NISSAN TIIDA 2007 Service Repair Manual

IDENTIFICATION INFORMATION
GI-37
< FEATURES OF NEW MODEL >
C
D
E
F
G
H
I
J
K
L
MB
GI
N
O
P
GREHatchback1.5 DCI 6 M/TVisia FTKALBY-EGA
Acenta FTKALEY-EGA
1.6 L5 M/T
VisiaFDTALBF-EGA
4 A/T FDTALBA-EGA
5 M/T
AcentaFDTALEF-EGA
4 A/T FDTALEA-EGA
1.8 L 6 M/TVisia FDSALBY-EGA
Acenta FDSALEY-EGA
Sedan1.5 DCI 6 M/TVisia BTKALBY-EGA
Acenta BTKALEY-EGA
1.6 L5 M/T
VisiaBDTALBF-EGA
4 A/T BDTALBA-EGA
5 M/T
AcentaBDTALEF-EGA
4 A/T BDTALEA-EGA
1.8 L 6 M/TVisia BDSALBY-EGA
Acenta BDSALEY-EGA
NNEHatchback1.5 DCI 6 M/TVisia FTKALBY-EGA
Acenta FTKALEY-EGA
1.6 L5 M/T
VisiaFDTALBF-EGA
4 A/T FDTALBA-EGA
5 M/T
AcentaFDTALEF-EGA
4 A/T FDTALEA-EGA
1.8 L 6 M/TVisia FDSALBY-EGA
Acenta FDSALEY-EGA
Sedan1.5 DCI 6 M/TVisia BTKALBY-EGA
Acenta BTKALEY-EGA
1.6 L5 M/T
VisiaBDTALBF-EGA
4 A/T BDTALBA-EGA
5 M/T
AcentaBDTALEF-EGA
4 A/T BDTALEA-EGA
1.8 L 6 M/TVisia BDSALBY-EGA
Acenta BDSALEY-EGA Destination
CodeBody Handle Engine Transmission Grade Model code

GI-38
< FEATURES OF NEW MODEL >
IDENTIFICATION INFORMATION
Model code designations:
ESTHatchback1.5 DCI 6 M/TVisia FTKALBY-EGA
Acenta FTKALEY-EGA
1.6 L5 M/T
VisiaFDTALBF-EGA
4 A/T FDTALBA-EGA
5 M/T
AcentaFDTALEF-EGA
4 A/T FDTALEA-EGA
1.8 L 6 M/TVisia FDSALBY-EGA
Acenta FDSALEY-EGA
Sedan1.5 DCI 6 M/TVisia BTKALBY-EGA
Acenta BTKALEY-EGA
1.6 L5 M/T
VisiaBDTALBF-EGA
4 A/T BDTALBA-EGA
5 M/T
AcentaBDTALEF-EGA
4 A/T BDTALEA-EGA
1.8 L 6 M/TVisia BDSALBY-EGA
Acenta BDSALEY-EGA
ISRHatchback
1.6 L 4 A/TVisia FDTALBA-EGA
Acenta FDTALEA-EGA
SedanVisia BDTALBA-EGA
Acenta BDTALEA-EGA
TKYHatchback1.5 DCI 6 M/TVisia FTKALBY-EGA
Acenta FTKALEY-EGA
1.6 L5 M/T
VisiaFDTALBF-EGA
4 A/T FDTALBA-EGA
5 M/T
AcentaFDTALEF-EGA
4 A/T FDTALEA-EGA
Sedan1.5 DCI6 M/TVisia BTKALBY-EGA
Acenta BTKALEY-EGA
1.6 L5 M/T
VisiaBDTALBF-EGA
4 A/T BDTALBA-EGA
5 M/T
AcentaBDTALEF-EGA
4 A/T BDTALEA-EGA
Position (Left to
Right)Character Qualifier Definition
1 F Body typeF: Hatchback
B: Sedan
2
DS EngineDS: MR18DE
DT: HX 16 (1.6 L)
TK: K9K (1.5 DCI) 3
4 A Axle A: 2WD model
5LHandleL: LH drive
R: RH drive Destination
CodeBody Handle Engine Transmission Grade Model code

IDENTIFICATION INFORMATION
GI-39
< FEATURES OF NEW MODEL >
C
D
E
F
G
H
I
J
K
L
MB
GI
N
O
P
IDENTIFICATION NUMBER
VEHICLE IDENTIFICATION NUMBER ARRANGEMENT
6BGradeB: Visia
E: Acenta
T: Te k n a
7 Y TransmissionY: 6 M/ T
F: 5 M/T
A: 4 A/T
8
C11 Model code C11: Tiida 9
10
11 E Intake E: EGI
12 E ZoneE: Europe A (RHD)
G: Europe B (LHD)
Q: Russia
13 A Equipment A: Standard
14
xxxxx Option Codes 15
16
17 Position (Left to
Right)Character Qualifier Definition
1. Chassis number 2. Emissions control label 3. VIN number
4. FMVSS/CMVSS certification and tire
placard labels
LAIA0073E
VIN Position (Left
to Right)Character Qualifier Definition
1
3N1World Manufacturer Identifi-
cation3N1: Mexico 2
3
4 B Body typeB: 4-door sedan
F: 4-door hatchback

GI-40
< FEATURES OF NEW MODEL >
IDENTIFICATION INFORMATION
IDENTIFICATION PLATE
ENGINE SERIAL NUMBER
MR1.8 L
5 B EngineB: DS - 1.8 L Petrol
C: DT - 1.6 L Petrol
D: TK - 1.5L Diesel
6 A Axle A: 2wd
7
C11 Model code C11: Tiida 8
9
10 U Destination U: Europe
11 0 Place holder Place holder
12
XXXXXX Vehicle serial number Chassis number 13
14
15
16
17 VIN Position (Left
to Right)Character Qualifier Definition
LAIA0027E
STI0429

IDENTIFICATION INFORMATION
GI-41
< FEATURES OF NEW MODEL >
C
D
E
F
G
H
I
J
K
L
MB
GI
N
O
P
HR1.6 L
K9K (1.5 DCI)
AUTOMATIC TRANSAXLE NUMBER
MANUAL TRANSAXLE NUMBER
DimensionsINFOID:0000000001606152
Unit: mm (in)
ALAIA0002ZZ
ALAIA0003ZZ
SGI113A
PCIB1612E
Overall length Hatchback: 4,295 (169.1) Sedan: 4470 (176)
Overall width1,694.2 (66.7)
Overall height1,534.1 (60.4)
Front tread1,480 (58.3)

GI-42
< FEATURES OF NEW MODEL >
IDENTIFICATION INFORMATION
Wheels & Tires
INFOID:0000000001606153
Rear tread1,485 (58.5)
Wheelbase2,599.9 (102.4)
Road wheel
Size15 x 5.5 JJ
Offset mm (in) 40 (1.57)
Tire size
Conventional185/65 R15
Spar eT125/70D15

PRECAUTIONS
GI-43
< PRECAUTION >
C
D
E
F
G
H
I
J
K
L
MB
GI
N
O
PPRECAUTION
PRECAUTIONS
DescriptionINFOID:0000000001606115
Observe the following precautions to ensure safe and proper servicing. These precautions are not
described in each individual section.
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000001606116
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
 To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
 Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal
injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag
Module, see the SR section.
 Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or har-
ness connectors.
Precaution Necessary for Steering Wheel Rotation After Battery Disconnect
INFOID:0000000001606117
NOTE:
 This Procedure is applied only to models with Intelligent Key system and NATS (NISSAN ANTI-THEFT SYS-
TEM).
 Remove and install all control units after disconnecting both battery cables with the ignition knob in the
″LOCK″ position.
 Always use CONSULT-II to perform self-diagnosis as a part of each function inspection after finishing work.
If DTC is detected, perform trouble diagnosis according to self-diagnostic results.
For models equipped with the Intelligent Key system and NATS, an electrically controlled steering lock mech-
anism is adopted on the key cylinder.
For this reason, if the battery is disconnected or if the battery is discharged, the steering wheel will lock and
steering wheel rotation will become impossible.
If steering wheel rotation is required when battery power is interrupted, follow the procedure below before
starting the repair operation.
OPERATION PROCEDURE
1. Connect both battery cables.
NOTE:
Supply power using jumper cables if battery is discharged.
2. Use the Intelligent Key or mechanical key to turn the ignition switch to the ″ACC″ position. At this time, the
steering lock will be released.
3. Disconnect both battery cables. The steering lock will remain released and the steering wheel can be
rotated.
4. Perform the necessary repair operation.
5. When the repair work is completed, return the ignition switch to the ″LOCK″ position before connecting
the battery cables. (At this time, the steering lock mechanism will engage.)
6. Perform a self-diagnosis check of all control units using CONSULT-II.

GI-44
< PRECAUTION >
PRECAUTIONS
General Precaution
INFOID:0000000001606118
 Do not operate the engine for an extended period of time without
proper exhaust ventilation.
Keep the work area well ventilated and free of any flammable
materials. Special care should be taken when handling any flam-
mable or poisonous materials, such as gasoline, refrigerant gas,
etc. When working in a pit or other enclosed area, be sure to prop-
erly ventilate the area before working with hazardous materials.
Do not smoke while working on the vehicle.
 Before jacking up the vehicle, apply wheel chocks or other tire
blocks to the wheels to prevent the vehicle from moving. After jack-
ing up the vehicle, support the vehicle weight with safety stands at
the points designated for proper lifting before working on the vehi-
cle.
These operations should be done on a level surface.
 When removing a heavy component such as the engine or tran-
saxle/transmission, be careful not to lose your balance and drop
them. Also, do not allow them to strike adjacent parts, especially
the brake tubes and master cylinder.
 Before starting repairs which do not require battery power:
Turn off ignition switch.
Disconnect the negative battery terminal.
 If the battery terminals are disconnected, recorded memory of
radio and each control unit is erased.
 Battery posts, terminals and related accessories contain lead and
lead compounds. Wash hands after handling.
 To prevent serious burns:
Avoid contact with hot metal parts.
Do not remove the radiator cap when the engine is hot.
 Dispose of or recycle drained oil or the solvent used for cleaning
parts in an appropriate manner.
 Do not attempt to top off the fuel tank after the fuel pump nozzle
shuts off automatically.
Continued refueling may cause fuel overflow, resulting in fuel spray
and possibly a fire.
 Clean all disassembled parts in the designated liquid or solvent
prior to inspection or assembly.
 Replace oil seals, gaskets, packings, O-rings, locking washers,
cotter pins, self-locking nuts, etc. with new ones.
 Replace inner and outer races of tapered roller bearings and needle bearings as a set.
 Arrange the disassembled parts in accordance with their assembled locations and sequence.
 Do not touch the terminals of electrical components which use microcomputers (such as ECM).
Static electricity may damage internal electronic components.
 After disconnecting vacuum or air hoses, attach a tag to indicate the proper connection.
 Use only the fluids and lubricants specified in this manual.
 Use approved bonding agent, sealants or their equivalents when required.
SGI285
SGI231
SEF289H
SGI233

PRECAUTIONS
GI-45
< PRECAUTION >
C
D
E
F
G
H
I
J
K
L
MB
GI
N
O
P
 Use hand tools, power tools (disassembly only) and recommended
special tools where specified for safe and efficient service repairs.
 When repairing the fuel, oil, water, vacuum or exhaust systems,
check all affected lines for leaks.
 Before servicing the vehicle:
Protect fenders, upholstery and carpeting with appropriate covers.
Take caution that keys, buckles or buttons do not scratch paint.
WARNING:
To prevent ECM from storing the diagnostic trouble codes, do not carelessly disconnect the harness
connectors which are related to the engine control system and TCM (transmission control module)
system. The connectors should be disconnected only when working according to the WORK FLOW of
TROUBLE DIAGNOSES in EC and AT sections.
Precaution for Three Way CatalystINFOID:0000000001606119
If a large amount of unburned fuel flows into the catalyst, the catalyst temperature will be excessively high. To
prevent this, follow the instructions.
 Use unleaded gasoline only. Leaded gasoline will seriously damage the three way catalyst.
 When checking for ignition spark or measuring engine compression, make tests quickly and only when nec-
essary.
 Do not run engine when the fuel tank level is low, otherwise the engine may misfire, causing damage to the
catalyst.
Do not place the vehicle on flammable material. Keep flammable material off the exhaust pipe and the three
way catalyst.
Precaution for Fuel (Unleaded Regular Gasoline Recommended)INFOID:0000000001606120
Use unleaded regular gasoline with an octane rating of at least 87 AKI (Anti-Knock Index) number (Research
octane number 91).
CAUTION:
Do not use leaded gasoline. Using leaded gasoline will damage the three way catalyst. Do not use E-85
fuel (85% fuel ethanol, 15% unleaded gasoline) unless the vehicle is specifically designed for E-85 fuel
(i.e. Flexible Fuel Vehicle - FFV models). Using a fuel other than that specified could adversely affect
the emission control devices and systems, and could also affect the warranty coverage validity.
PBIC0190E
SGI234

GI-46
< PRECAUTION >
PRECAUTIONS
Precaution for Multiport Fuel Injection System or Engine Control System
INFOID:0000000001606121
 Before connecting or disconnecting any harness connector for the
multiport fuel injection system or ECM:
Turn ignition switch to “OFF” position.
Disconnect negative battery terminal.
Otherwise, there may be damage to ECM.
 Before disconnecting pressurized fuel line from fuel pump to injec-
tors, be sure to release fuel pressure.
 Be careful not to jar components such as ECM and mass air flow
sensor.
Precaution for HosesINFOID:0000000001606122
HOSE REMOVAL AND INSTALLATION
 To prevent damage to rubber hose, do not pry off rubber hose with
tapered tool or screwdriver.
 To reinstall the rubber hose securely, make sure that hose insertion
length and orientation is correct. (If tube is equipped with hose
stopper, insert rubber hose into tube until it butts up against hose
stopper.)
HOSE CLAMPING
 If old rubber hose is re-used, install hose clamp in its original posi-
tion (at the indentation where the old clamp was). If there is a trace
of tube bulging left on the old rubber hose, align rubber hose at
that position.
 Discard old clamps; replace with new ones.
SGI787
SMA019D
SMA020D
SMA021D
