4.TakeunlockinghandleDfromthestoragetraybetweenthefrontseats.
5.PositionunlockinghandleDonthedotmarking.CarefullyremovetheplasticcoversConbothsidesofthehardtop.
6.InsertunlockinghandleDintooneoftherearhardtoplocks.Unscrewthefasteningscrewapprox.2turns,pulloffthehandle,andcompletelyunscrewthescrewbyhand(approx.8turns).
7.Pulloutthefasteningscrewuptothestopandturnitanticlockwise2turns(topreventdamage).
8.Repeatprocedureontheothersideofthehardtop.
9.Togetherwithasecondpersonontheotherside,graspthehardtopatpointsEandF.
Warning!
Dangerofpinchingngersorhandsatthepoints“F”.
Evenlyliftthehardtopatbothsides.
10.Firstpullthehardtoprearwardandupoutofthelockingelements.Carefullyliftthehardtopupandoverthevehicletotherear.
MobileRoofs219

11.CarefullyremovebothprotectioncoversJtotherear.
12.FitbothplasticcoversCintothetrimpanel.Themarkingpointmustpointtotherear.Thesecoversarealsousedwiththehardtop.
13.Closefrontlockinglever.Pushonplasticcoverofthefronthardtoplock.
Puttingonthehardtop
Caution!
Riskofdamagetothewindstopandhardtop.
Alwaysremovethewindstopbeforefittingthehardtop.
Pleaseobservethechapter”WINDSTOP”onpage214.
1.Openallfoursidewindowsandconvertibletop.
2.TakeunlockinghandleDfromthestoragetraybetweenthefrontseats.PositionunlockinghandleDonthepointmarking.CarefullyremovebothplasticcoversConbothsidesofthehardtop.
220MobileRoofs

3.CarefullyfitbothprotectivecoversJintothetrimpanelfrombehind.4.Pulloffplasticcoverofthefronthardtoplock.5.Pressredlockbuttonofthefrontlockinglever.Fullyopenlockinglever.
MobileRoofs221

6.Checkwhethertherearscrewconnectionsonthehardtopareloosened(turnit2turnsclockwise).
7.Togetherwithasecondpersonontheotherside,graspthehardtopatpointsEandF.
8.Carefullyliftthehardtopupandoverthevehiclefrombehind.
Warning!
Dangerofpinchingngersorhandsatthepoints“F”.
Evenlylowerthehardtopatbothsides.
9.Firstpushthehardtopcompletelyintotheguidesonthewindshieldframe.Thencarefullylowerthehardtopintothelockingelementsattherear.
Caution!
Dangerofdamageduetoinadvertentoper-ationoftheconvertibletopwiththehardtoptted.
MakesurethatthefrontlockingleverGisalwayscorrectlylocked.Thisdisablestheconvertibletopdrive.
222MobileRoofs

10.SwivelfrontlockingleverGtotherear.ThelatchinghookHmustengageinthewindshieldframe(arrow).ThewhitemarkinglineJontheredlockingbuttonmustbecomevisiblewhenthehardtopislockedproperly.
11.Pushonplasticcoverofthefronthardtoplock.
12.Tightenthefasteningscrewbyhand.ThentightenthefasteningscrewwiththeunlockinghandleD(tighteningtorque34ft.lb.(46Nm)).
13.Repeatprocedureontheothersideofthehardtop.
14.FitbothplasticcoversCintothetrimpanelsoftherearhardtoplockingelementssothatthemarkingpointsareoppositeeachother.
15.Storeunlockinghandleinstoragetraybetweenthefrontseats.
MobileRoofs223

Targa
Generalinformation
Thisrooftypeisequippedwiththefollowingspecialfeatures:
–Rollerblind
–Slidingglassroof
–Glassrearhatch
Warning!
RiskofinjurywhenoperatingallcomponentsoftheTargaroof,especiallywhenclosingtheslidingglassroof.
Takecaretoensurethatnobodycanbeinjuredwhentheroofcomponentsareactuated.
Alwayswithdrawtheignitionkeywhenleavingthevehicle.Uninformedpersons(e.g.children)couldinjurethemselvesbyoperatingtheslidingglassroof,therollerblindortheglassrearhatch.
Incaseofdanger,releasethebuttonimme-diatelyandoperatetheslidingglassrooforrollerblindintheoppositedirection.
Rollerblind
Readinessforoperation
–Withtheignitionswitchedon(engineonoroff)or
–Whendoorisclosedandignitionkeywith-drawn,butonlyuntildoorisfirstopened.
Therollerblindcanbeoperatedindependentlyoftheslidingglassroofposition.
Warning!
Riskofinjuryanddamage.
Beforeoperatingtherollerblind,ensurethattherearenopersonsorobjectsintherangeofmovement.
Openingtherollerblindtothedesiredposition
Pulltherockerswitchtothefirststage(1)andholdituntiltherollerblindhasreachedthedesiredposition.
Openingtherollerblindfully(one-touch
operation)
Taptherockerswitchtothefirststage(1).Therollerblindmovestoitsfinalposition.Touchtherockerswitchagaintostopinanyposition.
Closingtherollerblindtothedesiredposition
Pushtherockerswitchtothefirststage(2)andholdituntiltherollerblindhasreachedthedesiredposition.
224MobileRoofs

Closingtherollerblindfully(one-touch
operation)
Taptherockerswitchtothefirststage(2).Therollerblindmovestoitsfinalposition.Touchtherockerswitchagaintostopinanyposition.
Slidingglassroof
Readinessforoperation
–Withignitionswitchedon(engineonoroff)or
–Whendoorisclosedandignitionkeywith-drawn,butonlyuntildoorisfirstopened.
–Theglassrearhatchmustbeclosed.
Openingslidingglassroof
Warning!
Riskofinjuryanddamage.
Beforeopeningtheslidingglassroof,ensurethattherearenopersonsorobjectsintherangeofmovement.
Pulltherockerswitchtothesecondstage(3)andholdituntiltheslidingglassroofhasreachedthedesiredposition.
Closingtheslidingglassroof
Warning!
Riskofinjuryanddamage.
Beforeclosingtheslidingglassroof,ensurethattherearenopersonsorobjectsintherangeofmovement.
Pushtherockerswitchtothesecondstage(4)andholdituntiltheslidingglassroofhasreachedthedesiredposition.
MobileRoofs225

Glassrearhatch
Openingtheglassrearhatch
Theslidingglassroofmustbeclosed.
Tounlockit,operatethepull-buttonAbesidethedriver’sseat,or
pushthebuttonfortheglassrearhatchontheremotecontrol.
Pleaseobservethechapter”KEYWITHRADIOREMOTECONTROL”onpage23.
Liftglassrearhatch.
Theinteriorlightisswitchedonwhentheglassrearhatchisunlocked.
Closingglassrearhatch
Warning!
Riskofpinching.Theglassrearhatchisautomaticallypulledintothelockandlocked.
Ensurethatyourfingersarenotcaughtundertheglassrearhatch.
Placeyourhandontheglassrearhatch.
Lowertheglassrearhatchuntilitisautomati-callyclosedandlocked.
Messageinon-boardcomputer
Glassrearhatch
Amessageappearsontheon-boardcomputeriftheglassrearhatchisnotcompletelyclosed.
Fullyclosetheglassrearhatch.
226MobileRoofs

Emergencyoperationofslidingglassroof
Closingtheslidingglassroof
Beforeusingemergencyoperation,pleasecheckwhetherthefusesmaybedefective.
Pleaseobservethechapter”ELECTRICALSYSTEM”onpage292.
Warning!
Riskofinjuryanddamage.
Donotoperatetheslidingglassroofwiththerockerswitchduringandafteremergencyoperation.
1.Removeignitionkey.
2.Movethefrontpassengerseatforwardandfoldthebackrestforward.Foldtherearseatbackrestsforward.
3.Graspundertherear-wallliningAwithyourhands.Forcefullypulltherear-wallliningAforward.
YouwillfindtheAllenkeysforemergencyoperationonthebackontheliningA.
4.TakebothAllenkeysBoutoftheirholder.
MobileRoofs227

5.InserttheAllenkeysintothedriveaxlesCoftheelectricmotors.
6.PressbothAllenkeysintothedriveaxlesuntiltheyengageaudibly.Thisrequiresasomewhatgreatereffort.
7.KeepbothAllenkeyspressedinandturnthemtotheright.Keepturninguntiltheslidingroofisclosed.
8.RemovetheAllenkeys.Closetherear-walllining.
9.Pleasehavethefaultremediedatanauthor-izedPorschedealer.
