NISSAN TIIDA 2007 Service Repair Manual
Manufacturer: NISSAN, Model Year: 2007, Model line: TIIDA, Model: NISSAN TIIDA 2007Pages: 5883, PDF Size: 78.95 MB
Page 2771 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EM-124
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
*: Total indicator reading
VALVE LIFTER
Unit: mm (in)
VALVE CLEARANCE
Unit: mm (in)
*: Approximately 80°C](/img/5/57395/w960_57395-2770.png "NISSAN TIIDA 2007 Service Repair Manual EM-124
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
*: Total indicator reading
VALVE LIFTER
Unit: mm (in)
VALVE CLEARANCE
Unit: mm (in)
*: Approximately 80°C")
EM-124
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
*: Total indicator reading
VALVE LIFTER
Unit: mm (in)
VALVE CLEARANCE
Unit: mm (in)
*: Approximately 80°C (176°F)
AVAILABLE VALVE LIFTER
Camshaft end play 0.075 - 0.153 (0.0030 - 0.0060) 0.2 (0.008)
Camshaft sprocket runout [TIR*] — 0.15 (0.0059) Items Standard Limit
ItemsStandard
Valve lifter outer diameter 29.977 - 29.987 (1.1802 - 1.1806)
Valve lifter hole diameter 30.000 - 30.021 (1.1811 - 1.1819)
Valve lifter clearance 0.013 - 0.044 (0.0005 - 0.0017)
Items Cold Hot* (reference data)
Intake 0.26 - 0.34 (0.010 - 0.013) 0.304 - 0.416 (0.012 - 0.016)
Exhaust 0.29 - 0.37 (0.011 - 0.015) 0.308 - 0.432 (0.012 - 0.017)
Thickness mm (in) Identification mark
3.00 (0.1181) 300
3.02 (0.1189) 302
3.04 (0.1197) 304
3.06 (0.1205) 306
3.08 (0.1213) 308
3.10 (0.1220) 310
3.12 (0.1228) 312
3.14 (0.1236) 314
3.16 (0.1244) 316
3.18 (0.1252) 318
3.20 (0.1260) 320
3.22 (0.1268) 322
3.24 (0.1276) 324
3.26 (0.1283) 326
3.28 (0.1291) 328
3.30 (0.1299) 330
3.32 (0.1307) 332
KBIA0119E
Page 2772 of 5883
![NISSAN TIIDA 2007 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)
EM-125
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
Cylinder HeadINFOID:0000000001381444
CYLINDER HEAD
Unit: mm (in)
VALVE DIM](/img/5/57395/w960_57395-2771.png "NISSAN TIIDA 2007 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)
EM-125
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
Cylinder HeadINFOID:0000000001381444
CYLINDER HEAD
Unit: mm (in)
VALVE DIM")
SERVICE DATA AND SPECIFICATIONS (SDS)
EM-125
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
Cylinder HeadINFOID:0000000001381444
CYLINDER HEAD
Unit: mm (in)
VALVE DIMENSIONS
Unit: mm (in)
3.34 (0.1315) 334
3.36 (0.1323) 336
3.38 (0.1331) 338
3.40 (0.1339) 340
3.42 (0.1346) 342
3.44 (0.1354) 344
3.46 (0.1362) 346
3.48 (0.1370) 348
3.50 (0.1378) 350 Thickness mm (in) Identification mark
Items Standard Limit
Head surface distortion — 0.1 (0.004)
Normal cylinder head height “H” 125.0 (4.92) —
PBIC0924E
Valve head diameter “D” Intake 31.0 - 31.3 (1.220 - 1.232)
Exhaust 25.3 - 25.6 (0.996 - 1.008)
Valve length “a”Intake 101.65 (4.002)
Exhaust 102.46 (4.034)
“b”Intake
1.0 (0.039)
Exhaust
PBIC3878E
Page 2773 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EM-126
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
VA LV E G U I D E
Unit: mm (in)
VALVE SEAT
Unit: mm (in)
“c”Intake 2.1 - 2.8 (0.083 - 0.110)
Exhaust](/img/5/57395/w960_57395-2772.png "NISSAN TIIDA 2007 Service Repair Manual EM-126
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
VA LV E G U I D E
Unit: mm (in)
VALVE SEAT
Unit: mm (in)
“c”Intake 2.1 - 2.8 (0.083 - 0.110)
Exhaust")
EM-126
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
VA LV E G U I D E
Unit: mm (in)
VALVE SEAT
Unit: mm (in)
“c”Intake 2.1 - 2.8 (0.083 - 0.110)
Exhaust 2.3 - 3.0 (0.091 - 0.118)
“c′”Intake 3.0 (0.118)
Exhaust –
Valve stem diameter “d ”Intake 4.965 - 4.980 (0.1955 - 0.1961)
Exhaust 4.955 - 4.970 (0.1951 - 0.1957)
Valve seat angle “α”Intake
45°15′ - 45°45′
Exhaust
Items Standard Oversize (service) [0.2 (0.008)]
Va l v e g u i d eOuter diameter 9.023 - 9.034 (0.3552 - 0.3557) 9.223 - 9.234 (0.3631 - 0.3635)
Inner diameter (Finished size) 5.000 - 5.018 (0.1969 - 0.1976)
Cylinder head valve guide hole diameter 8.975 - 8.996 (0.3533 - 0.3542) 9.175 - 9.196 (0.3612 - 0.3620)
Interference fit of valve guide 0.027 - 0.059 (0.0011 - 0.0023)
Items Standard Limit
Valve guide clearanceIntake 0.020 - 0.053 (0.0008 - 0.0021)
0.1 (0.004)
Exhaust 0.030 - 0.063 (0.0012 - 0.0025)
Projection length “H” 11.4 - 11.8 (0.449 - 0.465)
PBIC2187E
Items Standard Oversize (service) [0.5 (0.02)]
Cylinder head seat recess diameter “D” Intake 31.400 - 31.416 (1.2362 - 1.2368) 31.900 - 31.916 (1.2559 - 1.2565)
Exhaust 25.900 - 25.916 (1.0197 - 1.0203) 26.400 - 26.416 (1.0394 - 1.0400)
Valve seat outer diameter “d”Intake 31.497 - 31.513 (1.2400 - 1.2407) 31.997 - 32.013 (1.2597 - 1.2604)
Exhaust 25.997 - 26.013 (1.0235 - 1.0241) 26.497 - 26.513 (1.0432 - 1.0438)
PBIC2745E
Page 2774 of 5883
![NISSAN TIIDA 2007 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)
EM-127
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
*1 : Diameter made by intersection point of conic angles α1 and α2
*
2](/img/5/57395/w960_57395-2773.png "NISSAN TIIDA 2007 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)
EM-127
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
*1 : Diameter made by intersection point of conic angles α1 and α2
*
2")
SERVICE DATA AND SPECIFICATIONS (SDS)
EM-127
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
*1 : Diameter made by intersection point of conic angles α1 and α2
*
2 : Diameter made by intersection point of conic angles α2 and α3
*
3 : Machining data
VALVE SPRING
Cylinder BlockINFOID:0000000001381445
CYLINDER BLOCK
Unit: mm (in)
Valve seat interference fitIntake
0.081 - 0.113 (0.0032 - 0.0044)
Exhaust
Diameter “d1”*
1Intake 29.0 (1.142)
Exhaust 23.0 (0.906)
Diameter “d2”*
2Intake 30.6 - 30.8 (1.205 - 1.213)
Exhaust 24.9 - 25.1 (0.980 - 0.988)
Angle “α1”Intake 60°
Exhaust 45°
Angle “α2”Intake
89°45′ - 90°15′
Exhaust
Angle “α3”Intake
120°
Exhaust
Contacting width “W”*
3Intake 1.05 - 1.35 (0.0413 - 0.0531)
Exhaust 1.25 - 1.55 (0.0492 - 0.0610)
Height “h”Intake
6.0 (0.236)5.45 (0.215)
Exhaust 5.43 (0.214)
Depth “H”6.0 (0.236)
Items Standard
Free height 42.26 mm (1.6638 in)
Installation height 32.40 mm (1.2756 in)
Installation load 136 - 154 N (13.9 - 15.7 kg, 31 - 35 lb)
Height during valve open 23.96 mm (0.9433 in)
Load with valve open 262 - 296 N (26.7 - 30.2 kg, 59 - 67 lb)
Items Limit
Valve spring squareness 1.8 mm (0.071 in)
Cylinder block top surface distortion Limit 0.1 (0.004)
PBIC3924E
Page 2775 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EM-128
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
AVAILABLE PISTON
Unit: mm (in)
PISTON RING
Unit: mm (in)
PISTON PIN
Cylinder bore inner diameter Standard](/img/5/57395/w960_57395-2774.png "NISSAN TIIDA 2007 Service Repair Manual EM-128
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
AVAILABLE PISTON
Unit: mm (in)
PISTON RING
Unit: mm (in)
PISTON PIN
Cylinder bore inner diameter Standard")
EM-128
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
AVAILABLE PISTON
Unit: mm (in)
PISTON RING
Unit: mm (in)
PISTON PIN
Cylinder bore inner diameter Standard 78.000 - 78.015 (3.0709 - 3.0715)
Out-of-round
Limit0.015 (0.0006)
Taper0.010 (0.0004)
Cylinder block main bearing housing inner diameter gradeGrade No. A
Grade No. B
Grade No. C
Grade No. D
Grade No. E
Grade No. F
Grade No. G
Grade No. H
Grade No. J
Grade No. K
Grade No. L
Grade No. M
Grade No. N
Grade No. P
Grade No. R
Grade No. S
Grade No. T
Grade No. U
Grade No. V
Grade No. W51.997 - 51.998 (2.0471 - 2.0472)
51.998 - 51.999 (2.0472 - 2.0472)
51.999 - 52.000 (2.0472 - 2.0472)
52.000 - 52.001 (2.0472 - 2.0473)
52.001 - 52.002 (2.0473 - 2.0473)
52.002 - 52.003 (2.0473 - 2.0474)
52.003 - 52.004 (2.0474 - 2.0474)
52.004 - 52.005 (2.0474 - 2.0474)
52.005 - 52.006 (2.0474 - 2.0475)
52.006 - 52.007 (2.0475 - 2.0475)
52.007 - 52.008 (2.0475 - 2.0476)
52.008 - 52.009 (2.0476 - 2.0476)
52.009 - 52.010 (2.0476 - 2.0476)
52.010 - 52.011 (2.0476 - 2.0477)
52.011 - 52.012 (2.0477 - 2.0477)
52.012 - 52.013 (2.0477 - 2.0478)
52.013 - 52.014 (2.0478 - 2.0478)
52.014 - 52.015 (2.0478 - 2.0478)
52.015 - 52.016 (2.0478 - 2.0479)
52.016 - 52.017 (2.0479 - 2.0479)
Difference in inner diameter between cylinders Standard Less than 0.015 (0.0006)
Item Standard Limit
Piston skirt diameter “A” 77.965 - 77.980 (3.0695 - 3.0701) —
Measure point “H” 37.1 (1.461) —
Piston pin hole diameter 19.006 - 19.012 (0.7483 - 0.7485) —
Piston to cylinder bore clearance 0.020 - 0.050 (0.0008 - 0.0020) 0.09 (0.0035)
PBIC0188E
Items Standard Limit
Piston ring side clearanceTop 0.040 - 0.080 (0.0016 - 0.0031) 0.11 (0.0043)
2nd 0.030 - 0.070 (0.0012 - 0.0028) 0.10 (0.0039)
Oil (rail ring) 0.045 - 0.125 (0.0018 - 0.0049) —
Piston ring end gapTop 0.20- 0.30 (0.0079 - 0.0118) 0.50 (0.0197)
2nd 0.35 - 0.50 (0.0138 - 0.0197) 0.66 (0.0260)
Oil (rail ring) 0.20 - 0.60 (0.0079 - 0.0236) 0.92 (0.0362)
Page 2776 of 5883
![NISSAN TIIDA 2007 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)
EM-129
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
Unit: mm (in)
CONNECTING ROD
Unit: mm (in)
CRANKSHAFT
Unit: mm (in)
Piston](/img/5/57395/w960_57395-2775.png "NISSAN TIIDA 2007 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)
EM-129
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
Unit: mm (in)
CONNECTING ROD
Unit: mm (in)
CRANKSHAFT
Unit: mm (in)
Piston")
SERVICE DATA AND SPECIFICATIONS (SDS)
EM-129
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
Unit: mm (in)
CONNECTING ROD
Unit: mm (in)
CRANKSHAFT
Unit: mm (in)
Piston pin outer diameter 18.996 - 19.002 (0.7479 - 0.7481)
Piston to piston pin oil clearance Standard 0.008 - 0.012 (0.0003 - 0.0005)
Center distance129.84 - 129.94 (5.11 - 5.12)
Bend [per 100 (3.94)] Limit 0.15 (0.0059)
Torsion [per 100 (3.94)] Limit 0.30 (0.0118)
Connecting rod small end clearance Standard –0.018 - –0.044 (–0.0007 - –0.0017)
Connecting rod small end inner diameter Standard 18.958 - 18.978 (0.7464 - 0.7472)
Connecting rod side clearance Standard 0.200 - 0.352 (0.0079 - 0.0139)
Connecting rod big end diameterGrade No. A
Grade No. B
Grade No. C
Grade No. D
Grade No. E
Grade No. F
Grade No. G
Grade No. H
Grade No. J
Grade No. K
Grade No. L
Grade No. M
Grade No. N43.000 - 43.001 (1.6929 - 1.6929)
43.001 - 43.002 (1.6929 - 1.6930)
43.002 - 43.003 (1.6930 - 1.6930)
43.003 - 43.004 (1 6930 - 1.6931)
43.004 - 43.005 (1.6931 - 1.6931)
43.005 - 43.006 (1.6931 - 1.6931)
43.006 - 43.007 (1.6931 - 1.6932)
43.007 - 43.008 (1.6932 - 1.6932)
43.008 - 43.009 (1.6932 - 1.6933)
43.009 - 43.010 (1.6933 - 1.6933)
43.010 - 43.011 (1.6933 - 1.6933)
43.011 - 43.012 (1.6933 - 1.6934)
43.012 - 43.013 (1.6934 - 1.6934)
Center distance “r” 41.68 - 41.76 (1.6409 - 1.6441)
Out-of-round Limit 0.003 (0.0001)
Taper Limit 0.004 (0.0002)
Runout [TIR*] Limit 0.10 (0.0039)
Crankshaft end playStandard 0.098 - 0.260 (0.0039 - 0.0102)
Limit 0.35 (0.0138)
SEM645PBIC3459J
Page 2777 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EM-130
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
*: Total indicator reading
Connecting Rod BearingINFOID:0000000001381446
CONNECTING ROD BEARING GRADE TABL](/img/5/57395/w960_57395-2776.png "NISSAN TIIDA 2007 Service Repair Manual EM-130
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
*: Total indicator reading
Connecting Rod BearingINFOID:0000000001381446
CONNECTING ROD BEARING GRADE TABL")
EM-130
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
*: Total indicator reading
Connecting Rod BearingINFOID:0000000001381446
CONNECTING ROD BEARING GRADE TABLE
Unit: mm (in)
Crankshaft pin journal diameter grade. “Dp”Grade No. A
Grade No. B
Grade No. C
Grade No. D
Grade No. E
Grade No. F
Grade No. G
Grade No. H
Grade No. J
Grade No. K
Grade No. L
Grade No. M
Grade No. N
Grade No. P
Grade No. R
Grade No. S
Grade No. T
Grade No. U39.971 - 39.970 (1.5737 - 1.5736)
39.970 - 39.969 (1.5736 - 1.5736)
39.969 - 39.968 (1.5736 - 1.5735)
39.968 - 39.967 (1.5735 - 1.5735)
39.967 - 39.966 (1.5735 - 1.5735)
39.966 - 39.965 (1.5735 - 1.5734)
39.965 - 39.964 (1.5734 - 1.5734)
39.964 - 39.963 (1.5734 - 1.5733)
39.963 - 39.962 (1.5733 - 1.5733)
39.962 - 39.961 (1.5733 - 1.5733)
39.961 - 39.960 (1.5733 - 1.5732)
39.960 - 39.959 (1.5732 - 1.5732)
39.959 - 39.958 (1.5732 - 1.5731)
39.958 - 39.957 (1.5731 - 1.5731)
39.957 - 39.956 (1.5731 - 1.5731)
39.956 - 39.955 (1.5731 - 1.5730)
39.955 - 39.954 (1.5730 - 1.5730)
39.954 - 39.953 (1.5730 - 1.5729)
Crankshaft main journal diameter grade. “Dm”Grade No. A
Grade No. B
Grade No. C
Grade No. D
Grade No. E
Grade No. F
Grade No. G
Grade No. H
Grade No. J
Grade No. K
Grade No. L
Grade No. M
Grade No. N
Grade No. P
Grade No. R
Grade No. S
Grade No. T
Grade No. U
Grade No. V
Grade No. W47.979 - 47.978 (1.8889 - 1.8889)
47.978 - 47.977 (1.8889 - 1.8889)
47.977 - 47.976 (1.8889 - 1.8888)
47.976 - 47.975 (1.8888 - 1.8888)
47.975 - 47.974 (1.8888 - 1.8887)
47.974 - 47.973 (1.8887 - 1.8887)
47.973 - 47.972 (1.8887 - 1.8887)
47.972 - 47.971 (1.8887 - 1.8886)
47.971 - 47.970 (1.8886 - 1.8886)
47.970 - 47.969 (1.8886 - 1.8885)
47.969 - 47.968 (1.8885 - 1.8885)
47.968 - 47.967 (1.8885 - 1.8885)
47.967 - 47.966 (1.8885 - 1.8884)
47.966 - 47.965 (1.8884 - 1.8884)
47.995 - 47.964 (1.8884 - 1.8883)
47.994 - 47.963 (1.8883 - 1.8883)
47.963 - 47.962 (1.8883 - 1.8883)
47.962 - 47.961 (1.8883 - 1.8882)
47.961 - 47.960 (1.8882 - 1.8882)
47.960 - 47.959 (1.8882 - 1.8881)
Grade number Thickness Identification color Remarks
0 1.498 - 1.501 (0.0590 - 0.0591) Black
Grade and color are the same
for upper and lower bearings. 1 1.501 - 1.504 (0.0591 - 0.0592) Brown
2 1.504 - 1.507 (0.0592 - 0.0593) Green
3 1.507 - 1.510 (0.0593 - 0.0594) Yellow
4 1.510 - 1.513 (0.0594 - 0.0596) Blue
01UPR 1.498 - 1.501 (0.0590 - 0.0591) Black
Grade and color are different
for upper and lower bearings. LWR 1.501 - 1.504 (0.0591 - 0.0592) Brown
12UPR 1.501 - 1.504 (0.0591 - 0.0592) Brown
LWR 1.504 - 1.507 (0.0592 - 0.0593) Green
23UPR 1.504 - 1.507 (0.0592 - 0.0593) Green
LWR 1.507 - 1.510 (0.0593 - 0.0594) Yellow
34UPR 1.507 - 1.510 (0.0593 - 0.0594) Yellow
LWR 1.510 - 1.513 (0.0594 - 0.0596) Blue
Page 2778 of 5883
![NISSAN TIIDA 2007 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)
EM-131
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
UNDERSIZE TABLE
Unit: mm (in)
CONNECTING ROD BEARING OIL CLEARANCE
Unit: m](/img/5/57395/w960_57395-2777.png "NISSAN TIIDA 2007 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)
EM-131
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
UNDERSIZE TABLE
Unit: mm (in)
CONNECTING ROD BEARING OIL CLEARANCE
Unit: m")
SERVICE DATA AND SPECIFICATIONS (SDS)
EM-131
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
UNDERSIZE TABLE
Unit: mm (in)
CONNECTING ROD BEARING OIL CLEARANCE
Unit: mm (in)
Main BearingINFOID:0000000001381447
MAIN BEARING GRADE TABLE
Unit: mm (in)
UNDERSIZE TABLE
Unit: mm (in)
MAIN BEARING OIL CLEARANCE
Unit: mm (in)
Item Thickness Crankshaft pin journal diameter
US 0.25 (0.0098) 1.627 - 1.635 (0.0641 - 0.0644) Grind so that bearing clearance is the specified value.
Connecting rod bearing oil clearanceStandard 0.029 - 0.039 (0.0011 - 0.0015)
Limit 0.10 (0.0039)
Grade number Thickness Identification color Remarks
0 1.996 - 1.999 (0.0786 - 0.0787) Black
Grade and color are the same
for upper and lower bearings. 1 1.999 - 2.002 (0.0787 - 0.0788) Brown
2 2.002 - 2.005 (0.0788 - 0.0789) Green
3 2.005 - 2.008 (0.0789 - 0.0791) Yellow
4 2.008 - 2.011 (0.0791 - 0.0792) Blue
5 2.011 - 2.014 (0.0792 - 0.0793) Pink
01UPR 1.996 - 1.999 (0.0786 - 0.0787) Black
Grade and color are different
for upper and lower bearings. LWR 1.999 - 2.002 (0.0787 - 0.0788) Brown
12UPR 1.999 - 2.002 (0.0787 - 0.0788) Brown
LWR 2.002 - 2.005 (0.0788 - 0.0789) Green
23UPR 2.002 - 2.005 (0.0788 - 0.0789) Green
LWR 2.005 - 2.008 (0.0789 - 0.0791) Yellow
34UPR 2.005 - 2.008 (0.0789 - 0.0791) Yellow
LWR 2.008 - 2.011 (0.0791 - 0.0792) Blue
45UPR 2.008 - 2.011 (0.0791 - 0.0792) Blue
LWR 2.011 - 2.014 (0.0792 - 0.0793) Pink
SEM685D
Items Thickness Main journal diameter
0.25 (0.0098) 2.126 - 2.134 (0.0837 - 0.0840) Grind so that bearing clearance is the specified value.
Main bearing oil clearance Standard 0.024 - 0.034 (0.0009 - 0.0013)
Page 2779 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EM-132
< SYMPTOM DIAGNOSIS >[MR18DE]
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
SYMPTOM DIAGNOSIS
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
NVH Troubleshooting - Engine NoiseINFOI](/img/5/57395/w960_57395-2778.png "NISSAN TIIDA 2007 Service Repair Manual EM-132
< SYMPTOM DIAGNOSIS >[MR18DE]
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
SYMPTOM DIAGNOSIS
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
NVH Troubleshooting - Engine NoiseINFOI")
EM-132
< SYMPTOM DIAGNOSIS >[MR18DE]
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
SYMPTOM DIAGNOSIS
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
NVH Troubleshooting - Engine NoiseINFOID:0000000001337774
WBIA0769E
1. Piston pin noise 2. Piston slap noise 3. Main bearing noise
4. Water pump noise 5. Timing chain and tensioner noise 6. Drive belt noise (stick/slipping)
7. Tappet noise 8. Camshaft bearing noise 9. Connecting rod noise
Page 2780 of 5883
![NISSAN TIIDA 2007 Service Repair Manual NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
EM-133
< SYMPTOM DIAGNOSIS >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
Use the Chart Below to Help You Find the Cause of the SymptomINFOID:0000000001](/img/5/57395/w960_57395-2779.png "NISSAN TIIDA 2007 Service Repair Manual NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
EM-133
< SYMPTOM DIAGNOSIS >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
Use the Chart Below to Help You Find the Cause of the SymptomINFOID:0000000001")
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
EM-133
< SYMPTOM DIAGNOSIS >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
Use the Chart Below to Help You Find the Cause of the SymptomINFOID:0000000001337775
1. Locate the area where noise occurs.
2. Confirm the type of noise.
3. Specify the operating condition of engine.
4. Check specified noise source.
If necessary, repair or replace these parts.
A: Closely related B: Related C: Sometimes related —: Not relatedA. Rotational mechanism B. Water pump C. Timing chain
D. Drive belt E. Crankshaft pulley F. A/C compressor
G. Water pump H. Generator I. Tension pulley
J. Valve mechanism K. Valves
Location
of noiseType of
noiseOperating condition of engine
Source of
noiseCheck itemRefer-
ence page Before
warm-
upAfter
warm-
upWhen
start-
ingWhen
idlingWhen
racingWhile
driving
Top of en-
gine
Rocker
cover
Cylinder
headTicking or
clickingCA—AB—Tappet
noiseValve clearanceEM-238
Rattle C A — A B CCamshaft
bearing
noiseCamshaft journal oil
clearance
Camshaft runoutEM-186EM-186
Crank-
shaft pul-
ley
Cylinder
block
(Side of
engine)
Oil panSlap or
knock—A—BB—Piston pin
noisePiston to piston pin oil
clearance
Connecting rod bushing
oil clearanceEM-219
EM-219
Slap or
rapA——BBAPiston
slap noisePiston to cylinder bore
clearance
Piston ring side clear-
ance
Piston ring end gap
Connecting rod bend
and torsionEM-219EM-219
EM-219
EM-219
Knock A B C B B BConnect-
ing rod
bearing
noiseConnecting rod bushing
oil clearance
Connecting rod bearing
oil clearanceEM-219EM-219
Knock A B — A B CMain bear-
ing noiseMain bearing oil clear-
ance
Crankshaft runoutEM-219EM-219
Front of
engine
Front cov-
erTapping or
tickingAA—BBBTiming
chain and
chain ten-
sioner
noiseTiming chain cracks
and wear
Timing chain tensioner
operationEM-177
Front of
engineSqueak-
ing or fizz-
ingAB—B—CDrive belt
(Sticking
or slip-
ping)Drive belt deflection
EM-142
CreakingA B ABABDrive belt
(Slipping)Idler pulley bearing op-
eration
Squall
CreakAB—BABWater
pump
noiseWater pump operationCO-44
