Peugeot 307 CC 2003 User Guide

22-09-2003
122
10YOUR 307 CC AT A GLANCE
CRUISE CONTROL The cruise control makes it possi- ble to maintain a constant vehiclespeed, programmed by the dri-
ver, irrespective of the profile ofthe road and without any action
on the accelerator or the brake ped-als. In order for the vehicle speed to be memorised, it must be greaterthan 25 mph (40 km/h) (manualgearbox) or 37 mph (60 km/h)(automatic gearbox), with at least4th gear engaged (2nd gear forthe automatic gearbox).Activation
Place knob 1in the ONposition.
A speed can now be memorised.  Place knob 1in the OFFposition to deactivate the system.
Memorising a speed When you reach the required speed, press button 2or 3. The speed is
memorised and will be maintained automatically.Note: it is possible to accelerate temporarily without deactivating the
cruise control. Deactivating the memorised speed If you wish to deactivate the memorised speed:  press button 4or the brake or clutch pedal.
Recalling the memorised speed After deactivation, press button 4. Your vehicle reverts to the last memo-
rised speed. Cancelling the stored speed  Place knob 1in the OFFposition or switch off the ignition.
Do not use the cruise control on slippery roads or in heavy traffic.

9999
12YOUR 307 CC AT A GLANCE
Outside the vehicle: Lift
the catch, raise the bon- net and secure the strutto keep the bonnet open.
OPENING THE BONNET
FILLING WITH FUEL This operation must be carried out with the engine switched off.
 Open the fuel filler flap.
 Insert the key then turn it to the left.
 Remove the cap and hook it onto the clip on the inside of the flap.
A label on the inside of the flap shows which type of fuel to use.
When you fill your tank, do not continue after the third cut-off of the
pump. This could cause a malfunction. The capacity of the tank is approximately 60 litres.  After filling the tank, lock the cap and close the flap.
Low fuel level warning light From the time this light comes on, you have enough fuel remaining to drive for approximately 30 miles (50 km) .Inside the vehicle:
Push the
handle on the left-hand side,under the fascia.
22-09-2003

22-09-2003
11 7
Moving Off With the engine running, to move
off from position P:
 It is essential to press the
brake pedal to exit position P,
 Select the function R, D or M,
then gradually release thepressure on the brake pedal;
the vehicle will move off
immediately.
You can also move off fromposition N:
 Release the handbrake, withyour foot on the brake.
 Select function R, D or M,
then gradually release thepressure on the brake pedal;
the vehicle will move off
immediately.
When the engine is idlingwith the brakes notapplied, if function R, D
or Mis selected, the vehi-
cle moves without the acceleratorbeing pressed. For this reason, do not
leave children unsuper- vised inside the vehicle,with the engine running .
14
YOUR 307 CC AT A GLANCE
AUTOMATIC GEARBOX 'PORSCHE TIPTRONIC SYSTEM'
The four-speed
automaticgearbox offers a choice between the comfort
of automatic integral regulation enhanced by a sportand snow pro-
gramme , or the pleasure of manual gear changing .
Gear selection gate  Move the lever in the gate to select one of the functions.
Once the function is selected, the indicator light for that function is displayed on the instrument panel screen.
S:sport programme.


:snow programme.
P ark :to immobilise the vehicle or to start the
engine , with the handbrake on or off.
R everse :to reverse (select this function with the
vehicle stationary and the engine at idle). N eutral :to start the engine or to park, with the
handbrake on.Note: if position Nis engaged by mistake while
the car is moving, allow the engine to return to idling speed before engaging function Dto
accelerate. D rive :for automatic gear changing.
M anual :for manual gear changing.
To change the four gearsmanually:
 Push the lever to the +symbol to change up a gear and pull the lever
towards the Ðsymbol to change down a gear.
Note: the S(sport) and

(snow) programmes do not operate when in
manual mode.

22-09-2003
82
13YOUR 307 CC AT A GLANCE
N¡ Symbol Function
AUTOMATIC AIR CONDITIONING
Air flow adjustment. Setting the air distribution.
1 23 4 56 7 89 Air intake control. Air conditioning control.
Switching off.
Demisting the rear screen and mirrors.
Temperature adjustment. Automatic comfort programme. Automatic visibility programme.
Note:
in the cabriolet version, the performance of the
system may be reduced.

22-09-2003
PEUGEOT SERVICING
18
PEUGEOT SERVICING
Your vehicle benefits from extended service intervals.
Ð For 2 litre 180 bhp engine vehicles: every 12,000 miles (20,000 km) or every two years.
Ð For 1.6 litre and 2 litre engine vehicles: every 20,000 miles (30,000 km) or every two years.
Your service indicator indicates when the services are due; the point at which a service is due is calculated from the last ind i-
cator reset (see corresponding section).The point at which a service is due is determined by two parameters:
Ð the distance travelled,
Ð the time elapsed since the last service. Note: the distance remaining may be weighted by the time factor, in accordance with the user's driving habits.
The extension of the service intervals means that the engine oil level must be checked regularly: topping up of the oil between oil changes is normal. It is for this reason that the PEUGEOT network invites you to an intermediate visit between each regular Service. The service indicator does not show when this service is due. It must be carried out every 10,000 miles (15,000 km) maximum for the 1.6 litre and 2 litre engines and every 6,000 miles (10,000 km) maximum for the 2 litre 180 bhpengines.
A PEUGEOT dealer will carry out a quick check, and will top up the levels if necessary (oil, coolant, screen-wash up to 2 litres). If the oil level is too low there is a risk of serious damage to the engine: check the engine oil level at least every 2,000 to 3,000 miles (3,000 to 5,000 km), depending on the conditions of use. This extended servicing has been made possible by modifications to our vehicles and to the lubricants:
THUS IT IS ESSENTIAL TO ONLY USE LUBRICANTS WHICH ARE SUITED TO YOUR ENGINE AND RECOMMENDED
BY THE MANUFACTURER (see "Lubricants" pages). * Whichever comes first.

22-09-2003
PEUGEOT SERVICING19
SPECIAL FEATURES Some of your vehicle's vital components have specific servicing schedules. The brake fluid must be replaced every every 40,000 miles (60,000 km) or every 2 years.
The passenger compartment filter must be checked at each visitto the PEUGEOT dealer (intermediate visits and regu-
lar services).The timing belt: contact a PEUGEOT dealer.
Arduous conditions of use If the vehicle is used under certain particularly arduous conditions: Ð Continuous door-to-door use.
Ð Town use.
Ð Repeated short journeys, with the engine cold in low temperatures.
Or prolonged stay under the following conditions: Ð Countries with temperatures often above +30 ¡C.
Ð Countries with temperatures often below minus 15 ¡C.
Ð Countries with a dusty atmosphere.
Ð Countries whose lubricants or fuels do not conform to our recommendations.
It is necessary to follow an "Arduous conditions" service schedule which includes: Ð shorter service intervals:¥ Every 10,000 miles (15,000 km) or every year for the 2 litre 180 bhp engine vehicles. ¥ Every 12,000 miles (20,000 km) or every year for the 1.6 litre and 2 litre engine vehicles.
Ð special operations: ¥ Replacement of the air filter every 10,000 miles (15,000 km) for the 2 litre 180 bhp engine vehicles.

22-09-2003
PEUGEOT SERVICING
20
SERVICE INDICATOR This indicates when the next service is due in accordance with the manu-facturer's servicing schedule. Operation For 5 seconds after the ignition is switched on, the spanner symbolis-ing the servicing operations comeson; the distance recorder displayindicates the number of miles [kilo-
metres] (rounded off) remaining untilthe next service. Example:
4,800 miles remain before
the next service. For five seconds after the ignition is switched on, thedisplay indicates: The distance remaining to the next
service is less than 500 miles. Example:
400 miles remain before
the next service.For 5 seconds after the ignition is switched on, the indicator displays: 5 seconds after the ignition was switched on, the distance recorderresumes its normal operation andthe spanner remains lit. It indicates that a service must be
carried out soon. The display indi-cates the total and trip distance.
5 seconds after the ignition wasswitched on, the distance recorderresumes its normal operation andthe display indicates the total and tripdistance.
The service is overdue. The service spanner flashes for
5 seconds after the ignition isswitched on. Example:
the service is overdue by
300 miles, your vehicle must be ser- viced as soon as possible. For 5 seconds after the ignition is switched on, the display indicates:
5 seconds after the ignition was switched on, the distance recorderresumes its normal operation andthe service spanner remains lit. The display indicates the total and trip distance. Note: the service spanner may also
come on if more than two years have elapsed since the last service (refer to
the "PEUGEOT Servicing" section).

22-09-2003
PEUGEOT SERVICING21
Zero re-set
Your PEUGEOT dealer carries out this operation after each service.
However, if you carry out the service yourself, the re-set procedure is asfollows:
Switch off the ignition,
 Press and hold the trip recorder re-set button,
 Switch on the ignition.
The display begins a countdown. When the display shows "0000.0",
release the button; the service sym- bol disappears. Important: after this operation, if
you wish to disconnect the battery, lock the vehicle and wait for at leastfive minutes, otherwise the zero re-set will not be registered.

These services are to be carried out with 10W40 synthetically based oilminimum.
They can also be carried out with 5W30 Fuel Economy oilor with 5W40 synthetic oil .
Arduous conditions of use (see corresponding section).
* Whichever comes first.
PEUGEOT SERVICING
22
TYPES OF SERVICE Each vehicle has its own servicing cycle, based upon the engine type.
This cycle consists of alternating two types of service, A and C, intermediate visits and a few additional operations depending on your vehicle; these correspond to key stages in the life of your vehicle. When the first service is carried out and at each subsequent service, your dealer will advise you of the type and content of the next service due. THE MAINTENANCE CYCLE FOR YOUR 1.6 LITRE AND 2 LITRE 307 CC
Service every 20,000 miles (30,000 km) or 2 years.
1st service at 6,000 miles
(10,000 km) or 6 months*.
This is necessary in order
to benefit from the warranty. MILES (KM) 20,000 (30,000) 40,000 (60,000) 60,000 (90,000)
80,000 (120,000) 100,000 (150,000) 120,000 (180,000) 140,000 (210,000) 160,000 (240,000)
Intermediate top-upvisit incorporatedin the Servicing Schedule.
22-09-2003

These services are to be carried out with 10W40 synthetically based oilminimum.
They can also be carried out with 5W30 Fuel Economy oilor with 5W40 synthetic oil .
Arduous conditions of use (see corresponding section).
* Whichever comes first.
PEUGEOT SERVICING
22
TYPES OF SERVICE Each vehicle has its own servicing cycle, based upon the engine type.
This cycle consists of alternating two types of service, A and C, intermediate visits and a few additional operations depending on your vehicle; these correspond to key stages in the life of your vehicle. When the first service is carried out and at each subsequent service, your dealer will advise you of the type and content of the next service due. THE MAINTENANCE CYCLE FOR YOUR 1.6 LITRE AND 2 LITRE 307 CC
Service every 20,000 miles (30,000 km) or 2 years.
1st service at 6,000 miles
(10,000 km) or 6 months*.
This is necessary in order
to benefit from the warranty. MILES (KM) 20,000 (30,000) 40,000 (60,000) 60,000 (90,000)
80,000 (120,000) 100,000 (150,000) 120,000 (180,000) 140,000 (210,000) 160,000 (240,000)
Intermediate top-upvisit incorporatedin the Servicing Schedule.
