MobileRoofs
Lifting/SlidingRoof......................................200ConvertibleTop...........................................204Emergencyoperationoftheconvertibletop...207Windstop....................................................214Hardtop.....................................................218Targa.........................................................224RoofTransportSystem................................229
MobileRoofs199

Lifting/SlidingRoof
Generalinformation
Warning!
Riskofinjurywhenoperatingorautomaticallyclosingthelifting/slidingroof.
Takecaretoensurethatnobodycanbeinjuredwhenthelifting/slidingroofisoperated.
Alwayswithdrawtheignitionkeywhenleavingthevehicle.Uninformedpersons(e.g.children)couldinjurethemselvesbyoperatingthelifting/slidingroof.
Incaseofdanger,releasethebuttonimmedi-atelyandoperatethelifting/slidingroofintheoppositedirection.Readinessforoperation
–Whentheignitionisswitchedon(engineswitchedonoroff)or
–Withdoorsclosedandignitionkeywithdrawn,butonlyuntiladoorisfirstopened.
Openingthelifting/slidingroof-A
PressrearofrockerswitchAuntillifting/slid-ingroofreachesthedesiredposition.
One-touchoperation
TouchrearofrockerswitchA.Lifting/slidingroofopenstoitsendposition.Stopitinanypositionbytouchinganybutton.
Note
Thelifting/slidingroofopensuntilitreachesthebestpositionrelativetonoise.Itcanbeopenedfully,however,ifyoupresstherockerswitchagain.
200MobileRoofs

Closingthelifting/slidingroof-B
PressfrontofrockerswitchBuntillifting/slid-ingroofreachesthedesiredposition.
One-touchoperation
TouchfrontofrockerswitchB.Lifting/slidingroofclosestoitsendposition.Stopitinanypositionbytouchinganybutton.
Liftingthelifting/slidingroof-C
PresscenterofrockerswitchCuntillift-ing/slidingroofreachesthedesiredposition.
One-touchoperation
TouchtherockerswitchCinthecenter.Lifting/slidingroofopenstoitsendposition.Touchbuttonagaintostopinanyposition.
Loweringthelifting/slidingroof-B
PressfrontofrockerswitchBuntillifting/slid-ingroofreachesthedesiredposition.
Emergencyoperation
Checkingelectricalfuses
Warning!
Riskofseriouspersonalinjuryanddamagetothelifting/slidingroofduringemergencyoperation.
Donotoperatethelifting/slidingroofwiththerockerswitchduringandafteremergencyoperation.
Beforeusingemergencyoperation,pleasecheckwhetherdefectivefusesarethecauseofthemalfunction.
Pleaseobservethechapter”ELECTRICALSYSTEM”onpage292.
MobileRoofs201

Closingtheslidingroof
1.CarefullyunclipbothcoversAwithascrewdriv-er.IfthecarisequippedwithHomeLink,theHomeLinkbuttonsmustbecarefullyunclippedinsteadofthecovers.
2.UnscrewthetwoscrewsB.
3.Folddownthecoverofthelifting/slidingroofdriveattherear.RemovetheAllenkey(arrow)fromitsholder.
4.InserttheAllenkeyintothedriveaxle.
5.PresstheAllenkeyintothedriveaxle,keepitpressedandturnitclockwiseuntilthelifting/slidingroofisclosed.
6.RemovetheAllenkey.Closethecoverandscrewinthescrews.
7.HavethefaultremediedatanauthorizedPorschedealer.
Caution!
Riskofdamagetothelifting/slidingroof.
Afteremergencyoperation,donotoperatethelifting/slidingroofusingtherockerswitch.
202MobileRoofs

DriveslowlytoanauthorizedPorschedealerinordertohavethefaultremedied.
MobileRoofs203

ConvertibleTop
Generalinformation
Briefoperatinginstructionscanbefoundonthebacksideofthedriver’ssunvisor.
Pleaseobservethechapter”CARCAREINSTRUCTIONS”onpage257.
Warning!
Whenopeningorclosingtheconvertibletop,seriouspersonalinjurymayoccurifaperson’sbodypartsarenearorinthewayoftheconvertibletopmechanism’smovingparts.
Makeabsolutelysurethatnobodycanbeinjuredbytheconvertible-topmechanismortheconvertible-topcompartmentlid.
Donotoperateconvertibletop:
–Attemperaturesbelow32°F(0°C).
–Whenonesideofthecarisonacurb,ahoistorajack.
–Whenitemsofluggageorotherobjectshindertheconvertibletopmovement.
–Withtherollbarsextended.
Avoidfrequentoperationoftheconvertibletopwiththeengineoff;thevehiclebatterywouldbeunintentionallydischargedrapidly.
Driveonlywiththeconvertibletopfullyopenorclosed(endpositions).
Whenopeningorclosingtheconvertibletop,ensurethereissufficientclearanceabovetheconvertibletop(e.g.inthegarage).
Topreventdampstainsandabrasions,onlyopentheconvertibletopinadry,cleanstate.
Parkyourcarintheshadewheneverpossible,asthefabric,rubbermaterialandcolorcanbeharmedbylongexposuretosunlight.
Theconvertibletopmayonlybeactuatedduringdrivingonevensurfaces.
Theconvertibletopmustnotbeusedwithstrongcounterwind(overapprox.50mph/80km/h).
Doorwindowsandsidewindows
Thesidewindowsareloweredautomaticallywhentheconvertibletopisopened.Thedoorwindowscloseautomaticallyifconvertibletopoperationisnotinterruptedwhentheconvertibletopreachesitsfinalposition.Whenthedoorwindowsareclosed,therearsidewindowscanalsobeclosed.Whenopeningthedoorwindows,therearwindowsopenautomatically.
Thesidewindowsareloweredautomaticallywhentheconvertibletopisclosed.Allwindowsclose
automaticallyifconvertibletopoperationisnotinterruptedwhentheconvertibletopreachesitsfinalposition.
Preconditionsforoperationofthe
convertibletop
–Theignitionmustbeswitchedon(enginerunningoroff),
–theenginecompartmentlidmustbeclosed,
–thespeedmustbebelowapprox.30mph(50km/h).Ifthismaximumspeedisexceed-ed,theopening/closingprocedureoftheconvertibletopwillbeinterrupted.
Reducespeed.Pressbuttonagain.Theopening/closingprocessisended.
204MobileRoofs

Openingconvertibletop
Warning!
Riskofinjuryanddamagewhenoperatingtheconvertibletop.
Makeabsolutelysurethatnobodycanbeinjuredbytheconvertible-topmechanismortheconvertible-topcompartmentlid.
Beforeopeningtheconvertibletop,makesurethattherearenoobjectsbehindtherearseats.
Inordertoabortconvertibletopoperationintheeventofdanger,immediatelyreleasetherockerswitch.
Pulltherockerswitchbackandholdwithoutinterruptionuntiltheconvertibletopisinthefinalpositionoruntilthedoorwindowsareinthedesiredposition.Themessageontheon-boardcomputergoesout.Incaseofdanger,releasetherockerswitch.Convertibletopoperationstops.
Pleaseobservethechapter”WARNINGSONTHEINSTRUMENTPANELANDTHEON-BOARDCOMPUTER”onpage143.
Closingconvertibletop
Warning!
Riskofinjuryanddamagewhenoperatingtheconvertibletop.
Makeabsolutelysurethatnobodycanbeinjuredbytheconvertible-topmechanismortheconvertible-topcompartmentlid.
Keepthelidsofthemake-upmirrorsinthesunvisorsclosedwhenclosingtheconvertibletop.
MobileRoofs205

Inordertoabortconvertibletopoperationintheeventofdanger,immediatelyreleasetherockerswitch.
Pushtherockerswitchforwardandholdwithoutinterruptionuntiltheconvertibletopisinthefinalpositionoruntilthedoorwindowsareinthedesiredposition.Themessageontheon-boardcomputergoesout.Incaseofdanger,releasetherockerswitch.Convertibletopoperationstops.
Pleaseobservethechapter”WARNINGSONTHEINSTRUMENTPANELANDTHEON-BOARDCOMPUTER”onpage143.
Iftheconvertibletopdoesnotlockinthe
windshieldframe
Openconvertibletopagain,starttheengineandclosetheconvertibletopagainusingtherockerswitch.Assistwiththeclosingprocessbygraspingtheconvertibletopatthehandholdandpullingittowardthewindshieldframe(arrow).
Messagesinon-boardcomputer
Rearlid
Iftheenginecompartmentlidisopenwhenactivatingtheconvertibletop,amessageappearsintheon-boardcomputer.Theconvertibletopcannotbeopened.
Closeenginecompartmentlid.
Convertibletopstatus
Pleaseobservethechapter”WARNINGSONTHEINSTRUMENTPANELANDTHEON-BOARDCOMPUTER”onpage143.
206MobileRoofs

Emergencyoperationoftheconvertible
top
Beforeemergencyoperation
Warning!
Thereisdangerofinjuryanddamageduringemergencyoperation.Thereisdangerofcrushingortrappingbodypartsatallmovableconvertibletoppartswhichcouldcauseseriouspersonalinjury.
Takegreatcarewhenperformingemergencyoperation.
Donotoperatetheconvertibletopduringandafteremergencyoperation.
Beforeperformingemergencyoperation,pleasecheck:Wastheignitionswitchedonandwastheenginecompartmentlidclosedduringoperationoftheconvertibletopwiththerockerswitch?Areelectricalfusesdefective?
Pleaseobservethechapter”ELECTRICALSYSTEM”onpage292.
Removetheignitionkeysothattheconvertibletopisnotoperatedunintentionally.
Takescrewdriveroutofthetoolkit.
Pleaseobservethechapter”LUGGAGECOMPARTMENT(VEHICLESWITHOUTFOUR-WHEELDRIVE)”onpage177.
Pleaseobservethechapter”LUGGAGECOMPARTMENT(VEHICLESWITHFOUR-WHEELDRIVE)”onpage179.
Foldtherearseatbackrestsforward.
Removingrearwalllining
1.UnscrewscrewsAfromtherearwalllining.Pulloutandrepositionthescrewdriverinsertifnecessary.
2.Grasptherearwallliningatthecut-outsforthesafetybeltsandpressdownward.Pullrearwallliningforwardandliftupandout.
Openingconvertibletopcompartmentlid“D”
1.TakeredAllenkeyBoutofitsholder.
2.PuthandleofscrewdriverontoAllenkeyB.InsertAllenkeyintothedriveaxleCandturnitcounterclockwise(indirectionofthearrow)untiltheconvertibletopcompartmentlidDisfullyopen.RemovetheAllenkey.
MobileRoofs207

Warning!
TheAllenkeycanrotateoryoutandtherebycauseseriouspersonalinjuryiftheconverti-bletopisactuated.
AlwaysremovetheAllenkeyBfromthedriveaxleCbeforeoperatingtheconvertibletop.
Whenyouhaveopenedtheconvertibletopcompartmentlid,trytoclosetheconvertibletopusingtherockerswitch.Iftheconvertibletopcannotbeclosed,continuewithemergencyoperation.
Openingsideaps“F”
1.Removeignitionkey.
2.UsethescrewdrivertoremoveplasticlidEfromtheliningfrombehind.
3.InsertAllenkeyBintothedriveaxlefortheleftsideflapF.TurnAllenkeycounterclockwise(indirectionofarrow)untilthesideflapFisfullyopen(perceptiblestop).
4.Repeatprocedurewiththerightsideflap.RemovetheAllenkey.
