PORSCHE 911 CARRERA 2007 5.G Owners Manual
Manufacturer: PORSCHE, Model Year: 2007, Model line: 911 CARRERA, Model: PORSCHE 911 CARRERA 2007 5.GPages: 355, PDF Size: 7.31 MB
Page 271 of 355
Donotusecommerciallyavailablesealantortireinflatingbottles.OnlyusePorscheapprovedtiresealant.
Pleaseobservethechapter”TIREPRESSURESFORCOLDTIRES”onpage334.
Eachtire,includingthespare(ifprovided),shouldbecheckedevery2weekswhencold(68°F/20°C)andinflatedtotheinflationpres-surerecommendedinthisOwner’sManualoronthetire-pressureplate.IfyourvehiclehastiresofadifferentsizethanthesizeindicatedinthisOwner’sManualoronthetire-pressureplate,youshoulddeterminethepropertireinflationpressureforthosetires.
Asanaddedsafetyfeature,yourvehiclehasbeenequippedwithaTirePressureMonitoring(TPC)thatilluminatesalowtirepressuremessagewhenoneormoreofyourtiresissignificantlyunder-inflated.Accordingly,whenthelowtirepressuremessageilluminates,youshouldstopandcheckyourtiresassoonaspossible,andinflatethemtotheproperpressure.Drivingonasignificantlyunder-inflatedtirecausesthetiretooverheatandcanleadtotirefailure.Under-inflationalsoreducesfuelefficiencyandtiretreadlife,andmayaffectthevehicle’shandlingandstoppingability.
PleasenotethattheTPCisnotasubstituteforpropertiremaintenance,anditisthedriver’sresponsibilitytomaintaincorrecttirepressure,evenifunder-inflationhasnotreachedthelevelto
triggerilluminationoftheTPClowtirepressuremessage.
Onvehicleswithtirepressuremonitoring:
Pleaseobservethechapter”TPCTIREPRESSUREMONITORING”onpage127.
Whentiresarewarm,thetirepressureisincreased.
Neverletairoutofhottires.Thiscouldcausethetirepressuretofallbelowtheprescribedvalue.
Insufficienttirefillingpressurecancausetirestooverheatandthusbedamaged-eveninvisibly.Hid-dentiredamageisnoteliminatedbysubsequentlycorrectingthetirepressure.
Overloading
Danger!
Riskofdamagetovehicleparts,lossofcontrolandseriouspersonalinjuryordeath.
Donotoverloadyourvehicle.Becarefulabouttheroofload.
Ifloadingthevehiclealsocorrectthetirepressure.Tirepressureforloadedvehiclecanbefoundonthetirepressureplateandinthechaptertechnicaldata.
Neverexceedthespecifiedaxleload.Over-loadingcanshortentheservicelifeofthetiresandcar,aswellasleadtodangerousvehiclereactionsandlongbrakingdistances.Damageduetooverloadingisnotcoveredbythevehi-clewarranty.
Pleaseobservethechapter”LOADINGINFORMATION”onpage278.
Pleaseobservethechapter”TIREPRESSURESFORCOLDTIRES”onpage334.
PracticalTips,EmergencyService269
Page 272 of 355
Exampleofatirepressureplate
Tirepressureplate
Informationonthetirepressureplate
ASeatingcapacityMaximumnumberofvehicleoccupants,includingthedriver.
BVehicleloadlimitIsthemaximumtotalweightlimitspecifiedoftheload(passengersandcargo)forthevehicle.Thisisthemaximumweightofpassengersandcargothatcanbeloadedintothevehicle.Pleaseobservethechapter”LOADINGINFORMATION”onpage278.
CTiresizeforthefrontaxleCheckwithyourauthorizedPorschedealeraboutthecurrentreleasestatus.
DRecommendedtirepressureforthefrontaxleThesevaluesareforcoldtires(68°F/20°C).
ETiresizefortherearaxleCheckwithyourauthorizedPorschedealeraboutthecurrentreleasestatus.
FRecommendedtirepressurefortherearaxleThesevaluesareforcoldtires(68°F/20°C).
GInvehicleswithcollapsiblesparewheel:Sizeandtirepressureofthesparewheel.
Tiretraction
Warning!
Whendrivingonwetorslushyroads,awedgeofwatermaybuildupbetweenthetiresandtheroad.Thisphenomenonisknownas“hydroplane”andmaycausepartialorcompletelossoftraction,vehiclecontrolorstoppingability.
Reducespeedonwetsurfacetopreventthis.
Tirelife
Tirelifedependsonvariousfactors,i.e.,roadsurfaces,trafficandweatherconditions,drivinghabits,typeoftiresandtirecare.
Inspectyourtiresforwearanddamagebeforedrivingoff.Ifyounoticeunevenorsubstantialwear,wheelsmightneedalignmentortiresshouldbebalancedorreplaced.
270PracticalTips,EmergencyService
Page 273 of 355
Tirewear
TheoriginalequipmenttiresonyourPorschehavebuilt-intirewearindicators.Theyaremoldedintothebottomofthetreadgroovesandwillappearasapproximately1/2in.(12mm)bandswhenthetiretreaddepthisdownto1/16ofanin.(1.6mm).
Whentheindicatorsappearintwoormoreadjacentgrooves,itistimetoreplacethetires.Werecommend,however,thatyoudonotletthetiresweardowntothisextent.Worntirescannotgriptheroadsurfaceproperlyandareevenlesseffectiveonwetroads.
IntheUnitedStates,statelawsmaygoverntheminimumtreaddepthpermissible.Followallsuchlaws.
Danger!
Drivingonworntirescanresultinlossofcontrolofthevehicleandcouldcauseseriouspersonalinjuriesordeath.
Donotdrivewithworntiresortiresshowingcutsorbruisesastheymayleadtosuddendeflationandlossofcontrolwhichcouldcauseseverepersonalinjury.
Specializedhighperformancetiresonhighperformancesportscarsexhibitmorewearthanthoseonafamilysedan,orevenahighperformancesedan.Therefore,itisimportanttocheckyourtirepressureandconditionatleasteverytwoweeks.
Ifyounoticethattiresarewearingunevenly,consultyourPorschedealer.Unevenwearmaynotalwaysbeduetoimproperwheelalignment.Itcanbetheresultofindividualdrivinghabitssuchascorneringathighspeeds.Ifthetirepressureisnotcheckedandadjustedregularly,abnormaltirewearcanalsooccur.
Tirecare
Avoiddamagingtiresandwheelrims.
Ifyoumustdriveoveracurborotherobstacle,driveslowlyandatanobtuseangle.
Checktiresforunevenwearanddamagebeforedrivingoff.
Removeimbeddedmaterial.
Replacewornordamagedtiresimmediately.
Keepoil,fuel,brakefluid,etc.awayfromtires.
Replacemissingvalvestemcaps.
Keeptiresinflatedcorrectly.
Washtireswhenwashingthevehicle.Alsocleaninnersideofwheels.
Donotuseabrasivecleanerswhenwashingthewheels.
Checkwheelrimsforcorrosion.
Removeroadsalt,ifdrivinginwinter.
Tiredamage,puncture
Checktiresforimbeddedmaterial,cuts,punctures,cracksandbulges(sidewall)beforedrivingoff.
Incaseoftiredamage,whereitisuncertainwhetherthereisabreakintheplywithallitsconsequencesortiredamagecausedbythermalormechanicaloverloadingduetolossofpressureoranyotherpriordamage,werecommendthatthetirebereplacedforsafetyreasons.
Ifonefaultytireisreplaceditshouldbenotedthatthedifferenceintreaddepthononeaxlemustnotexceed30%.Handlinginconsistenciesmayresult.
Performavisualinspectionifnecessary.
Danger!
Riskofseriouspersonalinjuryordeath.Drivingthevehiclewithlowtirepressureincreasesriskofatirefailureandresultinglossofcontrol.Furthermore,lowtirepressureincreasesrateofwearoftheaffectedtires.
Checktires-includingsidewalls-regularlyforforeignbodies,nicks,cuts,cracksandbulges.
PracticalTips,EmergencyService271
Page 274 of 355
Afterdrivingoffroad,examinetiresforsignsofdamagesuchascuts,tears,bulgesorforeignobjectsstuckinthetread.Replaceadamagedtireifnecessary.
Crosscurbedgesslowlyandatrightanglesifpossible.Avoiddrivingoversteeporsharpcurbs.
Incasesofdoubt,havethewheel(particularlytheinnerside)checkedbyanauthorizedPorschedealer.
Tirereplacements
Ifindoubt,contactyourPorschedealer.UseonlytiremakesandtypesapprovedbyPorsche.
IfyoudonotuseaPorscherecommendedreplacementtire,makesurethatyoupur-chaseyournewtiresfromareputabletiredealerandthatthedealercomplieswithallmanufacturerswarningsforthosetires.
Onlytireswiththesamemakeandwiththesamespecicationcode(e.g.“N0”,“N1”...)canbemounted.
Beforemountingnewtires,checkwithyourPorschedealeraboutthecurrentreleasestatus.
Usetireswith“ZR”qualitystandards.Therearecurrentlynostandardsconcerningtirestrengthatspeedsabove150mph(240km/h).
Tiresshouldbereplacednolessthanononeaxleatthetime.Onlytiresofthesamemakeandtypemustbeused.Mixedtiresarenotpermissible.
Initially,newtiresdonothavetheirfulltraction.Youshouldthereforedriveatmoderatespeedsduringthefirst60-120miles(100-200km).
Ifnewtiresareinstalledonlyononeaxle,anoticeablechangeinhandlingoccursduetothedifferenttreaddepthoftheothertires.Thishappensespeciallyifonlyreartiresarereplaced.However,thisconditiondisappearsasthenewtiresarebrokenin.
Pleaseadjustyourdrivingstyleaccordingly.
Installationofnewtiresshouldonlybedonebyaqualifiedtiretechnician.
Valves
Rubbervalvestemsmustbereplacedeverytimeatireisreplaced.Formetalvalves,theinstallationandreplacementinstructionsmustbeobserved.
UseonlygenuinePorschemetalvalves.
Protectthevalveinsertsagainstsoilingwithvalvecaps.Soiledvalveinsertscancauseagraduallossofair.
Useonlyplasticvalvecaps.
Parkingatthecurb
Warning!
Hardimpactsagainstcurbs(ortrafcislands)aredangerousandmaycausehiddentiredamagewhichisnotnoticeableuntillater.Suchdamagecanresultinaccidentsathighspeedscausingseriouspersonalinjuryordeath.Dependingontheforceofimpact,theedgeoftherimcanalsobedamaged.
Ifyouareindoubt,havethewheelcheckedbyanexpert,particularlyifyoususpectdamageontheinside.
272PracticalTips,EmergencyService
Page 275 of 355
Ifyoumustdriveoveracurborotherobstacle,driveslowlyandatanobtuseangle.Exercisecarewhenparkingalongcurbs.
Wheelalignment,wheelbalancing
Asaprecaution,havewheelswithsummertiresbalancedinthespring,andthosewithmudandsnowtiresbeforewinter.Unbalancedwheelsmayaffectcarhandlingandtirelife.Onlythespecifiedweightsmaybeusedforwheelbalancing.Self-adhesiveweightsmustnotcomeintocontactwithcleaningagents,sincetheycoulddropoff.Uneventreadwearindicateswheelimbalance.Inthisevent,thevehicleshouldbecheckedatanauthorizedPorschedealer.
Warning!
If,duringatrip,unevenrunningorvibrationsoccurthatcouldbecausedbydamagetotiresorthecar,thespeedmustbereducedimmediately,butwithoutbrakingsharply.Ifyoucontinueyourtripwithouthavingthecauseofthefaultremedied,youmightlosecontrolofyourvehiclewhichcouldcauseseriouspersonalinjuryordeath.
Stopthevehicleandcheckthetires.
Ifnocauseforthefaultcanbefound,drivecarefullytothenearestauthorizedPorschedealer.
Removingandstoringtires
Afterchanging,adjusttirepressureandtorquewheelboltsdiagonallyto94ft.lb.(130Nm).
Tiresmustalwaysremainonthesamesideofthevehicle.Whenwheelsareremoved,thedirectionofrotationandpositionofeachwheelshouldbemarked.
Example
FR(frontright),FL,RRandRL.
Wheelsmustalwaysbefittedinaccordancewiththeirmarking.
Theperceptionthattiredurabilityandperformanceareimmunetotheeffectsofstorageandageisunfounded.Chemicaladditives,whichmaketherubberelastic,losetheireffectivenessinthecourseoftimeandtherubberbecomesbrittleandcracks.
Therefore,thetiresshouldbeinspectedfromtimetotime.
Note
Undernocircumstancesshouldtiresolderthan6yearsbeusedonyourPorsche.
Theageofthetirecanbeobtainedfromthe“DOT”codenumber.If,forexample,thelastfournumbersread0706,thenthetirewasproducedinthe7thweekof2006.
Storetiresinacoolanddryplace.
PracticalTips,EmergencyService273
Page 276 of 355
Snowtires
Forabettergriponsnowandice,useradialM+Stireswithstuds.CheckwithyourlocalMotorVehicleBureauforpossiblerestrictions.
Danger!
Riskoflossofcontrolanddamagetothevehicleaswellasseriouspersonalinjuryordeath.Thestandardtiresproleandrubbermixtureareoptimizedforwetanddrydrivingconditions,andmaynotprovefavorableforsnowconditions.
ThereforeinstallM+Stiresbeforedrivinginsuchconditions.
Beforemountingsnowtires,consultwithyourPorschedealer.Hehasthetechnicalinformationnecessarytoadviseyouonwheelandtirecompatibility.
Snowtiresshouldhavethesameloadcapacityasoriginalequipmenttiresandshouldbemountedonallfourwheels.Snowtireswithstudsshouldberunatmoderatespeedswhennewinordertogivethestudstimetosettle.
Danger!
Tireswithbadlyworntreadsandstudsareverydangerousandcouldcauseaccidentsresultinginseriouspersonalinjuriesordeath.
Makesuretheyarereplacedimmediately.
Donotdriveavehicleequippedwithsnowtiresatprolongedhighspeed.Snowtiresdonothavethesamedegreeoftractionondry,wetorsnowfreeroadsasanormaltire.Furthermore,snowtireswearrapidlyundertheseconditions.
Complywithallstateandlocallawsgoverningsnowtireandtreaddepthrequirements.
Danger!
Riskofaccidentandseriouspersonalinjuryordeathduetoexcessivespeed.
Alwayscheckthemaximumspeedratingonthetiresidewallonanytireonthevehicle.
Neverexceedthemaximumspeedratingofthetires.
Fitwintertirestobothaxleswellbeforethecoldseasonbegins.YourauthorizedPorschedealerwillbepleasedtoadviseyou.
Maintenancenote
Werecommendfittingwintertiresonthevehicleattemperaturesbelow45°F(7°C).
Wintertireslosetheirtractioncapabilitywhentheirtreaddepthfallsbelow5/32in.(4mm).
274PracticalTips,EmergencyService
Page 277 of 355
Snowchains
Caution!
Riskofdamagetobody,axleorbrakecompo-nents.
Fitsnowchainsonlytotherearwheels,andonlywiththetire/rimcombinationlistedintheTechnicalData.Toensureadequateclearancebetweenchainandbody,Porscherecommendsonlytheuseoffine-linkchainssuchasthoseapprovedbyPorsche.
Pleaseobservethechapter”TECHNICALDATA”onpage328.
Followinstructionsissuedbythesupplierofthechains.
Differentstatesandcountrieshavevaryingstatutoryrequirementsregardingmaximumspeed.Checkwithlocalauthoritiesforpossiblerestrictions.
Removechainsassoonastheroadsarefreeoficeandsnow.
Fittingsnowchains
911Carrera,911CarreraS
Theuseofsnowchainsisnotpermittedwhen5mmspacersaremounted.
Caution!
Riskofdamagetothewheelhousingsifthe5mmspacersarenotremovedbeforettingsnowchains.
Topermitthefittingofsnowchains,havethe5mmspacersremovedonall4wheels.
Tofit/removethespacers:PleaseconsultanauthorizedPorschedealer.
Pleaseobservethechapter”5MMSPACERS”onpage288.
Tiredesignations
Duetonewspeedandloadratingsforradialtires,newdesignationshavecomeintoforceforsnowtiresforyourPorsche.
ThedesignationtobeusedforZRtiresise.g.,265/40ZR18(Z=codeletterforradialtiresforspeedsabove150mph/240km/h).
PracticalTips,EmergencyService275
Page 278 of 355
ExampleofInscription
Inscriptiononradialtire
ATiresize
Example:P295/30ZR19100Y
–P-ThetireisdesignedforPassengervehicle.Thisinformationisnotincludedonalltires.
–295-Indicationoftirewidthinmm
–30-Indicationoftireheighttotirewidthratioinpercent
–ZR-codeletterforradialtiresforspeedsabove150mph/240km/hTherearecur-rentlynostandardsconcerningtirestrengthatspeedsabove150mph(240km/h).
–R-Belttypecodeletterforradial
–19-Indicationofrimdiameterininches
–100-Loadcapacitycoefficient
–Y-Speedcodeletter
–XL(ExtraLoad)-Tirewithincreasedloadrating
BTIN(TireIdenticationNumber)
Example:DOTxxxxxxxxxxxx
–DOT-TheDOTsymbolindicatesthatthetirescomplywiththerequirementsoftheUSDepartmentofTransportationandprovidesinformationabout:
–firsttwo-digitcodemeansmanufacture’sidentificationmark.
–secondtwo-digitcodemeanstiresize.
–thirdfour-digitcodemeanstiretypecode.
276PracticalTips,EmergencyService
Page 279 of 355
–fourthfour-digitcodemeansdateofmanu-facture.If,forexample,thelastfournumbersread0204,thetirewasproducedinthe2ndweekof2004.
CTireplycompositionandmaterial
Thenumberoflayersinthetreadandsidewallsandtheirmaterialcomposition.
DMaximumpermissibleinationpressure
Themaximumpermissiblecoldinflationpressuretowhichatirecanbeinflated.
Donotexceedthepermissibleinflationpressure.
EMaximumLoadrating
Themaximumloadinkilogramsandpoundscanbecarriedbythetire.Ifyoureplacetiresalwaysuseatirethathasthesamemaximumloadratingasthefactoryinstalledtire.
FRadial
Theidentificationindicatesifthetirehasradialstructure.
GTermoftubelessortubetire
Identificationfortubelesstires.
Speedcodeletter
Thespeedcodeletterindicatesthemaximumpermissiblespeedforthetire.Thiscodeletterisshownonthetiresidewall.
T=upto118mph(190km/h)
H=upto131mph(210km/h)
V=upto150mph(240km/h)
W=upto167mph(270km/h)
Y=upto186mph(300km/h)
Tipondriving
TireswithamaximumspeedratingthatislowerthanthespecifiedmaximumvehiclespeedmaybemountedonlyiftheybearanM+Sidentificationonthetiresidewall.
Pleasenotethatinadditiontothewintertires,all-seasonandall-terraintiresarealsosubjecttospeedlimitsandbearthisidentification.
Inscriptiononlightalloywheels
Maintenancenote
Protectthevalveinsertsagainstsoilingwithvalvecaps.Useonlyplasticvalvecaps.Soiledvalveinsertscancauseagraduallossofair.
A-RimwidthininchesB-Rim-angecontourcodeletterC-Symbolfordrop-centerrimD-RimdiameterininchesE-DoublehumpF-Rimoffsetinmm
Noteonoperation
TherimwidthininchesAandtherimoffsetFarevisiblefromtheoutside.Thisinformationcanbefoundnearthetirevalve.
PracticalTips,EmergencyService277
Page 280 of 355
LoadingInformation
Denitions
TheCurbweight-actualweightofyourvehicle-vehicleweightincludingstandardandoptionalequipment,fluidsandemergencytools.Thisweightdoesnotincludepassengersandcargo.
TheGrossVehicleWeightissumofthecurbweightandtheweightofpassengersandcargocombined.
TheGrossVehicleWeightRatingisthemaxi-mumtotalweightofvehicle,passengers,luggageandoptionalequipment.
TheGrossAxleWeightRatingisthemaximumloadlimitforthefrontortherearaxle.Thisinformationislocatedonthesafetycompliancestickerlocatedinthedriver’ssidedoorjamb.
Fordeterminingthecompatibilityofthetireandvehicleloadcapabilities:
Pleaseobservethechapter”TECHNICALDATA”onpage328.
Theloadcapacitycoefficient(e.g.“100”)isaminimumrequirement.
TheGrossCombinedWeightRatingisthemaxi-mumtotalweightratingofvehicle,passengersandcargo.
TheVehicleCapacityWeight-LoadLimit-isthemaximumtotalweightlimitspecifiedoftheload(passengersandcargo)forthevehicle.Thisisthe
maximumweightofpassengersandcargothatcanbeloadedintothevehicle.Thisinformationcanbefoundonthetirepressureplate.
Themaximumloadedvehicleweightisthesumofcurbweight,accessoryweight,vehiclecapacityweightandproductionoptionsweight.
Theloadratingisthemaximumloadthatatireisratedtocarryforagiveninflationpressure.
Themaximumloadratingistheloadratingforatireatthemaximumpermissibleinflationpressure.
Thecargocapacityisthepermissibleweightofcargo,thesubtractedweightofpassengersfromtheloadlimit.
Neverexceedthepermissiblelimits.
Danger!
Riskoflossofcontrol,damagetothevehicleandseriouspersonalinjuryordeath.
Neverexceedthespecifiedaxleloads.Overloadingcanshortentheservicelifeofthetiresandcar,aswellasleadtodangerousvehiclereactionsandlongbrakingdistances.Damageduetooverloadingisnotcoveredbythevehiclewarranty.
278PracticalTips,EmergencyService
