SSANGYONG MUSSO 1998 Workshop Owner's Guide

GENERAL INFORMATION 0B-19
VEHICLE LIFTING PROCEDURES
To raise the vehicle, place the lifting equipment only at
the points indicated. Failure to use these precise
positions may result in permanent vehicle body
deformation.
Many dealer service facilities and service stations are
equipped with automative hoists that bear upon some
parts of the frame in order to lift the vehicle. If any other
hoist method is used, take special care to avoid
damaging the fuel tank, the filter neck, the exhaust
system, or the underbody.
Vehicle Lifting Points
Using Jack
(Rearward of Front Tire)
Using Jack
(Forward of Rear Tire)
2300 DOHC
The engine number is stamped on the upper rear left-
hand side of the cylinder block.

SECTION 1
ENGINE
SECTION 1A1(M162 ENGINE)
GENERAL ENGINE INFORMATION
Specifications . . . . . . . . . . . . . . . . . . . . . . . 1A1-1
Engine Specifications . . . . . . . . . . . . . . . . . . 1A1-1
Component Locator . . . . . . . . . . . . . . . . . . 1A1-3
Front View . . . . . . . . . . . . . . . . . . . . . . . . . . 1A1-3
Side View . . . . . . . . . . . . . . . . . . . . . . . . . . . 1A1-4
Performance Curve . . . . . . . . . . . . . . . . . . 1A1-5
E32 Engine . . . . . . . . . . . . . . . . . . . . . . . . . . 1A1-5
Special Tools . . . . . . . . . . . . . . . . . . . . . . . 1A1-6
Special Tools Table . . . . . . . . . . . . . . . . . . . . 1A1-6
Diagnosis . . . . . . . . . . . . . . . . . . . . . . . . . . 1A1-7
Oil Leak Diagnosis . . . . . . . . . . . . . . . . . . . . 1A1-7
Engine Cranking at The
Front of Crankshaft . . . . . . . . . . . . . . . . . . 1A1-8
Compression Pressure Test . . . . . . . . . . . . . 1A1-9
Cylinder Pressure Leakage Test . . . . . . . . . 1A1-11
General Information . . . . . . . . . . . . . . . . . 1A1-13
Cleanliness and Care . . . . . . . . . . . . . . . . . 1A1-13
On-Engine Service . . . . . . . . . . . . . . . . . . . 1A1-13
Application
Engine Model
Displacement (CC)
Cylinder (Bore x Stroke) (mm)
Fuel Injection / Ignition System
Compression Ratio
Number of Cylinders
Camshaft Valve Arrangement
Camshaft Drive Type
Max. Output (ps/rpm)
Max. Torque (kg•m/rpm)
Firing Order
Ignition Type
Ignition Timing
Valve Timing Intake Open/Close
ExhaustOpen/Close
Valve Clearance Adjustment
SPECIFICATIONS
ENGINE SPECIFICATIONS
E32 Engine
M162.990
3199
89.9 x 84.0
MSE 3.62S
10 : 1
6
DOHC
Chain-Driven
222 / 5500
31.6 / 3750
1-5-3-6-2-4
Distributorless Double Ignition
BTDC 8° ± 2°
ATDC 11° / ABDC 34°
BBDC 31° / BTDC 14°
Automatic Control
TABLE OF CONTENTS

1A1-2 GENERAL ENGINE INFORMATION
Application
Idle Speed (rpm)
Fuel Injection Pressure (kg/cm²)
Oil Capacity (liter)
Lubrication Type
Oil Filter Type
Fuel
ENGINE SPECIFICATIONS (Cont'd)
E32 Engine
700 ± 50
3 - 4
8.2
Forced by Gear Pump
Full Flow with Paper Filter
Unleaded Gasoline
MSE 3.62S/3.53S (Motorsteuer Elektronik : German)
MSE : Engine Control Electronic
3.62S : 6 Cylinder Version
3.53S : 4 Cylinder Version

GENERAL ENGINE INFORMATION 1A1-3
COMPONENT LOCATOR
FRONT VIEW
1 HFM Sensor
2 Intake Air Duct
3 Resonance Flap
4 Cylinder Head Cover
5 Exhaust Camshaft
6 Intake Camshaft
7 Cylinder Head
8 Spark Plug Connector
9 Valve Tappet
10 Injector
11 Exhaust Valve12 Intake Manifold
13 Connecting Rod
14 Exhaust Manifold
15 Crankshaft
16 Engine Mounting Bracket
17 Starter
18 Crankcase
19 Oil Pump Sprocket
20 Oil Strainer
21 Oil Pan
22 Drain Plug

1A1-4 GENERAL ENGINE INFORMATION
23 Camshaft Adjuster
24 Cooling Fan and Viscous Clutch
25 Piston
26 Flywheel of Drive Plate27 Oil Pump Drive Chain
28 Oil Return Pipe
29 Timing Chain
30 Oil Pump
SIDE VIEW

GENERAL ENGINE INFORMATION 1A1-5
PERFORMANCE CURVE
E32 ENGINE

1A1-6 GENERAL ENGINE INFORMATION
SPECIAL TOOLS
SPECIAL TOOLS TABLE
000 589 10 99 01
Torque Wrench
001 589 76 21 00
Compression Pressure
Tester119 589 01 09 00
Spark Plug Wrench001 589 65 09 00
Socket

GENERAL ENGINE INFORMATION 1A1-7
OIL LEAK DIAGNOSIS
Most fluid oil leaks are easily located and repaired by
visually finding the leak and replacing or repairing the
necessary parts. On some occasions a fluid leak may
be difficult to locate or repair. The following procedures
may help you in locating and repairing most leaks.
Finding the Leak
1. Identify the fluid. Determine whether it is engine oil,
automatic transmission fluid, power steering fluid, etc.
2. Identify where the fluid is leaking from.
2.1 After running the vehicle at normal operating
temperature, park the vehicle over a large sheet
of paper.
2.2 Wait a few minutes.
2.3 You should be able to find the approximate
location of the leak by the drippings on the
paper.
3. Visually check around the suspected component.
Check around all the gasket mating surfaces for
leaks. A mirror is useful for finding leaks in areas that
are hard to reach.
4. If the leak still cannot be found, it may be necessary
to clean the suspected area with a degreaser, steam
or spray solvent.
4.1 Clean the area well.
4.2 Dry the area.
4.3 Operate the vehicle for several miles at normal
operating temperature and varying speeds.
4.4 After operating the vehicle, visually check the
suspected component.
4.5 If you still cannot locate the leak, try using the
powder or black light and dye method.
Powder Method
1. Clean the suspected area.
2. Apply an aerosol-type powder (such as foot powder)
to the suspected area.
3. Operate the vehicle under normal operating
conditoins.
4. Visually inspect the suspected component. You
should be able to trace the leak path over the white
powder surface to the source.
Black Light and Dye Method
A dye and light kit is available for finding leaks, Refer to
the manufacturer's directions when using the kit.
1. Pour the specified amount of dye into the engine oil
fill tube.2. Operate the vehicle normal operating conditions as
directed in the kit.
3. Direct the light toward the suspected area. The dyed
fluid will appear as a yellow path leading to the
source.
Repairing the Leak
Once the origin of the leak has been pinpointed and
traced back to its source, the cause of the leak must be
determined n order for it to be repaired properly. If a
gasket is replaced, but the sealing flange is bent, the
new gasket will not repair the leak. The bent flange must
be repaired also. Before attempting to repair a leak,
check for the following conditions and correct them as
they may cause a leak.
Gaskets
lThe fluid level/pressure is too high.
lThe crankcase ventilation system is malfunctioning.
lThe fasteners are tightened improperly or the threads
are dirty or damaged.
lThe flanges or the sealing surface is warped.
lThere are scratches, burrs or other damage to the
sealing surface.
lThe gasket is damaged or worn.
lThere is cracking or porosity of the component.
lAn improper seal was used (where applicable).
Seals
lThe fluid level/pressure is too high.
lThe crankcase ventilation system is malfunctioning.
lThe seal bore is damaged (scratched, burred or
nicked).
lThe seal is damaged or worn.
lImproper installation is evident.
lThere are cracks in the components.
lThe shaft surface is scratched, nicked or damaged.
lA loose or worn bearing is causing excess seal wear.
DIAGNOSIS

1A1-8 GENERAL ENGINE INFORMATION
ENGINE CRANKING AT THE FRONT OF CRANKSHAFT
Preceding Work : Removal of cooling fan
1 Vibration Damper Assembly
2 Crankshaft Pulley
Notice
lRemove the negative ground cable before proceeding the work.
lRotate the pulley in normal engine rotating direction when cranking.3 Bolt.................................................8.6 ± 0.9 Nm
Tools Required
000 589 10 99 01 Torque wrench
001 589 65 09 00 Socket

GENERAL ENGINE INFORMATION 1A1-9
COMPRESSION PRESSURE TEST
1 Compression Pressure Tester
2 Diagram Sheet3 Adaptor
4 Sealing Cone
Tools Required
001 589 76 21 00 Compression Pressure Tester
119 589 01 09 00 Spark Plug Wrench
Standard Service Data
Compression Ratio
Normal Engine Temperature
Normal Compression Pressure
Permissible Pressure Difference Between Individual
Cylinders10 : 1
80°C
Min. 10 bar, Max. 14 bar
Min. 6 bar, Max. 10 bar
Max. 1.5 bar General
Fuel Optimization
