCD steering switch is turned ON to indicated that ASCD
system is ready for operation.
SET lamp illuminates when following conditions are met.
 CRUISE lamp is illuminated.
 SET/COAST switch on ASCD steering switch is turned ON while vehicle speed is within the range of ASCD
setting.
SET lamp remains lit during ASCD control.
Refer to EC-424, "
System Description" for the ASCD function.
Component Function CheckINFOID:0000000001693422
1.ASCD INDICATOR FUNCTION
Check ASCD indicator under the following conditions.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to EC-592, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001693423
1.CHECK DTC
Check that DTC U1000 or U1001 is not displayed.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Perform trouble diagnosis for DTC U1000, U1001. Refer to EC-481, "
DTC Logic".
2.CHECK COMBINATION METER OPERATION
Refer to MWI-22, "
CONSULT-III Function (METER/M&A)".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Check combination meter circuit. Refer to MWI-4, "
METER SYSTEM : System Diagram".
3.CHECK INTERMITTENT INCIDENT
Refer to GI-55, "
Intermittent Incident".
>> INSPECTION END
ASCD INDICATOR CONDITION SPECIFICATION
CRUISE LAMP  Ignition switch: ON MAIN switch: Pressed at the
1st time →at the 2nd timeON → OFF
SET LAMPMAIN switch: ON
 When vehicle speed: Be-
tween 40 km/h (25 MPH) and
144 km/h (89 MPH) ASCD: Operating ON
 ASCD: Not operating OFF

COOLING FAN
EC-593
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
COOLING FAN
DescriptionINFOID:0000000001693424
Cooling fan operates at each speed when the current flows in the cooling fan motor as follows.
Refer to EC-433, "
System Diagram" for cooling fan operation.
Component Function CheckINFOID:0000000001693425
1.CHECK COOLING FAN LOW SPEED FUNCTION
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “COOLING FAN” in “ACTIVE TEST” mode with CONSULT-III and touch “LOW” on the CON-
SULT-III screen.
3. Make sure that cooling fans operates at low speed.
Without CONSULT-III
1. Start engine and let it idle.
2. Turn air conditioner switch and blower fan switch ON.
3. Make sure that cooling fan operates at low speed.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Check cooling fan low speed control circuit. Refer to EC-593, "
Diagnosis Procedure".
2.CHECK COOLING FAN HIGH SPEED FUNCTION
With CONSULT-III
1. Touch “HI” on the CONSULT-III screen.
2. Make sure that cooling fans operates at higher speed than low speed.
Without CONSULT-III
1. Perform IPDM E/R auto active test and check cooling fan motors operation.
2. Make sure that cooling fan operates at high speed.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Check cooling fan high speed control circuit. Refer to EC-593, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001693426
1.CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R harness connector.
3. Check the voltage between IPDM E/R harness connector and ground.
Is the inspection result normal?
YES-2 >> With A/C models: GO TO 3.
YES-2 >> Without A/C models: GO TO 5.
NO >> GO TO 2.
2.DETECT MALFUNCTIONING PART
Check the following.
 50A fusible link (letter J) (with A/C models)
 40A fusible link (letter J) (without A/C models)
 Harness for open or short between IPDM E/R and battery
IPDM E/R
Ground Continuity
Connector Terminal
E44 22 Ground Existed

EC-594
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
COOLING FAN
>> Repair or replace malfunctioning part.
3.CHECK COOLING FAN MOTORS CIRCUIT FOR OPEN AND SHORT
1. Disconnect cooling fan motor harness connector.
2. Check the continuity between IPDM E/R harness connector and cooling fan motor harness connector.
3. Check the continuity between cooling fan motor harness connector or IPDM E/R harness connector and
ground.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 7.
NO >> GO TO 4.
4.DETECT MALFUNCTIONING PART
Check the following.
 Harness for open or short between cooling fan motor and IPDM E/R
 Harness for open or short between cooling fan motor and ground
 Harness for open or short between IPDM E/R and ground
Resistor E5
>> Repair or replace malfunctioning part.
5.CHECK COOLING FAN MOTORS CIRCUIT FOR OPEN AND SHORT
1. Disconnect cooling fan motor harness connector.
2. Check the continuity between IPDM E/R harness connector and cooling fan motor harness connector.
3. Check the continuity between cooling fan motor harness connector or IPDM E/R harness connector and
ground.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 7.
NO >> GO TO 6.
IPDM E/R Cooling fan motor
Continuity
Connector Terminal Connector Terminal
E44 24
E3 1 Existed
E45 30
Cooling fan motor IPDM E/R
Ground Continuity
Connector Terminal Connector Terminal
E3 2 E4659
Ground Existed
39
IPDM E/R Cooling fan motor
Continuity
Connector Terminal Connector Terminal
E4423
E31
Existed 24 2
E45 30 3
Cooling fan motor IPDM E/R
Ground Continuity
Connector Terminal Connector Terminal
E3 4 E4659
Ground Existed
39

COOLING FAN
EC-595
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
6.DETECT MALFUNCTIONING PART
Check the following.
 Harness for open or short between cooling fan motor and IPDM E/R
 Harness for open or short between cooling fan motor and ground
 Harness for open or short between IPDM E/R and ground
>> Repair or replace malfunctioning part.
7.CHECK GROUND CONNECTION
Check ground connection E24. Refer to Ground Inspection in GI-58, "
Circuit Inspection".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace ground connection.
8.CHECK COOLING FAN MOTOR
Refer to EC-595, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 9.
NO >> Replace malfunctioning cooling fan motor.
9.CHECK INTERMITTENT INCIDENT
Perform GI-55, "
Intermittent Incident".
Is the inspection result normal?
YES >> Replace IPDM E/R.
NO >> Repair or replace harness or connector.
Component InspectionINFOID:0000000001693427
1.CHECK OVERALL FUNCTION
Check if the vehicle is equipped with an air conditioner.
Is it equipped with an air conditioner?
YES >> GO TO 2.
NO >> GO TO 3.
2.CHECK COOLING FAN MOTOR
1. Turn ignition switch OFF.
2. Disconnect cooling fan motor harness connector.
3. Supply cooling fan motor terminals with battery voltage and check operation.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace cooling fan motor.
3.CHECK COOLING FAN MOTOR
1. Turn ignition switch OFF.
2. Disconnect cooling fan motor harness connector.
3. Supply cooling fan motor terminals with battery voltage and check operation.
Te r m i n a l s
Operation
(+) (–)
1 2 Cooling fan operates.

EC-596
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
COOLING FAN
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace cooling fan motor.
Te r m i n a l s
Operation
(+) (–)
14
Cooling fan operates at low speed.
23
1 and 2 3 and 4 Cooling fan operates at high speed.

ELECTRICAL LOAD SIGNAL
EC-597
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
ELECTRICAL LOAD SIGNAL
DescriptionINFOID:0000000001693428
The electrical load signal (Headlamp switch signal, rear window defogger switch signal, etc.) is transferred
through the CAN communication line from BCM to ECM via IPDM E/R.
Component Function CheckINFOID:0000000001693429
1.CHECK REAR WINDOW DEFOGGER SWITCH FUNCTION
1. Turn ignition switch ON.
2. Connect CONSULT-III and select “DATA MONITOR” mode.
3. Select “LOAD SIGNAL” and check indication under the following conditions.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Go to EC-597, "
Diagnosis Procedure".
2.CHECK LIGHTING SWITCH FUNCTION
Check “LOAD SIGNAL” indication under the following conditions.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Go to EC-597, "
Diagnosis Procedure".
3.CHECK HEATER FAN CONTROL SWITCH FUNCTION
Select “HEATER FAN SW” and check indication under the following conditions.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to EC-597, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001693430
1.INSPECTION START
Confirm the malfunctioning circuit (rear window defogger, headlamp or heater fan). Refer to EC-597, "
Compo-
nent Function Check".
Which circuit is related to the incident?
Rear window defogger>>GO TO 2
Headlamp>>GO TO 3.
Heater fan>>GO TO 4.
2.CHECK REAR WINDOW DEFOGGER SYSTEM
Refer to DEF-6, "
System Diagram".
Monitor item Condition Indication
LOAD SIGNAL Rear window defogger switchON ON
OFF OFF
Monitor item Condition Indication
LOAD SIGNAL Lighting switchON at 2nd position ON
OFF OFF
Monitor item Condition Indication
HEATER FAN SW Heater fan control switchON ON
OFF OFF

EC-598
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
ELECTRICAL LOAD SIGNAL
>> INSPECTION END
3.CHECK HEADLAMP SYSTEM
Refer to EXL-10, "
System Diagram" (XENON TYPE) or EXL-8, "System Diagram" (HALOGEN TYPE).
>> INSPECTION END
4.CHECK HEATER FAN CONTROL SYSTEM
Refer to HAC-118, "
System Description" (without NAVI system) or HAC-232, "System Description" (with NAVI
system).
>> INSPECTION END

EVAP CANISTER PURGE VOLUME CONTROL SOLENOID VALVE
EC-599
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
EVAP CANISTER PURGE VOLUME CONTROL SOLENOID VALVE
DescriptionINFOID:0000000001697487
The EVAP canister purge volume control solenoid valve uses a ON/
OFF duty to control the flow rate of fuel vapor from the EVAP canis-
ter. The EVAP canister purge volume control solenoid valve is
moved by ON/OFF pulses from the ECM. The longer the ON pulse,
the greater the amount of fuel vapor that will flow through the valve.
Component Function CheckINFOID:0000000001697488
1.CHECK EVAP CANISTER PURGE VOLUME CONTROL SOLENOID VALVE FUNCTION
With CONSULT-III
1. Turn ignition switch OFF.
2. Disconnect the EVAP purge hose from EVAP canister purge volume control solenoid valve (EVAP canis-
ter side).
3. Start engine and let it idle.
4. Select “PURG VOL CONT/V” in “ACTIVE TEST” mode wit CONSULT-III.
5. Touch “Qu” and “Qd” on CONSULT-III screen to adjust “PURG VOL CONT/V” and check vacuum exist-
ence under the following conditions.
Without CONSULT-III
1. Turn ignition switch OFF.
2. Disconnect the EVAP purge hose from EVAP canister purge volume control solenoid valve (EVAP canis-
ter side).
3. Start engine and let it idle for at least 100 seconds.
4. Check vacuum existence under the following conditions.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to EC-599, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001697489
1.CHECK EVAP CANISTER
Refer to EC-683, "
Inspection".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace.
2.CHECK EVAP CANISTER PURGE VOLUME CONTROL SOLENOID VALVE POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect EVAP canister purge volume control solenoid valve harness connector.
PBIA9215J
PURG VOL CONT/V Vacuum
100% Existed
0 % Not existed
Condition Vacuum
At idle Not existed
About 2,000 rpm Existed

EC-600
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
EVAP CANISTER PURGE VOLUME CONTROL SOLENOID VALVE
3. Turn ignition switch ON.
4. Check the voltage between EVAP canister purge volume control solenoid valve harness connector and
ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
3.DETECT MALFUNCTIONING PART
Check the following.
 Harness connectors E7, F121
 Harness for open or short between EVAP canister purge volume control solenoid valve and IPDM E/R
 Harness for open or short between EVAP canister purge volume control solenoid valve and ECM
>> Repair open circuit or short to ground or short to power in harness or connectors.
4.CHECK EVAP CANISTER PURGE VOLUME CONTROL SOLENOID VALVE OUTPUT SIGNAL CIRCUIT
FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between EVAP canister purge volume control solenoid valve harness connector and
ECM harness connector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES-1 >> With CONSULT-III: GO TO 5.
YES-2 >> Without CONSULT-III: GO TO 6.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
5.CHECK EVAP CANISTER PURGE VOLUME CONTROL SOLENOID VALVE OPERATION
With CONSULT-III
1. Reconnect all harness connectors disconnected.
2. Start engine.
3. Perform “PURG VOL CONT/V” in “ACTIVE TEST” mode with CONSULT-III. Check that engine speed var-
ies according to the valve opening.
Does engine speed vary according to the valve opening?
YES >> GO TO 7.
NO >> GO TO 6.
6.CHECK EVAP CANISTER PURGE VOLUME CONTROL SOLENOID VALVE
Refer to EC-601, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 7.
NO >> Replace EVAP canister purge volume control solenoid valve.
7.CHECK INTERMITTENT INCIDENT
Refer to GI-55, "
Intermittent Incident".
>> INSPECTION END
EVAP canister purge volume control solenoid valve
Ground Voltage
Connector Terminal
F32 1 Ground Battery voltage
EVAP canister purge volume control solenoid valve ECM
Continuity
Connector Terminal Connector Terminal
F32 2 F7 9 Existed

EVAP CANISTER PURGE VOLUME CONTROL SOLENOID VALVE
EC-601
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
Component InspectionINFOID:0000000001697490
1.CHECK EVAP CANISTER PURGE VOLUME CONTROL SOLENOID VALVE
With CONSULT-III
1. Turn ignition switch OFF.
2. Reconnect all harness connectors disconnected.
3. Disconnect EVAP purge hoses connected to EVAP canister purge volume control solenoid valve.
4. Turn ignition switch ON.
5. Select “PURG VOL CONT/V” in “ACTIVE TEST” mode with CONSULT-III.
6. Touch “Qd” and “Qu” on CONSULT-III screen to adjust “PURG
VOL CONT/V” opening and check air passage continuity of
EVAP canister purge volume control solenoid valve under the
following conditions.
Without CONSULT-III
1. Turn ignition switch OFF.
2. Disconnect EVAP canister purge volume control solenoid valve harness connector.
3. Disconnect EVAP purge hoses connected to EVAP canister purge volume control solenoid valve.
4. Check air passage continuity of EVAP canister purge volume control solenoid valve under the following
conditions.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace EVAP canister purge volume control solenoid valve
Condition
(PURG VOL CONT/V value)Air passage continuity
between (A) and (B)
100% Existed
0% Not existed
PBIA9668J
ConditionAir passage continuity
between (A) and (B)
12V direct current supply between
terminals 1 and 2Existed
No supply Not existed
