NISSAN TIIDA 2007 Service Repair Manual

BRC-68
< ECU DIAGNOSIS >[ABS]
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
ALFWA0019GB

ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
BRC-69
< ECU DIAGNOSIS >[ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
Wiring Diagram - RHDINFOID:0000000001731382
AWFWA0013GB

BRC-70
< ECU DIAGNOSIS >[ABS]
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
Fail-Safe
INFOID:0000000001731341
CAUTION:
If the Fail-Safe function is activated, perform Self Diagnosis for ABS/TCS/VDC system.
ABS/EBD SYSTEM
ALFWA0020GB

ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
BRC-71
< ECU DIAGNOSIS >[ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
In case of an electrical malfunction with the ABS, the ABS warning lamp, VDC OFF indicator lamp and SLIP
indicator lamp will turn on. In case of an electrical malfunction with the EBD system, the BRAKE warning lamp,
ABS warning lamp, VDC OFF indicator lamp and SLIP indicator lamp will turn on.
The system will revert to one of the following conditions of the Fail-Safe function.
1. For ABS malfunction, only the EBD is operative and the condition of the vehicle is the same condition of
vehicles without ABS/TCS/VDC system.
2. For EBD malfunction, the EBD and ABS become inoperative, and the condition of the vehicle is the same
as the condition of vehicles without ABS/TCS/VDC or EBD system.
VDC/TCS SYSTEM
In case of TCS/VDC system malfunction, the VDC OFF indicator lamp and SLIP indicator lamp are turned on
and the condition of the vehicle is the same as the condition of vehicles without TCS/VDC system. In case of
an electrical malfunction with the TCS/VDC system, the ABS control continues to operate normally without
TCS/VDC control.
DTC No. IndexINFOID:0000000001731342
DTC Items (CONSULT screen terms) Reference
C1101 RR RH SENSOR-1
BRC-30, "
Description"C1102 RR LH SENSOR-1
C1103 FR RH SENSOR-1
C1104 FR LH SENSOR-1
C1105 RR RH SENSOR-2
BRC-33, "
Description"C1106 RR LH SENSOR-2
C1107 FR RH SENSOR-2
C1108 FR LH SENSOR-2
C1109 BATTERY VOLTAGE [ABNORMAL]BRC-36, "
Description"
C1110 CONTROLLER FAILUREBRC-38, "DTC Logic"
C 1111 P U M P M O T O RBRC-39, "Description"
C1113 G-SENSORXX-XX, "*****"
C1115 ABS SENSOR [ABNORMAL SIGNAL]BRC-41, "Description"
C1116 STOP LAMP SWBRC-44, "Description"
C1120 FR LH IN ABS SOLBRC-46, "Description"
C1121 FR LH OUT ABS SOLBRC-49, "Description"
C1122 FR RH IN ABS SOLBRC-46, "Description"
C1123 FR RH OUT ABS SOLBRC-49, "Description"
C1124 RR LH IN ABS SOLBRC-46, "Description"
C1125 RR LH OUT ABS SOLBRC-49, "Description"
C1126 RR RH IN ABS SOLBRC-46, "Description"
C1127 RR RH OUT ABS SOLBRC-49, "Description"
C1130 ENGINE SIGNAL 1
BRC-52, "
Description"
C1131 ENGINE SIGNAL 2
C1132 ENGINE SIGNAL 3
C1133 ENGINE SIGNAL 4
C1136 ENGINE SIGNAL 6
C1140 ACTUATOR RLYBRC-54, "
Description"
C1142 PRESS SEN CIRCUITXX-XX, "*****"
C1143 ST ANG SEN CIRCUIT
XX-XX, "*****"
C1144 ST ANG SEN SIGNAL

BRC-72
< ECU DIAGNOSIS >[ABS]
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
C1145 YAW RATE SENSOR
XX-XX, "*****"
C1146 SIDE G-SEN CIRCUIT
C1155 BR FLUID LEVEL LOWBRC-56, "
Description"
C1156 ST ANG SEN COM CIRXX-XX, "*****"
C1160 DECEL G SEN SETXX-XX, "*****"
C1163 ST ANGL SEN SAFEXX-XX, "*****"
C1164 CV1
XX-XX, "*****"
C1165 CV2
C1166 SV1
C1167 SV2
C1170 VARIANT CORDINGBRC-38, "
DTC Logic"
C1178 ABS ACTIVE BOOSTER SV NGXX-XX, "*****"
C1179 ABS DELTA S SEN NGXX-XX, "*****"
C1181 ABS ACTIVE BOOSTER RESPONSE NG
XX-XX, "*****"
C1184 ABS BRAKE RELEASE SW NG
C1189 ABS BRAKE BOOSTER DEFECT
U1000 CAN COMM CIRCUITBRC-59, "
Description"
DTC Items (CONSULT screen terms) Reference

ABS
BRC-73
< SYMPTOM DIAGNOSIS >[ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
SYMPTOM DIAGNOSIS
ABS
Symptom TableINFOID:0000000001731343
If ABS warning lamp, VDC OFF indicator lamp and SLIP indicator lamp turn ON, perform self-diagnosis.
NOTE:
 1: The ABS does not operate when the speed is 10 km/h (6 MPH) or less.
 2: Under the following conditions, ABS is activated and vibration is felt when brake pedal is lightly depressed. However, this is normal.
- When shifting gears
- When driving on slippery road
- During cornering at high speed
- When passing over bumps or grooves [at approximately 50 mm (1.97 in) or more]
- When pulling away just after starting engine [at approximately 10 km/h (6 MPH) or higher]Symptom Check item Reference
Excessive ABS function operation fre-
quencyBrake force distribution
BRC-74, "
Diagno-
sis Procedure"Looseness of front and rear axle
Wheel sensor and rotor system
Unexpected pedal reactionBrake pedal stroke
BRC-75, "
Diagno-
sis Procedure"Make sure the braking force is sufficient when the ABS is not operating.
The braking distance is long Check stopping distance when the ABS is not operating.BRC-76, "
Diagno-
sis Procedure"
ABS function does not operate (Note 1) ABS actuator and electric unit (control unit)BRC-77, "Diagno-
sis Procedure"
Pedal vibration or ABS operation sound
occurs (Note 2)Brake pedal
BRC-78, "Diagno-
sis Procedure"ABS actuator and electric unit (control unit)

BRC-74
< SYMPTOM DIAGNOSIS >[ABS]
EXCESSIVE ABS FUNCTION OPERATION FREQUENCY
EXCESSIVE ABS FUNCTION OPERATION FREQUENCY
Diagnosis ProcedureINFOID:0000000001731344
1.CHECK START
Check front and rear brake force distribution using a brake tester.
Is the inspection result normal?
YES >> GO TO 2
NO >> Check brake system.
2.CHECK FRONT AND REAR AXLE
Make sure that there is no excessive play in the front and rear axles. Refer to front: FA X - 6 , "
On-Vehicle
Inspection and Service", Rear: RAX-5, "On-Vehicle Inspection and Service".
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair or replace malfunctioning components.
3.CHECK WHEEL SENSOR AND SENSOR ROTOR
Check the following.
 Wheel sensor installation for damage.
 Sensor rotor installation for damage.
 Wheel sensor connector connection.
 Wheel sensor harness inspection.
Is the inspection result normal?
YES >> GO TO 4
NO >>  Replace wheel sensor or sensor rotor. Refer to BRC-83, "
Removal and Installation".
 Repair harness.
4.CHECK ABS WARNING LAMP DISPLAY
Make sure that the ABS warning lamp is turned off after the ignition switch is turned ON or when driving.
Is the ABS warning lamp illuminated?
YES >> Perform self-diagnosis. Refer to BRC-25, "CONSULT-III Function (ABS)".
NO >> Normal

UNEXPECTED PEDAL REACTION
BRC-75
< SYMPTOM DIAGNOSIS >[ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
UNEXPECTED PEDAL REACTION
Diagnosis ProcedureINFOID:0000000001731345
1.CHECK BRAKE PEDAL STROKE
Check brake pedal stroke. Refer to BR-6, "
Inspection and Adjustment".
Is the stroke too large?
YES >>  Bleed air from brake tube and hose. Refer to BR-8, "Bleeding Brake System".
 Check brake pedal, brake booster, and master cylinder for mount play, looseness, brake system
fluid leakage, etc. Refer to BR-18, "
On-Board Inspection" (master cylinder), BR-19, "On Board
Inspection" (brake booster).
NO >> GO TO 2
2.CHECK FUNCTION
Disconnect ABS actuator and electric unit (control unit) connector to deactivate ABS. Check if braking force is
normal in this condition. Connect connector after inspection.
Is the inspection result normal?
YES >> Normal
NO >> Check brake system.

BRC-76
< SYMPTOM DIAGNOSIS >[ABS]
THE BRAKING DISTANCE IS LONG
THE BRAKING DISTANCE IS LONG
Diagnosis ProcedureINFOID:0000000001731346
CAUTION:
The stopping distance on slippery road surfaces might be longer with the ABS operating than when
the ABS is not operating.
1.CHECK FUNCTION
Turn ignition switch OFF and disconnect ABS actuator and electric unit (control unit) connector to deactivate
ABS. In this condition, check stopping distance. After inspection, connect connector.
Is the inspection result normal?
YES >> Normal
NO >> Check brake system.

ABS FUNCTION DOES NOT OPERATE
BRC-77
< SYMPTOM DIAGNOSIS >[ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
ABS FUNCTION DOES NOT OPERATE
Diagnosis ProcedureINFOID:0000000001731347
CAUTION:
ABS does not operate when speed is 10 km/h (6 MPH) or lower.
1.CHECK ABS WARNING LAMP DISPLAY
Make sure that the ABS warning lamp turns OFF after ignition switch is turned ON or when driving.
Is the inspection result normal?
YES >> Normal
NO >> Perform self-diagnosis. Refer to BRC-25, "
CONSULT-III Function (ABS)".
