SECTION 1D3
OM600 ENGINE COOLING
Specifications . . . . . . . . . . . . . . . . . . . . . . . 1D3-1
General Specifications . . . . . . . . . . . . . . . . . 1D3-1
Fastener Tightening Specifications . . . . . . . . 1D3-1
Diagnosis . . . . . . . . . . . . . . . . . . . . . . . . . . 1D3-2
Cooling Circulation . . . . . . . . . . . . . . . . . . . . 1D3-2
Thermostat Operation . . . . . . . . . . . . . . . . . 1D3-3
Cooling System Leakage Test . . . . . . . . . . . 1D3-4
Maintenance and Repair . . . . . . . . . . . . . . 1D3-5On-Vehicle Service . . . . . . . . . . . . . . . . . . . . 1D3-5
Drain and Filling of Coolant . . . . . . . . . . . . . 1D3-5
Coolant Pump . . . . . . . . . . . . . . . . . . . . . . . . 1D3-6
Coolant Pump Housing . . . . . . . . . . . . . . . . . 1D3-8
Cooling Fan Clutch . . . . . . . . . . . . . . . . . . . 1D3-10
Radiator . . . . . . . . . . . . . . . . . . . . . . . . . . . 1D3-12
Cooling Sub-System . . . . . . . . . . . . . . . . . . 1D3-14
Thermostat . . . . . . . . . . . . . . . . . . . . . . . . . 1D3-16
TABLE OF CONTENTS
Caution: Disconnect the negative battery cable before removing or installing any electrical unit or when a
tool or equipment could easily come in contact with exposed electrical terminals. Disconnecting this cable
will help prevent personal injury and damage to the vehicle. The ignition must also be in LOCK unless otherwise
noted.
Application
Coolant
Mixing Ratio (Water : anticorrosion)
CapacityDescription
ALUTEC P- 78
50 : 50
10.5L - 11L
9.5L - 10L
SPECIFICATIONS
GENERAL SPECIFICATIONS
Application
Coolant Pump Bolt
Belt Pulley Bolt
Coolant Pump Housing Return Pipe Bolt
Thermostat Bolt
Cooling Fan Clutch Socket Bolt (Center)
Cooling Fan Clutch Socket Bolt (Side)
Radiator Bolt
Coolant Sub-tank BoltN
· ·· ·
·m
10
10
10
10
45
10
3 - 7
3 - 7
FASTENER TIGHTENING SPECIFICATIONS
662LA
661LA

OM600 ENGINE COOLING 1D3-3
THERMOSTAT OPERATION
Operation
1. At warming up
Valve closes until temperature of coolant reaches to 85°C.
B. From Radiator
C. From Crankcase
D. To Crankcase
2. At partial opening.
Valve opens partially as temperature of coolant is maintained
between 85-100°C.
3. At full opening.
Valve opens full as temperature of coolant is more then
100°C.

1D3-4 OM600 ENGINE COOLING
COOLING SYSTEM LEAKAGE TEST
Tools Required
124 589 15 21 00 Tester
Test
1. Loosen the pressure cap by 1 notch and remove the cap
after.
Notice
Do not remove radiator cap when coolant is above 90°C.
2. Add the coolant to the arrow mark of coolant reservoir.
3. Connect the special tool to the injector of reservoir and apply
1.4bar pressure.
Tester 124 589 15 21 00
4. If the pressure on the tester drops, check the hose, pipe
and leakage and, replace or retighten.

OM600 ENGINE COOLING 1D3-5
DRAIN AND FILLING OF COOLANT
Preceding Work : Removal of skid plate
Drain / Filling
1. Loosen the pressure cap of reservoir by 1 notch and remove
pressure and then loosen the cap.
Notice
Do not remove radiator cap when coolant is above 90°C.
2. Open the drain plug and drain the coolant.
Notice
Collect the coolant by using the proper bottle.
3. Remove the drain plug(1) and seal(2) of cylinder block and
drain the coolant.
4. Replace the seal to new one and tighten the drain plug
Installation Notice
Tightening Torque 30 Nm
5. Tighten the drain plug of the lower radiator.
6. Fill the coolant through coolant reservoir-tank.
Notice
lA proportion of 50% by volume of water / anticorrosion
must be ensured
7. After engine is running at idle speed, check the level of
coolant. If necessary, add enough specified coolant.
MAINTENANCE AND REPAIR
ON-VEHICLE SERVICE

1D3-6 OM600 ENGINE COOLING
COOLANT PUMP
Preceding Work : Removal of cooling fan
Removal of V-belt
1 Tensioning Lever
2 Gasket ................................................... Replace
3 Bolt........................................................... 10 Nm4 Belt Pulley
5 Bolt........................................................... 10 Nm
6 Coolant Pump

OM600 ENGINE COOLING 1D3-7
Removal & Installation Procedure
1. Loose the bolts(5) and remove the pulley (4).
Installation Notice
Tightening Torque 10 Nm
2. Loose the bolts (3).
Installation Notice
Tightening Torque 10 Nm
3. Pull the tensioning lever(1) to the arrow direction.
4. Remove the coolant pump(6).
Notice
Clean gasket residues on the sealing surface of coolant
pump and replace the gasket.
5. Installation should follow the removal procedure in the
reverse order.

1D3-8 OM600 ENGINE COOLING
COOLANT PUMP HOUSING
Preceding Work : Removal of coolant pump
Removal of thermostat
Removal of alternator
1 Gasket ................................................... Replace
2 Coolant Pump Housing
3 Connector
4 Bolt........................................................... 10 Nm5 Coolant Hose
6 Return Pipe
7 O-Ring
8 Temperature Sensor
Notice
The bolt on the arrow should be installed last.

OM600 ENGINE COOLING 1D3-9
Removal & Installation Procedure
1. Disconnect the connector(3).
2. Separate the coolant hose (5) and return pipe(6).
3. Remove the bolts(4) evenly.
Installation Notice
Tightening Torque 10 Nm
Notice
Clean gasket residues on the sealing surface of coolant
pump and replace the gasket.
4. Remove the coolant pump housing(2).
5. Installation should follow the removal procedure in the
reverse order.

OM600 ENGINE COOLING 1D3-13
Removal & Installation Procedure
1. Drain coolant from the radiator.
2. Remove the coolant thermoswich connector from radiator.
3. Remove the each coolant hose.
4. Remove the auto T/M oil cooling hose and cooling line.
Installation Notice
5. Loosen the radiator upper mounting bolt and remove the
mounting stopper and insulator.
6. Remove the radiator.
7. Check the radiator pin for crack, leakage and bending and
replace it if necessany.
8. Installation should follow the removal procedure in the
reverse order.
Tightening TorqueHose : 29 - 40Nm

OM600 ENGINE COOLING 1D3-15
Removal & Installation Procedure
Cooling Fan Shroud
1. Remove the radiator deaeration hose and tube.
Installation Notice
Tightening Torque 3 - 7 Nm
Tightening torque 3-7Nm
2. Check the shroud.
3. Installation should follow the removal procedure in the
reverse order.
Coolant Sub-Tank
1. Drain the coolant from radiator.
2. Remove the each hose.
3. Loosen the mounting bolt of sub-tank and remove the
coolant sub-tank.
Installation Notice
4. Installation should follow the removal procedure in the
reverse order.
Tightening Torque 3 - 7 Nm
