NISSAN TIIDA 2007 Service Repair Manual

DLK-252
< FUNCTION DIAGNOSIS >[WITH I-KEY & SUPER LOCK]
DOOR LOCK FUNCTION
If the following conditions are not satisfied, door lock and unlock operation is not performed even if the request
switch is operated.
*: Even with a registered Intelligent Key remaining inside the vehicle, door locks can be unlocked from outside of the vehicle with a spare
Intelligent Key as long as key IDs are different.
OUTSIDE KEY ANTENNA DETECTION AREA
The outside key antenna detection area of door lock/unlock function
is in the range of approximately 80 cm (31.50 in) surrounding the
driver and passenger door handles (1) and the back door request
switch (2). However, this operating range depends on the ambient
conditions.
DOOR LOCK AND UNLOCK CONTROL
When the Intelligent Key detects that door request switch is pressed, it starts corresponding with outside key
antenna (request switch pressed door). Then, the Intelligent Key is checked to be near the door.
If the Intelligent Key is within the outside key antenna detection area, it receives the request signal and trans-
mits the key ID signal to the Intelligent Key unit. Intelligent Key unit receives the key ID signal and compares it
with the registered key ID. Intelligent Key unit sends door lock and unlock signal to BCM via CAN communica-
tion.
SUPER LOCK OPERATION
Super lock provides a higher anti-theft performance than a conventional power door lock system. The super
lock system is controlled by BCM and Intelligent Key unit.
When super lock is set, all doors cannot be opened from inside.
ANTI-HIJACK MODE
When door lock is unlocked, pressing LOCK buttons on Intelligent Key once will lock all doors. When door lock
is locked, pressing UNLOCK button on Intelligent Key once will unlock driver door. Pressing UNLOCK button
on Intelligent Key a second time within 5 seconds from the first time will unlock all doors and back door (hatch-
back) can be opened with back door opener switch or trunk (sedan) can be opened with trunk lid opener
switch.
CONVENIENCE MODE
When door lock is unlocked, pressing LOCK buttons on Intelligent Key once will lock all doors. When door lock
is locked, pressing UNLOCK button on Intelligent Key once will unlock all doors and back door (hatchback)
can be opened with back door opener switch or trunk (sedan) can be opened with trunk lid opener switch.
NOTE:
Anti-hijack mode can be set to ON or OFF with CONSULT-III. Once OFF, the convenience mode will be active.
For setting information with CONSULT-III, refer to DLK-53, "
CONSULT-III Function (INTELLIGENT KEY)". For
setting information without CONSULT-III, refer to Owner's Manual.
Each request switch operation Operation condition
Lock operation All doors are closed.
 Key switch is OFF. (Key is removed from ignition key cylinder)
 Ignition knob switch is OFF. (Ignition switch is not pressed)
 No Intelligent Keys are inside the vehicle.
 Intelligent Key is within outside key antenna detection area.
Unlock Operation Key switch is OFF. (Key is removed from ignition key cylinder)
 Ignition knob switch is OFF. (Ignition switch is not pressed)
 Intelligent Key is not inside the vehicle.*
 Intelligent Key is within outside key antenna detection area.
JMKIA0666ZZ

DOOR LOCK FUNCTION
DLK-253
< FUNCTION DIAGNOSIS >[WITH I-KEY & SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
DOOR REQUEST SWITCH : Component Parts LocationINFOID:0000000001396680
ALKIA0816ZZ

DLK-254
< FUNCTION DIAGNOSIS >[WITH I-KEY & SUPER LOCK]
DOOR LOCK FUNCTION
ALKIA0815ZZ
1. Combination meter M24 2. Key warning lamp (combination meter) 3. Lock warning lamp (combination meter)
4. Stop lamp switch M203
(view with instrument panel LH re-
moved)5. Steering lock solenoid M6
(bottom view of steering column)6. Key switch and ignition knob switch (A/
T) M32
7. Key switch and ignition knob
switch (M/T) M328. Instrument panel antenna M10
(view with glove box removed)9. BCM M18, M19, M20
10. Intelligent Key Unit M52 11. Intelligent key warning buzzer (driver side)
D6 (view with front door finisher removed)12. Front outside antenna (driver side) D10
(Passenger side) D106
13. Front door request switch (driver
side) D5
(Passenger side) D10314. Door unlock sensor D14
[Front door lock actuator (driver side)]15. Front door switch (driver side) B34
(Passenger side) B29
16. Front console antenna B45
(view with front console removed)17. Rear door switch LH B71
RH B5318. Rear floor antenna B46
(behind rear seat)
19. Trunk request switch B67
(sedan)20. Rear bumper antenna B81
(view with rear fascia removed)21. Intelligent Key warning buzzer (trunk)
B82 (sedan)
(view with trunk finisher LH removed)
22. Back door request switch D406
(hatchback)23. Back door lock assembly (back door switch)
D405 (hatchback view with back door open)

DOOR LOCK FUNCTION
DLK-255
< FUNCTION DIAGNOSIS >[WITH I-KEY & SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
DOOR REQUEST SWITCH : Component DescriptionINFOID:0000000001396681
KEY REMINDER
KEY REMINDER : System DiagramINFOID:0000000001396682
KEY REMINDER OPERATION
KEY REMINDER : System DescriptionINFOID:0000000001396683
KEY REMINDER OPERATION
Key reminder have the following 2 functions.
Item Function
Intelligent Key unit Controls the door lock function with BCM.
BCM Controls the door lock function with Intelligent Key unit.
Door request switch Transmits operation signal (lock and unlock) to Intelligent Key unit.
Door switch Detects door state (open or close).
Key switch Detects mechanical key is inserted into ignition key cylinder.
Ignition knob switch Detects ignition knob state (push or release).
Outside key antenna Detects Intelligent Key is in detection area of outside key antenna.
Inside key antenna Detects Intelligent Key is in detection area of inside key antenna.
Intelligent KeyTransmits key ID to Intelligent Key unit when request signal is received from out-
side key antenna.
Door lock actuator Receives lock/unlock signal from BCM and locks/unlocks each door.
Super lock actuatorReceives super lock set/release signal from BCM and sets/releases super lock
system.
ALKIA0713GB

DLK-256
< FUNCTION DIAGNOSIS >[WITH I-KEY & SUPER LOCK]
DOOR LOCK FUNCTION
CAUTION:
The above function operates when the Intelligent Key is inside the vehicle. However, there may be
times when the Intelligent Key can not be detected, and this function will not operate when the Intelli-
gent Key is on the instrument panel, rear parcel shelf or in the glove box. Also, this system some times
does not operate if the Intelligent Key is in the door pocket for the open door.
Operation Operation condition Operation
Driver door closeRight after driver side door is closed under the following con-
ditions
 Door lock operation
 Driver side door is opened
 Driver side door is in unlock state.All doors unlock
Any door open to all door closeRight after all doors are closed under the following condi-
tions
 Intelligent Key is inside the vehicle
 Any door is opened
 All doors are locked by door lock and unlock switch. All doors unlock
 Honk Intelligent Key warning
buzzer

DOOR LOCK FUNCTION
DLK-257
< FUNCTION DIAGNOSIS >[WITH I-KEY & SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
KEY REMINDER : Component Parts LocationINFOID:0000000001396684
ALKIA0816ZZ

DLK-258
< FUNCTION DIAGNOSIS >[WITH I-KEY & SUPER LOCK]
DOOR LOCK FUNCTION
ALKIA0815ZZ
1. Combination meter M24 2. Key warning lamp (combination meter) 3. Lock warning lamp (combination meter)
4. Stop lamp switch M203
(view with instrument panel LH re-
moved)5. Steering lock solenoid M6
(bottom view of steering column)6. Key switch and ignition knob switch (A/
T) M32
7. Key switch and ignition knob
switch (M/T) M328. Instrument panel antenna M10
(view with glove box removed)9. BCM M18, M19, M20
10. Intelligent Key Unit M52 11. Intelligent key warning buzzer (driver side)
D6 (view with front door finisher removed)12. Front outside antenna (driver side) D10
(Passenger side) D106
13. Front door request switch (driver
side) D5
(Passenger side) D10314. Door unlock sensor D14
[Front door lock actuator (driver side)]15. Front door switch (driver side) B34
(Passenger side) B29
16. Front console antenna B45
(view with front console removed)17. Rear door switch LH B71
RH B5318. Rear floor antenna B46
(behind rear seat)
19. Trunk request switch B67
(sedan)20. Rear bumper antenna B81
(view with rear fascia removed)21. Intelligent Key warning buzzer (trunk)
B82 (sedan)
(view with trunk finisher LH removed)
22. Back door request switch D406
(hatchback)23. Back door lock assembly (back door switch)
D405 (hatchback view with back door open)

DOOR LOCK FUNCTION
DLK-259
< FUNCTION DIAGNOSIS >[WITH I-KEY & SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
KEY REMINDER : Component DescriptionINFOID:0000000001396685
Item Function
Intelligent Key unit Controls the door lock function with BCM.
BCM Controls the door lock and unlock operation with Intelligent Key unit.
Door switch Detects door state (open or close).
Inside key antenna Detects Intelligent Key is in detection area of inside key antenna.
Intelligent Key Transmits key ID to Intelligent Key unit when Intelligent Key searching.
Door lock actuator Receives lock and unlock signal from BCM and locks/unlocks each door.

DLK-260
< FUNCTION DIAGNOSIS >[WITH I-KEY & SUPER LOCK]
BACK DOOR OPENER FUNCTION
BACK DOOR OPENER FUNCTION
BACK DOOR OPENER SWITCH
BACK DOOR OPENER SWITCH : System DiagramINFOID:0000000001396698
BACK DOOR OPENER OPERATION
BACK DOOR OPENER SWITCH : System DescriptionINFOID:0000000001396699
BACK DOOR OPENER OPERATION
When back door opener switch is pressed, BCM opens back door opener actuator.
NOTE:
Back door opener actuator is not for locking the back door. The function is only to open the back door.
OPERATION CONDITION
If the following conditions are not satisfied, back door opener operation is not performed.
BACK DOOR OPENER SWITCH : Component Parts LocationINFOID:0000000001530244
JMKIA0402GB
Back door opener switch operation Operation condition
Back door open Vehicle speed is less than 5 km/h (3 MPH).
 All doors are unlocked.
1. BCM M18, M20
(view with glove box removed)2. Back door lock assembly (back door switch)
D405
(hatchback view with back door open)3. Back door opener switch D408
ALKIA0818ZZ

BACK DOOR OPENER FUNCTION
DLK-261
< FUNCTION DIAGNOSIS >[WITH I-KEY & SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
BACK DOOR OPENER SWITCH : Component DescriptionINFOID:0000000001396701
Item Function
BCM Controls the back door opener function.
Back door opener switch Transmits back door opener switch operation signal to BCM.
Back door opener actuator Opens the back door with the back door open signal from BCM.
Combination meter Transmits vehicle speed signal to BCM via CAN communication.
