Page 251 of 355
FuelEvaporationControl
Fueltankventing
Theevaporationchamberandthecarboncanisterpreventfuelfromescapingtotheatmosphereatextremehighoutsidetemperatures,whendrivingabruptlyaroundcurvesandwhenthecarisparkedataninclineorinanyothernonlevelposition.
Vaporcontrolsystemandstorage
Whenthefueltankisfilled,vaporsarecollectedintheevaporationchamberbyaventlineleadingthevaporstothecarboncanisterwheretheyarestoredaslongastheenginedoesnotrun.
Purgesystem
Whentheengineisrunning,thefuelvaporsfromthecanisterwillbemixedwithfreshairfromtheambientairofthecanister.Thismixturewillbedirectedtotheintakeairhousingbythetankventline,mixedwiththeintakeairandburnedduringnormalcombustion.
Maintenance,CarCare249
Page 252 of 355
WasherFluid
Capacity
–Withoutheadlightcleaningsystem:approxi-mately2.6quarts(2.5liters).
–Withheadlightcleaningsystem:approximately6.3quarts(6.0liters).
Washeruid
Thereservoir,withabluescrewcap,isintheluggagecompartment,totherearleft.
Cleanwaterisgenerallynotenoughtocleanthewindshieldandheadlights.Dependingon
theseason,mixthewaterwiththeappropriateadditives.Followtheinstructionsforthemixtureratio.
Onlyusewindowcleanerconcentratewhichmeetsthefollowingrequirements:
–Dilutability1:100
–Phosphate-free
–Suitableforplasticheadlightlenses.
WerecommendwindowcleanerconcentratesapprovedbyPorsche.YourauthorizedPorschedealerwillbepleasedtoadviseyou.
Summerlling
Water+windowcleanerconcentrateatthemixingratioindicatedonthecontainer.
Winterlling
Water+antifreezeprotection+windowcleanerconcentrateatthemixingratioindicatedonthecontainer.
Pleasenotealltheinformationonthecontain-ersofthewindowcleanerconcentrateortheantifreezeprotection.
Toppingoffwasheruid
1.Pleasenotealltheinformationontherefillcontainerofthecleaningagent.
2.Opencapofthewasher-fluidreservoir(arrow).
3.Topupwasherfluidandclosecapproperly.
Donotuseenginecoolantanti-freezeoranyothersolutionthatcandamagethecar’spaint,inthewasherreservoir.
Warninglight
Iflessthan0.52quarts(0.5liter)remains,awarningmessageappearsontheon-boardcomputer.
Addwasherfluid.
250Maintenance,CarCare
Page 253 of 355
PowerSteering
Generalinformation
Powersteeringisassistedbyhydraulicauxiliaryforces.Thehydraulicfluidreservoirislocatedintheenginecompartment.
Note
Theflownoiseheardatfullsteeringlockisdesign-relatedanddoesnotindicateadefectinthesteeringsystem.
Warning!
Riskofaccidentresultinginseriouspersonalinjuryordeath.Whentheengineisstopped(e.g.whenbeingtowed)orthehydraulicsystemfails,thereisnoassistanceforsteering.Therefore,substantiallymoreforcewillhavetobeexertedinordertosteer.
Exercisegreatcarewhenbeingtowed.
HavethefaultremediedatyournearestauthorizedPorschedealer.
Checkinghydraulicuid
Pleaseobservethechapter”EXERCISEEXTREMECAUTIONWHENWORKINGONYOURVEHICLE”onpage232.
OnlyusehydraulicfluidauthorizedbyPorsche.
Pleaseobservethechapter”CAPACITIES”onpage335.
Checkthefluidlevelwiththeenginestoppedandcold(approximately68°F/20°C).
1.Opentheenginecompartmentlid.
2.Openthereservoircap.
3.Wipemeasuringrod.Closecapandreopen.Thefluidlevelshouldlieintheareabelowthe“Cold”marking.Addhydraulicfluidifnecessary.
4.Closecapcarefully.Closeenginecompart-mentlid.
Noticeablelossoffluidindicatesleakageinthesystem.ThecauseshouldberemediedimmediatelyatanauthorizedPorschedealer.
Maintenance,CarCare251
Page 254 of 355
Filter
Airlter
Adirtyairfilternotonlyreducesengineperform-ance,butcanleadtoprematureenginewear.
Regularfilterreplacementispartoftheroutinemaintenanceservice.
Industyconditions,checkthefilterelementmorefrequentlyandreplaceifnecessary.
Combinationlter
Thefreshairpassingthroughthecombinationfilterintothepassengercompartmentisvirtuallyfreeofdust,pollen,andunpleasantodors.
Iftheoutsideairispollutedbyexhaustfumes,presstherecirculating-airbutton.
Adirtyfiltercanbethecauseofreducedairflow:
HavefilterreplacedbyyourauthorizedPorschedealer.
Regularfilterreplacementispartoftheroutinemaintenanceservice.
252Maintenance,CarCare
Page 255 of 355
ManualTransmissionOil
ThetransmissionoilhastobecheckedandchangedattheintervalslistedinyourMaintenanceSchedule.
Pleaseobservethechapter”CAPACITIES”onpage335.
WerecommendthatyouhavethetransmissionoilchangedatyourPorschedealer,whohastherequiredlubricantsandthenecessaryfillingequipment.
Ifyoususpectanoilleakinthetransmission,haveyourauthorizedPorschedealercheckitoutimmediately.
Maintenance,CarCare253
Page 256 of 355
AutomaticTransmissionFluid
ThetorqueconverterandthetransmissionarelubricatedwithAutomaticTransmissionFluid(ATF).Thefinaldriverequirestransmissionoil.
Pleaseobservethechapter”CAPACITIES”onpage335.
DonottowthecarorruntheenginewithoutATFinthetransmission.Theautomatictransmissionmaybedamagedbyevenatinyspeckofdirt,onlyacleanfunnelorspoutmustbeusedwhenaddingATF.
TheATFandtransmissionoilhastobecheckedandchangedattheintervalslistedinyourMainte-nanceSchedule.
WerecommendthatyouhavetheATFandtrans-missionoilchangedatyourPorschedealer,whohastherequiredlubricantsandthenecessaryfillingequipment.
Ifyoususpectanoilleakinthetransmission,haveyourauthorizedPorschedealercheckitoutimmediately.
254Maintenance,CarCare
Page 257 of 355
WiperBlades
Generalinformation
Whenwiperperformancedeteriorates,replacethewipers.
Pleaseobservethechapter”CARCAREINSTRUCTIONS”onpage257.
Caution!
Riskofdamageifthewiperarmaccidentallyfallsbackontothewindow.
Alwaysholdthewiperarmsecurelywhenreplacingthewiperblade.
Caution!
Riskofdamageifwiperbladesthatarefrozeninplaceareloosenedimproperly.
Thawthewiperbladesbeforelooseningthem.
Maintenancenote
PeriodicallycleanthewiperbladeswithPorschewindowcleaner,especiallyafterthevehiclehasbeenwashedinacarwash.Iftheyareverydirty(e.g.withinsectremains),theycanbecleanedwithaspongeorcloth.
Ifthewiperbladesruborsqueak,thiscanbeasaresultofthefollowing:
Ifthevehicleiswashedinanautomaticcarwash,waxresiduesmayadheretothewindshield.Thesewaxresiduescanberemovedbyusingwindowcleanerconcentrate.
Pleaseobservethechapter”WASHERFLUID”onpage250.
PleasecontactyourauthorizedPorschedealerforfurtherinformation.
Thewiperbladesmaybedamaged.
Replacedamagedwiperbladesassoonaspossible.
Changingwindshieldwiperblades
Caution!
Riskofdamage.Ifawiperbladeisnotchangedproperly,itcancomeloosewhenthecarismoving.
Checkwhetherthewiperbladeisseatedsecurely.Thewiperblademustengagethewiperarmproperly.
A-Passenger’sside,curvedwiperbladeB-Driver’sside,wiperbladewithspoiler
1.Applythehandbrake.
2.Switchthewipersoff(position0)andremovetheignitionkey.
3.Foldwindshieldwiperarmawayfromthewindshield.
4.Presstogethertheplasticspringofthewiperblade(rightarrow).Pullwiperbladeoutofwiperarm.
5.Insertnewwiperbladeuntilyoufeelitengage.Ensurethatthenewwiperbladeisinsertedintothewiperarminthesameposition:
Maintenance,CarCare255
Page 258 of 355
–directionofthespoileronthedriverside,
–curvatureonthepassengerside.
6.Carefullyfoldwiperarmbackontothewind-shield.
Changingrearwindowwiperblade
Caution!
Riskofdamage.Ifawiperbladeisnotchangedproperly,itcancomeloosewhenthecarismoving.
Checkwhetherthewiperbladeisseatedsecurely.Thewiperblademustengagethewiperarmproperly.
Applythehandbrake.
Switchtherearwiperoff(position0)andremovetheignitionkey.
Foldwiperarmawayfromtheglass.
1.Presstogethertheplasticspringofthewiperblade.
2.Pullwiperbladeupwardsandoutofwiperarm.
3.Insertnewwiperbladeintothewiperarmfromabove.
4.Presstogethertheplasticspringofthewiperbladeandengageitinthewiperarmuntilitsnapsintoplace.
5.Carefullyfoldwiperarmbackontothewindow.
256Maintenance,CarCare
Page 259 of 355
CarCareInstructions
Long-termmaintenanceofvalue
Pleaseobservethechapter”EXERCISEEXTREMECAUTIONWHENWORKINGONYOURVEHICLE”onpage232.
Regularandcorrectcarehelpstomaintainthevalueofyourcarandisalsoaprecondi-tionfortheNewVehicleWarrantyandtheAntiCorrosionWarranty.
YourauthorizedPorschedealerhasspeciallydevelopedcar-careproductsfromthePorscheprogramavailableeithersinglyorascompletecar-caresets.Theywillbepleasedtohelpyouselectsuitableproducts.
WhetheryouusePorscheproductsorothercommerciallyavailablecleaningagentsrstmakesureoftheircorrectapplication.
APorschethatiswell-caredforcanlooklikenewforyears.Italldependsontheamountofcaretheowneriswillingtogivethecar.
Warning!
Riskofseriouspersonalinjuryordamagetothevehicleorproperty.Cleaningagentsmaybehazardoustoyourhealth.Mostchemicalcleanersareconcentrateswhichrequiredilution.Highconcentrationsmightcauseproblemsrangingfromirritationtoseriousinjuryaswellasdamagetoyourvehicle.
Keepcleaningagentsoutofreachfromchildren.
Observeallcautionlabels.
Alwaysreaddirectionsonthecontainerbeforeusinganyproduct.Thesedirectionsmaycontaininformationnecessarytoavoidpersonalinjury.
Donotusefuel,kerosene,naphtha,nailpolishremoverorothervolatilecleaningfluids.Theymaybetoxic,flammableorhazardousinotherways.Onlyusespotremovingfluidsinawellventedarea.
Donotcleantheundersideofchassis,fenders,wheelcovers,etc.,withoutprotectingyourhandsandarmsasyoumaycutyourselfonsharp-edgedmetalparts.
Moistureandroadsaltonbrakesmayaffectbrakingefficiency.
Testthebrakesaftereachvehiclewashing.
Washing
Washingandpreservation
Thebestmethodofprotectingyourcarfromthedamagingeffectsoftheenvironmentisfrequentwashingandtheapplicationofapreservative.Theundersideofyourvehicleshouldalsobethoroughlywashedforcinders,saltorsandingatwinter’send.
Thelongersalt,roaddustandindustrialdust,deadinsects,birddroppingsorsubstancesfromtrees(resin,pollen)areallowedtoremainonthebodywork,themoreseriousistheirharmfuleffect.
Newcarsshouldbewashedcarefullywithplentyofclearwatertoprotectthenewpaintwork.Darkpaintfinishesshowupthesmallestofsurfacedamage(e.g.,scratches)morereadilythanlightercolors.
Darkcolorsarealsomoresusceptibletoscratch-ingbecauseofthecompositionoftheirpigmentsandrequireparticularlycarefulpaintcare.
Donotwashyourcarinbrightsunlightorwhilethebodyworkisstillhot.
Whenwashingbyhand,useabundantwater,asoftspongeorwashbrush,andPorschecarshampoo.
Beginbysprayingthebodythoroughlywithwatertorinseawayloosedirt.
Maintenance,CarCare257
Page 260 of 355
Afterwashing,rinsethecarwithplentyofwaterandthendrywithachamoisleather.Donotusethesamechamoisleatherfordryingasyouuseforcleaningthewindshieldandwindows.
Warning!
Moisturewhichgetsontothebrakesduringacarwashcanreducebrakingefciencyormakethebrakespullunevenlywhichcouldincreasethedangerofanaccident,causingseriouspersonalinjuriesordeath.
Alwaysapplythebrakesafewtimesafterwashingthecartotestbrakingefficiencyanddrythebrakediscs.Whendoingthis,takecarenottohamperotherroadusersbehindyou(trafficconditionspermitting).
Automaticcarwashes
Pleaseobservethechapter”WIPERBLADES”onpage255.
Optionaladd-onpartsorpartswhichprojectbeyondthecontoursofthevehiclemaybedamagedbydesignfeatures(e.g.brushes)ofautomaticcarwashes.
Thefollowingpartsareparticularlysusceptible
todamage:
–Convertibletop(hotwaxtreatmentcannotbeused,asthewaxattackstheconvertibletopmaterial)
–Windshieldwipers(alwaysswitchthemofftopreventthemwipingunintentionallyinintermittentorsensoroperation)
–Externalantennas(alwaysunscrew)
–RoofTransportSystem(alwaysremovecompletely)
–Rearspoiler
–Wheels(thewidertherimandthelowerthetireheight,thegreatertheriskofdamage)
–High-glosswheels(topreventthesefromgettingscratched,donotcleanwiththewheel-cleaningbrushesofthecarwash).
Pleaseconsulttheoperatorbeforeusingautomaticcarwashes.
Washanddrybyhandallpointsnotreachedbyacarwash,suchasdoorandlidseamsordoorsills.
Note
Automaticcarwashesspraywateratoddanglesandhighpressures,whicharenotseeninnormaldriving.Therefore,watercansometimesfinditswayintothepassengerscompartmentduringorshortlyafterthecarwash.
Convertibletop
Careandtreatment
Neverremovesnowandiceusingasharpedgedobject.
Incorrectcareandtreatmentcandamagetheconvertibletopandcauseleaks.AnyrepairworkcanbedonebyyourauthorizedPorschedealer.
Note
Nofoldingtopis100%leakproof.
Duetotheconstantchangingofloadsandstrainstowhichacarissubjecttowhendrivingonroads,minorwindnoiseandseepageatjointsbetweenthetop,bodyanddoorsonconvertibletopscannotbecompletelysealedincertainareas.Thereforesmallleaksareconsiderednormalforthesemodels.Inaddition,yourconvertibletopshouldnotbewashedinacarwash.Thetopmayexperiencedamagebythebrushesormayexperienceleaksduetothehighpressurewaterstreamsdirectedinareaswhichwouldnotencounterwaterinnormaldrivingconditions.
