Hands-freemicrophone
Hands-freemicrophonesAinstalledatthefactorymustbeadaptedtothetypeoftelephoneinuse.YourauthorizedPorschedealerwillbepleasedtoadviseyou.
Automaticcar-wash
Unscrewexternalantennasbeforeusinganautomaticcar-wash.
Controls,Instruments189

190Controls,Instruments

ShiftingGears
ManualTransmission,Clutch........................192TiptronicS..................................................193SelectorLeverPositions..............................195
ShiftingGears191

ManualTransmission,Clutch
Generalinformation
Thepositionsofthegearsareshownontheshiftdiagramonthegearshiftlever.
Warning!
Riskofaccident,resultinginseriouspersonalinjuryordeath.
Donotobstructthepedaltravelwithfloormatsorotherobjects.NonskidfloormatsofthecorrectsizeareavailableatyourauthorizedPorschedealer.
Warning!
Toavoiddamagetotheclutchandtransmis-sion:
Alwaysdepresstheclutchpedalfullywhenchanginggears.Makesurethatthegearshiftleveriscompletelyengaged.
Onlyshiftintoreversewhenthecarhascometoacompletestop.
Whenshiftinggears,alwaysensurethattheclutchpedalisfullydepressedandthegearhasfullyengaged.
Selectreverseonlywhenvehicleisstationary.
Selectanappropriatelylowgearonupwardanddownwardslopes.Thiswillensureoptimumuseofenginepowerandenginebraking.
Whenreversegearisselectedandtheignitionison,thebackuplightsareilluminated.
Permittedenginespeed
Youshouldchangeintoahighergearbeforetheneedlereachestheredmarkonthetachometer,oreaseofftheaccelerator.
Iftheredzoneisreachedduringacceleration,fuelfeedisinterrupted.
Caution!
Riskofenginedamage(overrevving)whenshiftingdowntoalowergear.
Takecarenottoexceedthemaximumpermittedenginespeedwhenshiftingdown.
192ShiftingGears

TiptronicS
Function
ThePorscheTiptronicisafive-speedtransmissionwithan“automatic”anda“manual”selectionmode.
Inautomaticselectionmode(selectorleverpositionD),gearchangingisautomatic.Youcanchangetemporarilyfromautomatictomanualmodeusingtherockerswitchesonthesteeringwheel.
Inmanualselectionmode(selectorleverpositionM),youchangegearusingtherockerswitchesonthesteeringwheel.
YoucanchangebetweenselectorleverpositionDandMasyouwishwhiledriving.
Note
Takecarenottooperatetherockerswitchesonthesteeringwheelinadvertentlyineitherautomaticormanualmode,therebytriggeringundesiredgearchanges.
Keylockposition
TheignitionkeycanbewithdrawnonlyinselectorleverpositionP.
Transmissionselectorlever
Changingtheselectorleverposition
Theselectorleverislockedwiththeignitionkeywithdrawn.
TheselectorlevercanbemovedfrompositionPorNonlywith:
–Theignitionswitchedon
–Thebrakepedalpressedand
–Thereleasebuttonpressed
Releasebutton
Thereleasebutton(arrow)intheselectorleverpreventsunintentionalgearchanges.
ThereleasebuttonmustbepressedwhenshiftingtopositionRorP.
Starting
TheenginecanbestartedonlyifthebrakepedalisdepressedandtheselectorleverisinpositionPorN.
Movingoff
Onlyselectthedesiredpositionformovingoff(D,MorR)whentheengineisidlingandthebrakepedalisdepressed.
Sincethevehiclecreepswheningear,donotreleasethebrakeuntilyouwanttomoveoff.
Afterselectingagear,donotaccelerateuntilyoucanfeelthatthegearisengaged.
ShiftingGears193

Indicatorforselectorleverpositionand
engagedgear
Indication
Whentheengineisrunning,theselectorleverpositionandengagedgearareindicated.
Iftheselectorleverisbetweentwopositions:
–Thecorrespondingselectorleverpositionintheinstrumentclusterflashesfortwosecondsand
–Thewarning“Selectorlevernotengaged”appearsintheon-boardcomputer.
Engagetheselectorlevercorrectly.
–Theselectorleverpositionisdisplayedimmediatelyafterthecorrectpositionhasbeendetected.
–Thecurrentgearisshownafterabriefdetectionperiod.
Ifthereisafaultinthetransmission:
–The4thgeardisplayflashes.
–Thewarning“Tiptronicemergencyrun”appearsontheon-boardcomputer.
Pleaseobservethechapter”REDUCEDDRIVINGPROGRAM”onpage198.
HavethefaultremediedatanauthorizedPorschedealer.
194ShiftingGears

SelectorLeverPositions
P-Parkinglock
Engageparkinglockonlywhenvehicleisstationary.
Engageparkinglockafterapplyingthehandbrakeandreleaseitbeforereleasingthehandbrake.
TheignitionkeycanbewithdrawnonlyinselectorleverpositionP.
R-Reversegear
Selectonlyifcarisstationaryandthebrakeisapplied.
N-Neutral
SelectorleverpositionNmustbeselectedfortowingorincarwashes,forexample.
Onlyselectthedesiredpositionformovingoff(D,MorR)whentheengineisidlingandthebrakepedalisdepressed.
D-Automaticselectionmode
Function
SelectpositionDfor“normal”driving.Thegearsareshiftedautomaticallyaccordingtotheacceleratorpositionandspeed.
Dependingonthewaythevehicleisdrivenandontheresistance(e.g.uphill),thegear-changingpointsareshiftedtowardshigherorlowerengine-speedranges.Theacceleratorposition,drivingspeed,enginespeed,longitudinalandlateralaccelerationandtheroadprofileallhaveaninfluenceonthegear-changingcharacteristic.
Unwantedupwardshifts,e.g.beforebends,arepreventedbyswiftlyreleasingtheacceleratorpedal.
Dependingonlateralacceleration,upwardchangesonbendsarenotmadeuntiltheengine-speedlimitisreached.
Underbraking,anddependingontheamountofdeceleration,theTiptronicchangesdownearlier.Forsubsequentcornering,therightgearisengagedwhenpressureisappliedtothebrakesbeforethebend.Thebendistakenintherightgear,andwhenyouaccelerateoutofthebendyoudonothavetoshiftdown.
Drivingoff
In2ndgear,thevehiclemovesoffwiththethrottleonlyslightlyopen.Moveoffin1stgearwiththethrottleopenwiderorwhentheengineiscold.
Sportmodeswitchedon
Pleaseobservethechapter”SPORTMODE”onpage78.
IftheSportmodeprogramisswitchedon,Tiptronicswitchestoasportygear-changingmapandshortenstheshiftingperiods.Decelerationdownshiftsarecommencedearlier.Downshiftsarealreadycarriedoutinthecaseofslightdecelera-tions,evenathigherenginespeeds.
Shiftinggearsonthesteeringwheel
Withtherockerswitchesonthesteeringwheel,youcanchangetemporarilyfromautomaticselectionmodeDtomanualmodeM.
Example:
–Shiftingdownbeforebendsandonenteringbuilt-upareas.
–Shiftingdownondownwardslopes(enginebraking).
–Shiftingdownforbriefspurtsofacceleration.
–Selecting1stgearforstartingoff.
Manualselectionmoderemainsengaged:
–forcornering(dependingonthelateralacceleration)andoverrunning,
–whenthevehicleisstationary(e.g.atajunction).
Thesystemleavesmanualselectionmode:
ShiftingGears195

–automaticallyafterapprox.8seconds(unlesscorneringoroverrunning),
–ifyoudepresstheacceleratorforkickdown,
–aftermovingoff.
Temporarychange-down
Conditions:Speedishigherthanapprox.33mph(54km/h).
Rapidacceleration.TheTiptronictemporarilychangestothesportiestgear-changingmap,i.e.tothehighestpossiblegear-changingpoints.Correspondingly,thetransmissionshiftsdownimmediatelybyoneortwogears.
Endingthefunction:
Releasetheacceleratormarkedly(byapprox.25%).
Kickdown
ThekickdownfunctionisactiveinselectorleverpositionD,evenifyoutemporarilychangetomanualmodeMusingtherockerswitchesonthesteeringwheel.
Foroptimumacceleration,e.g.whenovertak-ing,depresstheacceleratorpedalbeyondthefull-throttlepoint(kickdown).
Thetransmissionshiftsdowndependingonthespeedoftravelandenginespeed.Upwardshiftsoccuratthehighestpossibleenginespeeds.Thesegear-changingspeedsremainactiveuntil
theacceleratorisreleasedtoapprox.80%ofthefull-throttleposition.
M-Manualselectionmode
Function
ThecurrentlyselectedgearisretainedwhenyouchangefromDtoM.
IfyouchangefromMtoD,thegear-changingmapsuitableforyourcurrentdrivingstyleisselectedandtheappropriategearischosen.
196ShiftingGears

Warning!
Thekickdownfunctionisnotactiveinmanualselectionmode“M”.
Thereforeshiftdownmanuallywhenaccelerat-ing(e.g.toovertake).
Tworockerswitchesintheuppersteering-wheelspokesletyoucomfortablyandreliablyselectthefiveforwardspeeds.
Shiftingup
Pressupperpart(+)ofarockerswitch.
Shiftingdown
Presslowerpart(-)ofarockerswitch.
Dependingondrivingspeedandenginespeed,youcanshiftupordownatanytime.Gearchangeswhichwouldexceedtheupperorlowerengine-speedlimitwillnotbeexecutedbythecontroller.
Youcanchangedowntwogearsbyquicklypressingtherockerswitchestwice.
Iftheengine-speedlimitisreached,anautomaticupwardshiftisperformedor,justbeforeidlingspeedisreached,adownwardshiftisperformed.
Selectanappropriatelylowgearonupwardanddownwardslopes.Thiswillensureoptimumuseofenginepowerandenginebraking.
PSMswitchedoffand/orSportmodeswitched
on
Pleaseobservethechapter”PORSCHESTABILITYMANAGEMENT(PSM)”onpage79.
Pleaseobservethechapter”SPORTMODE”onpage78.
IfthePSMisswitchedoffand/orSportmodeisswitchedon,anautomaticupshiftdoesnotoccurwhentheenginespeedlimitisreached.
Cancellingupshiftsuppression
Thisrestrictioncanbecancelledforonegearchangebydepressingtheacceleratortokickdown.If,forexample,theenginespeedlimitisreachedduringovertakingandtheautomaticupshiftdoesnotoccur,thetransmissioninthiscaseshiftsupbyacceleratingtokickdown.
Depresstheacceleratorpedalbeyondthefull-throttlepoint(kickdown).
Manualmodefailure
Ifmanualmodefails,thecontrolelectronicsswitchtoautomaticmode.Inthisevent,theinstrumentclusterwilldisplayselectorleverpositionD.
HavethefaultremediedatanauthorizedPorschedealer.
Stopping
Forabriefstop(e.g.atatrafficlight),leavetheselectorleverindrivepositionandholdthevehiclewiththebrakepedal.
Foralongerstopwiththeenginerunning,selectpositionN(neutral)andholdvehicleinpositionwiththefootbrake.SelectleverpositionDonlywhenthefootbrakepedalisdepressed.
Donotholdthecaronaslopeusingtheaccelerator.Usethebrakepedalorthehandbrakeinstead.
Beforeleavingthevehicle,alwaysapplythehandbrakeandmovetheselectorlevertopositionP.
Parking
Goeasyontheaccelerator!
Whenparkingormaneuveringinasmallspace,controlthespeedbycarefuluseofthefootbrake.
Drivinginwinter
Inwintryroadconditionsitisadvisabletotakesteepinclinesinmanualmode.Thispreventstheoccurrenceofgearchangesthatcouldcausewheelspin.
ShiftingGears197

Tow-starting,towing
Pleaseobservethechapter”TOWING”onpage321.
Reduceddrivingprogram
Atransmissionfaultisindicatedbythefollowingsymptoms:
–The4thgeardisplayontheinstrumentclusterflashes.
–Thewarning“Tiptronicemergencyrun”appearsontheon-boardcomputer.
–Thetransmissionnolongershifts.
Warning!
Reversegearlockmonitoringisdisabledintheemergencyrunningprogram.Damagetothevehiclemayresultaswellaslossofcontrol,ifthevehicleismovingforwardfastenoughtocauserearwheellockup.
DonotshiftintoRwhilethevehicleismovingforward.
Proceedasfollowsintheeventofatransmissionfault:
1.Stopinasafeplace.
2.MoveselectorlevertopositionP,switchtheignitionoffandwaitfor10seconds.
3.Starttheengine.2ndgearinselectorpositionDandreversegearRarenowavailable.
4.HavethefaultseentoimmediatelyatanauthorizedPorschedealer.
